500 Billion Documents & Counting: Scaling Elasticsearch for Production

First deployed as a proof of concept in mid-2012, Verizon Business moved fully into production with Elasticsearch in mid-2013 and has continued to push forward ever since. Bhaskar will take you through this entire history - including a peek inside the architecture handling over 500 Billion documents - with a look forward at the next year for Verizon and Elasticsearch.

Presented by Bhaskar Karambelkar, Verizon Enterprise Solutions

Transcript

1. Scaling Elasticsearch for Production Scale Data Bhaskar V. Karambelkar Senior Security Data Scientist @ Verizon
2. { } CC-BY-ND 4.0 Introduction • Security Data Scientist / Tech Lead @ Verizon. • Avid Elasticsearch user and advocate since 2012. • Interested in information security and data analytics. 2
3. { } CC-BY-ND 4.0 Why Elasticsearch ? • Logs stayed on disks. • No easy way to fetch/search logs. • Hard to scale. • Untapped potential in log data DRUM ROLLS…… Log Management. 3 Before Elasticsearch Disks RDBMS Logs Events Incidents Tickets
4. { } CC-BY-ND 4.0 Expectations • Must be able to store massive amounts of data. • Must be able to get data in at a very high rate and get data out at an acceptable rate. • Should be schema agnostic. • Must be able to search/filter/analyze data. • Must support MULTI-TENANCY. • Distributed/fault-tolerant/load-balanced/etc. 4
5. { } CC-BY-ND 4.0 Progress 5 Jul  ‘13 Sept  ‘13 Nov’  13 Dec  ‘14 Boxes/Nodes 14/14 28/28 28/56 128/128 Cores/RAM/DISK 12/128GB/ 3TBx12 8/64GB/1TBx6 AVG  DAILY  VOLUME 500  M 1  B. 2.5/3  B 10+  B TOTAL  VOLUME ~  10  B. ~  100  B. ~  200  B >  500  B  &  counting
6. { } CC-BY-ND 4.0 Know your data and platform • Volume / Velocity / Variety / Veracity will affect your choices and their interactions even more so. • Select a proper base config for your nodes. Get the CPU- Cores x RAM x Disk ratio right. • Decide on self hosted vs. cloud hosted. • Prefer JBODs for data disks over RAID, SAN/NAS. • Virtualization vs. bare metal: know the tradeoffs. • SSDs vs. Spinning Disks, (Speed vs. Capacity). 6
7. { } CC-BY-ND 4.0 The Must DO’s • Change Cluster name. • Dedicated Master, Data and Client nodes. • Use Aliases from get go. • Keep all nodes in same subnet. Use unicast discovery. • Have enough memory for JVM heap + FS Cache. • Tune kernel parameters, user/process/file/network limits. • Always CHECK JVM version compatibility. Also, stick to Oracle JVM. • Learn Query DSL and Elasticsearch APIs. 7
8. { } CC-BY-ND 4.0 The Should DO’s • Tune JVM params, but avoid going overboard. • Tune network/connectivity parameters. • Tune recovery parameters. • Configure gateway parameters. • Tune thread pools: Bulk/Index/Search. • Prefer bulk indexing. • Tune caching parameters, especially field data. • In general don’t be afraid to tweak-n-tune till you hit performance sweet spot. • Having a knowledge of text analytics in the team will go a long way. 8
9. { } CC-BY-ND 4.0 The Do NOTs • Avoid running Elasticsearch along with another service on the same box. • Avoid vertical scaling i.e. avoid 2+ nodes per box. • Don’t grow cluster beyond ~150 nodes. Deploy multiple clusters and use Tribe node. • Don’t allow unrestricted/unsupervised querying unless you know the user base. • Never send data for indexing or search queries to Master nodes. 9
10. { } CC-BY-ND 4.0 Compared to Hadoop • In terms of scalability & design Elasticsearch ≠ Hadoop • Not inferior, just different. • Bulkier nodes for Hadoop, leaner for Elasticsearch. • Scale Elasticsearch horizontally, never vertically. • Load characteristics, (CPU/Mem/IO), differ. 10
11. { } CC-BY-ND 4.0 Indexing • Bulk indexing with refresh interval = -1. Send data directly to data nodes. • Set aside more resources for bulk thread pool. • We saw slight performance gain when using raw TCP over HTTP. • Build new index per month/week/day/hour(?) and use aliases. • Number of Indexes x Shards x Replicas not only affects storage but also Memory. 11
12. { } CC-BY-ND 4.0 Indexing cont. • Don’t use a lot of “types” in a single index. • Use mappings/templates for pre-defining field types. • Disable ‘_all’ field unless really needed. Avoid ‘storing’ fields outside of ‘_source’. • Know which fields to NOT index. Decide which analyzer/ token-filter/char-filter works best. 12
13. { } CC-BY-ND 4.0 Searching • Use filters. • Avoid ‘query string’ query. • Know difference between “bool” and ‘and/or/not’ filters. • Know the impact of faceting/aggregations/sorting on field data cache for high cardinality fields like “timestamp”. • For bulk searching use ‘scroll’. • Rely on explain/validate queries for performance tuning. • Search Templates for simplified queries. • Send searches to client nodes. Not to data nodes and never ever to Master nodes. 13
14. { } CC-BY-ND 4.0 Monitoring / Management • For monitoring we prefer Nagios, but Marvel works really well too. • Use automated deployment / configuration management via Chef/Puppet/Salt/Ansible. • Prefer to share a single config file for all node types. • We retain raw data in HDFS for a year in case of data loss / re- indexing required. Data in Elasticsearch retained for max 90 days. • Know when to use rolling upgrades vs full upgrades. 14
15. { } Thank You Questions / Comments T : @bhaskar_vk , LI : bhaskarvk
