Going edge-to-edge with Gesture Navigation

To aid developers to create immersive experiences, Android Q adds new system navigation models to allow apps to take over more of the user’s screen.

This talk will look at how apps should work with the new gesture navigation, and ways to mitigate gesture conflicts. We’ll look at how to update apps to go edge-to-edge, drawing behind the system bars to create a immersive experience for users. Finally we’ll go through ways to make the WindowInsets APIs easier to use.

Transcript

1. Going edge-to-edge Gesture Navigation
2. Chris Banes @chrisbanes @rohanscloud Rohan Shah
4. Which nav will Android use in the future? 3-button mode is required for Android devices Gestural nav may be offered as a polished, immersive experience, and can additionally be offered out-of-box
5. Why is this so important for apps? Gaining an edge on user experience given market desire for beautiful UI Handling conflicts with gestures for optimal UX
6. Making your app nav-ready 1. Make your UI edge-to-edge 2. Leverage insets for better UI 3. Override system gestures
7. What is
 edge-to-edge?
8. 10:00
9. App bounds 10:00
12. 10:00
13. 10:00
14. 10:00 Drawing behind the navigation bar Strongly recommended on Q Optional before Q
15. 10:00
16. 10:00
17. 10:00 Drawing behind the status bar Recommended on Q Optional before Q
18. 10:00
19. 10:00
20. Going edge-to-edge
21. System will help From Q onwards, the system is responsible for protecting system buttons/handles
22. System will help From Q onwards, the system is responsible for protecting system buttons/handles
23. System will help From Q onwards, the system is responsible for protecting system buttons/handles Protection can be in the form of dynamic color adaptation
24. System will help From Q onwards, the system is responsible for protecting system buttons/handles Or the system can draw a translucent scrim Shown in button mode when targetSdkVersion >= 29
25. Going immersive Avoid overlaps with system UI Request to be laid out fullscreen Change system bar colors 1 2 3
26. <style name="Theme.MyApp" parent="..."> <item name="android:navigationBarColor"> @android:color/transparent </item> </style> values-v29/themes.xml Change system bar colors 1
27. <style name="Theme.MyApp" parent="..."> <!-- 70% white --> <item name="android:navigationBarColor"> #B3FFFFFF </item> </style> values/themes.xml Change system bar colors 1
28. <style name="Theme.MyApp" parent="..."> <!-- 70% black --> <item name="android:navigationBarColor"> #B3000000 </item> </style> values-night/themes.xml Change system bar colors 1
29. view.systemUiVisibility = // Tells the system that you wish to be laid out // as if the navigation bar was hidden View.SYSTEM_UI_FLAG_LAYOUT_HIDE_NAVIGATION or // Tells the system that you wish to be laid out at // the most extreme scenario of any other flags View.SYSTEM_UI_FLAG_LAYOUT_STABLE Request to be laid out fullscreen 2
30. view.systemUiVisibility = // Tells the system that you wish to be laid out // as if the navigation bar was hidden View.SYSTEM_UI_FLAG_LAYOUT_HIDE_NAVIGATION or // Optional, if we want you be laid out fullscreen, // behind the status bar View.SYSTEM_UI_FLAG_LAYOUT_FULLSCREEN or // Tells the system that you wish to be laid out at // the most extreme scenario of any other flags View.SYSTEM_UI_FLAG_LAYOUT_STABLE Request to be laid out fullscreen 2
31. Insets
32. What are insets? A collection of values which tell you how much to inset (move) content in by Which content to move, depends on the inset type and its purpose
33. I N S E T S System window Tells you where the system- ui is being displayed over your app Use to move clickable views away from edges
34. I N S E T S System window Tells you where the system- ui is being displayed over your app Use to move clickable views away from edges
