Javaday / ParisJug 2022 - Remèdes aux oomkill, warm-ups, et lenteurs pour des conteneurs JVM

Mes conteneurs JVM sont en prod, oups ils se font _oomkill_, _oups_ le démarrage traîne en longueur, _oups_ ils sont lent en permanence. Nous avons vécu ces situations.

Ces problèmes émergent parce qu’un conteneur est par nature un milieu restreint. Sa configuration a un impact sur le process Java cependant ce process a lui aussi des besoins pour fonctionner.

Il y a un espace entre la heap Java et le RSS : c’est la mémoire off-heap et elle se décompose en plusieurs zones. À quoi servent-elles ? Comment les prendre en compte ? La configuration du CPU impacte la JVM sur divers aspects : Quelles sont les influences entre le GC et le CPU ? Que choisir entre la rapidité ou la consommation CPU au démarrage ?

Au cours de cette université nous verrons comment diagnostiquer, comprendre et remédier à ces problèmes.

1. Remèdes aux oomkill, warm-ups, et lenteurs pour des conteneurs JVM Redux
2. Orateurs Brice Dutheil @BriceDutheil Jean-Philippe Bempel @jpbempel
3. Agenda My container gets oomkilled How does the memory actually work Some case in hands Container gets respawned Things that slow down startup Break
4. My container gets oomkilled
5. The containers are restarting. What’s going on ? $ kubectl get pods NAME READY STATUS RESTARTS AGE my-pod-5759f56c55-cjv57 3/3 Running 7 3d1h $ kubectl describe pod my-pod-5759f56c55-cjv57 ... State: Running Started: Mon, 06 Jun 2020 13:39:40 +0200 Last State: Terminated Reason: OOMKilled Exit Code: 137 Started: Thu, 06 Jun 2020 09:20:21 +0200 Finished: Mon, 06 Jun 2020 13:39:38 +0200
6. 🔥 🔥 🔥🔥 🔥 🔥 🔥 🚨 Crisis mode 🚨 If containers are oomkilled Just increase the container memory limits and investigate later
7. Linux Oomkiller • Out Of Memory Killer Linux mechanism employed to kill processes when the memory is critically low • For regular processes the oomkiller selects the bad ones. • Within a restrained container, i.e. with memory limits, ◦ If available memory reaches 0 in this container then the oomkiller terminates all processes ◦ There is usually a single process in container
8. Linux oomkiller and containers Monitor it • kube_pod_container_status_last_terminated_reason, if the exit code is 137, the attached reason label will be set to OOMKilled • Trigger an alert by coupling with kube_pod_container_status_restarts_total Synthetic oomkill docker run --memory-swap=100m --memory=100m \ --rm -it azul/zulu-openjdk:11 \ java -Xms100m -XX:+AlwaysPreTouch --version
9. Monitor the resident memory of a process Eg with micrometer you may have those • Heap Max : jvm_memory_max_bytes • Heap Live : jvm_memory_bytes_used • Process RSS : process_memory_rss_bytes And system ones, eg Kubernetes metrics • Container RSS : container_memory_rss • Memory limit : kube_pod_container_resource_limi ts_memory_bytes RSS Heap Max Heap Liveset memory limit
10. Memory of a JVM process
11. Memory As JVM based developers • Used to think about JVM Heap sizing, mostly -Xms, -Xmx, … • Possibly some deployment use container-aware flags: -XX:MinRAMPercentage, -XX:MaxRAMPercentage, … JVM Heap Xmx or MaxRAMPercentage
12. Why should I be concerned by native? Still have no idea what is happening off-heap How can you size properly the heap or the container ? JVM Heap
13. JVM Memory Breakdown Running A JVM requires memory: • The Java Heap • The Meta Space (pre-JDK 8 the Permanent Generation) • Direct byte buffers • Code cache (compiled code) • Garbage Collector (like card table) • Compiler (C1/C2) • Threads • Symbols • etc. JVM subsystems
14. JVM Memory Breakdown Except a few flags for meta space, code cache, or direct memory There’s no control over memory consumption of the other components But It is possible to get their size at runtime.
