Kubernetes Library with client-go

Kubernetes Library with client-go

SDN x Cloud Native Meetup #6

https://github.com/chenyunchen/K8S-Meetup

Yun Chen

July 14, 2018
Tweet

More Decks by Yun Chen

Other Decks in Programming

Transcript

  1. WHO AM I Chen Yun Chen (Alex) > [email protected] >

    blog.yunchen.tw Experience > Software Engineer at Linker Networks
  2. api : Resources Object apimachinery : Options Object > k8s.io/kubernetes

    > k8s.io/client-go > k8s.io/apiserver https://github.com/kubernetes 5
  3. API/CORE/V1/TYPES.GO HTTPS://GITHUB.COM/KUBERNETES/API/BLOB/MASTER/CORE/V1/TYPES.GO type Volume struct {} type PersistentVolume struct {}

    type PersistentVolumeClaim struct {} type Container struct {} type Pod struct {} type Service struct {} type Node struct {} type Namespace struct {} type ConfigMap struct {} ... 6
  4. APIMACHINERY/PKG/APIS/META/V1/META.GO HTTPS://GITHUB.COM/KUBERNETES/APIMACHINERY/BLOB/MASTER/PKG/APIS/META/ V1/META.GO type Object interface { GetNamespace() string SetNamespace(namespace

    string) GetName() string SetName(name string) GetGenerateName() string SetGenerateName(name string) GetUID() types.UID SetUID(uid types.UID) GetLabels() map[string]string SetLabels(labels map[string]string) ... } 8
  5. 9

  6. CLIENTSET type Clientset struct { *discovery.DiscoveryClient admissionregistrationV1alpha1 *admissionregistrationv1alpha1.AdmissionregistrationV1alpha1Client appsV1 *appsv1.AppsV1Client

    authenticationV1 *authenticationv1.AuthenticationV1Client autoscalingV2beta1 *autoscalingv2beta1.AutoscalingV2beta1Client batchV1 *batchv1.BatchV1Client batchV1beta1 *batchv1beta1.BatchV1beta1Client certificatesV1beta1 *certificatesv1beta1.CertificatesV1beta1Client coreV1 *corev1.CoreV1Client eventsV1beta1 *eventsv1beta1.EventsV1beta1Client extensionsV1beta1 *extensionsv1beta1.ExtensionsV1beta1Client networkingV1 *networkingv1.NetworkingV1Client policyV1beta1 *policyv1beta1.PolicyV1beta1Client schedulingV1alpha1 *schedulingv1alpha1.SchedulingV1alpha1Client settingsV1alpha1 *settingsv1alpha1.SettingsV1alpha1Client storageV1 *storagev1.StorageV1Client ... } 11
  7. 12

  8. 13

  9. CLIENTS ℂK8S褸ᗭक़㬵ᓕቘ import ( "os" "path/filepath" "k8s.io/client-go/kubernetes" "k8s.io/client-go/tools/clientcmd" ) ...

    // Windows: c:\Users\$UserName os.Getenv("USERPROFILE") // Linux: /Users/UserName/ os.Getenv("HOME") // ፗ矑ֵአkubectlጱconfig(/.kube/config)㬵叨ኞclientsets kubeconfig := filepath.Join(os.Getenv("HOME"), ".kube", "config") k8s, err := clientcmd.BuildConfigFromFlags("", kubeconfig) clientset, err := kubernetes.NewForConfig(k8s) 14
  10. CLIENTS ℂK8S褸ᗭ獉㬵ᓕቘ import ( "k8s.io/client-go/rest" "k8s.io/client-go/kubernetes" ) ... k8s, err

    := rest.InClusterConfig() clientset, err := kubernetes.NewForConfig(k8s) "SYSTEM:serviceaccount:DEFAULT:DEFAULT" CANNOT GET AT THE CLUSTER SCOPE. 15
  11. IF ℂ褸ᗭ獉 : CLUSTERROLE 襑Ԫضਧ嬝ᥝߺ犚虻რጱ稗褖 kind: ClusterRole apiVersion: rbac.authorization.k8s.io/v1 metadata:

