Building container images on your cluster with Knative Build
Talk from KubeCon US 2018 in Seattle all about using Knative Build to run your build process on your Kubernetes cluster. Explains the usecase, the state of the project and speculates about the future.
Gareth Rushgrove
December 12, 2018
Transcript
45 slides
-
This talk - Why build on your cluster? - The
power of Custom Resources - Knative Build - Higher-level interfaces - The future What will we cover in this session -
CI systems are production too A compromise of your build
infrastructure is BAD -
Why maintain separate build machines? Less variation makes for lower
operations overhead -
Build is a scheduling problem And Kubernetes is a pretty
handy scheduler -
The importance of extensions - Features that not everyone needs
can still run on Kubernetes - Not everything needs to be in the core API - Adoption of extensions will help Kubernetes stand the test of time Solving specific problems as well as general ones -
Knative Build is a CRD which adds primitives to Kubernetes
for modelling the software build process -
Installing Knative Build $ kubectl apply -f https://storage.googleapis.com/knative-releases/build/latest/release.yaml namespace "knative-build"
created clusterrole.rbac.authorization.k8s.io "knative-build-admin" created serviceaccount "build-controller" created clusterrolebinding.rbac.authorization.k8s.io "build-controller-admin" created customresourcedefinition.apiextensions.k8s.io "builds.build.knative.dev" created customresourcedefinition.apiextensions.k8s.io "buildtemplates.build.knative.dev" created customresourcedefinition.apiextensions.k8s.io "clusterbuildtemplates.build.knative.dev" created customresourcedefinition.apiextensions.k8s.io "images.caching.internal.knative.dev" created service "build-controller" created service "build-webhook" created configmap "config-logging" created deployment.apps "build-controller" created deployment.apps "build-webhook" created -
What did we just install? $ kubectl get pods --namespace
knative-build NAME READY STATUS RESTARTS AGE pod/build-controller-5bf486fb95-dm446 1/1 Running 0 2m pod/build-webhook-7b8f64b77c-k7k5j 1/1 Running 0 2m NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE service/build-controller ClusterIP 10.96.253.190 <none> 9090/TCP 2m service/build-webhook ClusterIP 10.105.50.131 <none> 443/TCP 2m NAME DESIRED CURRENT UP-TO-DATE AVAILABLE AGE deployment.apps/build-controller 1 1 1 1 2m deployment.apps/build-webhook 1 1 1 1 2m NAME DESIRED CURRENT READY AGE replicaset.apps/build-controller-5bf486fb95 1 1 1 2m replicaset.apps/build-webhook-7b8f64b77c 1 1 1 2m -
What makes up Knative Build - A Build can include
multiple steps where each step specifies a Builder. - A Builder is a type of container image that you create to accomplish any task, whether that's a single step in a process, or the whole process itself. - A BuildTemplate can be used to defined reusable templates. - Authenticate with ServiceAccount using Kubernetes Secrets. What are the new API primitives? -
Hello Build apiVersion: build.knative.dev/v1alpha1 kind: Build metadata: name: date spec:
steps: - name: date image: debian:stable-slim args: ['/bin/date'] Thanks @sebgoa -
Running the build $ kubectl apply -f date.yaml build.build.knative.dev "date"
created $ kubectl get build NAME AGE date 9s $ kubectl get pods NAME READY STATUS RESTARTS AGE date-pod-c9b010 0/1 Init:1/2 0 41s $ kubectl logs date-pod-c9b010 Build successful -
Existing build templates - Bazel - Buildah - Buildkit -
Buildpacks - Jib - Kaniko Mainly generic build tool templates, but lots of potential Imagine higher-level templates for... -
Installing build templates $ kubectl apply -f https://raw.githubusercontent.com/knative/build-templates/master/kaniko/kaniko.yaml buildtemplate.build.knative.dev "kaniko"
created $ kubectl get buildtemplates NAME AGE kaniko 2m -
Parameters apiVersion: build.knative.dev/v1alpha1 kind: BuildTemplate metadata: name: kaniko spec: parameters:
- name: IMAGE description: The name of the image to push - name: DOCKERFILE description: Path to the Dockerfile to build. default: /workspace/Dockerfile steps: - name: build-and-push image: gcr.io/kaniko-project/executor args: - --dockerfile=${DOCKERFILE} - --destination=${IMAGE} -