15. By monitoring Eg with micrometer Time series • jvm_memory_used_bytes • jvm_memory_committed_bytes • jvm_memory_max_bytes Dimensions • area : heap or nonheap • id : memory zone, depends on GC and JVM (e.g. G1 Eden Space, Compressed Class Space…)
16. Monitoring is only as good as data is there Observability metrics rely on MBean to get memory areas Most JVM don’t export metrics for everything that uses memory
17. Time to investigate the footprint With diagnostic tools
18. jcmd – a swiss knife Get the actual flag values $ jcmd $(pidof java) VM.flags | tr ' ' '\n' 6: ... -XX:InitialHeapSize=4563402752 -XX:InitialRAMPercentage=85.000000 -XX:MarkStackSize=4194304 -XX:MaxHeapSize=4563402752 -XX:MaxNewSize=2736783360 -XX:MaxRAMPercentage=85.000000 -XX:MinHeapDeltaBytes=2097152 -XX:NativeMemoryTracking=summary ... PID Xms Xmx
19. JVM’s Native Memory Tracking 1. Start the JVM with -XX:NativeMemoryTracking=summary 2. Later run jcmd $(pidof java) VM.native_memory Modes • summary • detail • baseline/ diff
20. $ jcmd $(pidof java) VM.native_memory 6: Native Memory Tracking: Total: reserved=7168324KB, committed=5380868KB - Java Heap (reserved=4456448KB, committed=4456448KB) (mmap: reserved=4456448KB, committed=4456448KB) - Class (reserved=1195628KB, committed=165788KB) (classes #28431) ( instance classes #26792, array classes #1639) (malloc=5740KB #87822) (mmap: reserved=1189888KB, committed=160048KB) ( Metadata: ) ( reserved=141312KB, committed=139876KB) ( used=135945KB) ( free=3931KB) ( waste=0KB =0.00%) ( Class space:) ( reserved=1048576KB, committed=20172KB) ( used=17864KB) ( free=2308KB) ( waste=0KB =0.00%) - Thread (reserved=696395KB, committed=85455KB) (thread #674) (stack: reserved=692812KB, committed=81872KB) (malloc=2432KB #4046) (arena=1150KB #1347) - Code (reserved=251877KB, committed=105201KB) (malloc=4189KB #11718) (mmap: reserved=247688KB, committed=101012KB) - GC (reserved=230739KB, committed=230739KB) (malloc=32031KB #63631) (mmap: reserved=198708KB, committed=198708KB) - Compiler (reserved=5914KB, committed=5914KB) (malloc=6143KB #3281) (arena=180KB #5) - Internal (reserved=24460KB, committed=24460KB) (malloc=24460KB #13140) - Other (reserved=267034KB, committed=267034KB)
21. $ jcmd $(pidof java) VM.native_memory 6: Native Memory Tracking: Total: reserved=7168324KB, committed=5380868KB - Java Heap (reserved=4456448KB, committed=4456448KB) (mmap: reserved=4456448KB, committed=4456448KB) - Class (reserved=1195628KB, committed=165788KB) (classes #28431) ( instance classes #26792, array classes #1639) (malloc=5740KB #87822) (mmap: reserved=1189888KB, committed=160048KB) ( Metadata: ) ( reserved=141312KB, committed=139876KB) ( used=135945KB) ( free=3931KB) ( waste=0KB =0.00%) ( Class space:) ( reserved=1048576KB, committed=20172KB) ( used=17864KB) ( free=2308KB) ( waste=0KB =0.00%) - Thread (reserved=696395KB, committed=85455KB) (thread #674) (stack: reserved=692812KB, committed=81872KB) (malloc=2432KB #4046) (arena=1150KB #1347) - Code (reserved=251877KB, committed=105201KB) (malloc=4189KB #11718) (mmap: reserved=247688KB, committed=101012KB) - GC (reserved=230739KB, committed=230739KB) (malloc=32031KB #63631) (mmap: reserved=198708KB, committed=198708KB) - Compiler (reserved=5914KB, committed=5914KB) (malloc=6143KB #3281) (arena=180KB #5) - Internal (reserved=24460KB, committed=24460KB) (malloc=24460KB #13140) - Other (reserved=267034KB, committed=267034KB) (classes #28431) (thread #674) Java Heap (reserved=4456448KB, committed=4456448KB)
