Data model on Android

 Jerzy Chalupski chalup, futuresimple  [email protected] Data model on
Android Base CRM http://porcupineprogrammer.blogspot.com/ 

Data model on Android 61 releases 200+ migrations 50 models
~90 relations ~2 years on Google Play ~100k LOC

futuresimple chalup

UI + Services ContentProvider Database

UI + Services ContentProvider Database BOILERPLATE UNFRIENDLY APIS

UI + Services ContentProvider Database BOILERPLATE BOILERPLATE UNFRIENDLY APIS

UI + Services ContentProvider Database BOILERPLATE BOILERPLATE UNFRIENDLY APIS MIGRATIONS
BOILERPLATE

UI + Services ContentProvider Database BOILERPLATE UNFRIENDLY APIS

public class Address { public Long id; public String region;
public String zip; public String country; public String city; public String street; } @Override public ContentValues getContentValues() { ContentValues values = new ContentValues(); values.put(Addresses.ID, id); values.put(Addresses.REGION, region); values.put(Addresses.ZIP, zip); values.put(Addresses.COUNTRY, country); values.put(Addresses.CITY, city); values.put(Addresses.STREET, street); return values; } POJOs with android.content.*

public class Address { public Long id; public String region;
public String zip; public String country; public String city; public String street; } public static Address getObjectFromCursor(Cursor c) { Address object = new Address(); int cId = c.getColumnIndex(Addresses.ID); object.id = c.isNull(cId) ? null : c.getLong(cId); object.region = c.getString(c.getColumnIndex(Addresses.REGION)); object.zip = c.getString(c.getColumnIndex(Addresses.ZIP)); object.country = c.getString(c.getColumnIndex(Addresses.COUNTRY)); object.city = c.getString(c.getColumnIndex(Addresses.CITY)); object.street = c.getString(c.getColumnIndex(Addresses.STREET)); return object; } POJOs with android.content.*

MINI QUIZ TIME! What’s wrong with this code? Cursor c
= /* some valid cursor */; boolean isDirty = c.getBoolean(c.getColumnIndex("is_dirty"));

MINI QUIZ TIME! What’s wrong with this code? “Cannot resolve
method Cursor.getBoolean(int)” Cursor c = /* some valid cursor */; boolean isDirty = c.getBoolean(c.getColumnIndex("is_dirty"));

MINI QUIZ TIME! ContentValues values = new ContentValues(); values.put("is_dirty", true);
What’s wrong with this code? “Cannot resolve method Cursor.getBoolean(int)” Cursor c = /* some valid cursor */; boolean isDirty = c.getBoolean(c.getColumnIndex("is_dirty"));

MINI QUIZ TIME! ContentValues values = new ContentValues(); values.put("is_dirty", true);
boolean isDirty = c.getInt(c.getColumnIndex("is_dirty")) == 1; What’s wrong with this code? “Cannot resolve method Cursor.getBoolean(int)” Cursor c = /* some valid cursor */; boolean isDirty = c.getBoolean(c.getColumnIndex("is_dirty"));

public class Address { @Column(Addresses.ID) public Long id; @Column(Addresses.REGION) public
String region; @Column(Addresses.ZIP) public String zip; @Column(Addresses.COUNTRY) public String country; @Column(Addresses.CITY) public String city; @Column(Addresses.STREET) public String street; } MicroOrm microOrm = new MicroOrm(); Address address = microOrm.fromCursor(cursor, Address.class); ContentValues values = microOrm.toContentValues(address); POJOs with MicroOrm

 chalup/microorm POJOs with MicroOrm List<Address> addresses = Lists.newArrayList(); if
(c != null && c.moveToFirst()) { do { addresses.add(Address.getObjectFromCursor(c)); } while (c.moveToNext()); } BEFORE: AFTER: List<Address> addresses = microOrm.listFromCursor(c, Address.class);

MINI QUIZ TIME! How many parameters there is in ContentResolver’s
query method? resolver.query(uri, ?);

MINI QUIZ TIME! How many parameters there is in ContentResolver’s
query method? resolver.query(uri, null, null, null, null);

MINI QUIZ TIME! resolver.query(uri, null, null, null, null); resolver.query(uri, null,
null, null, null, null); // API 16 How many parameters there is in ContentResolver’s query method?

