Consistency in Observability of Microservices at Lyft (Monitorama 2017 PDX)

Transcript

1. Consistency in Monitoring Observability of Microservices @ Fighting Entropy and Delaying the Heat Death of the Universe Yann Ramin @theatrus - yramin@lyft.com
2. Monitorama 2017 PDX / @theatrus Hi! I’m Yann
 @theatrus Engineering Manager
 Observability Team @ Lyft
 Logging, TSDBs, performance profiling, low-level infrastructure

 Previously from the world of embedded systems
 “C is the best programming language”
3. Monitorama 2017 PDX / @theatrus Approaches and techniques to avoid production incidents with hundreds of micro services and diverse teams
4. What are we trying to solve? When developers are on-call with microservices or scaling operational mindfulness
5. Monitorama 2017 PDX / @theatrus “I didn’t realize it was logging errors all weekend.”
6. Monitorama 2017 PDX / @theatrus “I clicked production deploy and Jenkins went green! [closes laptop, goes home]” This is an opportunity for excellence
7. Monitorama 2017 PDX / @theatrus “No one setup a PagerDuty rotation before going to production!”
8. Monitorama 2017 PDX / @theatrus “We need alarms on thingX! Lets copy and paste them from my last service!”
9. Monitorama 2017 PDX / @theatrus “I have no idea what is broken.”
10. Monitorama 2017 PDX / @theatrus We routinely approach monitoring as operations
11. Monitorama 2017 PDX / @theatrus We need to abstract and modularize
12. Some backstory Consistency leads to consistency
13. Monitorama 2017 PDX / @theatrus ~ Today Python, PHP, and Go Common base libraries for each language Hundreds of micro services, no monorepo* Deploys frequently, sometimes “never” Common “base” deploy, Salt (masterless), AWS
14. Monitorama 2017 PDX / @theatrus DevOps? Teams on-call for their services No operations No SRE Infrastructure team enables, not operates
15. System Metrics and Pipeline Get the basics right
16. Monitorama 2017 PDX / @theatrus Make it easy to produce metrics (everywhere) (safely)
17. Monitorama 2017 PDX / @theatrus Big Secret ! We use the statsd protocol
18. Monitorama 2017 PDX / @theatrus Comfortable Compartmentalization
19. Monitorama 2017 PDX / @theatrus Lyft’s Pipeline Setup Cascaded github.com/lyft/statsrelay +
 github.com/lyft/statsite ➡ TSDBs


20. Monitorama 2017 PDX / @theatrus Data you get Service level aggregates centrally (correct histograms)
 Per host data processed locally Default 60 second period(!), option for 1 second
21. Monitorama 2017 PDX / @theatrus Monitor yourself Send to central aggregation Local stats
22. Monitorama 2017 PDX / @theatrus So many events
23. Monitorama 2017 PDX / @theatrus So many events Billions per second, with aggregation/sampling This is only ~200k metrics per seconds, thanks to rollups Per-instance cardinality limits Opt-in mechanisms for per-host and per-second data
24. Monitorama 2017 PDX / @theatrus System metrics CollectD Custom scripts Even some bash functions All to local statsrelay
25. Monitorama 2017 PDX / @theatrus What do we get? Comprehensive system metrics All metric producers are sandboxed, rate limited, and monitored No UDP spam over the network LIFO queueing
26. Monitorama 2017 PDX / @theatrus Instrument the core libraries
27. Monitorama 2017 PDX / @theatrus Problem Developers add metrics after it already broke once Adding metrics on core functions is not DRY Not all developers think in terms of metrics
28. Monitorama 2017 PDX / @theatrus class StatsdHandler(logging.Handler) every log call now produces metrics scoped by severity!
29. Monitorama 2017 PDX / @theatrus Instrument the RPC Record RPC inbound errors, successes, timings in core servers
 Gunicorn + https://pypi.python.org/pypi/blinker + statsd
30. Monitorama 2017 PDX / @theatrus Don’t be afraid of monkey patching
31. Monitorama 2017 PDX / @theatrus gunicorn.conf
32. Monitorama 2017 PDX / @theatrus It’s also the worst. (not gunicorn)
33. Monitorama 2017 PDX / @theatrus
34. Monitorama 2017 PDX / @theatrus
35. Monitorama 2017 PDX / @theatrus What do we get? Consistent Measurement Consistent Visibility Point to Point Debugging Unified Tracing
36. Deploy Time Standards
37. Monitorama 2017 PDX / @theatrus orca Salt module for “Orchestration” Provisions all remote resources a service needs during deploy Interacts with PagerDuty, makes sure a PD service is created Makes sure an on-call schedule is associated Otherwise blocks production deploy
38. Application Metrics dtrt, easily
39. Monitorama 2017 PDX / @theatrus Python from lyft_stats.stats import get_stats
 stat_handler = get_stats(‘my_prefix’).scope(‘foo’)