22. $ jcmd $(pidof java) VM.native_memory 6: Native Memory Tracking: Total: reserved=7168324KB, committed=5380868KB - Java Heap (reserved=4456448KB, committed=4456448KB) (mmap: reserved=4456448KB, committed=4456448KB) - Class (reserved=1195628KB, committed=165788KB) (classes #28431) ( instance classes #26792, array classes #1639) (malloc=5740KB #87822) (mmap: reserved=1189888KB, committed=160048KB) ( Metadata: ) ( reserved=141312KB, committed=139876KB) ( used=135945KB) ( free=3931KB) ( waste=0KB =0.00%) ( Class space:) ( reserved=1048576KB, committed=20172KB) ( used=17864KB) ( free=2308KB) ( waste=0KB =0.00%) - Thread (reserved=696395KB, committed=85455KB) (thread #674) (stack: reserved=692812KB, committed=81872KB) (malloc=2432KB #4046) (arena=1150KB #1347) - Code (reserved=251877KB, committed=105201KB) (malloc=4189KB #11718) (mmap: reserved=247688KB, committed=101012KB) - GC (reserved=230739KB, committed=230739KB) (malloc=32031KB #63631) (mmap: reserved=198708KB, committed=198708KB) - Compiler (reserved=5914KB, committed=5914KB) (malloc=6143KB #3281) (arena=180KB #5) - Internal (reserved=24460KB, committed=24460KB) (malloc=24460KB #13140) - Other (reserved=267034KB, committed=267034KB) (malloc=267034KB #631) - Symbol (reserved=28915KB, committed=28915KB) (malloc=25423KB #330973) (arena=3492KB #1) - Native Memory Tracking (reserved=8433KB, committed=8433KB) (malloc=117KB #1498) (tracking overhead=8316KB) - Arena Chunk (reserved=217KB, committed=217KB) (malloc=217KB) - Logging (reserved=7KB, committed=7KB) (malloc=7KB #266) - Arguments (reserved=19KB, committed=19KB) (malloc=19KB #521) Total: reserved=7168324KB, committed=5380868KB Class (reserved=1195628KB, committed=165788KB) Thread (reserved=696395KB, committed=85455KB) Code (reserved=251877KB, committed=105201KB) GC (reserved=230739KB, committed=230739KB) Compiler (reserved=5914KB, committed=5914KB) Internal (reserved=24460KB, committed=24460KB) Other (reserved=267034KB, committed=267034KB)
23. Direct byte buffers Those are the memory segments that are allocated outside the Java heap. Unused buffers are only freed upon GC. Netty for example use them. • < JDK 11, they are reported in the Internal section • ≥ JDK 11, they are reported in the Other section Internal (reserved=24460KB, committed=24460KB) Other (reserved=267034KB, committed=267034KB)
24. Garbage Collection Full blown memory management for the Java Heap (and Metaspace) Requires memory for its internal data structures (like G1 regions, remembered sets, etc.) On small containers this might be a thing to consider GC (reserved=230739KB, committed=230739KB) (malloc=32031KB #63631) (mmap: reserved=198708KB, committed=198708KB)
25. 💡Memory mapped files They are not reported by Native Memory Tracking, at this time But are be accounted in the RSS.
26. Native Memory Tracking 👍 Good insights on the JVM sub-systems, but Does NMT show everything ? Nope Is NMT data correct ? Yes, but not for resident memory usage ⚠ Careful about the overhead! Measure if this is important for you !
27. Huh what virtual, committed, reserved memory? virtual memory : memory management technique that provides an "idealized abstraction of the storage resources that are actually available on a given machine" which "creates the illusion to users of a very large memory". reserved memory : Contiguous chunk of memory from the virtual memory that the program requested to the OS. committed memory : writable subset of reserved memory, might be backed by physical storage
28. Xmx = 4,25 GiB theory reality Touched pages of Java heap = 3 GiB Touched off-heap Xmx RSS Memory limit = 5 GiB Total: reserved=7168324KB, committed=5380868KB
29. RSS is the real footprint Only dirty memory page count for the oomkiller $ ps o pid,rss -p $(pidof java) PID RSS 6 4701120
30. What does it means with JVM flags ? -Xms / -Xmx for the Java heap -XX:MaxPermSize, -XX:MaxMetaspaceSize, -Xss, -XX:MaxDirectMemorySize ⇒ indication of how much memory heap memory is/can be reserved ⚠ These flags do have a big impact on JVM subsystems, bad settings may trigger unwanted behaviors : - GC if metaspace is too small - Heap resizing ig Xms ≠ Xmx - … Be careful
31. Avoid -XX:*RAMPercentage Sets the Java heap size as a function of the available physical memory. It works. ⚠ Small containers -XX:InitialRAMPercentage ⟹ -Xms mem < 96MiB -XX:MinRAMPercentage mem > 96MiB -XX:MaxRAMPercentage ⟹ -Xmx