null, null, null, null); // API 16 How many parameters there is in ContentResolver’s query method? What about SQLiteDatabase? db.query(table, ?);

null, null, null, null); // API 16 How many parameters there is in ContentResolver’s query method? What about SQLiteDatabase? db.query(table, null, null, null, null, null, null); db.query(table, null, null, null, null, null, null, null); db.query(true, table, null, null, null, null, null, null, null); db.query(true, table, null, null, null, null, null, null, null, null);

ContentResolver API resolver.query(uri, null, null, null, null); resolver.query(uri, null, "is_dirty
= ?", new String[] { String.valueOf(1) }, null ); ContentValues values = new ContentValues(); values.put("is_dirty", true); resolver.update(uri, values, null, null);

 futuresimple/android-db-commons ProviderAction.query(uri).perform(resolver); FluentCursor fluentCursor = ProviderAction .query(uri) .where("is_dirty =
?", 1) .perform(resolver); fluentCursor.toFluentIterable(new Function<Cursor, T>() { /* ... */ }); ProviderAction .update(uri) .value("is_dirty", true) .perform(resolver); ProviderAction API

@Override public Loader<Cursor> onCreateLoader(int id, Bundle args) { CursorLoader loader
= new CursorLoader(getActivity()); loader.setUri(Contacts.CONTENT_URI); loader.setSelection("is_dirty = ?"); loader.setSelectionArgs(new String[] { String.valueOf(1) }); return loader; } @Override public void onLoadFinished(Loader<Cursor> loader, Cursor c) { if (c != null && c.moveToFirst()) { do { // interesting code } while (c.moveToNext()); } } CursorLoader API

CursorLoaderBuilder API @Override public Loader<Cursor> onCreateLoader(int id, Bundle args) {
return CursorLoaderBuilder .forUri(Contacts.CONTENT_URI) .where("is_dirty = ?", 1) .build(getActivity()); }  futuresimple/android-db-commons

 futuresimple/android-db-commons @Override public Loader<List<Long>> onCreateLoader(int id, Bundle args) {
return CursorLoaderBuilder .forUri(Contacts.CONTENT_URI) .transform(new Function<Cursor, Long>() { /* ... */ }) .build(getActivity()); } @Override public Loader<Long> onCreateLoader(int id, Bundle args) { return CursorLoaderBuilder .forUri(Contacts.CONTENT_URI) .wrap(new Function<Cursor, Long>() { /* ... */ }) .build(getActivity()); } CursorLoaderBuilder API

UI + Services ContentProvider Database MIGRATIONS BOILERPLATE

BACKEND MOBILE

BACKEND MOBILE 250k items?

BACKEND MOBILE ?

BACKEND MOBILE

BACKEND MOBILE OFFLINE MODE = DATA MIGRATIONS

SQLite’s ALTER TABLE no ALTER COLUMN no DROP COLUMN no
touching of PRIMARY KEY no ADD/DROP/ALTER CONSTRAINT

CREATE TABLE users ( _id INTEGER PRIMARY KEY, email TEXT,
first_name TEXT, last_name TEXT ); CREATE TABLE users ( _id INTEGER PRIMARY KEY, email TEXT, - first_name TEXT, - last_name TEXT + name TEXT ); SQLite’s ALTER TABLE ?

first_name TEXT, last_name TEXT ); CREATE TABLE users ( _id INTEGER PRIMARY KEY, email TEXT, - first_name TEXT, - last_name TEXT + name TEXT ); SQLite’s ALTER TABLE ALTER TABLE users RENAME TO tmp;

first_name TEXT, last_name TEXT ); CREATE TABLE users ( _id INTEGER PRIMARY KEY, email TEXT, - first_name TEXT, - last_name TEXT + name TEXT ); SQLite’s ALTER TABLE ALTER TABLE users RENAME TO tmp; CREATE TABLE users ( _id INTEGER PRIMARY KEY, email TEXT, name TEXT );

first_name TEXT, last_name TEXT ); CREATE TABLE users ( _id INTEGER PRIMARY KEY, email TEXT, - first_name TEXT, - last_name TEXT + name TEXT ); SQLite’s ALTER TABLE ALTER TABLE users RENAME TO tmp; CREATE TABLE users ( _id INTEGER PRIMARY KEY, email TEXT, name TEXT ); INSERT INTO users (_id, email) SELECT _id, email FROM tmp;