35. System window I N S E T S Tells you where the system- ui is being displayed over your app Use to move clickable views away from edges
36. System window I N S E T S Tells you where the system- ui is being displayed over your app Use to move clickable views away from edges
37. System gesture Represents the areas of the window where system gestures take priority Includes the vertical edges for swiping back, and bottom edge for home Use to move draggable views away from edges New in Q I N S E T S
38. System gesture New in Q I N S E T S Represents the areas of the window where system gestures take priority Includes the vertical edges for swiping back, and bottom edge for home Use to move draggable views away from edges
39. System gesture New in Q I N S E T S Represents the areas of the window where system gestures take priority Includes the vertical edges for swiping back, and bottom edge for home Use to move draggable views away from edges
40. System gesture New in Q I N S E T S Represents the areas of the window where system gestures take priority Includes the vertical edges for swiping back, and bottom edge for home Use to move draggable views away from edges
41. System gesture New in Q I N S E T S Represents the areas of the window where system gestures take priority Includes the vertical edges for swiping back, and bottom edge for home Use to move draggable views away from edges
42. Mandatory
 system gesture Subset of system gesture insets Defines areas which cannot be overridden by apps In Q, currently only used by the home gesture zone I N S E T S New in Q
43. System window insets Use to move clickable views away from edges System gesture insets Use to move draggable views away from edges Mandatory system gesture insets Use to check what gesture areas can not be excluded
44. So how do I actually handle insets? WindowInsets
45. ViewCompat.setOnApplyWindowInsetsListener(view) { v, insets -> // Do something with the insets // return the insets insets } Tip: always use the ViewCompat method
46. getSystemWindowInsets(): Insets getSystemGestureInsets(): Insets getMandatorySystemGestureInsets(): Insets getStableInsets(): Insets WindowInsetsCompat
47. getSystemWindowInsets(): Insets getSystemGestureInsets(): Insets getMandatorySystemGestureInsets(): Insets getStableInsets(): Insets WindowInsetsCompat data class Insets( left: Int, top: Int, right: Int, bottom: Int )
49. <style name="Theme.MyApp" parent="..."> <item name="android:navigationBarColor"> @android:color/transparent </item> </style> values-v29/themes.xml
50. <style name="Theme.MyApp" parent="..."> <item name="android:navigationBarColor"> @android:color/transparent </item> </style> values-v29/themes.xml
51. view.systemUiVisibility = SYSTEM_UI_FLAG_LAYOUT_HIDE_NAVIGATION or SYSTEM_UI_FLAG_LAYOUT_STABLE
52. view.systemUiVisibility = SYSTEM_UI_FLAG_LAYOUT_HIDE_NAVIGATION or SYSTEM_UI_FLAG_LAYOUT_STABLE
53. view.systemUiVisibility = SYSTEM_UI_FLAG_LAYOUT_HIDE_NAVIGATION or SYSTEM_UI_FLAG_LAYOUT_STABLE
54. VC.setOnApplyWindowInsetsListener(bottomNav) { v, insets -> v.updatePadding( bottom = insets.systemWindowInsets.bottom ) insets }
55. VC.setOnApplyWindowInsetsListener(bottomNav) { v, insets -> v.updatePadding( bottom = insets.systemWindowInsets.bottom ) insets }
56. VC.setOnApplyWindowInsetsListener(bottomNav) { v, insets -> v.updatePadding( bottom = insets.systemWindowInsets.bottom ) insets }
57. VC.setOnApplyWindowInsetsListener(bottomNav) { v, insets -> v.updateLayoutParams<MarginLayoutParams>( bottomMargin = insets.systemWindowInsets.bottom ) insets }
58. VC.setOnApplyWindowInsetsListener(bottomNav) { v, insets -> v.updateLayoutParams<MarginLayoutParams>( bottomMargin = insets.systemWindowInsets.bottom ) insets }
