Scheduling background job on Android at the right time

Android provides three different APIs to run jobs in the future. All of them have their benefits and downsides. Semantic changes between API levels presents an additional challenge for programmers. Not only is it hard to know when to use the proper API, but you will also end up with many different paths in your code all doing the same task for different environments. Your app should be smart and run jobs only when it's the right time and all conditions are met. This talk will give you an overview about all options you have on Android and how to master them in an efficient way.

Ralf

March 14, 2017
Tweet

More Decks by Ralf

Other Decks in Programming

Transcript

  1. Motivation • Every app has some kind of repeated work

    • Don’t waste battery unnecessarily • App should still work correctly even in Doze mode or in App Standby • Scheduling repeated work is quite a headache with 3 different APIs all doing similar things
  2. AlarmManager + Available on all devices + Easy to send

    broadcast to start a service delayed - API behavior differs between platform versions - A lot of boilerplate - Device state ignored - …
  3. JobScheduler + Easy to use with fluent API + Respects

    device state - Only on API 21+ (some features only API 24+) - Platform bugs - Still a lot of boilerplate code
  4. GCM Network Manager + Similar API like JobScheduler + minSdkVersion

    9 - Part of Google’s Play Services SDK - Can’t be used without Play Services being pre-installed (most Chinese devices) - API contains some gotchas
  5. (Firebase JobDispatcher) + Wrapper for job scheduling engines - Setup

    is difficult - Library not maintained - Only GCM NetworkManager supported - Many open issues → I would not recommend using it
  6. Requirements • Show the reminder in a notification • Sync

    reminders with the server • Support all devices • Be a good citizen
  7. Reminder job • Must be exact • Can have multiple

    at the same time • AlarmManager is the correct API
  8. Reminder job <receiver android:name=".reminder.ReminderReceiver" android:exported="false"/> public class ReminderReceiver extends BroadcastReceiver

    { private static final String EXTRA_ID = "EXTRA_ID"; @Override public void onReceive(Context context, Intent intent) { int id = intent.getIntExtra(EXTRA_ID, -1); if (id < 0) { return; } Reminder reminder = ReminderEngine.instance().getReminderById(id); if (reminder != null) { ReminderEngine.instance().showReminder(reminder); } } }
  9. API 14-18 public static void schedule(Context context, Reminder reminder) {

    Intent intent = new Intent(context, ReminderReceiver.class); intent.putExtra(EXTRA_ID, reminder.getId()); int requestCode = reminder.getId(); int flags = PendingIntent.FLAG_UPDATE_CURRENT | PendingIntent.FLAG_ONE_SHOT; PendingIntent pendingIntent = PendingIntent .getBroadcast(context, requestCode, intent, flags); AlarmManager manager = (AlarmManager) context.getSystemService(Context.ALARM_SERVICE); manager.set(AlarmManager.RTC_WAKEUP, reminder.getTimestamp(), pendingIntent); }
  10. API 14-18 public static void schedule(Context context, Reminder reminder) {

    Intent intent = new Intent(context, ReminderReceiver.class); intent.putExtra(EXTRA_ID, reminder.getId()); int requestCode = reminder.getId(); int flags = PendingIntent.FLAG_UPDATE_CURRENT | PendingIntent.FLAG_ONE_SHOT; PendingIntent pendingIntent = PendingIntent .getBroadcast(context, requestCode, intent, flags); AlarmManager manager = (AlarmManager) context.getSystemService(Context.ALARM_SERVICE); manager.set(AlarmManager.RTC_WAKEUP, reminder.getTimestamp(), pendingIntent); }
  11. API 19-22 public static void schedule(Context context, Reminder reminder) {

    Intent intent = new Intent(context, ReminderReceiver.class); intent.putExtra(EXTRA_ID, reminder.getId()); int requestCode = reminder.getId(); int flags = PendingIntent.FLAG_UPDATE_CURRENT | PendingIntent.FLAG_ONE_SHOT; PendingIntent pendingIntent = PendingIntent .getBroadcast(context, requestCode, intent, flags); AlarmManager manager = (AlarmManager) context.getSystemService(Context.ALARM_SERVICE); manager.set(AlarmManager.RTC_WAKEUP, reminder.getTimestamp(), pendingIntent); }
  12. API 19-22 public static void schedule(Context context, Reminder reminder) {

    Intent intent = new Intent(context, ReminderReceiver.class); intent.putExtra(EXTRA_ID, reminder.getId()); int requestCode = reminder.getId(); int flags = PendingIntent.FLAG_UPDATE_CURRENT | PendingIntent.FLAG_ONE_SHOT; PendingIntent pendingIntent = PendingIntent .getBroadcast(context, requestCode, intent, flags); AlarmManager manager = (AlarmManager) context.getSystemService(Context.ALARM_SERVICE); manager.setExact(AlarmManager.RTC_WAKEUP, reminder.getTimestamp(), pendingIntent); }
  13. API 23-25 public static void schedule(Context context, Reminder reminder) {