32. Avoid -XX:*RAMPercentage Different environments ⇒ different load, different subsystem behavior E.g. preprod : 100 req/s 👉 40 java threads total 👉 mostly liveness endpoints 👉 low versatility in data 👉 low GC activity requirement prod-us : 1000 req/s 👉 200 java threads total 👉 mostly business endpoints 👉 variance in data 👉 higher GC requirements
33. Avoid -XX:*RAMPercentage 1 GiB 4 GiB prod-us preprod Java heap ≃ 850 MiB Java heap ≃ 3.4 GiB MaxRAMPercentage = 85 ~ 150 MiB for every subsystems Maybe OK for quiet workloads ~ 600 MiB for every subsystems Likely not enough for loaded systems ⟹ leads to oomkill
34. Avoid -XX:*RAMPercentage Traffic, Load are not linear, and do not have linear effects • MaxRAMPercentage is a linear function of the container available RAM • Too low MaxRAMPercentage ⟹ waste of space • Too high MaxRAMPercentage ⟹ risk of oomkills • Requires to find the sweet spot for all deployments • Requires to adjust if load changes • Need to convert back a percentage to raw value
35. Avoid -XX:*RAMPercentage -XX:*RAMPercentage flags sort of works, Its drawbacks don’t make this quite compelling. ✅ Prefer -Xms / -Xmx
36. How to configure memory requirement Off heap memory consumption is hard to estimate with prod load • Require to understand the each JVM subsystem and make predictions. • Fixing some of these values may have side effect, and it needs to be maintained. We propose instead an empiric approach
37. How to configure memory requirement In our experience it’s best to actually retrofit. What does it mean ? Give a larger memory limit to the container, much higher than the max heap size. Heap Container memory limit at 5 GiB
38. How to configure memory requirement In our experience it’s best to actually retrofit. What does it mean ? Give a larger memory limit to the container, much higher than the max heap size. 1. Observe the RSS evolution Heap RSS Container memory limit at 5 GiB
39. How to configure memory requirement In our experience it’s best to actually retrofit. What does it mean ? Give a larger memory limit to the container, much higher than the max heap size. 1. Observe the RSS evolution 2. If RSS stabilizes after some time Heap RSS RSS stabilizing Container memory limit at 5 GiB
40. How to configure memory requirement In our experience it’s best to actually retrofit. What does it mean ? Give a larger memory limit to the container, much higher than the max heap size. 1. Observe the RSS evolution 2. If RSS stabilizes after some time 3. Set the new memory limit with enough leeway (eg 200 MiB) Heap RSS New memory limit With some leeway for RSS increase Container memory limit at 5 GiB
41. How to configure memory requirement If RSS less than Heap size at start, it’s the trap of virtual memory. If actual heap usage grows up to Xmx (i.e touched pages), this will lead to oomkill RSS Touched pages of Java heap = 3 GiB Touched off-heap Theoric Java heap memory available Actual available memory
42. How to configure memory requirement To avoid the virtual memory pitfall use -XX:+AlwaysPreTouch All Java heap pages touched RSS
43. Other things to consider • Growing number of Direct byte buffers (e.g. with Netty, and used in other libraries like gRPC) • Native allocator, glibc’s malloc can be fragmenting the native memory. Slow but steady increase of memory Can represent Gigabytes on long running containers • Memory mapped files In theory reclaimable memory, but still account in RSS
44. My Container gets re-spawn
45. Container Restarted
46. Quick Fix Increase Probe liveness timeout (either initial delay or interval) livenessProbe: httpGet: path: / port: 8080 initialDelaySeconds: 60 periodSeconds: 10
47. JIT Compilation
48. Troubleshooting Compile Time Use jstat -compiler <pid> to see cumulated compilation time (in s) $ jstat -compiler 1 Compiled Failed Invalid Time FailedType FailedMethod 6002 0 0 101.16 0
49. Troubleshooting using JFR Use java -XX:StartFlightRecording jcmd 1 JFR.dump name=1 filename=petclinic.jfr jfr print --events jdk.CompilerStatistics petclinic.jfr
50. Troubleshooting using JFR
