Elasticsearch data/

Elasticsearch data/

Igor Motov

July 14, 2014
Tweet

More Decks by Igor Motov

Other Decks in Programming

Transcript

  1. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited About Me • Igor Motov • Developer at Elasticsearch Inc. • Github: imotov • Twitter: @imotov
  2. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited About Elasticsearch Inc. • Founded in 2012 By the people behind the Elasticsearch and Apache Lucene http://www.elasticsearch.com Headquarters: Amsterdam and Los Altos, CA • We provide Training (public & onsite) Development support Production support subscription (SLA)
  3. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited file descriptors ! ! ! “Make sure to increase the number of open files descriptors on the machine (or for the user running elasticsearch). Setting it to 32k or even 64k is recommended.” ! ! Source: setup and configuration guide
  4. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited ! ! where are all these file descriptors go?
  5. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited ! ! files, data structures and their usage
  6. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited main concepts • node a running elasticsearch instance (typically JVM process) • cluster a group of nodes sharing the same set of indices • index a set of documents of possibly different types stored in one or more shards • shard a lucene index, allocated on one of the nodes
  7. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited Index shards shard 0 shard 1 shard 2 shard 3 shard 4 hash(_id)%5= 0 1 2 3 4 document
  8. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited Node 2 Index shards Shard 0 Shard 1 Shard 2 Shard 3 Shard 4 Node 1
  9. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited master node • elected when nodes form a cluster • coordinates work of other nodes through cluster state • the only node that can update cluster state • publishes cluster state to other node
  10. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited cluster state • nodes list of nodes in the cluster, their addresses, attributes and master • index metadata settings, mappings and aliases • shard routing table where the shards can be found • index templates • cluster settings persistent and transient
  11. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited cluster state - persistent • nodes list of nodes in the cluster, their addresses, attributes and master • index metadata settings, mappings and aliases • shard routing table where the shards can be found • index templates • cluster settings persistent and transient
  12. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited data • node level persistent cluster settings, templates • index level aliases, index settings, mappings • shard level shard metadata, lucene index, transaction log
  13. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited data directory • “data” directory in elasticsearch home by default • path.data in config/elasticearch.yml • --path.data=… on command line • handled by deb and rpm packages !
  14. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited multiple nodes per data dir • <data_dir>/<cluster_name>/nodes/NNN where NNN = 0, 1, 2, ... ! • node.max_local_storage_nodes! default 50
  15. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited summary <cluster>/ nodes/ <N>/ _state/ - cluster state node.lock - lock indices/ <index-name>/ _state/ - index metadata 0/ _state/ - shard metadata index/ - index data translog/ - transaction log data
  16. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited transaction log shard lucene index transaction log lucene buffer
  17. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited transaction log • transaction log stores every operation (create/update/delete) fsync-ed every 5 sec (configurable) replayed on node restart • lucene segments fsync-ed when transaction log is full (every 30 min, 200mb or 500 operations)
  18. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited lucene index • inverted index • stored fields • doc values • …
  19. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited inverted index • Document 1: { “text”: “Elasticsearch is an open source, distributed search engine.”, “date”: “2014-07-01” } • Document 2: { “text”: “Elasticsearch is a search server based on Lucene.”, “date”: “2014-07-02” }
  20. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited analysis • “Elasticsearch is an open source, distributed search engine.” could be translated into tokens: – elasticsearch – open – source – distributed – search – engine • “Elasticsearch is a search server based on Lucene.” could be translated into tokens: – elasticsearch – search – server – based – lucene
  21. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited inverted index - field text token document frequency postings (document ids) based 1 2 distributed 1 1 elasticsearch 2 1, 2 engine 1 1 lucene 1 2 open 1 1 search 2 1, 2 server 1 2 source 1 1
  22. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited inverted index - field date token document frequency postings (document ids) 2014-07-01 1 1 2014-07-02 1 2
  23. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited inverted index • tokens->documents • easy to build • difficult to update • segmented • segments are merged periodically
  24. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited field data • “uninverted" inverted index • documents->tokens • can be built from inverted index on demand • can be stored with index as doc values • segmented • used by sorting, aggregations, scripts, etc
  25. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited field data - text document tokens 1 distributed, elasticsearch, engine, open, search, source 2 based, elasticsearch, lucene, search, server
  26. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited field data - date document tokens 1 2014-07-01 2 2014-07-02
  27. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited stored fields • _source - JSON source of the entire document • _parent id • routing • ttl • _uid • any other field marked as “stored”
  28. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited all together now • searching for terms “distributed” and “service” • sorting by the field “date”
  29. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited Node 1 Node 2 QUERY phase - node level Shard 0 Shard 1 Shard 2 Shard 3 Shard 4 Search Action Cluster State • using cluster state all relevant shards are identified • requesting node sends QUERY requests to this shards
  30. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited QUERY phase - shard level Shard Engine Segment 1 Segment 2 Segment 3 Segment 4 Segment N ……. • each shard searches all segments in the shard one after another
  31. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited QUERY phase - inverted index token document frequency postings (document ids) based 1 2 distributed 1 1 elasticsearch 2 1, 2 engine 1 1 lucene 1 2 open 1 1 search 2 1, 2 server 1 2 source 1 1
  32. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited QUERY phase - field data document tokens 1 2014-07-01 2 2014-07-02
  33. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited QUERY phase - shard level Shard Engine Segment 1 Segment 2 Segment 3 Segment 4 Segment N ……. seg1, 2, [2014-07-02] seg1, 1, [2014-07-01] ……. • all segments are searched and top 10 documents are collected for each shard • for each document internal Lucene id and sort key is stored
  34. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited Node 1 Node 2 QUERY phase - node level Shard 0 Shard 1 Shard 2 Shard 3 Shard 4 Search Action • top 10 ids and sort keys for each shard are sent to requesting node • requesting node resorts them and finds global top10
  35. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited Node 1 Node 2 FETCH phase - node level Shard 0 Shard 1 Shard 2 Shard 3 Shard 4 Search Action • global top 10 documents are requested • only shards that have these top 10 documents are contacted
  36. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited FETCH phase - shard level Shard Engine Segment 1 Segment 2 Segment 3 Segment 4 Segment N ……. • _source (stored field) is retrieved from corresponding segments
  37. Copyright Elasticsearch 2014. Copying, publishing and/or distributing without written permission

    is strictly prohibited Node 1 Node 2 FETCH phase - node level Shard 0 Shard 1 Shard 2 Shard 3 Shard 4 Search Action • requesting node combines all documents and sends them to the client
