Methodical Improvement of Software Sytems

ECSA-2014 Tutorial on Software Improvement, by Alex Heusingfeld (@goldstift) and Gernot Starke (@gernotstarke).

Transcript

1. Systematic Software Improvement Alexander Heusingfeld Dr. Gernot Starke
2. Reality
3. Goal
4. Thesis: Education focused on „build-from-scratch“ Software of systems
5. Thesis: Business requires more maintenance competence
6. Thesis: Improvement is more than Refactoring of single classes of Systems
7. These: Verbesserung ist mehr als Refactoring „Große“ Umbauten bedeuten (oft): • Umbau DB-Struktur, Datenmigration • Austausch von Software-Infrastruktur (z.B. Frameworks) • umfangreiche Änderung interner Abläufe • massive Änderung interner Schnittstellen
8. Thesis: Management responsible for budget ignores architecture principles
9. Architecture Improvement Method
10. analyze evaluate improve
11. analyze evaluate improve • architecture • code • runtime • organization
12. analyze evaluate improve determine „value“ of problems / risks / issues and their remedies
13. analyze evaluate improve • define improvement strategy • refactor • re-architect • re-organize • remove debt
14. „Analysis“ Overview analyze evaluate improve Qualitative Analysis Context Analysis Stakeholder Analysis Stakeholder Interview prepares validates external stakeholder Quantitative Analysis finds risks and non-risks gives overview fundamental crosscutting Legend: collect issues collect improvement opportunities Development Process Analysis part of find input for
15. analyze evaluate improve „Analysis“ Details Qualitative Analysis ATAM Context Analysis Issue Tracker Analysis Data Analysis Documentation Analysis Runtime Analysis Stakeholder Analysis Stakeholder Interview prepares Requirements Analysis foundation for part of validates external stakeholder Quantitative Analysis finds risks and non-risks identify risk areas Questionnaire prepares gives overview Software Archeology supported by measure at runtime Static Code Analysis measure code supports fundamental crosscutting Legend: collect issues collect improvement opportunities part of Development Process Analysis part of find input for Infrastructure Analysis part of Instrument System provide better information
16. Common Wording analyze evaluate improve crosscutting practices & principles Issue (Problem) Improvement (remedy) Cost Risk Cause cost of improvement improvement has risks or consequence improvements resolve cause (root) causes of issues cost of issue (potential) cost of risk risk might result in issue solve issue with improvement(s) improvement solves issue(s)
17. analyze evaluate improve collect… Groundwork (1) analyze evaluate improve crosscutting practices & principles Iterate!
18. Groundwork (2) analyze evaluate improve crosscutting practices & principles collect issues! collect improvements! m:n
19. Groundwork (3) analyze evaluate improve crosscutting practices & principles collect issues collect opportunities for improvement create from Explicit Assumption Improvement Backlog keep explicit list or table helps understand Issue List keep explicit list or table m:n mapping
20. Groundwork (4) analyze evaluate improve crosscutting practices & principles fundamental Legend: collect issues collect opportunities for improvement create from change has impact Impact Analysis might create new problems Expect Denial Explicit Assumption Improvement Backlog Fail Fast Fast Feedback Separate Cause From Effect Slide or Write Traceability keep trace to problem stakeholders deny problems traces help prove your points keep explicit list or table helps understand root cause analysis presentation or written report solution to what problem(s) Issue List Artifact keep explicit list or table m:n mapping
21. „Analysis“ Overview Qualitative Analysis Context Analysis Stakeholder Analysis Stakeholder Interview prepares validates external stakeholder Quantitative Analysis finds risks and non-risks gives overview fundamental crosscutting Legend: collect problems collect improvement opportunities Development Process Analysis part of find input for analyze evaluate improve Talk to the right people!
22. „Analysis“ Overview Qualitative Analysis Context Analysis Stakeholder Analysis Stakeholder Interview prepares validates external stakeholder Quantitative Analysis finds risks and non-risks gives overview fundamental crosscutting Legend: collect problems collect improvement opportunities Development Process Analysis part of find input for analyze evaluate improve Understand the neighbourhood!
