Lynn Root - Tracing, Fast and Slow: Digging into and improving your web service’s performance

Do you maintain a [Rube Goldberg](https://s-media-cache-ak0.pinimg.com/564x/92/27/a6/9227a66f6028bd19d418c4fb3a55b379.jpg)-like service? Perhaps it’s highly distributed? Or you recently walked onto a team with an unfamiliar codebase? Have you noticed your service responds slower than molasses? This talk will walk you through how to pinpoint bottlenecks, approaches and tools to make improvements, and make you seem like the hero! All in a day’s work.

The talk will describe various types of tracing a web service, including black & white box tracing, tracing distributed systems, as well as various tools and external services available to measure performance. I’ll also present a few different rabbit holes to dive into when trying to improve your service’s performance.

https://us.pycon.org/2017/schedule/presentation/565/

Transcript

1. Lynn Root | SRE | @roguelynn Tracing: Fast & Slow Digging into and improving your web service’s performance
2. $ whoami
3. —
4. agenda —
5. agenda • Overview and problem space —
6. agenda • Overview and problem space • Approaches to tracing —
7. agenda • Overview and problem space • Approaches to tracing • Tracing at scale —
8. agenda • Overview and problem space • Approaches to tracing • Tracing at scale • Diagnosing performance issues —
9. agenda • Overview and problem space • Approaches to tracing • Tracing at scale • Diagnosing performance issues • Tracing services & systems —
10. Tracing Overview —
11. machine-centric • Focus on a single machine —
12. machine-centric • Focus on a single machine • No view into a service’s dependencies —
13. workflow-centric • Understand causal relationships —
14. workflow-centric • Understand causal relationships • End-to-end tracing —
16. why trace? —
17. why trace? • Performance analysis —
18. why trace? • Performance analysis • Anomaly detection —
19. why trace? • Performance analysis • Anomaly detection • Profiling —
20. why trace? • Performance analysis • Anomaly detection • Profiling • Resource attribution —
21. why trace? • Performance analysis • Anomaly detection • Profiling • Resource attribution • Workload modeling —
22. Tracing Approaches —
23. manual
24. def request_id(f): @wraps(f) def decorated(*args, **kwargs): req_id = request.headers.get( "X-Request-Id", uuid.uuid4()) return f(req_id, *args, **kwargs) return decorated @app.route("/") @request_id def list_services(req_id): # log w/ ID for wherever you want to trace # app logic
25. upstream appserver { 10.0.0.0:80; } server { listen 80; # Return to client add_header X-Request-ID $request_id; location / { proxy_pass http://appserver; # Pass to app server proxy_set_header X-Request-ID $request_id; } }
26. log_format trace '$remote_addr … $request_id'; server { listen 80; add_header X-Request-ID $request_id; location / { proxy_pass http://app_server; proxy_set_header X-Request-ID $request_id; # Log $request_id access_log /var/log/nginx/access_trace.log trace; } }
27. blackbox
28. metadata propagation
30. Tracing at Scale —
31. four things to think about —
32. four things to think about • What relationships to track —
33. four things to think about • What relationships to track • How to track them —
34. four things to think about • What relationships to track • How to track them • Which sampling approach to take —
35. four things to think about • What relationships to track • How to track them • Which sampling approach to take • How to visualize to employ —
36. what to track
37. Request One Request Two Submitter Flow PoV
38. Request One Request Two Trigger Flow PoV
39. how to track
40. request ID
41. request ID + logical clock
42. request ID + logical clock + previous trace points
43. tradeoffs —
44. tradeoffs • Payload size —
45. tradeoffs • Payload size • Explicit relationships —
46. tradeoffs • Payload size • Explicit relationships • Collate despite lost data —
47. tradeoffs • Payload size • Explicit relationships • Collate despite lost data • Immediate availability —
48. how to sample
49. sampling approaches • Head-based —
50. sampling approaches • Head-based • Tail-based —
51. sampling approaches • Head-based • Tail-based • Unitary —
52. what to visualize
53. gantt chart — GET /home GET /feed GET /profile GET /messages GET /friends Trace ID: de4db33f
