Record Linkage - A real use case with Spark ML

Record Linkage - A real use case with Spark ML

Presentation from Spark Saturday DC, April 30th 2016

Alexis Seigneurin

April 30, 2016
Tweet

More Decks by Alexis Seigneurin

Other Decks in Technology

Transcript

  1. Who I am • Software engineer for 15 years •

    Consultant at Ippon USA, previously at Ippon France • Favorite subjects: Spark, Machine Learning, Cassandra • Spark trainer • @aseigneurin
  2. • 200 software engineers in France and the US •

    In the US: offices in DC, NYC and Richmond, Virginia • Digital, Big Data and Cloud applications • Java & Agile expertise • Open-source projects: JHipster, Tatami, etc. • @ipponusa
  3. The project • Record Linkage with Machine learning • Use

    cases: • Find new clients who come from insurance comparison services → Commission • Find duplicates in existing files (acquisitions) • Record Linkage • Entity resolution • Deduplication • Entity disambiguation • …
  4. • Find duplicates! Purpose +---+-------+------------+----------+------------+---------+------------+ | ID| veh|codptgar_veh|dt_nais_cp|dt_permis_cp|redmaj_cp| formule| +---+-------+------------+----------+------------+---------+------------+

    |...|PE28221| 50000|1995-10-12| 2013-10-08| 100.0| TIERS| |...|FO26016| 59270|1967-01-01| 1987-02-01| 100.0|VOL_INCENDIE| |...|FI19107| 77100|1988-09-27| 2009-09-13| 105.0|TOUS_RISQUES| |...|RE07307| 69100|1984-08-15| 2007-04-20| 50.0| TIERS| |...|FO26016| 59270|1967-01-01| 1987-02-07| 105.0|TOUS_RISQUES| +---+-------+------------+----------+------------+---------+------------+
  5. Steps 1. Preprocessing 1. Find potential duplicates 2. Feature engineering

    2. Manual labeling of a sample 3. Machine Learning to make predictions on the rest of the records
  6. Prototype • Crafted by a Data Scientist • Not architectured,

    not versioned, not unit tested… → Not ready for production • Spark, but a lot of Spark SQL (data processing) • Machine Learning in Python (Scikit Learn) → Objective: industrialization of the code
  7. • Data (CSV) + Schema (JSON) Inputs 000010;Jose;Lester;10/10/1970 000011;José;Lester;10/10/1970 000012;Tyler;Hunt;12/12/1972

    000013;Tiler;Hunt;25/12/1972 000014;Patrick;Andrews;1973-12-13 { "tableSchemaBeforeSelection": [ { "name": "ID", "typeField": "StringType", "hardJoin": false }, { "name": "name", "typeField": "StringType", "hardJoin": true, "cleaning": "digitLetter", "listFeature": [ "scarcity" ], "listDistance": [ "equality", "soundLike" ] }, ...
  8. • Spark CSV module → DataFrame Don’t use type inference

    Data loading +------+-------+-------+----------+ | ID| name|surname| birthDt| +------+-------+-------+----------+ |000010| Jose| Lester|10/10/1970| |000011| José| Lester|10/10/1970| |000012| Tyler| Hunt|12/12/1972| |000013| Tiler| Hunt|25/12/1972| |000014|Patrick|Andrews|1970-10-10| +------+-------+-------+----------+
  9. • Parsing of dates, numbers… • Cleaning of strings •

    UDF + DataFrame.withColumn() Data cleansing +------+-------+-------+----------+ | ID| name|surname| birthDt| +------+-------+-------+----------+ |000010| jose| lester|1970-10-10| |000011| jose| lester|1970-10-10| |000012| tyler| hunt|1972-12-12| |000013| tiler| hunt|1972-12-25| |000014|patrick|andrews| null| +------+-------+-------+----------+
  10. • Convert strings to phonetics (Beider-Morse) • Apache Commons Codec

    • … Feature calculation +------+-------+-------+----------+--------------------+ | ID| name|surname| birthDt| BMencoded_name| +------+-------+-------+----------+--------------------+ |000010| jose| lester|1970-10-10|ios|iosi|ioz|iozi...| |000011| jose| lester|1970-10-10|ios|iosi|ioz|iozi...| |000012| tyler| hunt|1972-12-12| tilir| |000013| tiler| hunt|1972-12-25| tQlir|tili|tilir| |000014|patrick|andrews| null|pYtrQk|pYtrik|pat...| +------+-------+-------+----------+--------------------+
  11. • Auto-join (more on that later…) Find potential duplicates +------+------+---------+...+------+------+---------+...

    | ID_1|name_1|surname_1|...| ID_2|name_2|surname_2|... +------+------+---------+...+------+------+---------+... |000010| jose| lester|...|000011| jose| lester|... |000012| tyler| hunt|...|000013| tiler| hunt|... +------+------+---------+...+------+------+---------+...
  12. • Several distance algorithms: • Levenshtein distance (Apache Commons Lang)

    • Date difference • … Distance calculation +------+...+------+...+-------------+--------------+...+----------------+ | ID_1|...| ID_2|...|equality_name|soundLike_name|...|dateDiff_birthDt| +------+...+------+...+-------------+--------------+...+----------------+ |000010|...|000011|...| 0.0| 0.0|...| 0.0| |000012|...|000013|...| 1.0| 0.0|...| 13.0| +------+...+------+...+-------------+--------------+...+----------------+
  13. • Standardization of distances only • Vectorization (2 vectors) •

