Flux (#fluxlang): a new (time series) data scripting language

Talk from InfluxDays London on Flux, the new scripting language being built by InfluxData.

Transcript

1. Flux (#fluxlang): a new (time series) data scripting language Paul Dix @pauldix paul@pauldix.net
2. IFQL -> Flux
3. Data scripting language?
4. MIT License Language & Engine written in Go
5. Talk Structure • Why Flux? • Design & Structure • Motivating Examples
6. Why not SQL?
7. Relational Algebra
8. SQL isn’t the only interpretation!
9. QUEL & POSTGRESQUEL range of E is EMPLOYEE retrieve into W (COMP = E.Salary / (E.Age - 18)) where E.Name = "Jones" select (e.salary / (e.age - 18)) as comp from employee as e where e.name = "Jones" SQL
11. Inertia
12. Additions & Semantics
13. Functional FTW!
14. Rethink Programmer Productivity
15. Language > Query
16. Change Reality
17. Existing Language?
18. Haskell or Lisp!
19. Flux Design Principles
20. Useable
21. Make Everyone a Data Programmer!
22. Readable
23. Flexible
24. Composable
25. Testable
26. Contributable
27. Shareable
28. Beginning Examples
31. showMeasurements(db: "telegraf")
32. showMeasurements(db: "telegraf") Function
33. showMeasurements(db: "telegraf") Named Argument
34. showMeasurements(db: "telegraf") String Literal
35. showTagKeys(db: "telegraf", measurement: "cpu")
36. showTagKeys(db: "telegraf", measurement: "cpu") Named Arguments
37. showTagKeys(db: "telegraf", measurements: ["redis", "mysql"])
38. showTagKeys(db: "telegraf", measurements: ["redis", "mysql"]) Passing an array
39. showTagValues(db: "telegraf", tag: "host")
40. showFieldKeys(db:"telegraf", measurement:"cpu")
41. // get all data from the telegraf db from(db:"telegraf") // filter that by the last hour |> range(start:-1h) // filter further by series with a specific measurement and field |> filter(fn: r => r._measurement == "cpu" and r._field == "usage_system")
42. // get all data from the telegraf db from(db:"telegraf") // filter that by the last hour |> range(start:-1h) // filter further by series with a specific measurement and field |> filter(fn: r => r._measurement == "cpu" and r._field == "usage_system") Comments
43. // get all data from the telegraf db from(db:"telegraf") // filter that by the last hour |> range(start:-1h) // filter further by series with a specific measurement and field |> filter(fn: r => r._measurement == "cpu" and r._field == "usage_system") Duration Literal
44. // get all data from the telegraf db from(db:"telegraf") // filter that by the last hour |> range(start:-1h) // filter further by series with a specific measurement and field |> filter(fn: r => r._measurement == "cpu" and r._field == "usage_system") Pipe forward operator
45. // get all data from the telegraf db from(db:"telegraf") // filter that by the last hour |> range(start:-1h) // filter further by series with a specific measurement and field |> filter(fn: r => r._measurement == "cpu" and r._field == "usage_system") Anonymous Function