23. Context Example
24. Qualitative Analysis Context Analysis Stakeholder Analysis Stakeholder Interview prepares validates external stakeholder Quantitative Analysis finds risks and non-risks gives overview fundamental crosscutting Legend: collect problems collect improvement opportunities Development Process Analysis part of find input for „Analysis“ Overview analyze evaluate improve Systemic issues with the organization?
25. „Analysis“ Overview Qualitative Analysis Context Analysis Stakeholder Analysis Stakeholder Interview prepares validates external stakeholder Quantitative Analysis finds risks and non-risks gives overview fundamental crosscutting Legend: collect problems collect improvement opportunities Development Process Analysis part of find input for analyze evaluate improve Quality issues?
26. Qualitative Analysis Preparation Identify the relevant stakeholders Kickoff Present the ATAM method Present the business objectives and architecture goals Present the architecture of the system Evaluation Explain detailed the architecture approaches Create a quality tree and scenarios Analyze architecture approaches with respect to the scenarios Follow-up Present the results
27. Qualitative Analysis Software Product Quality Attributes ISO 25010 Functional Suitability Reliability Performance efficiency Operability Security Compatibility Maintain- ability Transfer- ability Appropriate- ness Accuracy Compliance Availability Fault tolerance Recover- ability Compliance Time- behaviour Resource- utilisation Compliance Appropriate- ness Recognise- ability Learnability Ease-of-use Helpfulness Attractiveness Technical accessibility Compliance Confidential- ity Integrity Non- repudiation Account- ability Authenticity Compliance Replace- ability Co- existence Inter- operability Compliance Modularity Reusability Analyzability Changeability Modification stability Testability Compliance Portability Adaptability Installability Compliance
28. „Analysis“ Overview Qualitative Analysis Context Analysis Stakeholder Analysis Stakeholder Interview prepares validates external stakeholder Quantitative Analysis finds risks and non-risks gives overview fundamental crosscutting Legend: collect problems collect improvement opportunities Development Process Analysis part of find input for analyze evaluate improve Measure!
29. Stakeholder Analysis analyze evaluate improve top-management, business-management, project-management, product- management, process-management, client, subject-matter-expert, business-experts, business-development, enterprise-architect, IT-strategy, lead-architect, developer, tester, qa-representative, configuration-manager, release-manager, maintenance-team, external service provider, hardware- designer, rollout-manager, infrastructure-planner, infrastructure-provider, IT-administrator, DB-administrator, system-administrator, security- or safety-representative, end-user, hotline, service-technician, scrum-master, product-owner, business-controller, marketing, related-projects, public or government agency, authorities, standard-bodies, external service- or interface providers, industry- or business associations, trade-groups, competitors Role / Name Description Intention Contribution Contact Identify the right people!
30. Stakeholder Analysis (II) who MIGHT have problems or know things... analyze evaluate improve • use (pre-interview) questionnaire • conduct personal interviews: e.g. what are your top-3 issues with... 1. the system 2. the development / maintenance process 3. operation / infrastructure of the system 4. ...
31. analyze evaluate improve Static Code Analysis (here: SonarQube dashboard / Apache PDFbox)
32. analyze evaluate improve Static Code Analysis (here: afferent coupling)
33. Perishable Food Packaging > Embedded software + information systems > Regulated domain -> safety critical > Goal: Decrease SW development cost
34. Food: Analysis > Stakeholder analysis and -interviews > Development Process Analysis > Qualitative Analysis + View-Based-Understanding > Quantitative Analysis, Static Code Analysis > Central problem areas: > Lack of overview („knowledge islands“) > Low code quality > ad-hoc development: No systematic processes
35. Food: Root-Cause Analysis > Company focus primarily on hardware > Software development scattered in various departments > No (planned) software architecture
36. Food: Analysis (excerpt) issue (problem) description problem-cost time-to-market > 6 month (!) from business or government requirement to production sales loss might be > 1M$ production log data loss architecture does not ensure complete production logs - data records might get lost! Large volumes of perishable food could be at risk > 10-100k $ per incident scattered knowledge + low code quality no synergy effects, no conceptual integrity, no re-use between departments, ... >5-50k $ per maintenance update self-developed OR-mapper expensive maintenance, high know-how requirements, high deviation in performance 5-10k $ per maintenance update