 stat_handler.incr('foo.counter')

 stat_handler.incr('counter.example', 10, tags={'bar': 'baz'})

 stat_handler.timer('sample.timer', 10.0, per_host=True)
40. Monitorama 2017 PDX / @theatrus Go https://github.com/lyft/gostats
41. Monitorama 2017 PDX / @theatrus We also don’t discuss PHP.
42. Monitorama 2017 PDX / @theatrus Gripes statsd calls are not cheap (syscalls) Various workarounds (.pipeline())
43. Monitorama 2017 PDX / @theatrus Further Improvements libtelem - native library to handle consistent instrumentation, shared memory views Unified tracing, logging and metrics
44. Unified Data Lots of cron scripts and Grafana
45. Monitorama 2017 PDX / @theatrus Multiple System Syndrome CloudWatch is the only source for some data CloudWatch “Hold on let me log in” “My MFA token doesn’t work, can someone else log in?” Using different systems is distracting, delays debugging
46. Monitorama 2017 PDX / @theatrus Less tools The less tools for triage, the better Context switching is expensive Put everything up front, or one click away
47. Monitorama 2017 PDX / @theatrus Either federate (Grafana plugins) Or just copy it
48. dashboards dot git dot cat?
49. Monitorama 2017 PDX / @theatrus Central Monitoring and Alarm Hub Git Monorepo Ties in with our Salt infrastructure Dashboards defined as Salt states, deploys like a service Iteration to staging Grafana Manages Grafana, Wavefront, other services
50. Monitorama 2017 PDX / @theatrus Every service gets a default dashboard with base alarms
51. Monitorama 2017 PDX / @theatrus Add Services define extra resources they use in a Salt pillar Can also define custom rows and targets
52. Monitorama 2017 PDX / @theatrus
53. Monitorama 2017 PDX / @theatrus Infrastructure or Dependent Teams Own the Monitoring
54. Monitorama 2017 PDX / @theatrus Consistent Look and Feel Same rows, same metrics, approachable
55. Monitorama 2017 PDX / @theatrus Code Dashboard/Alarm Review
56. Monitorama 2017 PDX / @theatrus grep
57. Monitorama 2017 PDX / @theatrus Other advantages Alarms exist on dashboards Less copy and paste Global refactoring Customize alarms without learning about all the nuances
58. Monitorama 2017 PDX / @theatrus Even more features Contains a query parser and rewriter
 (plug for pyPEG2) Parse query, transform queries into alternate forms Generate “deploy” (canaries vs. production) dashboards Automatic staging environment dashboards Best practices lint
59. Monitorama 2017 PDX / @theatrus
60. Monitorama 2017 PDX / @theatrus What Sucks Grafana has a UI builder We’re making you write dashboards as Jinja2+YAML Small workaround tooling: Grafana management script
 python tools/manage_dashboard.py
61. Monitorama 2017 PDX / @theatrus What Sucks Monorepo was great to bootstrap and iterate Poor in all the classic monorepo ways
62. Monitorama 2017 PDX / @theatrus Query languages, alarming, and UX far too difficult For non-experts, and we shouldn’t expect our
 users to become experts in the field
63. Enrichment
64. Monitorama 2017 PDX / @theatrus
65. Trust and Self Defense Will the dashboard load? Can I trust the data? Can you take it down?
66. Monitorama 2017 PDX / @theatrus
67. Monitorama 2017 PDX / @theatrus Provide visibility, out of band, of monitoring health Updates every 15s Updates … a few hours later?
68. Monitorama 2017 PDX / @theatrus Add smart limits lyft/statsrelay samples/aggregates to limit maximum outgoing statsd event rate Limits cardinality of counters/timers/gauges
 my.metric.0x293fa3a93…
69. Monitorama 2017 PDX / @theatrus We’re not done yet. (Is anything ever done?)
70. Monitorama 2017 PDX / @theatrus