46. Operators + == != ( ) - < !~ [ ] * > =~ { } / <= = , : % >= <- . |>
47. Types • int • uint • float64 • string • duration • time • regex • array • object • function • namespace
48. Functions Overview
49. Inputs from, fromKafka, fromFile, fromS3, fromPrometheus, fromMySQL, etc.
50. Outputs to, toKafka, toFile, toS3, toPrometheus, toMySQL, etc.
51. Functions • count • covariance • cumulativeSum • derivative • difference • distinct • filter • first • from • group • integral • mean • min • percentile • range • sample • set • shift • skew • sort • spread • stateTracking • limit • map • max • window • yield • cov • highestMax • highestAverage • highestCurrent • lowestMin • join • last • stddev • sum • lowestAverage • lowestCurrent • pearsonR • stateCount • stateDuration • top • bottom
52. Flux ⊇ Graphite
53. Data Model
54. Example Series _measurement=mem,host=A,region=west,_field=free _measurement=mem,host=B,region=west,_field=free _measurement=cpu,host=A,region=west,_field=usage_system _measurement=cpu,host=A,region=west,_field=usage_user
55. Example Series _measurement=mem,host=A,region=west,_field=free _measurement=mem,host=B,region=west,_field=free _measurement=cpu,host=A,region=west,_field=usage_system _measurement=cpu,host=A,region=west,_field=usage_user Measurement
56. Example Series _measurement=mem,host=A,region=west,_field=free _measurement=mem,host=B,region=west,_field=free _measurement=cpu,host=A,region=west,_field=usage_system _measurement=cpu,host=A,region=west,_field=usage_user Field
57. Table _measurement host region _field _time _value mem A west free 2018-06-14T09:15:00 10 mem A west free 2018-06-14T09:14:50 10
58. _measurement host region _field _time _value mem A west free 2018-06-14T09:15:00 10 mem A west free 2018-06-14T09:14:50 10 Column
59. _measurement host region _field _time _value mem A west free 2018-06-14T09:15:00 10 mem A west free 2018-06-14T09:14:50 10 Record
60. _measurement host region _field _time _value mem A west free 2018-06-14T09:15:00 10 mem A west free 2018-06-14T09:14:50 10 Group Key _measurement=mem,host=A,region=west,_field=free
61. _measurement host region _field _time _value mem A west free 2018-06-14T09:15:00 10 mem A west free 2018-06-14T09:14:50 10 Every record has the same value! _measurement=mem,host=A,region=west,_field=free
62. Table Per Series _measurement host region _field _time _value mem A west free 2018-06-14T09:15:00 10 mem A west free 2018-06-14T09:14:50 11 _measurement host region _field _time _value mem B west free 2018-06-14T09:15:00 20 mem B west free 2018-06-14T09:14:50 22 _measurement host region _field _time _value cpu A west usage_user 2018-06-14T09:15:00 45 cpu A west usage_user 2018-06-14T09:14:50 49 _measurement host region _field _time _value cpu A west usage_system 2018-06-14T09:15:00 35 cpu A west usage_system 2018-06-14T09:14:50 38
63. input tables -> function -> output tables
64. input tables -> function -> output tables // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:50, start:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> sum()
65. input tables -> function -> output tables DateTime Literal // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:50, start:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> sum()
66. input tables -> function -> output tables What to sum on? // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:50, start:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> sum()
67. input tables -> function -> output tables Default columns argument // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:50, start:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> sum(columns: [“_value”])
68. input tables -> function -> output tables _meas ureme host region _field _time _valu e mem A west free 2018-06- 14T09:1 10 mem A west free 2018-06- 14T09:1 11 _meas ureme host region _field _time _valu e mem B west free 2018-06- 14T09:15 20 mem B west free 2018-06- 14T09:14 22 Input in table form // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:50, start:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> sum()
69. input tables -> function -> output tables _meas ureme host region _field _time _valu e mem A west free 2018-06- 14T09:1 10 mem A west free 2018-06- 14T09:1 11 _meas ureme host region _field _time _valu e mem B west free 2018-06- 14T09:15 20 mem B west free 2018-06- 14T09:14 22 sum() // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:50, start:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> sum()
70. input tables -> function -> output tables // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:50, start:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> sum() _meas ureme host region _field _time _valu e mem A west free 2018-06- 14T09:1 10 mem A west free 2018-06- 14T09:1 11 _meas ureme host region _field _time _valu e mem B west free 2018-06- 14T09:15 20 mem B west free 2018-06- 14T09:14 22 sum() _meas ureme host region _field _time _valu e mem A west free 2018-06- 14T09:1 21 _meas ureme host region _field _time _valu e mem B west free 2018-06- 14T09:15 42
71. N to N table mapping (1 to 1 mapping)
72. N to M table mapping
73. window // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:30, end:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> window(every:20s) 30s of data (4 samples)
74. window // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:30, end:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> window(every:20s) split into 20s windows
75. window _meas host region _field _time _valu mem A west free …14:30 10 mem A west free …14:40 11 mem A west free …14:50 12 mem A west free …15:00 13 _meas host region _field _time _valu mem B west free …14:30 20 mem B west free …14:40 22 mem B west free …14:50 23 mem B west free …15:00 24 // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:30, end:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> window(every:20s) Input
76. window _meas host region _field _time _valu mem A west free …14:30 10 mem A west free …14:40 11 mem A west free …14:50 12 mem A west free …15:00 13 _meas host region _field _time _valu mem B west free …14:30 20 mem B west free …14:40 22 mem B west free …14:50 23 mem B west free …15:00 24 window( every:20s) // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:30, end:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> window(every:20s)