first_name TEXT, last_name TEXT ); CREATE TABLE users ( _id INTEGER PRIMARY KEY, email TEXT, - first_name TEXT, - last_name TEXT + name TEXT ); SQLite’s ALTER TABLE ALTER TABLE users RENAME TO tmp; CREATE TABLE users ( _id INTEGER PRIMARY KEY, email TEXT, name TEXT ); INSERT INTO users (_id, email) SELECT _id, email FROM tmp; DROP TABLE tmp;

 futuresimple/android-schema-utils Sane migrations API CREATE TABLE users ( _id
INTEGER PRIMARY KEY, email TEXT, first_name TEXT, last_name TEXT ); CREATE TABLE users ( _id INTEGER PRIMARY KEY, email TEXT, - first_name TEXT, - last_name TEXT + name TEXT ); TableMigration migration = TableMigration .of(Tables.USERS) .to(CREATE_TABLE_USERS) .withMapping(/* ... */) .build(); mMigrationsHelper.performMigrations(db, migration);

CREATE TABLE users ( _id INTEGER PRIMARY KEY, email TEXT
); Migrations gotcha v1

); + first_name TEXT, + last_name TEXT Migrations gotcha v1 v5

); + first_name TEXT, + last_name TEXT TableMigration .of(Tables.USERS) .to(CREATE_TABLE_USERS) .build(); Migrations gotcha v1 v5

); - email TEXT + email TEXT NOT NULL + first_name TEXT, + last_name TEXT TableMigration .of(Tables.USERS) .to(CREATE_TABLE_USERS) .build(); Migrations gotcha v1 v5 v9

); - email TEXT + email TEXT NOT NULL + first_name TEXT, + last_name TEXT TableMigration .of(Tables.USERS) .to(CREATE_TABLE_USERS) .build(); db.execSQL( ”DELETE FROM users” + ”WHERE email IS NULL” ); TableMigration .of(Tables.USERS) .to(CREATE_TABLE_USERS) .build(); Migrations gotcha v1 v5 v9

); - email TEXT + email TEXT NOT NULL + first_name TEXT, + last_name TEXT TableMigration .of(Tables.USERS) .to(CREATE_TABLE_USERS) .build(); db.execSQL( ”DELETE FROM users” + ”WHERE email IS NULL” ); TableMigration .of(Tables.USERS) .to(CREATE_TABLE_USERS) .build(); Migrations gotcha v1 v5 v9 HAVE TO USE v5 SCHEMA

MIGRATIONS == OLD SCHEMAS

MINI QUIZ TIME! How would you keep old db schemas?

CREATE_TABLE_X_r1500

CREATE_TABLE_X_r1500 NO DIFFS

CREATE_TABLE_X_r1500 List of upgrades NO DIFFS

CREATE_TABLE_X_r1500 List of upgrades NO CURRENT SCHEMA NO DIFFS

CREATE_TABLE_X_r1500 List of upgrades Current schema with list of downgrades NO CURRENT SCHEMA NO DIFFS

CREATE_TABLE_X_r1500 List of upgrades Current schema with list of downgrades NO DIFFS NO CURRENT SCHEMA UNINTUITIVE

Sane(ish?) schema API private static final Schemas SCHEMA = Schemas.Builder
.currentSchema(10, new TableDefinition(Tables.ADDRESSES, new AddColumn(Addresses.REGION, "TEXT"), new AddColumn(Addresses.ZIP, "TEXT"), new AddColumn(Addresses.COUNTRY, "TEXT"), new AddColumn(Addresses.CITY, "TEXT"), new AddColumn(Addresses.STREET, "TEXT ") ) ) .upgradeTo(7, clear(Tables.ADDRESSES)) .downgradeTo(4, new TableDowngrade(Tables.ADDRESSES, new DropColumn(Addresses.REGION) ) ) .downgradeTo(2, dropTable(Tables.ADDRESSES)) .build();  futuresimple/android-schema-utils

Look ma, no boilerplate! @Override public void onCreate(SQLiteDatabase db) {
Schema currentSchema = SCHEMAS.getCurrentSchema(); for (String table : currentSchema.getTables()) { db.execSQL(currentSchema.getCreateTableStatement(table)); } } public void onUpgrade(final SQLiteDatabase db, int oldVersion, int newVersion) { SCHEMAS.upgrade(oldVersion, mContext, db); }  futuresimple/android-schema-utils

