Beginner's Guide to eBPF Programming for Networking

eBPF has been described as “Superpowers for Linux,” and recently we’ve seen an explosion of tools that use it to power networking, observability and security in the Cloud Native world. It's an exciting technology that enables running bespoke programs directly in the kernel. In this talk Liz uses live-coding examples to explore how eBPF programs are loaded and run in the kernel, and attached to a variety of networking-related events. You might have seen Liz give a similar talk before, with examples hooking into system calls. This updated version focuses networking examples, giving insight into how eBPF programs can inspect and manipulate packets to form the basis of sophisticated and high-performance networking tools.

Liz Rice

October 11, 2021
Tweet

More Decks by Liz Rice

Other Decks in Programming

Transcript

  1. @lizrice Attaching eBPF to events eBPF programs are event-driven and

    are run when the kernel or an application passes a certain hook point. Pre-defined hooks include system calls, function entry/exit, kernel tracepoints, network events, and several others. ebpf.io/what-is-ebpf/
  2. @lizrice SEC("kprobe/sys_execve") int hello(void *ctx) { bpf_printk("I'm alive!"); return 0;

    } eBPF Hello World $ sudo ./hello bash-20241 [004] d... 84210.752785: 0: I'm alive! bash-20242 [004] d... 84216.321993: 0: I'm alive! bash-20243 [004] d... 84225.858880: 0: I'm alive! Info about process that called execve syscall + userspace code to load eBPF program
  3. @lizrice Program types enum bpf_prog_type { BPF_PROG_TYPE_UNSPEC, BPF_PROG_TYPE_SOCKET_FILTER, BPF_PROG_TYPE_KPROBE, BPF_PROG_TYPE_SCHED_CLS,

    BPF_PROG_TYPE_SCHED_ACT, BPF_PROG_TYPE_TRACEPOINT, BPF_PROG_TYPE_XDP, BPF_PROG_TYPE_PERF_EVENT, BPF_PROG_TYPE_CGROUP_SKB, BPF_PROG_TYPE_CGROUP_SOCK, BPF_PROG_TYPE_LWT_IN, BPF_PROG_TYPE_LWT_OUT, BPF_PROG_TYPE_LWT_XMIT, BPF_PROG_TYPE_SOCK_OPS, BPF_PROG_TYPE_SK_SKB, BPF_PROG_TYPE_CGROUP_DEVICE, BPF_PROG_TYPE_SK_MSG, BPF_PROG_TYPE_RAW_TRACEPOINT, BPF_PROG_TYPE_CGROUP_SOCK_ADDR, BPF_PROG_TYPE_LWT_SEG6LOCAL, BPF_PROG_TYPE_LIRC_MODE2, BPF_PROG_TYPE_SK_REUSEPORT, BPF_PROG_TYPE_FLOW_DISSECTOR, /* See /usr/include/linux/bpf.h for the full list. */ };
  4. @lizrice Program types enum bpf_prog_type { BPF_PROG_TYPE_UNSPEC, BPF_PROG_TYPE_SOCKET_FILTER, BPF_PROG_TYPE_KPROBE, BPF_PROG_TYPE_SCHED_CLS,

    BPF_PROG_TYPE_SCHED_ACT, BPF_PROG_TYPE_TRACEPOINT, BPF_PROG_TYPE_XDP, BPF_PROG_TYPE_PERF_EVENT, BPF_PROG_TYPE_CGROUP_SKB, BPF_PROG_TYPE_CGROUP_SOCK, BPF_PROG_TYPE_LWT_IN, BPF_PROG_TYPE_LWT_OUT, BPF_PROG_TYPE_LWT_XMIT, BPF_PROG_TYPE_SOCK_OPS, BPF_PROG_TYPE_SK_SKB, BPF_PROG_TYPE_CGROUP_DEVICE, BPF_PROG_TYPE_SK_MSG, BPF_PROG_TYPE_RAW_TRACEPOINT, BPF_PROG_TYPE_CGROUP_SOCK_ADDR, BPF_PROG_TYPE_LWT_SEG6LOCAL, BPF_PROG_TYPE_LIRC_MODE2, BPF_PROG_TYPE_SK_REUSEPORT, BPF_PROG_TYPE_FLOW_DISSECTOR, /* See /usr/include/linux/bpf.h for the full list. */ }; eBPF - not just for syscalls!
  5. @lizrice Program types enum bpf_prog_type { BPF_PROG_TYPE_UNSPEC, BPF_PROG_TYPE_SOCKET_FILTER, BPF_PROG_TYPE_KPROBE, BPF_PROG_TYPE_SCHED_CLS,