37. Food: System Overview > C# / .NET as development & production platform Machine Operational Support Sales Support Database Machine Sensors Message Queue Legend: COTS C# Data Storage & Reporting Machine Configuration Frontend Machine Configuration Backend
38. Food: Safety Risk Wrong usage of Message Queue: > 1.-3. has to be transactional > Reporting „commits“ to MQ after 2! (too early!) > Problem in reporting leads to lost data! Machine Operational Support Sales Support Database Machine Sensors Message Queue Legend: COTS C# Data Storage & Reporting Machine Configuration Frontend Machine Configuration Backend 1 2 3
39. EU Telecom Provider > Business Intelligence Portfolio to support Marketing & Sales
40. Telco: Analysis > View-Based-Understanding > Data Analysis > (few) stakeholder interviews > Central problem areas: > BI Reporting highly fragmented & diverse > Report implementation details driven by business experts (provided data models + SQL query details as „requirements“) > Implementation partially based upon proprietary meta-model
41. Telco: Analysis (excerpt) problem / risk description problem-cost high development cost business benchmarks showed development to be overly expensive (and slow) per report-type 50-200% non-transparent software and data architecture of >50 developers and BI experts, only very few understood whole DWH vendor-lock-in proprietary tools implemented to process (proprietary) meta-model, high yearly license cost, 50 k€ license fee / yr, O(1000) dev-hrs wasted developer exodus core developers upset as company announced large outsourcing deal, (nearly) annihilating internal development 6-18 month without new business features
42. Croc: Sales & ERP Provider > Niche provider for sales & ERP „standard“ solution > Origin in „perishable“ market - but growing > 80% of clients: low-margin-high-volume > 20% of clients: low-volume-very-high-margin > Original idea: Universal-Core + Configuration > Starting point: low (dev + runtime) performance Company name changed due to anonymity requirements!
43. Croc: Analysis > Brief stakeholder analysis and -interviews > Static Code Analysis > Runtime Analysis > Data Analysis (including data model) > Central problem areas: > Excellent code quality („clean code“) - but very few unit tests > Extremely high configurability of everything > >150 developers with extremely different options
44. Croc: Analysis (2) „Configuration is the sequel to programming, with unsuitable means“ > Configuring UI structure, UI behavior, workflows, business and validation rules, reports and interfaces > Horrible persistent data structures for both runtime and configuration data > Some configuration stored in various XML formats
45. Croc: Analysis (3) > Few key tables with 500-700 columns (!!) each. > Stores complete application state - including cursor position. „Clean“ Code XML Configuration DB Legend: COTS Code Table-1 Table-2 Table-3 Table-4 Database Relational Data
46. „Evaluate“ Overview fundamental crosscutting Legend: issue list improvement backlog Estimate Issue Cost create from Estimate Improvement Cost Estimate in Interval Estimate Feature Value analyse impact Explicit Assumption requires based upon
47. fundamental crosscutting Legend: issue list improvement backlog Estimate Issue Cost create from Estimate Improvement Cost Estimate in Interval Estimate Feature Value analyse impact Explicit Assumption requires based upon „Evaluate“ Overview Map problems to „business“ terms!
48. „Evaluate“ Concepts Estimate Assumption Unit (Measure) Parameter Observation Probability based upon how certain? Correction Factors can observe require / allow Intervall time, money, etc Subject what do we estimate? tacke uncertainty by based upon
49. Rail Transport Provider > Heterogeneous IT landscape > Problem areas: > 6-12 month from initial business requirement to production („time-to-market“) > Stability, reliability > Performance
50. Rail - aim42 Analysis > Stakeholder Analysis + -Interviews > yielded several problems + problem-areas > Issue Tracker Analysis + Software Archeology > Qualitative (ATAM-like) Analysis > Static Code Analysis > Development Process Analysis
51. Rail (1): Overview Ticket Sales Frontend Cash Management Client Personalization Client Data / Contract User Management Rail Itinerary Vouchers Rebate and Reduction Cards Inter-European Connections (HAFAS) External Partners Booking Office Ticket Price Management Data Warehouse Marketing & Sales Campaigns Travel Agents API & UI Pricing Engine Ticket Sales Backend Legend: Java PHP Python C/C++ Web Server Extensions Pricing Data Store Haskell Cobol Security Extensions PL/ SQL bad!