UI + Services ContentProvider Database MIGRATIONS BOILERPLATE

Obvious index is obvious db.execSQL("CREATE TABLE " + Tables.RAW_CONTACTS +
" (" + // ... RawContacts.CONTACT_ID + " INTEGER REFERENCES contacts(_id)," + // ... ");"); db.execSQL("CREATE INDEX raw_contacts_contact_id_index ON " + Tables.RAW_CONTACTS + " (" + RawContacts.CONTACT_ID + ");");

“This would be easy if we knew the relations between
our models...”

Thneed public static final ModelGraph<ModelInterface> MODEL_GRAPH = ModelGraph .of(ModelInterface.class) .identifiedByDefault().by(ModelColumns.ID)
.where() .the(CONTACT).references(USER).by(Contacts.USER_ID) .the(CONTACT).groupsOther().by(Contacts.CONTACT_ID) .the(DEAL).references(CONTACT).by(Deals.CONTACT_ID) .the(DEAL).references(USER).by(Deals.USER_ID)  chalup/thneed

Thneed public static final ModelGraph<ModelInterface> MODEL_GRAPH = ModelGraph .of(ModelInterface.class) .identifiedByDefault().by(ModelColumns.ID)
.where() .the(CONTACT).references(USER).by(Contacts.USER_ID) .the(CONTACT).groupsOther().by(Contacts.CONTACT_ID) .the(DEAL).references(CONTACT).by(Deals.CONTACT_ID) .the(DEAL).references(USER).by(Deals.USER_ID) public class ModelGraph<TModel> { public void accept(ModelVisitor<? super TModel> visitor); public void accept(RelationshipVisitor<? super TModel> visitor); }  chalup/thneed

 futuresimple/android-autoindexer public class AutoIndexer { public static Collection<SqliteIndex> generateIndexes(ModelGraph<~>
graph); public static String getCreateStatement(SqliteIndex index); } AutoIndexer

 futuresimple/android-autoindexer public class AutoIndexer { public static Collection<SqliteIndex> generateIndexes(ModelGraph<~>
graph); public static String getCreateStatement(SqliteIndex index); } private static void createIndexes(SQLiteDatabase db) { FluentIterable<SqliteIndex> indexes = FluentIterable .from(AutoIndexer.generateIndexes(MODEL_GRAPH)) .filter(Predicates.not(AutoIndexer.isIndexOnColumn(ModelColumns.ID))) .filter(Predicates.not(AutoIndexer.isIndexOnColumn(BaseColumns._ID))); for (SqliteIndex index : indexes) { db.execSQL(AutoIndexer.getCreateStatement(index)); } } AutoIndexer

MINI QUIZ TIME! What are the issues related to schema
generation?

Autogenerate? Autodestruct. sqlite> select * from sqlite_master limit 10; type
name tbl_name rootpage sql ---------- ---------------- ---------------- ---------- ------------------------------------------- table android_metadata android_metadata 3 CREATE TABLE android_metadata (locale TEXT) table stages stages 4 CREATE TABLE stages (_id INTEGER PRIMARY KE index sqlite_autoindex stages 5 table sqlite_sequence sqlite_sequence 6 CREATE TABLE sqlite_sequence(name,seq) table sources sources 7 CREATE TABLE sources (id INTEGER PRIMARY KE table contacts contacts 8 CREATE TABLE contacts (_id INTEGER PRIMARY index sqlite_autoindex contacts 9 table deals deals 10 CREATE TABLE deals (_id INTEGER PRIMARY KEY index sqlite_autoindex deals 11 table notes notes 12 CREATE TABLE notes (_id INTEGER PRIMARY KEY

