Combinator Parsing

A dive into and a Haskell implementation of Graham Hutton's "Higher Order Functions for Parsing" from the Journal of Functional Programming, 1992.

1. Combinator Parsing By Swanand Pagnis
2. Higher-Order Functions for Parsing By Graham Hutton
3. • Abstract & Introduction • Build a parser, one fn at a time • Moving beyond toy parsers
4. Abstract
5. In combinator parsing, the text of parsers resembles BNF notation. We present the basic method, and a number of extensions. We address the special problems presented by whitespace, and parsers with separate lexical and syntactic phases. In particular, a combining form for handling the “offside rule” is given. Other extensions to the basic method include an “into” combining form with many useful applications, and a simple means by which combinator parsers can produce more informative error messages.
6. • Combinators that resemble BNF notation • Whitespace handling through "Offside Rule" • "Into" combining form for advanced parsing • Strategy for better error messages
7. Introduction
8. Primitive Parsers • Take input • Process one character • Return results and unused input
9. Combinators • Combine primitives • Define building blocks • Return results and unused input
10. Lexical analysis and syntax • Combine the combinators • Define lexical elements • Return results and unused input
11. input: "from:swiggy to:me" output: [("f", "rom:swiggy to:me")]
12. input: "42 !=> ans" output: [("4", "2 !=> ans")]
13. rule: 'a' followed by 'b' input: "abcdef" output: [(('a','b'),"cdef")]
14. rule: 'a' followed by 'b' input: "abcdef" output: [(('a','b'),"cdef")] Combinator
15. Language choice
16. Suggested: Lazy Functional Languages
17. Miranda: Author's choice
18. Haskell: An obvious choice.
19. Racket: Another obvious choice.
20. Ruby: to so $ for learning
21. OCaml: Functional, but not lazy.
22. Haskell %
23. Simple when stick to fundamental FP • Higher order functions • Immutability • Recursive problem solving • Algebraic types
24. Let's build a parser, one fn at a time
25. type Parser a b = [a] !-> [(b, [a])]
26. Types help with abstraction • We'll be dealing with parsers and combinators • Parsers are functions, they accept input and return results • Combinators accept parsers and return parsers
27. A parser is a function that accepts an input and returns parsed results and the unused input for each result
28. Parser is a function type that accepts a list of type a and returns all possible results as a list of tuples of type (b, [a])
29. (Parser Char Number) input: "42 it is!" !-- a is a [Char] output: [(42, " it is!")] !-- b is a Number
30. type Parser a b = [a] !-> [(b, [a])]
31. Primitive Parsers
32. succeed !:: b !-> Parser a b succeed v inp = [(v, inp)]
33. Always succeeds Returns "v" for all inputs
34. failure !:: Parser a b failure inp = []
35. Always fails Returns "[]" for all inputs
36. satisfy !:: (a !-> Bool) !-> Parser a a satisfy p [] = failure [] satisfy p (x:xs) | p x = succeed x xs !-- if p(x) is true | otherwise = failure []
37. satisfy !:: (a !-> Bool) !-> Parser a a satisfy p [] = failure [] satisfy p (x:xs) | p x = succeed x xs !-- if p(x) is true | otherwise = failure [] Guard Clauses, if you want to Google
38. literal !:: Eq a !=> a !-> Parser a a literal x = satisfy (!== x)
39. match_3 = (literal '3') match_3 "345" !-- !=> [('3',"45")] match_3 "456" !-- !=> []
40. succeed failure satisfy literal
41. Combinators
42. match_3_or_4 = match_3 `alt` match_4 match_3_or_4 "345" !-- !=> [('3',"45")] match_3_or_4 "456" !-- !=> [('4',"56")]