77. window _meas host region _field _time _valu mem A west free …14:30 10 mem A west free …14:40 11 mem A west free …14:50 12 mem A west free …15:00 13 _meas host region _field _time _valu mem B west free …14:30 20 mem B west free …14:40 22 mem B west free …14:50 23 mem B west free …15:00 24 window( every:20s) // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:30, end:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> window(every:20s) _meas ureme host region _field _time _valu e mem A west free …14:30 10 mem A west free …14:40 11 _meas ureme host region _field _time _valu e mem B west free …14:50 23 mem B west free …15:00 24 _meas ureme host region _field _time _valu e mem B west free …14:30 20 mem B west free …14:40 22 _meas ureme host region _field _time _valu e mem A west free …14:50 12 mem A west free …15:00 13
78. window _meas host region _field _time _valu mem A west free …14:30 10 mem A west free …14:40 11 mem A west free …14:50 12 mem A west free …15:00 13 _meas host region _field _time _valu mem B west free …14:30 20 mem B west free …14:40 22 mem B west free …14:50 23 mem B west free …15:00 24 window( every:20s) // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:30, end:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> window(every:20s) _meas ureme host region _field _time _valu e mem A west free …14:30 10 mem A west free …14:40 11 _meas ureme host region _field _time _valu e mem B west free …14:50 23 mem B west free …15:00 24 _meas ureme host region _field _time _valu e mem B west free …14:30 20 mem B west free …14:40 22 _meas ureme host region _field _time _valu e mem A west free …14:50 12 mem A west free …15:00 13 N to M tables
79. Window based on time _start and _stop columns
80. group // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:30, end:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> group(keys:[“region"])
81. group // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:30, end:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> group(keys:[“region"]) new partition key
82. group _meas host region _field _time _valu mem A west free …14:30 10 mem A west free …14:40 11 mem A west free …14:50 12 mem A west free …15:00 13 _meas host region _field _time _valu mem B west free …14:30 20 mem B west free …14:40 22 mem B west free …14:50 23 mem B west free …15:00 24 // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:30, end:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> group(keys:[“region"])
83. group _meas host region _field _time _valu mem A west free …14:30 10 mem A west free …14:40 11 mem A west free …14:50 12 mem A west free …15:00 13 _meas host region _field _time _valu mem B west free …14:30 20 mem B west free …14:40 22 mem B west free …14:50 23 mem B west free …15:00 24 group( keys: [“region”]) // example query from(db:"telegraf") |> range(start:2018-06-14T09:14:30, end:2018-06-14T09:15:01) |> filter(fn: r => r._measurement == “mem" and r._field == “free”) |> group(keys:[“region"]) _meas ureme host region _field _time _valu e mem A west free …14:30 10 mem B west free …14:30 20 mem A west free …14:40 11 mem B west free …14:40 21 mem A west free …14:50 12 mem B west free …14:50 22 mem B west free …15:00 13 mem B west free …15:00 23 N to M tables M == cardinality(group keys)
84. Group based on columns
85. Composable & Flexible
86. showTagValues(db: "telegraf", tag: "host")
87. New argument, same function definition showTagValues(db: "telegraf", tag: "host", startTime: 2018-06-14T09:15:00)
88. showTagValues = (db, tag, start=-1h, stop=now(), predicate=(r) => true) => from(db:db) |> range(start:start, stop:stop) |> filter(fn: predicate) |> group(by:[tag]) // get the distinct values for the tag |> distinct(column:tag) // collapse all tables into one |> group(none:true) // drop all columns except _value |> keep(columns: ["_value"])
89. showTagValues = (db, tag, start=-1h, stop=now(), predicate=(r) => true) => from(db:db) |> range(start:start, stop:stop) |> filter(fn: predicate) |> group(by:[tag]) // get the distinct values for the tag |> distinct(column:tag) // collapse all tables into one |> group(none:true) // drop all columns except _value |> keep(columns: ["_value"]) Assign function to variable
90. showTagValues = (db, tag, start=-1h, stop=now(), predicate=(r) => true) => from(db:db) |> range(start:start, stop:stop) |> filter(fn: predicate) |> group(by:[tag]) // get the distinct values for the tag |> distinct(column:tag) // collapse all tables into one |> group(none:true) // drop all columns except _value |> keep(columns: ["_value"]) Specify default argument value to make optional
91. showTagValues = (db, tag, start=-1h, stop=now(), predicate=(r) => true) => from(db:db) |> range(start:start, stop:stop) |> filter(fn: predicate) |> group(by:[tag]) // get the distinct values for the tag |> distinct(column:tag) // collapse all tables into one |> group(none:true) // drop all columns except _value |> keep(columns: ["_value"]) now function
92. showTagValues = (db, tag, start=-1h, stop=now(), predicate=(r) => true) => from(db:db) |> range(start:start, stop:stop) |> filter(fn: predicate) |> group(by:[tag]) // get the distinct values for the tag |> distinct(column:tag) // collapse all tables into one |> group(none:true) // drop all columns except _value |> keep(columns: ["_value"]) pass function as argument
93. showTagValues = (db, tag, start=-1h, stop=now(), predicate=(r) => true) => from(db:db) |> range(start:start, stop:stop) |> filter(fn: predicate) |> group(by:[tag]) // get the distinct values for the tag |> distinct(column:tag) // collapse all tables into one |> group(none:true) // drop all columns except _value |> keep(columns: ["_value"])
94. showTagValues( db:"telegraf", tag:"host", predicate: (r) => r._measurement == "redis")
95. Defining functions that take inputs // convert all values into floats from(db:"telegraf") |> range(start:-1h) |> filter(fn: (r) => r._measurement == "foo") |> map(fn: (r) => float(v:r._value))
96. Defining functions that take inputs // convert all values into floats from(db:"telegraf") |> range(start:-1h) |> filter(fn: (r) => r._measurement == "foo") |> map(fn: (r) => float(v:r._value)) map function
97. Defining functions that take inputs // convert all values into floats from(db:"telegraf") |> range(start:-1h) |> filter(fn: (r) => r._measurement == "foo") |> map(fn: (r) => float(v:r._value)) float function
98. Defining functions that take inputs // convert all values into floats from(db:"telegraf") |> range(start:-1h) |> filter(fn: (r) => r._measurement == "foo") |> map(fn: (r) => float(v:r._value)) only named arguments!