    Intent intent = new Intent(context, ReminderReceiver.class); intent.putExtra(EXTRA_ID, reminder.getId()); int requestCode = reminder.getId(); int flags = PendingIntent.FLAG_UPDATE_CURRENT | PendingIntent.FLAG_ONE_SHOT; PendingIntent pendingIntent = PendingIntent .getBroadcast(context, requestCode, intent, flags); AlarmManager manager = (AlarmManager) context.getSystemService(Context.ALARM_SERVICE); manager.setExact(AlarmManager.RTC_WAKEUP, reminder.getTimestamp(), pendingIntent); }
  14. API 23-25 public static void schedule(Context context, Reminder reminder) {

    Intent intent = new Intent(context, ReminderReceiver.class); intent.putExtra(EXTRA_ID, reminder.getId()); int requestCode = reminder.getId(); int flags = PendingIntent.FLAG_UPDATE_CURRENT | PendingIntent.FLAG_ONE_SHOT; PendingIntent pendingIntent = PendingIntent .getBroadcast(context, requestCode, intent, flags); AlarmManager manager = (AlarmManager) context.getSystemService(Context.ALARM_SERVICE); manager.setExactAndAllowWhileIdle(AlarmManager.RTC_WAKEUP, reminder.getTimestamp(), pendingIntent); }
  15. Reminder job public static void schedule(Context context, Reminder reminder) {

    // … if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.M) { manager.setExactAndAllowWhileIdle(AlarmManager.RTC_WAKEUP, when, pendingIntent); } else if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.KITKAT) { manager.setExact(AlarmManager.RTC_WAKEUP, when, pendingIntent); } else { manager.set(AlarmManager.RTC_WAKEUP, when, pendingIntent); } }
  16. Sync job • Can be inexact, but must be repeating

    • Run job only on an unmetered network and only if device is charging • Don’t wake up the device to sync data • JobScheduler and GCM Network Manager work best, AlarmManager is fallback
  17. public class SyncJob extends JobService { @Override public boolean onStartJob(JobParameters

    params) { // called on main thread new Thread(() -> { try { new SyncEngine().syncReminders(); } catch (IOException e) { e.printStackTrace(); } finally { jobFinished(params, false); // don't forget to call } }).start(); return true; // we have background work } @Override public boolean onStopJob(JobParameters params) { return false; // don't reschedule } } API 21-23
  18. private static final int JOB_ID = 1; public static void

    schedule(Context context) { long interval = TimeUnit.HOURS.toMillis(6); JobInfo jobInfo = new JobInfo.Builder(JOB_ID, new ComponentName(context, SyncJob.class)) .setRequiresCharging(true) .setRequiredNetworkType(JobInfo.NETWORK_TYPE_UNMETERED) .setPersisted(true) .setPeriodic(interval) .build(); JobScheduler jobScheduler = (JobScheduler) context .getSystemService(Context.JOB_SCHEDULER_SERVICE); jobScheduler.schedule(jobInfo); } API 21-23
  19. private static final int JOB_ID = 1; public static void

    schedule(Context context) { long interval = TimeUnit.HOURS.toMillis(6); JobInfo jobInfo = new JobInfo.Builder(JOB_ID, new ComponentName(context, SyncJob.class)) .setRequiresCharging(true) .setRequiredNetworkType(JobInfo.NETWORK_TYPE_UNMETERED) .setPersisted(true) .setPeriodic(interval) .build(); JobScheduler jobScheduler = (JobScheduler) context .getSystemService(Context.JOB_SCHEDULER_SERVICE); jobScheduler.schedule(jobInfo); } API 21-23
  20. private static final int JOB_ID = 1; public static void

    schedule(Context context) { long interval = TimeUnit.HOURS.toMillis(6); long flex = TimeUnit.HOURS.toMillis(3); JobInfo jobInfo = new JobInfo.Builder(JOB_ID, new ComponentName(context, SyncJob.class)) .setRequiresCharging(true) .setRequiredNetworkType(JobInfo.NETWORK_TYPE_UNMETERED) .setPersisted(true) .setPeriodic(interval, flex) .build(); JobScheduler jobScheduler = (JobScheduler) context .getSystemService(Context.JOB_SCHEDULER_SERVICE); jobScheduler.schedule(jobInfo); } API 24-25
  21. public class SyncJob extends GcmTaskService { @Override public int onRunTask(TaskParams

