Automating Access Control Lists with OpenDaylight and OpenVSwitch

This presentation shows how globo.com solved a problem with TCAM specialized memory limitation on the top of rack switches through a Software Defined Networking approach.

Transcript

1. Automating Access Control Lists with OpenDaylight and OpenVSwitch Gustavo Pantuza, Leopoldo Mauricio
2. Agenda Context Problem Solution
4. Largest media group in Latin America 17 years
10. Datacenter 5000 s e r v e r s B a n d w i d t h 2.4 Tb/s
11. Fabric PoDs ToR VMs Containers Bare metal
12. Cloud
13. Cloud
14. Xen Clusters Host Hypervisor OvS VMs
15. Xen Clusters
16. Environments Backend - BE Frontend - FE
17. Datacenter Spine Leaf Core ECMP BGP
18. Access Control Lists
19. 50000+ A C L s ACL API
20. Environment segmentation BE FE BE VRF FE VRF BE FE BE VRF FE VRF
21. TCAM Expensive Upgrade Small
23. No policies on networks
24. Moving forward SDN
25. Network API 8000+ Networks 500+ Equipments 6300+ Vlans 1700+ Environments
26. Xen Clusters Host Hypervisor OvS VMs
27. Network API
28. Controller
29. Virtual switch
31. Network API
32. { "kind": "backend#acl", "rules": [{ "action": "permit", "description": "Access from application A on port 80", "destination": "10.0.42.0/24", "id": "222222", "owner": "user", "protocol": "ip", "source": "10.5.190.0/24" }] }
33. { ... }
34. Workers 16 w o r k e r s
35. SDN control 56 s e r v e r s 6 c l u s t e r s
36. Controller requests per second 62.5 r e q s / s e c
38. No first packet delay
39. Network API Resilience
40. Transparent for users
41. Integration of all our cloud services Tsuru https://tsuru.io DBaas https://github.com/globocom/database-as-a-service NetowrkAPI https://github.com/globocom/GloboNetworkAPI ACL API FSaas DNSaaS
42. https://opensource.globo.com/
45. gustavopantuza@gmail.com leomauricio@gmail.com https://github.com/pantuza Linkedin