    namespace: default name: resources-editor rules: - apiGroups: ["extensions", "apps"] resources: ["deployments", "replicasets", "pods", "services", "endpoints", "jobs", "nodes"] verbs: ["get", "list", "watch", "create", "update", "patch", "delete"] 16
  12. IF ℂ褸ᗭ獉 : CLUSTERROLEBINDING 疥ਧ嬝অጱ稗褖搝ԨᛗServiceAccount kind: ClusterRoleBinding apiVersion: rbac.authorization.k8s.io/v1 metadata:

    name: editor-resources namespace: default subjects: - kind: ServiceAccount name: default namespace: default roleRef: kind: ClusterRole name: resources-editor apiGroup: rbac.authorization.k8s.io 17
  13. DISCOVERY import ( "fmt" ) ... version, _ := clientset.Discovery().ServerVersion()

    fmt.Println(version) // v1.11.0 apiList, _ := clientset.Discovery().ServerGroups() for _, api := range apiList.Groups { fmt.Printf("%s : %s \n", api.Name, api.Versions[0].Version) } // scheduling.k8s.io : v1beta1 // storage.k8s.io : v1 // networking.k8s.io : v1 resourceList, _ := clientset.Discovery().ServerResources() for _, r := range resourceList { fmt.Printf("%s : %s \n", r.GroupVersion, r.APIResources[0].Name) } // apps/v1 : controllerrevisions // batch/v1 : jobs // networking.k8s.io/v1 : networkpolicies 18
  14. GET(NAME, *V1.GETOPTIONS) kubectl get pod podname import ( metav1 "k8s.io/apimachinery/pkg/apis/meta/v1"

    ) ... clientset.CoreV1().Pods("namespace").Get("name", metav1.GetOptions{}) // GetOptions is the standard query options to the standard REST get call. type GetOptions struct { // When specified: // - if unset, then the result is returned from remote storage based on quorum-read flag; // - if it's 0, then we simply return what we currently have in cache, no guarantee; // - if set to non zero, then the result is at least as fresh as given rv. ResourceVersion string `json:"resourceVersion,omitempty" protobuf:"bytes,1,opt,name=resourceVersion"` } 19
  15. CREATE(RESOURCE *V1.RESOURCE) import ( corev1 "k8s.io/api/core/v1" metav1 "k8s.io/apimachinery/pkg/apis/meta/v1" ) ...

    containers := []corev1.Container{ { Name: "busybox", Image: "busybox", Command: []string{"sleep", "3600k"}, }, } pod := corev1.Pod{ ObjectMeta: metav1.ObjectMeta{ Name: "name", }, Spec: corev1.PodSpec{ Containers: containers, }, } clientset.CoreV1().Pods("namespace").Create(&pod) 20
  16. LIST(*V1.LISTOPTIONS) kubectl get pods import ( corev1 "k8s.io/api/core/v1" metav1 "k8s.io/apimachinery/pkg/apis/meta/v1"

    ) ... pods := []*corev1.Pod{} podsList, err := clientset.CoreV1().Pods("namespace").List(metav1.ListOptions{}) //podsList.Items: []Pod{} for _, p := range podsList.Items { pods = append(pods, &p) } // ListOptions is the query options to a standard REST list call. type ListOptions struct { // When specified for list: // - if unset, then the result is returned from remote storage based on quorum-read flag; // - if it's 0, then we simply return what we currently have in cache, no guarantee; // - if set to non zero, then the result is at least as fresh as given rv. // +optional ResourceVersion string `json:"resourceVersion,omitempty" protobuf:"bytes,4,opt,name=resourceVersion"` } 21
  17. WATCH(*V1.LISTOPTIONS) kubectl get pods --watch import ( metav1 "k8s.io/apimachinery/pkg/apis/meta/v1" )

    ... clientset.CoreV1().Pods("namespace").Watch(metav1.ListOptions{ResourceVersion: "0"}) // ListOptions is the query options to a standard REST list call. type ListOptions struct { // When specified for list: // - if unset, then the result is returned from remote storage based on quorum-read flag; // - if it's 0, then we simply return what we currently have in cache, no guarantee; // - if set to non zero, then the result is at least as fresh as given rv. // +optional ResourceVersion string `json:"resourceVersion,omitempty" protobuf:"bytes,4,opt,name=resourceVersion"` } 22
  18. UPDATE(*V1.RESOURCE) UPDATESTATUS(*V1.RESOURCE) import ( "fmt" corev1 "k8s.io/api/core/v1" "k8s.io/apimachinery/pkg/api/errors" ) ...

