1. KSQL THE POWER OF KAFKA THE SIMPLICITY OF SQL ALEXIS SEIGNEURIN - 2019
2. ME Data Engineer at Kafka certified Run the Kafka Meetup: meetup.com/Apache-Kafka-NYC
3. FREE E-BOOK I WROTE A guide to producing, consuming and processing events en.ippon.tech/apache-kafka
4. MY BLOG aseigneurin.github.io
5. KAFKA: A FEW REMINDERS Publish-subscribe system Messages are published to topics Messages are persisted Messages can be read by multiple consumers Multiple partitions for scaling
6. PRODUCER AND CONSUMER API (JAVA) Low-level API Producer: send() Consumer: subscribe(), seek(), poll()… Consumer groups
7. KAFKA STREAMS Client library for Java and Scala DSL: from(), map(), filter(), to()… Aggregations, joins, windowing Simple deployment model Allows to create “microservices” KStream / KTable
8. KAFKA STREAMS: QUICK EXAMPLE Properties props = new Properties(); props.put(StreamsConfig.APPLICATION_ID_CONFIG, "text-transformer"); props.put(StreamsConfig.BOOTSTRAP_SERVERS_CONFIG, "localhost:9092"); props.put(StreamsConfig.NUM_STREAM_THREADS_CONFIG, "8"); props.put(ConsumerConfig.AUTO_OFFSET_RESET_CONFIG, "earliest"); StreamsBuilder streamsBuilder = new StreamsBuilder(); streamsBuilder.stream("text-input", Consumed.with(Serdes.String(), Serdes.String())) .filter((key, value) -> value.contains("a")) .mapValues(text -> text.toUpperCase()) .to("text-output", Produced.with(Serdes.String(), Serdes.String())); Topology topology = streamsBuilder.build(); KafkaStreams streams = new KafkaStreams(topology, props); streams.start(); Application ID = Kafka consumer group Threads for parallel processing (relates to partitions) Topic to read from + key/value deserializers Transformations: map, filter… Topic to write to + key/value serializers
9. KAFKA STREAMS: KSTREAM KStream: stream of events Records are independent from each other Stateless Example (inspired from the documentation): ‣ Sum values as records arrive ‣ Records: ‣ (alice, 1) = 1 ‣ (charlie, 1) = 2 ‣ (alice, 3) = 5 ‣ → Adds to (alice, 1)
10. KAFKA STREAMS: KTABLE KTable: change log stream New records = updates Stateful (requires a state store) Example (inspired from the documentation): ‣ Sum values as records arrive ‣ Records: ‣ (alice, 1) = 1 ‣ (charlie, 1) = 2 ‣ (alice, 3) = 4 ‣ → Replaces (alice, 1)
11. KSQL Built on top of Kafka Streams SQL queries translate into Kafka Streams applications ‣ CREATE STREAM → KStream ‣ CREATE TABLE → KTable Interactive or non-interactive queries
12. WHICH API TO USE? Source: https://docs.confluent.io/current/ksql/docs/concepts/ksql-and-kafka-streams.html
13. KSQL Works with structured data: ‣ Delimited ‣ JSON ‣ Avro (Schema Registry)
14. KSQL: EXAMPLE { “title":"Toy Story”, ”id”:"862", "imdb_id":"tt0114709", … } { "title":"Full Metal Jacket”, “id”:”600”, ”imdb_id":"tt0093058", … } … { “userId":"14", “movieId":"1287", “rating":2.0, "timestamp":1260759187} {“userId”:”28", "movieId":"862", "rating": 2.0, "timestamp":1260759148} {“userId”:”7", "movieId":"1339", "rating": 3.5, “timestamp":1260759125} … Movielens dataset Topic: ratings Topic: movies