52. Rail (2): Challenges > Embrace new sales channels (mobile) > requires (much) higher availability > Marketing demands rapid price adjustments
53. Rail (4): Analysis (excerpt) issue (problem) description problem-cost time-to-market 6-12 month (!) from business requirement to production configuration of certain ticket types crashes backend when either end-users or sales-clerks configure specific ticket-types (groups > 5 persons, more than one rebate reason, border crossing or >2 train changes), several backend processes crash know-how drain in development many dissatisfied developers and business experts leave (development) organization, migration from internal to external development, fix-price projects
54. 7%# 6%# 12%# 8%# 67%# Cost%Distribu+on%for%So/ware%% Requirements# Design#/#Architecture# (ini9al)#Programming# Integra9on# Maintenance# Rail (5): Evaluation (excerpt) What‘s the (additional) cost of „heterogenity“? 1. Explicit assumptions • Heterogenity „costs“ in all phases • Phase effort is known h"p://courses.cs.vt.edu/~csonline/SE/Lessons/LifeCycle/
55. Rail (6)... Collected tasks in which additional effort might occur.. h"p://courses.cs.vt.edu/~csonline/SE/Lessons/LifeCycle/
56. „Improve“ Overview
57. „Improve“ Practices > Anticorruption Layer > Assertions > Automated-Tests > Branch-For-Improvement > Extract-Reusable-Component > Front-End-Switch > Group-Improvement-Actions > Handle-If-Else-Chains > Improve-Code-Layout > Improve Logging > Interface Segregation Principle > Introduce Boy Scout Rule > Introduce-Layering > Isolate-Changes > Keep-Data-Toss-Code > Manage Complex Client Dependencies With Facade > Measure-Everything > Never-Change-Running-System > Never-Rewrite-Running-System > Quality-Driven-Software-Architecture > Refactoring > Refactoring-Plan > Remove-Nested-Control-Structures > Sample-For-Improvement > Schedule-Work > Untangle-Code > Use Invariants To Kill Zombies
61. Automated Tests > Risk: Changes fail existing processes in prod > Put this into numbers: > Which processes are impacted by the new feature's code changes? > Estimate the hourly cost of those processes failing in production > Estimate the probability of each process's failure
62. Unit Tests > If you don’t have any, start with new features > Reproduce each bug as a unit test > Write small tests > Use self-explaining test case names
63. Integration Tests > Priority: Test your API! > cheaper than UI testing > usually not acceptance tested > Don’t use mocks if you’re not forced to! > only if 3rd-party regularly blocks you
65. Thesis: Logging is the most underestimated task in IT
66. State of Logging > Growing number of user transactions > much larger log files > log files distributed across multiple systems > Increasing demand for real-time analysis
67. Information Types > Operational data > Actions or state of the application > User interaction
68. Stakeholders Developer failure analysis after weeks Operations real-time health information Product Owner weekly usage reports ??? some complex daily report?
69. Improve Logging > Diagnostic contexts > Filters > Defined log format > Log aggregation > CorrelationID
70. Customer Story > A well-known German bank > Web application for customer self-service > Customers call support hotline for failures > Hotline shall track state of transactions
71. Customer Story Support??? Customer Developer
72. Customer Story CorrelationID! New CorrelationID: B6F51C-6324-AC336-6339 CID: B6F51C... CID: B6F51C... CID: B6F51C... CID: B6F51C... Customer Developer Corre... what?
73. Customer Story Customer
74. Thesis: Each piece of relevant information is actually an event
75. “An event is anything that we can observe occurring at a particular point in time.” — Alexander Dean, Unified Log Processing, Manning
76. Event Streams Taking the next step to continuous reporting
78. Questions? Comments? Dr. Gernot Starke, @gernotstarke gernot.starke@innoq.com http://gernotstarke.de Alexander Heusingfeld, @goldstift alexander.heusingfeld@innoq.com https://www.innoq.com/en/staff/alex innoQ Deutschland GmbH Krischerstr. 100 40789 Monheim am Rhein Germany Phone: +49 2173 3366-0 innoQ Schweiz GmbH info@innoq.com Gewerbestr. 11 CH-6330 Cham Switzerland Phone: +41 41 743 0116 www.innoq.com Offices in: Berlin Darmstadt München