    taskParams) { try { new SyncEngine().syncReminders(); return GcmNetworkManager.RESULT_SUCCESS; } catch (IOException e) { e.printStackTrace(); return GcmNetworkManager.RESULT_FAILURE; } } } With Google Play Services
  22. private static final String TAG = "SyncJob"; public void schedule(Context

    context) { long interval = TimeUnit.HOURS.toMillis(6); long flex = TimeUnit.HOURS.toMillis(3); PeriodicTask task = new PeriodicTask.Builder() .setTag(TAG) .setService(SyncJob.class) .setRequiresCharging(true) .setRequiredNetwork(Task.NETWORK_STATE_UNMETERED) .setPersisted(true) .setUpdateCurrent(true) .setPeriod(interval / 1_000) .setFlex(flex / 1_000) .build(); GcmNetworkManager.getInstance(context).schedule(task); } With Google Play Services
  23. private static final String TAG = "SyncJob"; public void schedule(Context

    context) { long interval = TimeUnit.HOURS.toMillis(6); long flex = TimeUnit.HOURS.toMillis(3); PeriodicTask task = new PeriodicTask.Builder() .setTag(TAG) .setService(SyncJob.class) .setRequiresCharging(true) .setRequiredNetwork(Task.NETWORK_STATE_UNMETERED) .setPersisted(true) .setUpdateCurrent(true) .setPeriod(interval / 1_000) .setFlex(flex / 1_000) .build(); GcmNetworkManager.getInstance(context).schedule(task); } With Google Play Services
  24. Sync job public void schedule(Context context) { if (Build.VERSION.SDK_INT >=

    Build.VERSION_CODES.N) { scheduleWithJobScheduler24(context); } else if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.LOLLIPOP) { scheduleWithJobScheduler21(context); } else if (GoogleApiAvailability.getInstance().isGooglePlayServicesAvailable(context) == ConnectionResult.SUCCESS) { scheduleWithGcmNetworkManager(context); } else { scheduleWithAlarmManager(context); } }
  25. Conclusion • A lot of boilerplate to achieve something that

    should be simple • It should be much easier
  26. android-job • Single API to use the JobSchduler, GCM Network

    Manager and AlarmManager • All API 24 features supported • Automatically chooses best API to run a job • Less boilerplate, e.g. no manifest entry needed • No reflection used • Maintained and improved continuously • … and more
  27. API private void scheduleAdvancedJob() { PersistableBundleCompat extras = new PersistableBundleCompat();

    extras.putString("key", "Hello world"); int jobId = new JobRequest.Builder(DemoSyncJob.TAG) .setExecutionWindow(30_000L, 40_000L) .setExact(30_000L) .setPeriodic(TimeUnit.HOURS.toMillis(3)) .setBackoffCriteria(5_000L, JobRequest.BackoffPolicy.EXPONENTIAL) .setRequiresCharging(true) .setRequiresDeviceIdle(false) .setRequiredNetworkType(JobRequest.NetworkType.CONNECTED) .setRequirementsEnforced(true) .setExtras(extras) .setPersisted(true) .setUpdateCurrent(true) .build() .schedule(); }
  28. Setup dependencies { compile 'com.evernote:android-job:1.1.7' } public class App extends

    Application { @Override public void onCreate() { super.onCreate(); JobManager.create(this).addJobCreator(new ReminderJobCreator()); } }
  29. Setup public class ReminderJobCreator implements JobCreator { @Override public Job

    create(String tag) { switch (tag) { case ReminderJob.TAG: return new ReminderJob(); case SyncJob.TAG: return new SyncJob(); default: return null; } } }
  30. Reminder job public class ReminderJob extends Job { public static

    final String TAG = "ReminderJob"; private static final String EXTRA_ID = "EXTRA_ID"; @NonNull @Override protected Result onRunJob(Params params) { int id = params.getExtras().getInt(EXTRA_ID, -1); Reminder reminder = ReminderEngine.instance().getReminderById(id); if (reminder == null) { return Result.FAILURE; } ReminderEngine.instance().showReminder(reminder); return Result.SUCCESS; } }
  31. Reminder job public static int schedule(@NonNull Reminder reminder) { PersistableBundleCompat

    extras = new PersistableBundleCompat(); extras.putInt(EXTRA_ID, reminder.getId()); long time = Math.max(1L, reminder.getTimestamp() - System.currentTimeMillis()); return new JobRequest.Builder(TAG) .setExact(time) .setExtras(extras) .setPersisted(true) .setUpdateCurrent(false) .build() .schedule(); }
  32. Reminder job public static int schedule(@NonNull Reminder reminder) { PersistableBundleCompat

    extras = new PersistableBundleCompat(); extras.putInt(EXTRA_ID, reminder.getId()); long time = Math.max(1L, reminder.getTimestamp() - System.currentTimeMillis()); return new JobRequest.Builder(TAG) .setExact(time) .setExtras(extras) .setPersisted(true) .setUpdateCurrent(false) .build() .schedule(); }
  33. Sync job public class SyncJob extends Job { public static

    final String TAG = "SyncJob"; @NonNull @Override protected Result onRunJob(Params params) { new SyncEngine().syncReminders(); return Result.SUCCESS; } }
  34. Sync job public static int schedule() { Set<JobRequest> jobRequests =

