Centralized Configuration using Spring Cloud, Consul and Vault
Eko Kurniawan Khannedy
July 26, 2017
Transcript
32 slides
-
CENTRALIZED CONFIGURATION WHAT IS CONSUL? ▸ Service Discovery (via DNS
or HTTP) ▸ Failure Detection (health checking) ▸ Key-Value Storage (for dynamic configuration) ▸ Multi Datacenter -
CENTRALIZED CONFIGURATION CONSUL CLUSTER ARCHITECTURE ▸ Datacenter ▸ Agent, a
the long running daemon on every member of the Consul cluster ▸ Server, an agent with an expanded set of responsibilities ▸ Client, an agent that forwards all RPCs to a server -
CENTRALIZED CONFIGURATION SETUP CONSUL CLUSTER IP Address Role 192.0.0.1 Bootstrap
Consul Server 192.0.0.2 Consul Server 192.0.0.3 Consul Server -
CENTRALIZED CONFIGURATION SETUP CONSUL SERVER 1 (BOOTSTRAP) { “bootstrap”: true,
“server”: true, “datacenter”: “blibli", “data_dir”: “/opt/var/consul”, “log_level”: “INFO”, “bind_addr” : “192.0.0.1”, “client_addr” : “192.0.0.1” } -
CENTRALIZED CONFIGURATION SETUP CONSUL SERVER 2 { “bootstrap”: false, “server”:
true, “datacenter”: “blibli", “data_dir”: “/opt/var/consul”, “log_level”: “INFO”, “bind_addr” : “192.0.0.2”, “client_addr” : “192.0.0.2”, “start_join” : [ “192.0.0.1”, “192.0.0.3” ] } -
CENTRALIZED CONFIGURATION SETUP CONSUL SERVER 3 { “bootstrap”: false, “server”:
true, “datacenter”: “blibli", “data_dir”: “/opt/var/consul”, “log_level”: “INFO”, “bind_addr” : “192.0.0.3”, “client_addr” : “192.0.0.3”, “start_join” : [ “192.0.0.1”, “192.0.0.2” ] } -
CENTRALIZED CONFIGURATION SETUP CONSUL CLIENT { “server”: false, “datacenter”: “blibli",
“data_dir”: “/opt/var/consul”, “log_level”: “INFO”, “bind_addr” : “192.0.1.1”, “client_addr” : “192.0.1.1”, “start_join” : [ “192.0.0.1”, “192.0.0.2”, “192.0.0.3” ] } -
CENTRALIZED CONFIGURATION START CONSUL AGENT consul agent -ui -config-dir /opt/consul/config
▸ All consul configuration saved as json file in a directory. ▸ Consul automatically read all json file in config directory. -
CENTRALIZED CONFIGURATION WHAT IS VAULT? Vault secures, stores, and tightly
controls access to tokens, passwords, certificates, API keys, and other secrets in modern computing. Vault handles leasing, key revocation, key rolling, and auditing. Through a unified API, users can access an encrypted Key/Value store and network encryption-as-a-service, or generate AWS IAM/STS credentials, SQL/NoSQL databases, X.509 certificates, SSH credentials, and more. -
CENTRALIZED CONFIGURATION VAULT ARCHITECTURE CLIENT BACKEND STORAGE ▸ Consul
▸ Cassandra ▸ MongoDB ▸ PostgreSQL ▸ …… -
CENTRALIZED CONFIGURATION CONFIGURED VAULT WITH CONSUL backend "consul" { address
= "127.0.0.1:8500" path = "vault" } listener "tcp" { address = "127.0.0.1:8200" tls_disable = 1 } -
CENTRALIZED CONFIGURATION INITIALIZED VAULT export VAULT_ADDR='http://127.0.0.1:8200' vault init Unseal
Key 1: Xjgw4P1d9f0lJZRlSqqmVM+AlHijLECiFa9cG2WwuNt+ Unseal Key 2: c9QjPxYlYT4JBEYGVFPRS7ieE3oRIe6bfd56lXYEFv6j Unseal Key 3: ho7eoaQTaBiiUC4PQBuJVvFABr4w0VAlGZKdSeBYuz3w Unseal Key 4: NMTsFqhUstk2cKxw/iCFE7pLVAFlWB+/gDxFd/sbLll5 Unseal Key 5: EZuPVPnjKu0TfxeOIP+qS7p1wiBJnraiO3S8WINevT7J Initial Root Token: dda76855-067d-e2b0-ff9c-4b35b3ddb05c -
CENTRALIZED CONFIGURATION WRITE VALUE TO VAULT vault auth vault write
secret/pyeongyang-common key=value -
CENTRALIZED CONFIGURATION READ VALUE FROM VAULT vault auth vault read
secret/pyeongyang-common Key Value --- ----- refresh_interval 768h0m0s key value -
CENTRALIZED CONFIGURATION NEXT PLAN ▸ Pyeongyang Backend Common + Member
will be the first project using Consul. (June Release Train) ▸ Configuration Management for all Spring Boot Projects should use Consul + Vault. (July - August Release Train) ▸ We will use Consul as Service Registry. ▸ We will use Client Side Load Balancing. -
CENTRALIZED CONFIGURATION REFERENCES ▸ https://www.consul.io/ ▸ https://www.vaultproject.io/ ▸ https://cloud.spring.io/spring-cloud-config/ ▸
https://cloud.spring.io/spring-cloud-consul/ ▸ http://cloud.spring.io/spring-cloud-vault/ ▸ https://spring.io/guides/gs/centralized-configuration/
