Making Microservices Micro with Istio Service Mesh

Ray Tsang
November 09, 2017

Making Microservices Micro with Istio Service Mesh

Presented at Devoxx Belgium 2017
Video: https://youtu.be/AGztKw580yQ
Microservices are here to stay. When applied properly, microservices techniques and culture ultimately help us continuously improve business at a faster pace than traditional architecture. However, microservices architecture itself can be complex to configure. All of a sudden, we are faced with the need for a service discovery server, how do we store service metadata, make decisions on whether to use client side load balancing or server side load balancing, deal with network resiliency, think how do we enforce service policies and audit, trace nested services calls.... The list goes on.

In this talk, Ray will introduce Istio, an open source service mesh framework created by Google, IBM, and Lyft. We'll see how the service mesh work, the technology behind it, and how it addresses aforementioned concerns.

Ray Tsang

November 09, 2017
Tweet

More Decks by Ray Tsang

Other Decks in Technology

Transcript

  1. 4 @saturnism @googlecloud @istiomesh @kubernetesio Microservices? You probably heard a

    lot already! No theories here - just a how to solve problems
  2. 9 @saturnism @googlecloud @istiomesh @kubernetesio apiVersion: extensions/v1beta1 kind: Deployment metadata:

    name: work-server-v1 ... spec: replicas: 2 template: ... spec: containers: - name: work-server image: saturnism/work-server-istio:v1
  3. 10 @saturnism @googlecloud @istiomesh @kubernetesio web browsers Scheduler kubectl web

    browsers scheduler Kubelet Kubelet Kubelet Kubelet Config file Kubernetes Master Container Image
  4. 11 @saturnism @googlecloud @istiomesh @kubernetesio Control Plane Cluster of machines

    as one Well-defined API & types Abstraction of infrastructure
  5. 14 @saturnism @googlecloud @istiomesh @kubernetesio Beyond Deployment Load Balancing Fault

    Tolerance Observability & Insight Monitoring & Tracing Circuit Breaking
  6. 15 @saturnism @googlecloud @istiomesh @kubernetesio Popular Open Source Tools Eureka

    - Service Registry Ribbon - Client Side LB Hystrix - Circuit Breaker Zipkin - Distributed Tracing Prometheus - Monitoring Grafana - Data Visualization
  7. 16 @saturnism @googlecloud @istiomesh @kubernetesio Eureka Service Registry Zuul API

    Gateway Zipkin Distributed Trace Prometheus Metrics Store Grafana Visualization Microservice A Ribbon Hystrix Tracer Metrics Archaius Centralized Config
  8. 17 @saturnism @googlecloud @istiomesh @kubernetesio Microservice A Ribbon Hystrix Tracer

    Metrics Microservice A Ribbon Hystrix Tracer Metrics Microservice A Ribbon Hystrix Tracer Metrics Microservice B Ribbon Hystrix Tracer Metrics Eureka Service Registry
  9. 20 @saturnism @googlecloud @istiomesh @kubernetesio At the end of the

    day... Let Microservice A talk to Microservice B!
  10. 23 @saturnism @googlecloud @istiomesh @kubernetesio What Where When How A

    complete framework for connecting, securing, managing and monitoring services Secure and monitor traffic for microservices and legacy services An open platform with key contributions from Google, IBM, Lyft and others Multi-environment and multi-platform, but Kubernetes first
  11. 24 @saturnism @googlecloud @istiomesh @kubernetesio Control Plane Service to Service

    Communication Routing Rules Retries Circuit Breaker Performance Monitoring Tracing
  12. 25 @saturnism @googlecloud @istiomesh @kubernetesio Eureka Service Registry Zuul API

    Gateway Zipkin Distributed Trace Prometheus Metrics Store Grafana Visualization Microservice A Ribbon Hystrix Tracer Metrics Archaius Centralized Config
  13. 26 @saturnism @googlecloud @istiomesh @kubernetesio Eureka Service Registry Zuul API

    Gateway Zipkin Distributed Trace Prometheus Metrics Store Grafana Visualization Microservice A Ribbon Hystrix Tracer Metrics Archaius Centralized Config
  14. 27 @saturnism @googlecloud @istiomesh @kubernetesio Eureka Service Registry Zuul API

