Corporation in the Middle Lee Brotherston! @synackpse #BSidesTO Edition

MITM vs Everything Else

Detection

How, what, why, when?

Capture all the Packets

PCAP Tools tcpdump wireshark tshark ! mergecap tcpsplice tcptrace captcp
pcapdiff tcpﬂow snort

SYN Server Client SYN/ACK ACK HTTP Request HTTP Response (Header
& Data) More Data……

SYN Server Client SYN/ACK ACK RST/PSH/ACK HTTP Response HTTP Request
? ? ?

HTTP/1.1 200 OK! Content-Type: text/html; charset=ISO-8859-1! Content-Script-Type: text/javascript! Connection: close!
Cache-Control: no-store, no-cache, must-revalidate, max-age=0! Expires: -1! Pragma: no-cache! ! <html><head><noscript><meta http-equiv="refresh" content="0;URL=http://64.71.251.10/noscript.pl? policy=72&category=ByteCap-075&"></noscript><title></title><script type="text/javascript">var version=2; var webServer="http:// 64.71.251.10";</script><script type="text/javascript" src="http:// 64.71.251.10/ByteCap-075-EO-English/index.js"></script></ head><noscript><frameset><frame src="http://64.71.251.10/ noscript.pl?policy=72&category=ByteCap-075&"></frameset></ noscript><body style="margin:0;"><script type="text/ javascript">Bulletin("policy=72&category=ByteCap-075&");</script></ body></html>

Packet Headers

TCPDUMP ip[6] = 0 and tcp[14:2] = 1

Wire/TShark tcp.window_size_value eq 1 and ip.flags.df == 0

Snort alert tcp $EXTERNAL_NET any -> $HOME_NET any (msg:"INJECTION suspected
TCP injection"; flow:stateless; window:1; fragbits:!D; sid:31337)

But wait, there’s more….

SYN Server Client SYN/ACK ACK RST/PSH/ACK HTTP Response HTTP Request

SYN Server Client SYN/ACK ACK HTTP Request HTTP Response (Header
& Data) Data

HTTP/1.1 200 OK! Content-Type: text/html; charset=ISO-8859-1! Content-Script-Type: text/HTML! Connection: close

Profiling Target Acquisition

Retention Time rewrite ^(.*)$ /index.php;! ! ! !

OoB Indexing rewrite ^(.*)$ /index.php;! +! /etc/hosts! +! .htaccess

Document Format ! <html>! <head>! <title>Oh Hai</title>! </head>

Document Format <!doctype html>! <html>! <head>! <title>Oh Hai</title>! </head>

– PIPEDA, 4.9 Principle 9 — Individual Access ! “Upon
request, an individual shall be informed of the existence, use, and disclosure of his or her personal information and shall be given access to that information.”

Mapping the Network

Traceroute (8 bits of goodness)

ttl=1 ttl expiry ttl=2 ttl expiry ttl=1 reply ttl=2 ttl=1
ttl=3

2 7.40.72.1! 3 209.148.241.61! 4 66.185.81.221! 5 69.63.251.242! 6 69.63.249.26!
7 *! ! 2 7.40.72.1! 3 209.148.241.61! 4 *! 5 *! 6 69.63.249.26! 7 *! tcptraceroute

Intercept Portscanning for i in `jot 65535 1`! do !
tcptraceroute -f4 -m5 host $i! done >> $i.log

2 7.11.164.41! 3 66.185.90.37! 4 209.148.224.205! 5 209.148.224.242! ! !
! 6 4.31.208.129  2 7.11.164.41! 3 66.185.90.37! 4 209.148.224.214! 5 209.148.224.209! 6 209.148.228.218! 7 209.148.228.217! 8 209.148.224.254! 9 4.31.208.129 tcptraceroute redux

Intercept Portscanning Redux nmap -sS —-ttl 64 host

Which Interface? My Server Destination Me

Scapy sendp(Ether(dst="be:ef:11:11:11:11", src="31:33:7a:aa:aa:aa")/ IP(src="11.11.11.11", dst="55.55.55.55",ttl=(1,30), options=IPOption('\x07'))/ TCP(sport=3125, dport=80, flags="S"), iface="en1")

So, that network… Internal Management LAN extWebServer = "http://64.71.255.194";! intWebServer
= “http://172.19.11.72";

SYN Server Client SYN/ACK ACK RST/PSH/ACK TTL = 1 TTL
= 2 TTL = 3

HTTP/1.1 200 OK! Date: Thu, 22 May 2014 14:29:09 GMT!
Server: PerfTech! Last-Modified: Thu, 17 Apr 2014 14:42:01 GMT! Accept-Ranges: bytes! Content-Length: 2387! Connection: close! Cache-Control: no-store, no-cache, must- revalidate, max-age=0! Expires: -1! Pragma: no-cache! Content-Type: application/x-javascript

Why So Bothered?

Why Metadata Matters • They know you rang a phone
sex service at 2:24 am and spoke for 18 minutes. But they don't know what you talked about.! ! • They know you called the suicide prevention hotline from the Golden Gate Bridge. But the topic of the call remains a secret.! ! • They know you spoke with an HIV testing service, then your doctor, then your health insurance company in the same hour. But they don't know what was discussed.

GET / HTTP/1.1! Host: squarelemon.com! User-Agent: Mozilla/5.0 (X11; Ubuntu; Linux
i686; rv:25.0) Gecko/20100101 Firefox/25.0! Accept: text/html,application/xhtml +xml,application/xml;q=0.9,*/*;q=0.8! Accept-Language: en-US,en;q=0.5! Accept-Encoding: gzip, deflate! Cookie: _pk_ses.4.9b83=*! Connection: keep-alive! If-Modified-Since: Fri, 18 Oct 2013 14:45:41 GMT! Cache-Control: max-age=0

What could possibly go wrong? Photo Attribution: Tom - @tdawks

I learnt Stuff!

–Johnny Appleseed “Type a quote here.”

Internet provider subscriber communications system US 8793386 B2

Internet advertising method and system using Web page US 8005717
B2

– Hanlon’s Brotherston’s Razor “Never attribute to malice that which
is adequately explained by stupidity Enhancing Shareholder Value.”

Thank you! Lee Brotherston! @synackpse!
