Spring on Google Cloud Platform

Spring on Google Cloud Platform

Pivotal and Google Cloud Platform (GCP) collaborate on a number of projects—including Pivotal Cloud Foundry Service Broker for GCP and Spring Boot starters—that make it easy to leverage GCP's managed services, whether you are starting a new project or migrating an existing on-premise project.

In this talk, we'll examine different GCP-created tools that help you develop and run Java and Spring applications, such as Spring Cloud GCP. In addition, we'll look at the different runtime environments that you can deploy to, such as Google Kubernetes Engine, App Engine, and Pivotal Cloud Foundry with GCP Service Broker.

Finally, we'll go over some of the platform services that help you monitor, troubleshoot, profile, and debug your Java production application.

Webinar: https://content.pivotal.io/webinars/jul-12-spring-on-google-cloud-platform-webinar

Ray Tsang

July 12, 2018
Tweet

More Decks by Ray Tsang

Other Decks in Technology

Transcript

  1. 3 @saturnism @gcpcloud Compute Big Data BigQuery Cloud Dataflow Cloud

    Dataproc Cloud Datalab Cloud Pub/Sub Genomics Storage & Databases Cloud Storage Cloud Bigtable Cloud Datastore Cloud SQL Cloud Spanner Persistent Disk Machine Learning Cloud Machine Learning Cloud Vision API Cloud Speech API Cloud Natural Language API Cloud Translation API Cloud Jobs API Data Studio Cloud Dataprep Cloud Video Intelligence API Advanced Solutions Lab Compute Engine App Engine Kubernetes Engine GPU Cloud Functions Container- Optimized OS Identity & Security Cloud IAM Cloud Resource Manager Cloud Security Scanner Key Management Service BeyondCorp Data Loss Prevention API Identity-Aware Proxy Security Key Enforcement Data Transfer Appliance
  2. 7 @saturnism @gcpcloud Goals Provide integration between GCP services and

    Spring Meet developers where they are Cut down on boilerplate code +
  3. 8 @saturnism @gcpcloud Collaboration with Pivotal Developed GitHub in the

    spring-cloud-gcp repository under the Spring Cloud organization owned by Pivotal. Close collaboration between Google and Pivotal engineers.
  4. 9 @saturnism @gcpcloud Feature GCP Service Spring Framework Configuration Cloud

    Runtime Config Spring Cloud Config Messaging Cloud Pub/Sub Spring Integration Spring Cloud Stream Spring Dataflow Database Cloud SQL Cloud Spanner Spring Data Spring Data Spanner Storage Cloud Storage Spring Resource Logging Stackdriver Logging Logback Trace Stackdriver Trace Spring Cloud Sleuth Spring Boot Starters for...
  5. 13 @saturnism @gcpcloud Cloud SQL Managed MySQL and PostgreSQL Scale

    out with read replicas High availability (HA) option Per-minute billing Instance sizes to fit any budget Granular access control using IAM roles
  6. 15 @saturnism @gcpcloud Message Processor Processor 2 Processor N ...

    Google Cloud Pub/Sub Google Cloud SQL database Spring Boot app
  7. 16 @saturnism @gcpcloud Managed Global Messaging Middleware Capture, pass messages

    across services At-least- once delivery semantics Configurable message retention policies Push/Pull message delivery patterns Cloud Pub/Sub
  8. 18 @saturnism @gcpcloud pom.xml <dependency> <groupId>org.springframework.cloud</groupId> <artifactId>spring-cloud-gcp-starter-pubsub</artifactId> </dependency> Code @Autowired

    PubSubTemplate pubSubTemplate; public void hello(String name) { pubSubTemplate.publish("my-topic", name + " said Hi"); }
  9. 21 @saturnism @gcpcloud Also Integrated Pub/Sub with... Spring Framework Use

    Case Spring Integration Enterprise Integration Pattern Middleware-Agnostic Code Spring Cloud Stream Event-driven Microservices Reactive Programming Middleware-Agnostic Code
  10. 22 @saturnism @gcpcloud Scalable mission-critical RDBMS Relational semantics Schemas, ACID

    transactions, SQL query Scale horizontally Automatic, synchronous replication 99.999% Availability Cloud Spanner
  11. 24 @saturnism @gcpcloud Code @RepositoryRestResource public interface PersonRestRepository extends SpannerRepository<Person,