    BPF_PROG_TYPE_SCHED_ACT, BPF_PROG_TYPE_TRACEPOINT, BPF_PROG_TYPE_XDP, BPF_PROG_TYPE_PERF_EVENT, BPF_PROG_TYPE_CGROUP_SKB, BPF_PROG_TYPE_CGROUP_SOCK, BPF_PROG_TYPE_LWT_IN, BPF_PROG_TYPE_LWT_OUT, BPF_PROG_TYPE_LWT_XMIT, BPF_PROG_TYPE_SOCK_OPS, BPF_PROG_TYPE_SK_SKB, BPF_PROG_TYPE_CGROUP_DEVICE, BPF_PROG_TYPE_SK_MSG, BPF_PROG_TYPE_RAW_TRACEPOINT, BPF_PROG_TYPE_CGROUP_SOCK_ADDR, BPF_PROG_TYPE_LWT_SEG6LOCAL, BPF_PROG_TYPE_LIRC_MODE2, BPF_PROG_TYPE_SK_REUSEPORT, BPF_PROG_TYPE_FLOW_DISSECTOR, /* See /usr/include/linux/bpf.h for the full list. */ };
  6. @lizrice Kprobes / kretprobes Entry to / exit from a

    kernel function Lots of kernel functions relate to networking example tcp_v4_connect() kernel function
  7. @lizrice Program types enum bpf_prog_type { BPF_PROG_TYPE_UNSPEC, BPF_PROG_TYPE_SOCKET_FILTER, BPF_PROG_TYPE_KPROBE, BPF_PROG_TYPE_SCHED_CLS,

    BPF_PROG_TYPE_SCHED_ACT, BPF_PROG_TYPE_TRACEPOINT, BPF_PROG_TYPE_XDP, BPF_PROG_TYPE_PERF_EVENT, BPF_PROG_TYPE_CGROUP_SKB, BPF_PROG_TYPE_CGROUP_SOCK, BPF_PROG_TYPE_LWT_IN, BPF_PROG_TYPE_LWT_OUT, BPF_PROG_TYPE_LWT_XMIT, BPF_PROG_TYPE_SOCK_OPS, BPF_PROG_TYPE_SK_SKB, BPF_PROG_TYPE_CGROUP_DEVICE, BPF_PROG_TYPE_SK_MSG, BPF_PROG_TYPE_RAW_TRACEPOINT, BPF_PROG_TYPE_CGROUP_SOCK_ADDR, BPF_PROG_TYPE_LWT_SEG6LOCAL, BPF_PROG_TYPE_LIRC_MODE2, BPF_PROG_TYPE_SK_REUSEPORT, BPF_PROG_TYPE_FLOW_DISSECTOR, /* See /usr/include/linux/bpf.h for the full list. */ };
  8. @lizrice Socket filter “The filtering actions include dropping packets (if

    the program returns 0) or trimming packets (if the program returns a length less than the original). … Note that we're not trimming or dropping the original packet which would still reach the intended socket intact; we're working with a copy of the packet metadata which raw sockets can access for observability. “ https://blogs.oracle.com/linux/post/bpf-a-tour-of-program-types
  9. @lizrice Socket filter Network packet data copy Filters what gets

    sent to userspace, for performant observability example attach_raw_socket()
  10. @lizrice Program types enum bpf_prog_type { BPF_PROG_TYPE_UNSPEC, BPF_PROG_TYPE_SOCKET_FILTER, BPF_PROG_TYPE_KPROBE, BPF_PROG_TYPE_SCHED_CLS,