Steps apiVersion: build.knative.dev/v1alpha1 kind: BuildTemplate metadata: name: kaniko spec: parameters:
- name: IMAGE description: The name of the image to push - name: DOCKERFILE description: Path to the Dockerfile to build. default: /workspace/Dockerfile steps: - name: build-and-push image: gcr.io/kaniko-project/executor args: - --dockerfile=${DOCKERFILE} - --destination=${IMAGE} -
Describing a build apiVersion: build.knative.dev/v1alpha1 kind: Build metadata: name: kubeval-build
spec: source: git: url: https://github.com/garethr/kubeval.git revision: master template: name: kaniko arguments: - name: IMAGE value: garethr/kubeval -
Running a build $ kubectl apply -f kubeval.yaml build.build.knative.dev "kubeval-build"
created $ kubectl get build kubeval-build -o yaml -w # grab the pod identifier $ kubectl logs -f kubeval-build-pod-8fd6e4 -c build-step-build-and-push INFO[0000] Downloading base image golang:1.8-alpine 2018/12/09 16:50:14 No matching credentials were found, falling back on anonymous INFO[0002] Executing 0 build triggers INFO[0002] Unpacking rootfs as cmd RUN apk --no-cache add make git requires it. INFO[0137] Taking snapshot of full filesystem... INFO[0138] Skipping paths under /builder/home, as it is a whitelisted directory INFO[0138] Skipping paths under /dev, as it is a whitelisted directory INFO[0138] Skipping paths under /kaniko, as it is a whitelisted directory INFO[0138] Skipping paths under /proc, as it is a whitelisted directory INFO[0138] Skipping paths under /sys, as it is a whitelisted directory INFO[0138] Skipping paths under /var/run, as it is a whitelisted directory -
The Kubernetes community is an interesting mix of systems engineers
and end users This is both a strength and a weakness -
If Knative is for tool builders, what about end users?
The pros and cons of low-level APIs -
Experimenting with template UI $ knt inspect kaniko kaniko https://raw.githubusercontent.com/knative/build-templates/master/kaniko/kaniko.yaml
Parameters (2) Description Default ---------------- -------------------------------- --------------------- IMAGE The name of the image to push DOCKERFILE Path to the Dockerfile to build. /workspace/Dockerfile Steps (1) Image Command Args -------------- ------------------------------ --------- -------------------------- build-and-push gcr.io/kaniko-project/executor --dockerfile=${DOCKERFILE} --destination=${IMAGE} -
Examples with TriggerMesh tm $ tm deploy build kubeval --source
https://github.com/garethr/kubeval.git \ --buildtemplate docker --args IMAGE=garethr/kubeval $ tm get build kubeval "stepStates": [ { "terminated": { "exitCode": 0, "reason": "Completed", "startedAt": "2018-12-12T01:42:48Z", "finishedAt": "2018-12-12T01:46:41Z", "containerID": "docker://45913da527d4ee1160d9f0cce0119ec4ddcd920470a086beae7b4a6170f850bb" } } ], "stepsCompleted": [ "build-step-build" ], -
Dockerfile to Knative Build FROM test-base AS Test RUN pytest
--black FROM test-base AS Check RUN safety check FROM app AS Security ARG MICROSCANNER RUN wget -O /microscanner https://get.aquasec.com/microscanner && chmod +x /microscanner RUN /microscanner $MICROSCANNER --full-output FROM release CMD ["gunicorn", "-b", ":5000", "app:app"] -
Generate steps from Dockerfile stages steps: - name: test image:
'docker:18.09' args: ['build', '--target', 'test', '-t', "${IMAGE}:test", '.'] - name: check image: 'docker:18.09' args: ['build', '--target', 'check', '-t', "${IMAGE}:check", '.'] - name: security image: 'docker:18.09' args: ['build', '--target', 'security', '-t', "${IMAGE}:check", '.'] - name: build image: 'docker:18.09' args: ['build', '-t', "${IMAGE}", '.'] -
Other things that might happen - A unified backend for
different CI systems on Kubernetes? - Custom scheduling algorithms for build? - Decouple description from consumption of build information? - Convertors for popular formats? - Opinionated per-language/framework builders, including full pipelines? Commence speculation -
Conclusions - Knative Build is for tool builder But if
you’re building CI and building tooling then you should join the conversation - Knative Build needs folks experimenting with UI Low level bits are important, but not as important as end user solutions - Custom Resources in Kubernetes are great Expect further commoditization of parts of the software delivery toolchain If all you remember is...