    Long> { public List<Person> findPersonByName(String name); @Query("SELECT * FROM person WHERE ...") public List<Event> findPersonWithQuery(String location); }
  12. 31 @saturnism @gcpcloud Feature GCP Service Spring Framework Configuration Cloud

    Runtime Config Spring Cloud Config Messaging Cloud Pub/Sub Spring Integration Spring Cloud Stream Spring Dataflow Database Cloud SQL Cloud Spanner Spring Data Spring Data Spanner Storage Cloud Storage Spring Resource Logging Stackdriver Logging Logback Trace Stackdriver Trace Spring Cloud Sleuth Spring Boot Starters for...
  13. 36 @saturnism @gcpcloud pom.xml <dependency> <groupId>com.google.cloud</groupId> <artifactId>google-cloud-vision</artifactId> </dependency> Code @Bean

    public ImageAnnotatorClient imageAnnotatorClient( CredentialsProvider credentialsProvider) throws IOException { ImageAnnotatorSettings clientSettings = ImageAnnotatorSettings.newBuilder() .setCredentialsProvider(credentialsProvider) .build(); return ImageAnnotatorClient.create(clientSettings); }
  14. 40 @saturnism @gcpcloud Jib - building container images https://github.com/GoogleContainerTools/jib Fast

    - Automatically split application into layers based on application dependency. Reproducible - Rebuilding your container image with the same contents always generates the same image. Daemonless - Reduce CLI dependencies. Build container image from within Maven or Gradle and push to any registry of your choice. No more writing Dockerfiles and calling docker build/push. Small - Uses Google's Distroless base image,
  15. 43 @saturnism @gcpcloud Pivotal Cloud Foundry Support Native - Google

    and Pivotal engineers built support for PCF on GCP. Use things like global load balancing and pre-emptible VMs to scale applications or reduce cost. Integrated - The GCP Service Broker lets developers provision and use Google services in their apps without manually creating and managing resources in the console. Observable - Stackdriver debugging, monitoring, and logging make it easy to observe your Spring applications deployed to PCF on GCP.
  16. 44 @saturnism @gcpcloud GCP Service Broker for Cloud Foundry VIRTUAL

    NETWORK LOAD BALANCING CDN DNS INTERCONNECT Management Compute Storage Networking Data Machine Learning STACKDRIVER IDENTITY AND ACCESS MANAGEMENT CLOUD ML SPEECH API VISION API TRANSLATE API 44 NATURAL LANGUAGE API
  17. 45 @saturnism @gcpcloud cf create-service SERVICE PLAN SERVICE_INSTANCE [-c PARAMETERS_AS_JSON]

    [-t TAGS] # generated topic name, no subscription $ cf create-service pubsub default orders # generated topic name, with a subscription $ cf create-service pubsub default orders -c \ '{"topic-name": "orders", "subscription-name": "accounting"}' cf bind-service APP_NAME SERVICE_INSTANCE [-c PARAMETERS_AS_JSON] [--binding-name BINDING_NAME] $ cf bind-service accounting-database orders -c '{"role": "pubsub.subscriber"}' $ cf bind-service website orders -c '{"role": "pubsub.publisher"}'
  18. 48 @saturnism @gcpcloud pom.xml <dependency> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-actuator</artifactId> </dependency> <dependency> <groupId>io.micrometer</groupId>

    <artifactId>micrometer-registry-prometheus</artifactId> <scope>runtime</scope> </dependency> Prometheus Endpoint $ curl http://localhost:8080/actuator/prometheus
  19. 49 @saturnism @gcpcloud jvm_gc_max_data_size_bytes 8.9653248E7 tomcat_global_request_seconds_count{name="http-nio-8080",} 322145.0 tomcat_global_request_seconds_sum{name="http-nio-8080",} 748.139 process_uptime_seconds