15. KTABLE OF MOVIES CREATE TABLE movies ( \ adult VARCHAR, \ belongs_to_collection VARCHAR, \ budget VARCHAR, \ genres VARCHAR, \ homepage VARCHAR, \ id VARCHAR, \ imdb_id VARCHAR, \ original_language VARCHAR, \ original_title VARCHAR, \ overview VARCHAR, \ popularity VARCHAR, \ poster_path VARCHAR, \ production_companies VARCHAR, \ production_countries VARCHAR, \ release_date VARCHAR, \ revenue VARCHAR, \ runtime VARCHAR, \ spoken_languages VARCHAR, \ status VARCHAR, \ tagline VARCHAR, \ title VARCHAR, \ video VARCHAR, \ vote_average VARCHAR, \ vote_count VARCHAR) \ WITH (KAFKA_TOPIC = 'movies', \ VALUE_FORMAT='JSON', \ KEY = 'id'); SHOW TABLES; DESCRIBE EXTENDED movies;
16. KTABLE OF MOVIES $ kafka-console-consumer --bootstrap-server localhost:9092 --topic movies SELECT ID, TITLE FROM MOVIES WHERE TITLE LIKE 'Toy %';
17. KSTREAM OF RATINGS CREATE STREAM ratings ( \ userId VARCHAR, \ movieId VARCHAR, \ rating DOUBLE, \ timestamp BIGINT \ ) \ WITH (KAFKA_TOPIC = 'ratings', VALUE_FORMAT='JSON'); DESCRIBE EXTENDED ratings; SELECT USERID, MOVIEID, RATING FROM RATINGS;
18. JOIN RATINGS WITH MOVIES SELECT USERID, MOVIEID, TITLE, RATING \ FROM RATINGS \ LEFT JOIN MOVIES ON RATINGS.MOVIEID = MOVIES.ID;
19. QUERY RUNNING IN THE BACKGROUND CREATE STREAM ratings_enriched \ WITH (KAFKA_TOPIC = 'ratings_enriched', VALUE_FORMAT='JSON') \ AS SELECT USERID, MOVIEID, TITLE, RATING \ FROM RATINGS \ LEFT JOIN MOVIES ON RATINGS.MOVIEID = MOVIES.ID; EXPLAIN CSAS_RATINGS_ENRICHED_0; kafka-console-consumer --bootstrap-server localhost:9092 --topic ratings_enriched Kill the KSQL CLI... TERMINATE CSAS_RATINGS_ENRICHED_0; DROP STREAM ratings_enriched;
20. DEPLOYMENT OPTIONS Interactive: KSQL CLI Non-interactive: ksql-server-start /path/to/ksql-server.properties --queries-file query.sql
21. NON-INTERACTIVE QUERIES cd dev/kafka-movies ksql-server-start \ ~/software/confluent-5.1.0/etc/ksql/ksql-server.properties \ \—queries-file src/main/resources/query1.sql (Start a second KSQL server)
22. WINDOWED AGGREGATIONS Windows: tumbling, hopping, session Functions: WINDOWSTART() and WINDOWEND()
23. WINDOWED AGGREGATIONS $ kafka-console-consumer --bootstrap-server localhost:9092 --topic events CREATE STREAM events ( \ id VARCHAR, \ info VARCHAR, \ source VARCHAR, \ userid BIGINT ) \ WITH (KAFKA_TOPIC = 'events', VALUE_FORMAT='JSON');
24. WINDOWED AGGREGATIONS SELECT * FROM EVENTS; SELECT \ SOURCE, \ WINDOWSTART(), \ WINDOWEND(), \ COUNT(*) \ FROM EVENTS \ WINDOW TUMBLING(SIZE 5 SECONDs) \ GROUP BY SOURCE; SELECT \ SOURCE, \ TIMESTAMPTOSTRING(WINDOWSTART(), 'yyyy-MM-dd HH:mm:ss'), \ TIMESTAMPTOSTRING(WINDOWEND(), 'yyyy-MM-dd HH:mm:ss'), \ COUNT(*) \ FROM EVENTS \ WINDOW TUMBLING(SIZE 5 SECONDs) \ GROUP BY SOURCE;
25. WINDOWED AGGREGATIONS Support for late events Event time vs Processing time | t1 | t2 | t3 | ... |* * * * |** * | * *** * *| ... | t1 | t2 | t3 | ... |* * * . |** * | * *** * *| ... \-----> *(t1)
26. WRAPPING UP Streaming SQL engine Tables + Streams Windowed aggregations Interactive vs non-interactive
27. THANKS! @aseigneurin aseigneurin.github.io