    pod := corev1.Pod{} for { _, err := clientset.CoreV1().Pods("namespace").Update(&pod) if errors.IsConflict(err) { fmt.Println("encountered conflict, retrying") } else if err != nil { panic(err) } else { break } } 23
  19. PATCH(NAME, TYPES.PATCHTYPE, []BYTE) import ( corev1 "k8s.io/api/core/v1" ) ... pod

    := corev1.Pod{} patchBytes, err := json.Marshal(pod) clientset.CoreV1().Pods("namespace").Patch("name", types.JSONPatchType, patchBytes) // Similarly to above, these are constants to support HTTP PATCH utilized by // both the client and server that didn't make sense for a whole package to be // dedicated to. type PatchType string const ( JSONPatchType PatchType = "application/json-patch+json" MergePatchType PatchType = "application/merge-patch+json" StrategicMergePatchType PatchType = "application/strategic-merge-patch+json" ) 24
  20. DELETE(NAME, *V1.DELETEOPTIONS) kubectl delete pod podname import ( metav1 "k8s.io/apimachinery/pkg/apis/meta/v1"

    ) ... clientset.CoreV1().Pods("namespace").Delete("name", metav1.DeleteOptions{}) // DeleteOptions may be provided when deleting an API object. type DeleteOptions struct { // Must be fulfilled before a deletion is carried out. If not possible, a 409 Conflict status will be // returned. // +optional Preconditions *Preconditions `json:"preconditions,omitempty" protobuf:"bytes,2,opt,name=preconditions"` // Should the dependent objects be orphaned. If true/false, the "orphan" // finalizer will be added to/removed from the object's finalizers list. // Either this field or PropagationPolicy may be set, but not both. // +optional OrphanDependents *bool `json:"orphanDependents,omitempty" protobuf:"varint,3,opt,name=orphanDependents"` PropagationPolicy *DeletionPropagation `json:"propagationPolicy,omitempty" protobuf:"varint,4,opt,name=propagationPolicy"` } 25
  21. *V1.DELETEOPTIONS.PROPAGATIONPOLICY // Orphans the dependents. DeletePropagationOrphan DeletionPropagation = "Orphan" //

    Deletes the object from the key-value store, the garbage collector will // delete the dependents in the background. DeletePropagationBackground DeletionPropagation = "Background" // The object exists in the key-value store until the garbage collector // deletes all the dependents whose ownerReference.blockOwnerDeletion=true // from the key-value store. API sever will put the "foregroundDeletion" // finalizer on the object, and sets its deletionTimestamp. This policy is // cascading, i.e., the dependents will be deleted with Foreground. DeletePropagationForeground DeletionPropagation = "Foreground" 26
  22. (MORE:)GORILLA/MUX import ( "net/http" "log" "github.com/gorilla/mux" ) ... func CreateDeploymentHandler(w

    http.ResponseWriter, r *http.Request) { //Do something here w.Write([]byte("Success!\n")) } func UpdateDeploymentHandler(w http.ResponseWriter, r *http.Request) { //Do something here w.Write([]byte("Success!\n")) } func DeleteDeploymentHandler(w http.ResponseWriter, r *http.Request) { //Do something here w.Write([]byte("Success!\n")) } func main() { r := mux.NewRouter() r.HandleFunc("/deployment/create", CreateDeploymentHandler).Methods("POST") r.HandleFunc("/deployment/update", UpdateDeploymentHandler).Methods("PUT") r.HandleFunc("/deployment/delete", DeleteDeploymentHandler).Methods("Delete") log.Fatal(http.ListenAndServe(":8000", r)) } 28
  23. TESTING: FAKE CLIENTSET import ( corev1 "k8s.io/api/core/v1" metav1 "k8s.io/apimachinery/pkg/apis/meta/v1" "k8s.io/client-go/kubernetes/fake"