    26874.681 tomcat_global_error_total{name="http-nio-8080",} 1.0 jvm_buffer_memory_used_bytes{id="direct",} 294913.0 jvm_buffer_memory_used_bytes{id="mapped",} 0.0 tomcat_servlet_request_max_seconds{name="default",} 0.0 system_cpu_usage 0.06456190138346932 process_files_max 1048576.0 http_server_requests_seconds_count{exception="None",method="GET",status="200",uri="/**",} 322111.0 http_server_requests_seconds_sum{exception="None",method="GET",status="200",uri="/**",} 527.459778932 http_server_requests_seconds_count{exception="None",method="GET",status="404",uri="/webjars/**",} 1.0 http_server_requests_seconds_sum{exception="None",method="GET",status="404",uri="/webjars/**",} 0.026788256 http_server_requests_seconds_count{exception="None",method="GET",status="304",uri="/**",} 33.0 http_server_requests_seconds_sum{exception="None",method="GET",status="304",uri="/**",} 0.171848745 http_server_requests_seconds_count{exception="None",method="GET",status="200",uri="/api/gateway/owners/{ownerId}",} 3.0 http_server_requests_seconds_sum{exception="None",method="GET",status="200",uri="/api/gateway/owners/{ownerId}",} 1.247613785 http_server_requests_seconds_max{exception="None",method="GET",status="200",uri="/**",} 0.073825406 http_server_requests_seconds_max{exception="None",method="GET",status="404",uri="/webjars/**",} 0.0 http_server_requests_seconds_max{exception="None",method="GET",status="304",uri="/**",} 0.0 http_server_requests_seconds_max{exception="None",method="GET",status="200",uri="/api/gateway/owners/{ownerId}",} 0.0 system_cpu_count 2.0 tomcat_threads_busy{name="http-nio-8080",} 0.0 tomcat_sessions_active_max 0.0 jvm_threads_live 69.0 tomcat_servlet_request_seconds_count{name="default",} 0.0 tomcat_servlet_request_seconds_sum{name="default",} 0.0 jvm_memory_committed_bytes{area="nonheap",id="Code Cache",} 4.2205184E7 jvm_memory_committed_bytes{area="nonheap",id="Metaspace",} 7.3269248E7 jvm_memory_committed_bytes{area="nonheap",id="Compressed Class Space",} 8781824.0 jvm_memory_committed_bytes{area="heap",id="PS Eden Space",} 4.0370176E7 jvm_memory_committed_bytes{area="heap",id="PS Survivor Space",} 2097152.0 jvm_memory_committed_bytes{area="heap",id="PS Old Gen",} 6.029312E7 jvm_memory_max_bytes{area="nonheap",id="Code Cache",} 2.5165824E8 jvm_memory_max_bytes{area="nonheap",id="Metaspace",} -1.0 jvm_memory_max_bytes{area="nonheap",id="Compressed Class Space",} 1.073741824E9 jvm_memory_max_bytes{area="heap",id="PS Eden Space",} 4.0370176E7 jvm_memory_max_bytes{area="heap",id="PS Survivor Space",} 2097152.0 jvm_memory_max_bytes{area="heap",id="PS Old Gen",} 8.9653248E7 ...
  20. 53 @saturnism @gcpcloud Download the Agents Add to Startup Command

    Line: For Profiler: $ java -agentpath:/opt/profiler/profiler_java_agent.so=... -jar myapp.jar For Debugger: $ java -agentpath:/opt/debugger/cdbg_java_agent.so -jar myapp.jar
  21. 65 @saturnism @gcpcloud Framework - Spring Boot Support IDE and

    Tooling - IntelliJ, Eclipse, Maven, Gradle Deployment - Container, App Engine, PCF, ... Monitoring/Diagnostics - Debug, Profile, Logging, Error Reporting, Prometheus Monitoring, ... End-to-end Developer Experience
  22. 66 @saturnism @gcpcloud Project Home https://cloud.spring.io/spring-cloud-gcp/ Documentation https://docs.spring.io/spring-cloud-gcp/docs/ Source and

    Samples https://github.com/spring-cloud/spring-cloud-gcp/ Short Code Labs http://g.co/codelabs/spring Long Code Lab http://bit.ly/spring-gcp-lab Recorded Conference Talks ◦ Power of Google Cloud Platform with Spring Cloud GCP ◦ Cloud Native with Spring Boot on Google Cloud Platform