    BPF_PROG_TYPE_SCHED_ACT, BPF_PROG_TYPE_TRACEPOINT, BPF_PROG_TYPE_XDP, BPF_PROG_TYPE_PERF_EVENT, BPF_PROG_TYPE_CGROUP_SKB, BPF_PROG_TYPE_CGROUP_SOCK, BPF_PROG_TYPE_LWT_IN, BPF_PROG_TYPE_LWT_OUT, BPF_PROG_TYPE_LWT_XMIT, BPF_PROG_TYPE_SOCK_OPS, BPF_PROG_TYPE_SK_SKB, BPF_PROG_TYPE_CGROUP_DEVICE, BPF_PROG_TYPE_SK_MSG, BPF_PROG_TYPE_RAW_TRACEPOINT, BPF_PROG_TYPE_CGROUP_SOCK_ADDR, BPF_PROG_TYPE_LWT_SEG6LOCAL, BPF_PROG_TYPE_LIRC_MODE2, BPF_PROG_TYPE_SK_REUSEPORT, BPF_PROG_TYPE_FLOW_DISSECTOR, /* See /usr/include/linux/bpf.h for the full list. */ };
  11. @lizrice XDP express data path “What if we could run

    eBPF on the network interface card?”
  12. @lizrice kernel NIC eBPF program packet arrives network stack Physical

    network connection XDP Only some NICs / drivers support XDP
  13. @lizrice XDP express data path Inbound packets Pass / drop

    / manipulate / redirect packets example attach_xdp()
  14. @lizrice Program types enum bpf_prog_type { BPF_PROG_TYPE_UNSPEC, BPF_PROG_TYPE_SOCKET_FILTER, BPF_PROG_TYPE_KPROBE, BPF_PROG_TYPE_SCHED_CLS,

    BPF_PROG_TYPE_SCHED_ACT, BPF_PROG_TYPE_TRACEPOINT, BPF_PROG_TYPE_XDP, BPF_PROG_TYPE_PERF_EVENT, BPF_PROG_TYPE_CGROUP_SKB, BPF_PROG_TYPE_CGROUP_SOCK, BPF_PROG_TYPE_LWT_IN, BPF_PROG_TYPE_LWT_OUT, BPF_PROG_TYPE_LWT_XMIT, BPF_PROG_TYPE_SOCK_OPS, BPF_PROG_TYPE_SK_SKB, BPF_PROG_TYPE_CGROUP_DEVICE, BPF_PROG_TYPE_SK_MSG, BPF_PROG_TYPE_RAW_TRACEPOINT, BPF_PROG_TYPE_CGROUP_SOCK_ADDR, BPF_PROG_TYPE_LWT_SEG6LOCAL, BPF_PROG_TYPE_LIRC_MODE2, BPF_PROG_TYPE_SK_REUSEPORT, BPF_PROG_TYPE_FLOW_DISSECTOR, /* See /usr/include/linux/bpf.h for the full list. */ };
  15. @lizrice Traffic control Traffic filters, attached to queueing disciplines Ingress

    / egress (separately) Pass / drop / manipulate / redirect packets example tc(“add-filter)
  16. @lizrice userspace kernel Network connection Traffic control ingress - ping

    reply IP Socket Raw socket App syscalls Qdisc TCP/UDP/ICMP
  17. @lizrice host pod app socket veth veth eth0 iptables conntrack

    iptables INPUT Linux routing iptables PREROUTING mangle iptables conntrack iptables FORWARD Linux routing iptables PREROUTING nat iptables POSTROUTING mangle iptables PREROUTING mangle iptables POSTROUTING nat
  18. @lizrice host pod app socket veth veth eth0 iptables conntrack

    iptables INPUT Linux routing iptables PREROUTING mangle Linux routing
  19. @lizrice userspace pod container sidecar container my-app.yaml containers: - name:

    my-app ... - name: my-app-init … - name: my-sidecar ... Sidecars need YAML
  20. @lizrice userspace pod container container my-app.yaml containers: - name: my-app

    ... - name: my-app-init … eBPF does not need app changes kernel
  21. @lizrice Inspect packets → Observability Identity-aware data flows, message parsing,

    security forensics... Drop or modify packets → Security Network policies, encryption... Redirect packets → Networking functions Load balancing, routing, service mesh... eBPF-enabled networking capabilities