    ) ... namespace := "default" pod := corev1.Pod{ ObjectMeta: metav1.ObjectMeta{ Name: "K8S-Pod-1", }, } fakeClientset := fake.NewSimpleClientset() _, err := fakeClientset.CoreV1().Pods(namespace).Create(&pod) result, err := suite.kubectl.GetPod("K8S-Pod-1") 29
  24. KUBERNETES.INTERFACE import ( "k8s.io/client-go/kubernetes" ) ... func CreatePod(clientset kubernetes.Interface, namespace

    string, pod *corev1.Pod) (*corev1.Pod, error) { return clientset.CoreV1().Pods(namespace).Create(pod) } func GetPod(clientset kubernetes.Interface, namespace string, podName string) (*corev1.Pod, error) { return clientset.CoreV1().Pods(namespace).Get(podName, metav1.GetOptions{}) } func DeletePod(clientset kubernetes.Interface, namespace string, podName string) (*corev1.Pod, error) { return clientset.CoreV1().Pods(namespace).Delete(podName, &metav1.GetOptions{}) } 30
  25. CLIENTS COMPONENT TYPE > Clientset return struct{} client-go/kubernetes > Dynamic

    Client return map[string]interface{} client-go/dynamic 32
  26. DYNAMIC CLIENT import ( metav1 "k8s.io/apimachinery/pkg/apis/meta/v1" schema "k8s.io/apimachinery/pkg/runtime/schema" ) ...

    resource := schema.GroupVersionResource{Group: "", Version: "v1", Resource: "pods"} dynamicClient.Resource(resource, "namespace").List(metav1.ListOptions{}) 33
  27. CLIENTS COMPONENT TYPE > Clientset return struct{} client-go/kubernetes > Dynamic

    Client return map[string]interface{} client-go/dynamic > Rest Client return struct or byte[] client-go/rest 34
  28. REST CLIENT import ( corev1 "k8s.io/api/core/v1" ) ... var pod

    corev1.Pod kubeconfig := filepath.Join(os.Getenv("HOME"), ".kube", "config") k8s, err := clientcmd.BuildConfigFromFlags("", kubeconfig) restclient, err := rest.RESTClientFor(k8s) restClient.Get().Resource("pods").Namespace("namespace").DO().Into(&pod) restClient.Get().Resource("pods").Namespace("namespace").DORaw() // byte[] 35
  29. 36

  30. RATE LIMITTING QUEUE import ( "k8s.io/client-go/util/workqueue" ) ... queue :=

    workqueue.NewRateLimitingQueue(workqueue.DefaultControllerRateLimiter()) defer queue.ShutDown() func NewItemExponentialFailureRateLimiter(baseDelay time.Duration, maxDelay time.Duration) RateLimiter { return &ItemExponentialFailureRateLimiter{ failures: map[interface{}]int{}, baseDelay: baseDelay, maxDelay: maxDelay, } } func DefaultItemBasedRateLimiter() RateLimiter { return NewItemExponentialFailureRateLimiter(time.Millisecond, 1000*time.Second) } 38
  31. INFORMER import ( "k8s.io/apimachinery/pkg/fields" "k8s.io/client-go/tools/cache" corev1 "k8s.io/api/core/v1" ) ... podListWatcher

    := cache.NewListWatchFromClient(clientset.CoreV1().RESTClient(), "pods", "default", fields.Everything()) indexer, informer := cache.NewIndexerInformer(podListWatcher, &corev1.Pod{}, 0, cache.ResourceEventHandlerFuncs{ AddFunc: func(obj interface{}) { key, err := cache.MetaNamespaceKeyFunc(obj) if err == nil { queue.Add(key) } }, UpdateFunc: func(old interface{}, new interface{}) { key, err := cache.MetaNamespaceKeyFunc(new) if err == nil { queue.Add(key) } }, DeleteFunc: func(obj interface{}) { // IndexerInformer uses a delta queue, therefore for deletes we have to use this // key function. key, err := cache.DeletionHandlingMetaNamespaceKeyFunc(obj) if err == nil { queue.Add(key) } }, }, cache.Indexers{}) stop := make(chan struct{}) defer close(stop) go informer.Run(stop) <-stop 40
  32. WORKER import ( "fmt" "k8s.io/client-go/tools/cache" "k8s.io/apimachinery/pkg/util/wait" ) ... if !cache.WaitForCacheSync(stopCh,

    informer.HasSynced) { return } go wait.Until(runWorker, time.Second, stop) func runWorker { for { key, quit := c.queue.Get() if quit { break } } defer queue.Done(key) obj, exists, _ := indexer.GetByKey(key) if exists { fmt.Printf("Sync/Add/Update for Pod %s\n", obj.(*v1.Pod).GetName()) } } } 41
