JHipster for Google Cloud Platform

JHipster for Google Cloud Platform

Ray Tsang from Google contributed a couple of generators for JHipster, including the initial Kubernetes support, Istio support, and Google App Engine support. In this session, we'll see how to use these generators to quickly create and deploy JHipster applications into these environments. We'll also look at the latest work being done on thin microservices architecture such that circuit breakers, retries, load balancing and more are delegated to Istio.

Ray Tsang

June 21, 2018
Tweet

More Decks by Ray Tsang

Other Decks in Technology

Transcript

  1. @saturnism @ludoch @gcpcloud JHipster Kubernetes App Engine Ray Tsang (@saturnism),

    Google Cloud Platform Ludovic Champenois (@ludoch), Google App Engine
  2. @saturnism @ludoch @gcpcloud Ray Tsang Developer Advocate Google Cloud Platform

    Spring Cloud GCP cloud.spring.io/spring-cloud-gcp/ @saturnism saturnism.me
  3. @saturnism @ludoch @gcpcloud Since Initial Contribution Community added a lot

    more! JHipster Registry / Consul Prometheus / Grafana MySQL, MariaDB, Couchbase, PostgreSQL, ElasticSearch Kafka ...
  4. @saturnism @ludoch @gcpcloud Eureka Service Registry Zuul API Gateway Zipkin

    Distributed Trace Prometheus Metrics Store Grafana Visualization Microservice A Ribbon Hystrix Tracer Metrics Archaius Centralized Config
  5. @saturnism @ludoch @gcpcloud More Kubernetes Native Support Use Kubernetes Service

    Discovery Use Kubernetes Ingress for Microservices URL Mapping Choose "No Service Discovery"
  6. @saturnism @ludoch @gcpcloud Eureka, Zuul, Hystrix, Ribbon How do we

    deal w/ microservices reliability concerns?!
  7. @saturnism @ludoch @gcpcloud Observability - Zipkin, Prometheus, Grafana Resiliency -

    Retries, circuit breaking, fault injection Traffic Control - Load balance, split, mirror, rate limit Security - mTLS, RBAC Policy Enforcement - Who can do what? Istio Service Mesh
  8. @saturnism @ludoch @gcpcloud Istio Service Mesh Use Sidecar Proxy to

    Intercept all communication "AOP for Microservices" - Matt Raible
  9. @saturnism @ludoch @gcpcloud App Engine Java8 Standard • Brand new

    Security Sandbox (based on gVisor) • Can run Spring Boot, JHipster, … BYOF • Free Tier with Automatic or Manual Scaling • Batteries Included ◦ Centralized Logging, Remote Debugging, Monitoring, Security Scanning, Traffic Splitting, CDN Static Content, …
  10. @saturnism @ludoch @gcpcloud App Engine Java8 Standard sub-generator, Beta •

    $ jhipster gae • Modified/Generated files: ◦ src/main/webapp/WEB-INF/appengine-web.xml ◦ src/main/webapp/WEB-INF/logging.properties ◦ src/main/resources/config/application-prod-gae.yml ◦ pom.xml • Prerequisites: ◦ Google CLoud SDK locally installed, with Java support • Configuration: ◦ App Engine Scaling properties ◦ Google MySQL database creation/reuse on a given App Engine project • Run App Engine DevServer Locally: ◦ $ ./mvnw appengine:run -DskipTests • Deploy to Google App Engine Java8: ◦ $ ./mvnw appengine:deploy -DskipTests -Pprod,prod-gae
  11. @saturnism @ludoch @gcpcloud appengine-web.xml: <appengine-web-app xmlns="http://appengine.google.com/ns/1.0"> <service>default</service> <threadsafe>true</threadsafe> <runtime>java8</runtime> <!--

    See https://cloud.google.com/appengine/docs/standard/java/config/appref#syntax--> <automatic-scaling> </automatic-scaling> <sessions-enabled>true</sessions-enabled> <instance-class>F4</instance-class> <precompilation-enabled>false</precompilation-enabled> <system-properties> <property name="java.util.logging.config.file" value="WEB-INF/logging.properties"/> </system-properties> <class-loader-config> <!-- temporary workaround to make sure the app uses it's memcache/mail jars.!--> <priority-specifier filename="cache-api-1.1.0.jar"/> </class-loader-config> </appengine-web-app>
  12. @saturnism @ludoch @gcpcloud application-prod-gae.yml # =================================================================== # Spring Boot configuration

    for the "gae" profile. # # This configuration overrides the application.yml file. # =================================================================== spring: datasource: type: com.zaxxer.hikari.HikariDataSource url: jdbc:mysql://google/jhipster2?cloudSqlInstance=pubrobots:us-central1:jhipster2&socketFactory=co m.google.cloud.sql.mysql .SocketFactory&useSSL=false username: root password: XXX hikari: maximumPoolSize: 8
  13. @saturnism @ludoch @gcpcloud App Engine Java8 Standard sub-generator, Beta Limitations

    • Only Monolith Application for now (Micro Services coming soon (™)) • F1 automatic scaling might be too small for decent applications • All static resources are served outside the JVM process ◦ So it is possible Web Pages are there , but the JVM is still booting ◦ Using Static scaling backends can help there • Future work: ◦ Spring Data for Google Cloud Datastore coming in Q3-Q4 ◦ Cloud Memcache investigation
  14. @saturnism @ludoch @gcpcloud Cloud Project = pubrobots SQL Instance name

    = jhipster3 Instance Connection Name: pubrobots:us-central1:jhipster3 Database Name: mydatabase url: jdbc:mysql://google/mydatabase?cloudSqlInstance=pubrobots:us-central1:jhipster3&socketFactory=com.go ogle.cloud.sql.mysql.So cketFactory&useSSL=false
  15. @saturnism @ludoch @gcpcloud Cloud Project = pubrobots SQL Instance name

    = jhipster3 Instance Connection Name: pubrobots:us-central1:jhipster3 Database Name: mydatabase