    Gateway Zipkin Distributed Trace Prometheus Metrics Store Grafana Visualization Microservice A Ribbon Hystrix Tracer Metrics Archaius Centralized Config
  15. 29 @saturnism @googlecloud @istiomesh @kubernetesio A C++ based L4/L7 proxy

    Low memory footprint Battle-tested @ Lyft 100+ services 10,000+ VMs 2M req/s An awesome team willing to work with the community!
  16. 30 @saturnism @googlecloud @istiomesh @kubernetesio Dynamic service discovery Load balancing

    TLS termination HTTP/2 gRPC proxying Circuit breakers Health checks Traffic split Fault injection ...
  17. 33 @saturnism @googlecloud @istiomesh @kubernetesio Proxy Microservice A Proxy Microservice

    B Service calls http://service-b/ Service Mesh transparently intercepts request, forwards to local proxy
  18. 34 @saturnism @googlecloud @istiomesh @kubernetesio Proxy Microservice A Proxy Microservice

    B Service calls http://service-b/ Service Mesh transparently intercepts request, forwards to local proxy Proxy has a list of destinations, load balances the request to a destination proxy
  19. 35 @saturnism @googlecloud @istiomesh @kubernetesio Proxy Microservice A Proxy Microservice

    B Service calls http://service-b/ Service Mesh transparently intercepts request, forwards to local proxy Proxy has a list of destinations, load balances the request to a destination proxy If allowed, destination proxy forwards the request to Service B instance
  20. 36 @saturnism @googlecloud @istiomesh @kubernetesio Proxy Microservice A Proxy Microservice

    B Service calls http://service-b/ Service Mesh transparently intercepts request, forwards to local proxy Proxy has a list of destinations, load balances the request to a destination proxy Destination proxy checks with a mixer to enforce policy, quota, ACL, etc Service B response goes back to the caller
  21. 37 @saturnism @googlecloud @istiomesh @kubernetesio Proxy Microservice A Proxy Microservice

    B Service calls http://service-b/ Service Mesh transparently intercepts request, forwards to local proxy Proxy has a list of destinations, load balances the request to a destination proxy Destination proxy checks with a mixer to enforce policy, quota, ACL, etc If allowed, destination proxy forwards the request to Service B instance Service B response goes back to the caller
  22. 38 @saturnism @googlecloud @istiomesh @kubernetesio Proxy Microservice A Proxy Microservice

    B Through the Proxy - Traffic Control - enforce routing rules & policies - Resiliency - Circuit Breaker, Retries - Monitoring - Record metrics - Observability - Record traces - Security - Mutual TLS! Encryption
  23. 39 @saturnism @googlecloud @istiomesh @kubernetesio Platform Services Proxy Microservice A

    Proxy Microservice B Zipkin Prometheus Grafana Istio Mixer
  24. 40 @saturnism @googlecloud @istiomesh @kubernetesio or Cloud Platform Services Proxy

    Microservice A Proxy Microservice B ... BlueMix Google Cloud Istio Mixer
  25. 42 @saturnism @googlecloud @istiomesh @kubernetesio Pod Istio Proxy Service A

    Istio CA istio:*.myorg.com SAN: “Istio:foo.prod.myorg.com” - Service account: foo - Namespace: prod Service B Istio Proxy Pod SAN: “Istio:bar.prod.myorg.com” - Service account: bar - Namespace: prod istio:*.myorg.com istio:*.myorg.com Issue & mount as k8s secrets Orchestrate Key & Certificate: - Generation - Deployment - Rotation - Revocation
  26. 44 @saturnism @googlecloud @istiomesh @kubernetesio • 0.1: a single Kubernetes

    namespace • 0.2 (just launched): a single Kubernetes cluster and external VMs • 0.3 (by end of year): production readiness within a single cluster • 1.0: (2018): complete mesh across all environments
  27. 45 @saturnism @googlecloud @istiomesh @kubernetesio • Install Kubernetes (v1.7+ for

    Initializers) ◦ Google Container Engine Alpha clusters • istio.io quickstart • Helm chart ◦ helm install incubator/istio • Take a lab! Getting started
  28. 46 @saturnism @googlecloud @istiomesh @kubernetesio 46 Learn more on istio.io

    Let us know on [email protected] Examples on github.com/saturnism/istio-by-example-java Try our Code Labs g.co/codelabs/cloud! Thank you!