99. Defining functions that take inputs // convert all values into floats from(db:"telegraf") |> range(start:-1h) |> filter(fn: (r) => r._measurement == "foo") |> map(fn: (r) => float(v:r._value)) make this a function?
100. Defining functions that take inputs castToFloat = (table=<-) { return table |> map(fn: (r) => float(v:r._value)) } user defined pipe forwardable function
101. Defining functions that take inputs // calling it from(db:"telegraf") |> range(start:-1h) |> filter(fn: (r) => r._measurement == "foo") |> castToFloat()
102. Defining functions that take inputs // convert all values into floats from(db:"telegraf") |> range(start:-1h) |> filter(fn: (r) => r._measurement == "foo") |> map(fn: (r) => float(v:r._value)) castToFloat = (table=<-) { return table |> map(fn: (r) => float(v:r._value)) } from(db:"telegraf") |> range(start:-1h) |> filter(fn: (r) => r._measurement == "foo") |> castToFloat()
103. Any pipe forward function can use arguments min(table: range(start: -1h, table: filter(fn: (r) => r.host == "server0", table: from(db: "mydb"))))
104. Make you a Lisp
105. New Query Functionality finally getting to those feature requests!
107. Math across measurements foo = from(db: "mydb") |> filter(fn: (r) => r._measurement == "foo") |> range(start: -1h) bar = from(db: "mydb") |> filter(fn: (r) => r._measurement == "bar") |> range(start: -1h) join( tables: {foo:foo, bar:bar}, on: [“foobar”, “_time”], fn: (t) => t.foo._value + t.bar._value, ) |> yield(name: "foobar")
109. Having Query from(db:"mydb") |> filter(fn: (r) => r._measurement == "cpu" and r._field == “usage_system”) |> range(start:-1h) |> window(every:10m) |> mean() // this is the having part |> filter(fn: (r) => r._value > 90)
110. Shareable
111. Imports and Namespaces import "math" from(db:"mydb") |> filter(fn: (r) => r.host == "server0") |> range(start: -1h) |> math.square()
112. Imports and Namespaces import "math" from(db:"mydb") |> filter(fn: (r) => r.host == "server0") |> range(start: -1h) |> math.square() namespace
113. Package Manager
114. Imports and Namespaces import “pauldix/math" from(db:"mydb") |> filter(fn: (r) => r.host == "server0") |> range(start: -1h) |> math.square() Username like RubyGems
115. Public Package Repository (like RubyGems, npm, etc.)
116. Imports and Namespaces import “github.com/pauldix/math” from(db:"mydb") |> filter(fn: (r) => r.host == "server0") |> range(start: -1h) |> math.square() Or from Github
117. Difficult SQL Queries
118. Exponential Moving Average from(db:"telegraf") |> range(start:-1h) |> filter(fn: (r) => r._measurement == "foo") |> exponentialMovingAverage(size:-10s)
119. SQL rolling average select id, temp, avg(temp) over (partition by group_nr order by time_read) as rolling_avg from ( select id, temp, time_read, interval_group, id - row_number() over (partition by interval_group order by time_read) as group_nr from ( select id, time_read, 'epoch'::timestamp + '900 seconds'::interval * (extract(epoch from time_read)::int4 / 900) as interval_group, temp from readings ) t1 ) t2 order by time_read;
120. Alerting import “alert” from(db:"telegraf") |> range(start: -1m) |> filter(fn: (r) => r._measurement == "work_queue" and r._field == "depth") |> mean() |> alert.track( warn: (r) => r._value > 200, crit: (r) => r._value > 500) |> alert.limit(duration:1m) |> toSlack(config: loadConfig(key: "slack"))
121. Wrap up
122. Get the nightlies! InfluxDB, Flux, Chronograf http://influxdata.com/download
123. Get the code, file issues! https://github.com/influxdata/platform
124. SQL is a great thing
125. But it’s not the only thing
126. Thank you Paul Dix @pauldix paul@influxdata.com