Autogenerate? Autodestruct. SQLiteMaster.dropIndexes(db); SQLiteMaster.dropTriggers(db); SQLiteMaster.dropViews(db); List<SQLiteSchemaPart> parts = SQLiteMaster.getSQLiteSchemaParts(db); sqlite>
select * from sqlite_master limit 10; type name tbl_name rootpage sql ---------- ---------------- ---------------- ---------- ------------------------------------------- table android_metadata android_metadata 3 CREATE TABLE android_metadata (locale TEXT) table stages stages 4 CREATE TABLE stages (_id INTEGER PRIMARY KE index sqlite_autoindex stages 5 table sqlite_sequence sqlite_sequence 6 CREATE TABLE sqlite_sequence(name,seq) table sources sources 7 CREATE TABLE sources (id INTEGER PRIMARY KE table contacts contacts 8 CREATE TABLE contacts (_id INTEGER PRIMARY index sqlite_autoindex contacts 9 table deals deals 10 CREATE TABLE deals (_id INTEGER PRIMARY KEY index sqlite_autoindex deals 11 table notes notes 12 CREATE TABLE notes (_id INTEGER PRIMARY KEY  futuresimple/sqlitemaster

 futuresimple/sqlitemaster Autogenerate? Autodestruct. SQLiteMaster.dropIndexes(db); SQLiteMaster.dropTriggers(db); SQLiteMaster.dropViews(db); List<SQLiteSchemaPart> parts =
SQLiteMaster.getSQLiteSchemaParts(db); sqlite> select * from sqlite_master limit 10; type name tbl_name rootpage sql ---------- ---------------- ---------------- ---------- ------------------------------------------- table android_metadata android_metadata 3 CREATE TABLE android_metadata (locale TEXT) table stages stages 4 CREATE TABLE stages (_id INTEGER PRIMARY KE index sqlite_autoindex stages 5 table sqlite_sequence sqlite_sequence 6 CREATE TABLE sqlite_sequence(name,seq) table sources sources 7 CREATE TABLE sources (id INTEGER PRIMARY KE table contacts contacts 8 CREATE TABLE contacts (_id INTEGER PRIMARY index sqlite_autoindex contacts 9 table deals deals 10 CREATE TABLE deals (_id INTEGER PRIMARY KEY index sqlite_autoindex deals 11 table notes notes 12 CREATE TABLE notes (_id INTEGER PRIMARY KEY

Forger<ModelInterface> forger; Upload upload = forger .iNeed(Upload.class) .with(Uploads.IS_CACHED, true) .in(mContentResolver);
Byproduct: Forger  futuresimple/forger

Attachment attachment = forger .iNeed(Attachment.class) .relatedTo(upload) .in(mContentResolver); Byproduct: Forger  futuresimple/forger

Forger<ModelInterface> forger; Attachment attachment = forger .iNeed(Attachment.class) // .relatedTo(upload) .in(mContentResolver);
Byproduct: Forger  futuresimple/forger

Attachment attachment = forger .iNeed(Attachment.class) .relatedTo(upload) .in(mContentResolver); Byproduct: Forger  futuresimple/forger

Forger<ModelInterface> forger = FORGER .inContextOf(User.class).in(mContentResolver); Upload upload = forger .iNeed(Upload.class)
.with(Uploads.IS_CACHED, true) .in(mContentResolver); Attachment attachment = forger .iNeed(Attachment.class) .relatedTo(upload) .in(mContentResolver); Byproduct: Forger  futuresimple/forger

 futuresimple/forger @Test public void shouldNotifyAboutReadyShareRequest() throws Exception { FORGER
.inContextOf(User.class).in(mContentResolver) .inContextOf(Contact.class).in(mContentResolver) .inContextOf(Upload.class).in(mContentResolver) .inContextOf(Attachment.class).in(mContentResolver) .inContextOf(ShareDocumentRequest.class).in(mContentResolver) .iNeed(ShareDocumentList.class).in(mContentResolver); testSubject.notifyReadyShareRequests(); verify(mNotificationManager).notify(anyInt(), any(Notification.class)); } Byproduct: Forger

UI + Services ContentProvider Database BOILERPLATE

Work in progress! AutoProvider Uri matching/building, CRUD basic implementation... ...or
something completely replacing ContentProvider

Work in progress! AutoProvider TableJoiner Uri matching/building, CRUD basic implementation...
...or something completely replacing ContentProvider The SQLite helper to end all SQLite helpers!

Work in progress! AutoProvider TableJoiner Cerberus Uri matching/building, CRUD basic
implementation... ...or something completely replacing ContentProvider The SQLite helper to end all SQLite helpers! Attaches itself to database and executes EXPLAIN QUERY PLAN for each query.

Thanks.
