Full Stack Reactive with React and Spring WebFlux - PWX 2019

You have streaming data and want to expose it as reactive streams with Spring Boot. Great! Spring WebFlux makes that pretty easy. But what about the UI? Can you stream that data to the UI and have it be reactive and constantly updating too?

This session explores techniques for making your app fully reactive with Spring WebFlux and React. Mostly live coding, with plenty of time for Q & A in the midst of it all.

* Blog post: Full Stack Reactive with Spring WebFlux, WebSockets, and React
* Screencast of demo: https://youtu.be/1xpwYe154Ys

Transcript

1. Full Stack Reactive with React and Spring WebFlux Matt Raible | @mraible December 4, 2019 Photo by Joey Newcombe flickr.com/photos/ogluc1f3r/14921486525
4. Blogger on raibledesigns.com and developer.okta.com/blog Web Developer and Java Champion Father, Skier, Mountain Biker, Whitewater Rafter Open Source Connoisseur Who is Matt Raible? Bus Lover Okta Developer Advocate
8. developer.okta.com
10. What About You?
11. Full Stack Reactive http://bit.ly/webflux-and-react
12. OAuth 2.0 Overview Today’s Agenda What is reactive programming? Introduction to Spring WebFlux Developing an API with WebFlux Handling Streaming Data with React Securing WebFlux and React
13. What is reactive programming? Asynchronous I/O
14. package com.example.io; import lombok.extern.log4j.Log4j2; import org.springframework.util.FileCopyUtils; import java.io.File; import java.io.FileInputStream; import java.io.IOException; import java.util.function.Consumer; @Log4j2 class Synchronous implements Reader { @Override public void read(File file, Consumer<BytesPayload> consumer) throws IOException { try (FileInputStream in = new FileInputStream(file)) { byte[] data = new byte[FileCopyUtils.BUFFER_SIZE]; int res; while ((res = in.read(data, 0, data.length)) != -1) { consumer.accept(BytesPayload.from(data, res)); } } } }
15. class Asynchronous implements Reader, CompletionHandler<Integer, ByteBuffer> { private int bytesRead; private long position; private AsynchronousFileChannel fileChannel; private Consumer<BytesPayload> consumer; private final ExecutorService executorService = Executors.newFixedThreadPool(10); public void read(File file, Consumer<BytesPayload> c) throws IOException { this.consumer = c; Path path = file.toPath(); this.fileChannel = AsynchronousFileChannel.open(path, Collections.singleton(StandardOpenOption.READ), this.executorService); ByteBuffer buffer = ByteBuffer.allocate(FileCopyUtils.BUFFER_SIZE); this.fileChannel.read(buffer, position, buffer, this); while (this.bytesRead > 0) { this.position = this.position + this.bytesRead; this.fileChannel.read(buffer, this.position, buffer, this); } } @Override public void completed(Integer result, ByteBuffer buffer) { ... } }
16. @Override public void completed(Integer result, ByteBuffer buffer) { this.bytesRead = result; if (this.bytesRead < 0) return; buffer.flip(); byte[] data = new byte[buffer.limit()]; buffer.get(data); consumer.accept(BytesPayload.from(data, data.length)); buffer.clear(); this.position = this.position + this.bytesRead; this.fileChannel.read(buffer, this.position, buffer, this); } @Override public void failed(Throwable exc, ByteBuffer attachment) { log.error(exc); }
17. Reactive Streams
18. Reactive Streams reactive-streams.org
19. Reactive Streams reactive-streams.org
20. Reactive Streams reactive-streams.org
21. Reactive Streams reactive-streams.org
22. Spring WebFlux
23. @SpringBootApplication public class DemoApplication { public static void main(String[] args) { SpringApplication.run(DemoApplication.class, args); } } @Entity class Blog { @Id @GeneratedValue private Long id; private String name; // getters, setters, toString(), etc } @RepositoryRestResource interface BlogRepository extends JpaRepository<Blog, Long> { }
24. Demo: Build a Spring WebFlux API
25. ES6, ES7 and TypeScript ES5: es5.github.io ES6: git.io/es6features ES7: bit.ly/es7features TS: www.typescriptlang.org TS ES7 ES6 ES5
26. @spring_io #springio17 TypeScript
27. “Node.js is a JavaScript runtime built on Chrome's V8 JavaScript engine. Node.js uses an event-driven, non- blocking I/O model that makes it lightweight and efficient. Node.js' package ecosystem, npm, is the largest ecosystem of open source libraries in the world.” https://nodejs.org https://github.com/creationix/nvm
28. Hello World with React http://codepen.io/gaearon/pen/ZpvBNJ?editors=0100 <div id="root"></div> <script> ReactDOM.render( <h1>Hello, world!</h1>, document.getElementById('root') ); </script>
29. Imperative Code if (count > 99) { if (!hasFire()) { addFire(); } } else { if (hasFire()) { removeFire(); } } if (count === 0) { if (hasBadge()) { removeBadge(); } return; } if (!hasBadge()) { addBadge(); } var countText = count > 99 ? "99+" : count.toString(); getBadge().setText(countText);
30. Declarative Code if (count === 0) { return <div className="bell"/>; } else if (count <= 99) { return ( <div className="bell"> <span className="badge">{count}</span> </div> ); } else { return ( <div className="bell onFire"> <span className="badge">99+</span> </div> ); }
31. https://facebook.github.io/create-react-app/
32. Learning React https://vimeo.com/213710634
33. Handling Streaming Data in React Polling with Interval Polling with RxJS WebSocket Server-Sent Events and EventSource RSocket
34. Demo: Build a React Client class ProfileList extends React.Component<ProfileListProps, ProfileListState> { constructor(props: ProfileListProps) { super(props); this.state = { profiles: [], isLoading: false }; } async componentDidMount() { this.setState({isLoading: true}); const response = await fetch('http://localhost:8080/profiles', { headers: { Authorization: 'Bearer ' + await this.props.auth.getAccessToken() } }); const data = await response.json(); this.setState({profiles: data, isLoading: false}); } render() { const {profiles, isLoading} = this.state; ... } }
35. @spring_io #springio17 JHipster jhipster.tech JHipster is a development platform to generate, develop and deploy Spring Boot + Angular/React Web applications and Spring microservices.
36. The JHipster Mini-Book v5.0 Available Now! jhipster-book.com 21-points.com @jhipster_book Write your own InfoQ mini-book! github.com/mraible/infoq-mini-book
37. Action! Try Spring WebFlux Try React Try OIDC Explore PWAs Enjoy the experience!
38. DIY: Full Stack Reactive http://bit.ly/webflux-and-react
39. CRUD with React and Spring Boot http://bit.ly/react-boot-crud
40. #LearnAllTheThings
41. developer.okta.com/blog @oktadev
42. Use the Source, Luke! git clone https://github.com/oktadeveloper/okta-spring-webflux-react- example.git https://github.com/oktadeveloper/okta-spring-webflux-react-example
43. Questions? Keep in touch! @starbuxman @mraible Presentation speakerdeck.com/mraible Code github.com/oktadeveloper
44. @oktadev
