PWLNYC - IronFleet

A whirlwind introduction to IronFleet.
Materials at: https://github.com/Randommood/PWLNYC2016

1. PWL NYC IRONFLEET (An extremely opinionated introduction)
2. Ines
 Sombra About Me @randommood
3. System verification My IronFleet Pitch Parting Thoughts Our Journey TODAY
4. 15”
5. The GOAL
6. Formal Methods “Scholarly” Testing The WAYS
7. Formal Methods Correctness tied to a specification (that you provide) & then you implement it FMs when applied correctly tend to result in systems with the highest integrity Usually targeted to smaller components. High investment + high rewards
8. Tedious, slow, and difficult to get right... (and then you still have to implement it)
9. Safety Liveness Something bad never happens Formal Methods find invariant violations to show if safety is not provided Something good eventually happens Ensuring liveness is critical, since a liveness bug may render the entire system unavailable
10. Only need to reason about two system states at a time A behavior is safe if each step between states preserves the system’s invariants Reasoning about infinite series of system states Challenging for automated theorem provers (timeouts are very likely) Safety Liveness
11. Only need to reason about two system states at a time A behavior is safe if each step between states preserves the system’s invariants Reasoning about infinite series of system states Challenging for automated theorem provers (timeouts are very likely) Safety Liveness HARD! !
12. I’m tired!
14. Practical formal verification of (non-trivial) distributed systems is a long time away
15. Practical formal verification of (non-trivial) distributed systems is a long time away Wrong? "
16. IronFleet introduces A methodology that slices a system into specific layers to make verification of practical distributed system implementations feasible
17. High level spec Distributed protocol Implementation Plus
 Refinements!
18. First system to mechanically verify liveness properties of a practical protocol & its implementation Ironfleet, you want to read it
19. Proofs that reason all the way down to the bytes of the UDP packets sent on the network, guaranteeing correctness despite packet drops, reorderings, or duplications Ironfleet really, go read it
20. Two Distributed Systems Paxos-based replicated- state-machine library Distribution for reliability 18,200 requests/second Sharded key-value store Distribution for improved throughput /moving “hot” keys to dedicated machine 28,800 requests/second IRONRSL IRONKV
21. Two Distributed Systems Prove complete functional correctness & its key liveness property: if the network is eventually synchronous for a live quorum of replicas, then a client repeatedly submitting a request eventually receives a reply IRONRSL GUARANTEES Proved complete functional correctness & an important liveness property: if the network is fair then the reliable-transmission component eventually delivers each message IRONKV GUARANTEES
22. VERIFICATION OVERVIEW
23. High level specification Specs for IronRSL - 85 lines & KV - 34 lines!
24. Abstract distributed protocol Introduces the concept of individual hosts that communicate only via network messages Prove that the distributed protocol-based specification is a refinement of the top-level specification, and for this TLA-style techniques are used as embodied in the Dafny language
25. Implementation Writes single-threaded imperative code to run on each host using Dafny Prove that the host implementation refines the host state machine in the distributed protocol layer Show that a distributed system comprising N host implementations refines the distributed protocol of N hosts
29. The developer UX
30. The developer UX “Dafny provides near-real-time IDE- integrated feedback. As the developer writes a given method or proof, she typically sees feedback in 1–10 seconds indicating whether the verifier is satisfied...“
31. The developer UX “Our build system tracks dependencies across files and outsources, in parallel, each file’s verification to a cloud virtual machine. Thus, while a full integration build done serially requires approximately six hours, in practice, the developer rarely waits more than 6–8 minutes”
32. “IronRSL (including replication, view changes, log truncation, batching, etc.) & IronKV (including delegation and reliable delivery) worked the first time we ran them.”
33. Want!
34. Used TLA embedding to build a library of fundamental TLA proof rules verified from first principles… which is a useful artifact for proving liveness properties More IronFleet tricks
35. A few questions What will out tests look like going forward? Libraries of TLA+ methods for liveness Tricks for verifying imperative code, weird?
36. THANK YOU! github.com/Randommood/ PWLNYC2016