54. — request flow graph A call B call C call C call D call E call E reply D reply B reply C reply C reply A reply 2200µs 1500µs 500µs 300µs 400µs 600µs 800µs 500µs 500µs 700µs 500µs 400µs 600µs 100µs
55. — context calling tree A B C C D E
56. keep in mind • What do I want to know? —
57. keep in mind • What do I want to know? • How much can I instrument? —
58. keep in mind • What do I want to know? • How much can I instrument? • How much do I want to know? —
59. suggested for performance —
60. suggested for performance — • Trigger PoV
61. suggested for performance — • Trigger PoV • Head-based sampling
62. suggested for performance — • Trigger PoV • Head-based sampling • Flow graphs
63. Diagnosing —
64. questions to ask — • Batch requests?
65. questions to ask • Batch requests? • Any parallelization opportunities? —
66. questions to ask • Batch requests? • Any parallelization opportunities? • Useful to add/fix caching? —
67. questions to ask • Batch requests? • Any parallelization opportunities? • Useful to add/fix caching? • Frontend resource loading? —
68. questions to ask • Batch requests? • Any parallelization opportunities? • Useful to add/fix caching? • Frontend resource loading? • Chunked or JIT responses? —
69. Systems & Services —
70. OpenTracing
71. self-hosted
72. Zipkin (Twitter) —
73. Zipkin (Twitter) • Out-of-band reporting to remote collector —
74. Zipkin (Twitter) • Out-of-band reporting to remote collector • Report via HTTP, Kafka, and Scribe —
75. Zipkin (Twitter) • Out-of-band reporting to remote collector • Report via HTTP, Kafka, and Scribe • Python libs only support propagation via HTTP —
76. Zipkin (Twitter) • Out-of-band reporting to remote collector • Report via HTTP, Kafka, and Scribe • Python libs only support propagation via HTTP • Limited web UI —
77. def http_transport(span_data): requests.post( "http://zipkinserver:9411/api/v1/spans", data=span_data, headers={"Content-type": "application/x-thrift"}) @app.route("/") def index(): with zipkin_span(service_name="myawesomeapp", span_name="index", # need to write own transport func transport_handler=http_transport, port=app_port, # 0-100 percent sample_rate=100): # do something
78. Jaeger (Uber) —
79. Jaeger (Uber) • Local daemon to collect & report —
80. Jaeger (Uber) • Local daemon to collect & report • Storage support for only Cassandra —
81. Jaeger (Uber) • Local daemon to collect & report • Storage support for only Cassandra • Lacking in documentation —
82. Jaeger (Uber) • Local daemon to collect & report • Storage support for only Cassandra • Lacking in documentation • Cringe-worthy client library —
83. import opentracing as ot config = Config(…) tracer = config.initialize_tracer() @app.route("/") def index(): with ot.tracer.start_span("ASpan") as span: span.log_event("test message", payload={"life": 42}) with ot.tracer.start_span("AChildSpan", child_of=span) as cspan: span.log_event("another test message") # wat time.sleep(2) # yield to IOLoop to flush the spans tracer.close() # flush any buffered spans
84. honorable mentions • AppDash • LightStep (private beta) —
85. services
86. Stackdriver Trace (Google) —
87. Stackdriver Trace (Google) • No Python client libraries; no gRPC client support —
88. Stackdriver Trace (Google) • No Python client libraries; no gRPC client support • Forward traces from Zipkin —
89. Stackdriver Trace (Google) • No Python client libraries; no gRPC client support • Forward traces from Zipkin • Storage limitation of 30 days —
90. X-Ray (AWS) —
91. X-Ray (AWS) • No first class Python support; Boto available —
92. X-Ray (AWS) • No first class Python support; Boto available • Configurable sampling, but not for Boto —
93. X-Ray (AWS) • No first class Python support; Boto available • Configurable sampling, but not for Boto • Flow graphs with latency, response %, sample % —
94. honorable mentions • Datadog • New Relic —
95. TL;DR —
96. tl;dr — • You need this
97. tl;dr — • You need this • Docs are lacking
98. tl;dr — • You need this • Docs are lacking • Language support lacking
99. tl;dr — • You need this • Docs are lacking • Language support lacking • One size fits all approaches
100. tl;dr — • You need this • Docs are lacking • Language support lacking • One size fits all approaches • But there’s an open spec!
101. Thanks! — Sources & links: rogue.ly/tracing Lynn Root | SRE | @roguelynn