61. <LinearLayout android:padding="32dp">
62. After applying all of the steps...
63. VC.setOnApplyWindowInsetsListener(bottomBar) { v, insets -> v.updatePadding( bottom = insets.systemWindowInsets.bottom ) insets } <LinearLayout android:padding="32dp"> Overwrites
64. VC.setOnApplyWindowInsetsListener(bottomBar) { v, insets -> v.updatePadding( bottom = bottomPad + insets.systemWindowInsets.bottom ) insets } val bottomPad = bottomBar.bottomPadding // 32dp
65. VC.setOnApplyWindowInsetsListener(bottomBar) { v, insets -> v.updatePadding( bottom = bottomPad + insets.systemWindowInsets.bottom ) insets } val bottomPad = bottomBar.bottomPadding
66. data class InitialPadding(
 val left: Int, val top: Int, val right: Int, val bottom: Int
 ) private fun recordInitialPaddingForView(view: View) = ... fun View.doOnApplyWindowInsets(f: (View, WindowInsets, InitialPadding) -> Unit) { // Create a snapshot of the view's padding state val initialPadding = recordInitialPaddingForView(this) // Set an OnApplyWindowInsetsListener which proxies to the given // lambda, passing in the original padding state ViewCompat.setOnApplyWindowInsetsListener(this) { v, insets -> f(v, insets, initialPadding) // Always return the insets, so that children can also use them insets } }
67. data class InitialPadding(
 val left: Int, val top: Int, val right: Int, val bottom: Int
 ) private fun recordInitialPaddingForView(view: View) = ... fun View.doOnApplyWindowInsets(f: (View, WindowInsets, InitialPadding) -> Unit) { // Create a snapshot of the view's padding state val initialPadding = recordInitialPaddingForView(this) // Set an OnApplyWindowInsetsListener which proxies to the given // lambda, passing in the original padding state ViewCompat.setOnApplyWindowInsetsListener(this) { v, insets -> f(v, insets, initialPadding) // Always return the insets, so that children can also use them insets } }
68. val right: Int, val bottom: Int
 ) private fun recordInitialPaddingForView(view: View) = ... fun View.doOnApplyWindowInsets(f: (View, WindowInsets, InitialPadding) -> Unit) { // Create a snapshot of the view's padding state val initialPadding = recordInitialPaddingForView(this) // Set an OnApplyWindowInsetsListener which proxies to the given // lambda, passing in the original padding state ViewCompat.setOnApplyWindowInsetsListener(this) { v, insets -> f(v, insets, initialPadding) // Always return the insets, so that children can also use them insets } }
69. bottomBar.doOnApplyWindowInsets { v, insets, initialPadding -> v.updatePadding( bottom = initialPadding.bottom + insets.systemWindowInsets.bottom ) insets }
70. - Nick Butcher
71. @BindingAdapter( "paddingLeftSystemWindowInsets", "paddingTopSystemWindowInsets", "paddingRightSystemWindowInsets", "paddingBottomSystemWindowInsets", requireAll = false ) fun applySystemWindows( view: View, applyLeft: Boolean, applyTop: Boolean, applyRight: Boolean, applyBottom: Boolean ) { view.doOnApplyWindowInsets { view, insets, padding -> val left = if (applyLeft) insets.systemWindowInsetLeft else val top = if (applyTop) insets.systemWindowInsetTop else 0
72. <androidx.recyclerview.RecyclerView android:clipToPadding="false" app:paddingBottomSystemWindowInsets="@{ true }" /> No more handling insets in code !
74. Overriding gestures
75. What conflicts will apps face? Swiping in from the edges will go back or re-activate system gestures when in immersive mode. Any horizontally-draggable content that relies on gestures in the back zone Examples: sliders, seek bars, drag handles, etc.
76. What conflicts will apps face? Swiping in from the edges will go back or re-activate system gestures when in immersive mode. Any horizontally-draggable content that relies on gestures in the back zone Examples: sliders, seek bars, drag handles, etc.
77. Overriding gestures New API available to you for opting out a small part of the edge for app use Should be used extremely sparingly and tied to a draggable handle or visual affordance New in Q
78. View.setSystemGestureExclusionRects(List<Rect> rects)
79. List<Rect> exclusionRects; public void onLayout(...) { // Update rect bounds and the exclusionRects list setSystemGestureExclusionRects(exclusionRects); } CustomView.java
80. List<Rect> exclusionRects; public void onDraw(Canvas canvas) { // Update rect bounds and the exclusionRects list setSystemGestureExclusionRects(exclusionRects); } CustomView.java
81. Restrictions on overriding gestures Apps can only opt out 200 dp of each edge If apps opt out of more, only the bottom 200 dp will be overridden for the app Requested
82. Restrictions on overriding gestures Apps can only opt out 200 dp of each edge If apps opt out of more, only the bottom 200 dp will be overridden for the app Honored Requested
83. Non-sticky immersive mode Apps can only opt out 200 dp of each edge from bringing in system bars and activating gestures
84. Non-sticky immersive mode Apps can only opt out 200 dp of each edge from bringing in system bars and activating gestures
85. Non-sticky immersive mode Apps can only opt out 200 dp of each edge from bringing in system bars and activating gestures
86. Non-sticky immersive mode Apps can only opt out 200 dp of each edge from bringing in system bars and activating gestures
87. Non-sticky immersive mode Apps can only opt out 200 dp of each edge from bringing in system bars and activating gestures
88. Sticky immersive mode By updating, apps can opt the entire edge out of bringing in system bars and reactivating gestures Once the gestures are active, the system will not respect any Back overrides
89. Sticky immersive mode By updating, apps can opt the entire edge out of bringing in system bars and reactivating gestures Once the gestures are active, the system will not respect any Back overrides
90. Sticky immersive mode By updating, apps can opt the entire edge out of bringing in system bars and reactivating gestures Once the gestures are active, the system will not respect any Back overrides
91. Sticky immersive mode By updating, apps can opt the entire edge out of bringing in system bars and reactivating gestures Once the gestures are active, the system will not respect any Back overrides
92. Sticky immersive mode By updating, apps can opt the entire edge out of bringing in system bars and reactivating gestures Once the gestures are active, the system will not respect any Back overrides
93. Sticky immersive mode By updating, apps can opt the entire edge out of bringing in system bars and reactivating gestures Once the gestures are active, the system will not respect any Back overrides
94. Sticky immersive mode Useful for single-purpose UIs that want to keep the user from accidentally going back Examples: games, drawing apps, etc.