51. Measuring startup time docker run --cpus=<n> -ti spring-petclinic CPUs JVM Startup time (s) Compile time (s) 4 8.402 17.36 2 8.458 10.17 1 15.797 20.22 0.8 20.731 21.71 0.4 41.55 46.51 0.2 86.279 92.93
52. C1 vs C2 C1 + C2 C1 only # compiled methods 6,117 5,084 # C1 compiled methods 5,254 5,084 # C2 compiled methods 863 0 Total Time (ms) 21,678 1,234 Total Time in C1 (ms) 2,071 1,234 Total Time in C2 (ms) 19,607 0
53. Compiler Settings To only use C1 JIT compiler: -XX:TieredStopAtLevel=1 To adjust C2 compiler threads: -XX:CICompilerCount=<n>
54. Measuring startup time docker run --cpus=<n> -ti spring-petclinic CPUs JVM Startup time (s) Compile time (s) JVM Startup time (s) XX:TieredStopAtLevel=1 Compile time (s) 4 8.402 17.36 6.908 (-18%) 1.47 2 8.458 10.17 6.877 (-19%) 1.41 1 15.797 20.22 8.821 (-44%) 1.74 0.8 20.731 21.71 10.857 (-48%) 2.08 0.4 41.55 46.51 22.225 (-47%) 3.67 0.2 86.279 92.93 45.706 (-47%) 6.95
55. GC
56. Troubleshooting GC Use -Xlog:gc / -XX:+PrintGCDetails
57. Troubleshooting GC with JFR/JMC
58. Settings properly GC: Metadata Threshold To avoid Full GC for loading more class anre Metaspace resize: Set initial Metaspace size high enough to load all your required classes -XX:MetaspaceSize=512M
59. Settings properly GC Use a fixed heap size : -Xms = -Xmx -XX:InitialHeapSize = -XX:MaxHeapSize Heap resize done during Full GC for SerialGC & Parallel GC. G1 is able to resize without FullGC (regions, not the metaspace)
60. GC ergonomics: GC selection To verify in log GC (-Xlog:gc): CPU Memory GC < 2 < 2GB Serial ≥ 2 < 2GB Serial < 2 ≥ 2GB Serial ≥ 2 ≥ 2 GB Parallel(<JDK9) / G1(≥JDK9) [0.004s][info][gc] Using G1
61. GC ergonomics: # threads selection -XX:ParallelGCThreads=<n> Used for Parallelizing work during STW phases -XX:ConcGCThreads=<n> Used for concurrent work while application is running
62. CPU resource tuning
63. CPU Resources shares, quotas ?
64. CPU shares Sharing cpu among containers of a node Correspond to Requests for Kubernetes Allow to use all the CPUs if needed sharing with all others containers $ cat /sys/fs/cgroup/cpu.weight 20 $ cat /sys/fs/cgroup/cpu.weight 10 resources: requests: cpu: 500m resources: requests: cpu: 250m
65. CPU quotas Fixing limits of CPU used by a container Correspond to Limits to kubernetes resources: limits: cpu: 500m resources: limits: cpu: 250m $ cat /sys/fs/cgroup/cpu.max 50000 100000 $ cat /sys/fs/cgroup/cpu.max 25000 100000
66. Shares / Quotas Shares and quota have nothing to do with a hardware socket resources: limits: cpu: 1 limits: cpu: 1
67. availableProcessors ergonomics Setting CPU shares/quotas have a direct impact on Runtime.availableProcessors() API Runtime.availableProcessors() API is used to : • size some concurrent structures • ForkJoinPool, used for Parallel Streams, CompletableFuture, …
68. Tuning CPU Trade-off cpu needs for startup time VS request time • Adjust CPU shares / CPU quotas • Adjust liveness timeout • Use readiness / startup probes
69. Conclusion
70. Memory • JVM memory is not only Java heap • Native parts are less known, and difficult to monitor and estimate • Yet they are important moving part to account to avoid OOMKills • Bonus revise virtual memory 💡 Careful with the units, KB ≠ KiB
71. Startup • Containers with <2 cpus are an constraint environment for JVM • Need to keep in mind that JVM subsystems like JIT or GC need to be adjusted for requirements • To be aware of these subsystems helps to find the balance between resources and requirements of your application
72. References
73. References Using Jdk Flight Recorder and JDK Mission Control MaxRAMPercentage is not what I wished for Off-Heap reconnaissance Startup, Containers and TieredCompilation Hotspot JVM performance tuning guidelines Application Dynamic Class Data Sharing in HotSpot JVM Jdk18 G1 Parallel GC Changes Unthrottled fixing cpu limits in the cloud Best Practices Java single-core containers Containerize your Java applications Université à Devoxx 2022