    JobManager.instance().getAllJobRequestsForTag(TAG); if (!jobRequests.isEmpty()) { return jobRequests.iterator().next().getJobId(); } long interval = TimeUnit.HOURS.toMillis(6); // every 6 hours long flex = TimeUnit.HOURS.toMillis(3); // wait 3 hours before job runs again return new JobRequest.Builder(TAG) .setPeriodic(interval, flex) .setPersisted(true) .setUpdateCurrent(true) .setRequiredNetworkType(JobRequest.NetworkType.UNMETERED) .setRequiresCharging(true) .setRequirementsEnforced(true) .build() .schedule(); }
  35. Sync job public static int schedule() { Set<JobRequest> jobRequests =

    JobManager.instance().getAllJobRequestsForTag(TAG); if (!jobRequests.isEmpty()) { return jobRequests.iterator().next().getJobId(); } long interval = TimeUnit.HOURS.toMillis(6); // every 6 hours long flex = TimeUnit.HOURS.toMillis(3); // wait 3 hours before job runs again return new JobRequest.Builder(TAG) .setPeriodic(interval, flex) .setPersisted(true) .setUpdateCurrent(true) .setRequiredNetworkType(JobRequest.NetworkType.UNMETERED) .setRequiresCharging(true) .setRequirementsEnforced(true) .build() .schedule(); }
  36. Sync job public static int schedule() { Set<JobRequest> jobRequests =

    JobManager.instance().getAllJobRequestsForTag(TAG); if (!jobRequests.isEmpty()) { return jobRequests.iterator().next().getJobId(); } long interval = TimeUnit.HOURS.toMillis(6); // every 6 hours long flex = TimeUnit.HOURS.toMillis(3); // wait 3 hours before job runs again return new JobRequest.Builder(TAG) .setPeriodic(interval, flex) .setPersisted(true) .setUpdateCurrent(true) .setRequiredNetworkType(JobRequest.NetworkType.UNMETERED) .setRequiresCharging(true) .setRequirementsEnforced(true) .build() .schedule(); }
  37. Sync job public static int schedule() { Set<JobRequest> jobRequests =

    JobManager.instance().getAllJobRequestsForTag(TAG); if (!jobRequests.isEmpty()) { return jobRequests.iterator().next().getJobId(); } long interval = TimeUnit.HOURS.toMillis(6); // every 6 hours long flex = TimeUnit.HOURS.toMillis(3); // wait 3 hours before job runs again return new JobRequest.Builder(TAG) .setPeriodic(interval, flex) .setPersisted(true) .setUpdateCurrent(true) .setRequiredNetworkType(JobRequest.NetworkType.UNMETERED) .setRequiresCharging(true) .setRequirementsEnforced(true) .build() .schedule(); }
  38. Sync job public static int schedule() { Set<JobRequest> jobRequests =

    JobManager.instance().getAllJobRequestsForTag(TAG); if (!jobRequests.isEmpty()) { return jobRequests.iterator().next().getJobId(); } long interval = TimeUnit.HOURS.toMillis(6); // every 6 hours long flex = TimeUnit.HOURS.toMillis(3); // wait 3 hours before job runs again return new JobRequest.Builder(TAG) .setPeriodic(interval, flex) .setPersisted(true) .setUpdateCurrent(true) .setRequiredNetworkType(JobRequest.NetworkType.UNMETERED) .setRequiresCharging(true) .setRequirementsEnforced(true) .build() .schedule(); }
  39. FAQ Which API is used? • Exact job → AlarmManager

    • API 21+ → JobScheduler • Play Services installed → GcmNetworkManager • Else → AlarmManager
  40. FAQ What happens after a reboot? • All jobs are

    rescheduled if necessary → even after a force close → even after the Play Services were updated
  41. android-job Tips & Tricks • Look at the samples in

    the README • Read the FAQ • Uncertain? Having problems? → Create an issue
  42. Conclusion • Android APIs force you to ◦ do the

    same thing multiple times ◦ write a lot of boilerplate ◦ catch many gotchas • android-job to the rescue