95. Common scenarios
96. Scrolling views Content should be drawn behind the navigation bar When the user scrolls to the end, the content is drawn above the navigation bar S C E N A R I O S
97. Scrolling views Content should be drawn behind the navigation bar When the user scrolls to the end, the content is drawn above the navigation bar S C E N A R I O S
98. Scrolling views Content should be drawn behind the navigation bar When the user scrolls to the end, the content is drawn above the navigation bar S C E N A R I O S
99. Scrolling views Content should be drawn behind the navigation bar When the user scrolls to the end, the content is drawn above the navigation bar S C E N A R I O S
100. Scrolling views Common way to achieve this is through padding We’ll pad our scrolling view using the system window insets S C E N A R I O S
101. recyclerview.setOnApplyWindowInsetsListener { v, insets -> // Set the bottom padding so that the content bottom // is above the nav bar (y-axis) v.updatePadding(bottom = insets.systemWindowInsetBottom) // return the insets insets }
102. <androidx.recyclerview.widget.RecyclerView android:id="@+id/recyclerview" android:layout_width="match_parent" android:layout_height="match_parent" android:clipToPadding="false" /> Enables our items to still be drawn within the parent’s padding
103. Bottom sheets For bottom sheets which collapse, ensure enough content is visible above the navigation bar to be dragged S C E N A R I O S
104. Bottom sheets For bottom sheets which collapse, ensure enough content is visible above the navigation bar to be dragged Use the system gesture insets to increase the peeking content height S C E N A R I O S
105. Bottom sheets For bottom sheets which collapse, ensure enough content is visible above the navigation bar to be dragged Use the system gesture insets to increase the peeking content height S C E N A R I O S
106. // Record the original peek height val origPeekHeight = behavior.peekHeight

 view.setOnApplyWindowInsetsListener { v, insets -> val gestureInsets = insets.getSystemGestureInsets() // Update the peek height so that it is above the navigation bar behavior.peekHeight = gestureInsets.bottom + origPeekHeight // return the insets insets }
107. Bottom sheets Remember, users can always swipe to go home Highlight draggable content to guide user S C E N A R I O S
108. Bottom navigation For bottom tabbed navigation, pad the bottom content in by the system window inset S C E N A R I O S
109. Bottom navigation For bottom tabbed navigation, pad the bottom content in by the system window inset S C E N A R I O S
110. Landscape S C E N A R I O S
111. Landscape S C E N A R I O S If you have content that starts near a vertical edge, think about padding all content in horizontally Make sure to test apps with button navigation too
112. rootView.setOnApplyWindowInsetsListener { v, insets -> // Set the left/right padding so that the content // is above the nav bar (y-axis) v.updatePadding( left = insets.systemWindowInsetLeft, right = insets.systemWindowInsetRight ) // return the insets insets }
113. Landscape S C E N A R I O S
114. Navigation drawers New swipe-when-peeking behavior in Q Beta 5 Works with all versions of DrawerLayout Update to DrawerLayout 1.1.0-alpha02 for best experience S C E N A R I O S
115. Carousels For ViewPagers and horizontal scrolling views, recommend to not exclude edges S C E N A R I O S
116. Carousels For ViewPagers and horizontal scrolling views, recommend to not exclude edges S C E N A R I O S
117. More support coming Raise bugs for difficult patterns issuetracker.google.com
118. TL;DR G E S T U R E N A V I G A T I O N Users will expect apps to work with all navigation modes Create immersive UIs by going edge-to-edge Proactively update Jetpack and MDC libraries for automatic support Only use gesture exclusion APIs if you really need them Let us know about troublesome scenarios in your apps
119. Chris Banes @chrisbanes @rohanscloud Rohan Shah Thanks!