    Spark ML’s VectorAssembler Standardization / vectorization +------+------+---------+----------+------+------+---------+----------+------------+--------------+ | ID_1|name_1|surname_1| birthDt_1| ID_2|name_2|surname_2| birthDt_2| distances|other_features| +------+------+---------+----------+------+------+---------+----------+------------+--------------+ |000010| jose| lester|1970-10-10|000011| jose| lester|1970-10-10|[0.0,0.0,...| [2.0,2.0,...| |000012| tyler| hunt|1972-12-12|000013| tiler| hunt|1972-12-25|[1.0,1.0,...| [1.0,2.0,...| +------+------+---------+----------+------+------+---------+----------+------------+--------------+
  14. From SQL… • Generated SQL requests • Hard to maintain

    (especially as regards to UDFs) val cleaningRequest = tableSchema.map(x => { x.CleaningFuction match { case (Some(udf), _) => udf + "(" + x.name + ") as " + x.name case _ => x.name } }).mkString(", ") val cleanedTable = sqlContext.sql("select " + cleaningRequest + " from " + tableName) cleanedTable.registerTempTable(schema.tableName + "_cleaned")
  15. … to DataFrames • DataFrame primitives • More work done

    by the Scala compiler val cleanedDF = tableSchema.filter(_.cleaning.isDefined).foldLeft(df) { case (df, field) => val udf: UserDefinedFunction = ... // get the cleaning UDF df.withColumn(field.name + "_cleaned", udf.apply(df(field.name))) .drop(field.name) .withColumnRenamed(field.name + "_cleaned", field.name) }
  16. val resDF = schema.cleanTable(rows)
 "The cleaning process" should "clean text

    fields" in {
 val res = resDF.select("ID", "name", "surname").collect()
 val expected = Array(
 Row("000010", "jose", "lester"),
 Row("000011", "jose", "lester ea"),
 Row("000012", "jose", "lester")
 )
 res should contain theSameElementsAs expected
 }
 "The cleaning process" should "parse dates" in { ... Comparison of Row objects 000010;Jose;Lester;10/10/1970
 000011;Jose =-+;Lester éà;10/10/1970
 000012;Jose;Lester;invalid date
  17. Shared SparkContext • Don’ts: • Use one SparkContext per class

    of tests → multiple contexts • Setup / tear down the SparkContext for each test → slow tests • Do’s: • Use a shared SparkContext object SparkTestContext {

 val conf = new SparkConf()
 .setAppName("deduplication-tests")
 .setMaster("local[*]")

 val sc = new SparkContext(conf)
 val sqlContext = new SQLContext(sc)

 }
  18. spark-testing-base • Holden Karau’s spark-testing-base library • https://github.com/holdenk/spark-testing-base • Provides:

    • Shared SparkContext and SQLContext • Comparison of RDDs, DataFrames, DataSets • Mock data generators
  19. Join strategy • For record linkage, first merge the two

    sources • Then auto-join Prospects New clients Duplicate
  20. Join - Volume of data • Input: 1M records •

    Cartesian product: 1000 B records → Find an appropriate join condition 0 25 50 75 100
  21. Join condition • Multiples join on 2 fields • Equality

    of values or custom condition (UDF) • Union between all the intermediate results • E.g. with fields name, surname, birth_date: df1.join(df2, (df1("ID_1") < df2("ID_2"))
 && (df1("name_1") === df2("name_2"))
 && (soundLike(df1("surname_1"), df2("surname_2"))) df1.join(df2, (df1("ID_1") < df2("ID_2"))
 && (df1("name_1") === df2("name_2"))
 && (df1("birth_date_1") === df2("birth_date_2"))) df1.join(df2, (df1("ID_1") < df2("ID_2"))
 && (soundLike(df1("surname_1"), df2("surname_2")))
 && (df1("birth_date_1") === df2("birth_date_2"))) UNION
  22. • 3 types of columns DataFrames extension +------+...+------+...+-------------+--------------+...+----------------+ | ID_1|...|

    ID_2|...|equality_name|soundLike_name|...|dateDiff_birthDt| +------+...+------+...+-------------+--------------+...+----------------+ |000010|...|000011|...| 0.0| 0.0|...| 0.0| |000012|...|000013|...| 1.0| 0.0|...| 13.0| +------+...+------+...+-------------+--------------+...+----------------+ Data Distances Non-distance features
  23. • DataFrame columns have a name and a data type

    • DataFrameExt = DataFrame + metadata over columns DataFrames extension case class OutputColumn(name: String, columnType: ColumnType)


 class DataFrameExt(val df: DataFrame, val outputColumns: Seq[OutputColumn]) { def show() = df.show() def drop(colName: String): DataFrameExt = ... def withColumn(colName: String, col: Column, columnType: ColumnType): DataFrameExt = ... ...
  24. Labeling • Manual operation • Is this a duplicate? →

    Yes / No • Performed on a sample of the potential duplicates • Between 1000 and 10 000 records
  25. Predictions • Machine Learning - Spark ML • Random Forests

    • (Gradient Boosting Trees also give good results) • Training on the potential duplicates labeled by hand • Predictions on the potential duplicates not labeled by hand
  26. Predictions • Sample: 1000 records • Training set: 800 records

    • Test set: 200 records • Results • True positives: 53 • False positives: 2 • True negatives: 126 • False negatives: 5 → Found 53 duplicates on the 58 expected (53+5) and only 2 errors •Precision ≈ 93% •Recall ≈ 91%
  27. Summary ✓ Single engine for Record Linkage and Deduplication ✓

    Machine Learning → Specific rules for each dataset ✓ Higher identification of matches • Previously ~50% → Now ~90%