43. alt !:: Parser a b !-> Parser a b !-> Parser a b (p1 `alt` p2) inp = p1 inp !++ p2 inp
44. (p1 `alt` p2) inp = p1 inp !++ p2 inp List concatenation
45. (match_3 `and_then` match_4) "345" # !=> [(('3','4'),"5")]
47. and_then !:: Parser a b !-> Parser a c !-> Parser a (b, c) (p1 `and_then` p2) inp = [ ((v1, v2), out2) | (v1, out1) !<- p1 inp, (v2, out2) !<- p2 out1 ]
48. and_then !:: Parser a b !-> Parser a c !-> Parser a (b, c) (p1 `and_then` p2) inp = [ ((v1, v2), out2) | (v1, out1) !<- p1 inp, (v2, out2) !<- p2 out1 ] List comprehensions
49. (v11, out11) (v12, out12) (v13, out13) … (v21, out21) (v22, out22) … (v31, out31) (v32, out32) … p1 p2
50. ((v11, v21), out21) ((v11, v22), out22) …
51. (match_3 `and_then` match_4) "345" # !=> [(('3','4'),"5")]
52. Manipulating values
53. match_3 = (literal '3') match_3 "345" !-- !=> [('3',"45")] match_3 "456" !-- !=> []
54. (number "42") "42 !=> answer" # !=> [(42, " answer")]
55. (keyword "for") "for i in 1!..42" # !=> [(:for, " i in 1!..42")]
56. using !:: Parser a b !-> (b !-> c) !-> Parser a c (p `using` f) inp = [(f v, out) | (v, out) !<- p inp ]
57. ((string "3") `using` float) "3" # !=> [(3.0, "")]
58. Levelling up
59. many !:: Parser a b !-> Parser a [b] many p = ((p `and_then` many p) `using` cons) `alt` (succeed [])
60. 0 or many
61. (many (literal 'a')) "aab" !=> [("aa","b"),("a","ab"),("","aab")]
62. (many (literal 'a')) "xyz" !=> [("","xyz")]
63. some !:: Parser a b !-> Parser a [b] some p = ((p `and_then` many p) `using` cons)
64. 1 or many
65. (some (literal 'a')) "aab" !=> [("aa","b"),("a","ab")]
66. (some (literal 'a')) "xyz" !=> []
67. positive_integer = some (satisfy Data.Char.isDigit) negative_integer = ((literal '-') `and_then` positive_integer) `using` cons positive_decimal = (positive_integer `and_then` (((literal '.') `and_then` positive_integer) `using` cons)) `using` join negative_decimal = ((literal '-') `and_then` positive_decimal) `using` cons
68. number !:: Parser Char [Char] number = negative_decimal `alt` positive_decimal `alt` negative_integer `alt` positive_integer
69. word !:: Parser Char [Char] word = some (satisfy isLetter)
70. string !:: (Eq a) !=> [a] !-> Parser a [a] string [] = succeed [] string (x:xs) = (literal x `and_then` string xs) `using` cons
71. (string "begin") "begin end" # !=> [("begin"," end")]
72. xthen !:: Parser a b !-> Parser a c !-> Parser a c p1 `xthen` p2 = (p1 `and_then` p2) `using` snd
73. thenx !:: Parser a b !-> Parser a c !-> Parser a b p1 `thenx` p2 = (p1 `and_then` p2) `using` fst
74. ret !:: Parser a b !-> c !-> Parser a c p `ret` v = p `using` (const v)
75. succeed, failure, satisfy, literal, alt, and_then, using, string, many, some, string, word, number, xthen, thenx, ret
76. Expression Parser & Evaluator
77. data Expr = Const Double | Expr `Add` Expr | Expr `Sub` Expr | Expr `Mul` Expr | Expr `Div` Expr
78. (Const 3) `Mul` ((Const 6) `Add` (Const 1))) # !=> "3*(6+1)"
79. parse "3*(6+1)" # !=> (Const 3) `Mul` ((Const 6) `Add` (Const 1)))
80. (Const 3) Mul ((Const 6) `Add` (Const 1))) # !=> 21
81. BNF Notation expn !::= expn + expn | expn − expn | expn ∗ expn | expn / expn | digit+ | (expn)
82. Improving a little: expn !::= term + term | term − term | term term !::= factor ∗ factor | factor / factor | factor factor !::= digit+ | (expn)
83. Parsers that resemble BNF
84. addition = ((term `and_then` ((literal '+') `xthen` term)) `using` plus)
85. subtraction = ((term `and_then` ((literal '-') `xthen` term)) `using` minus)
86. multiplication = ((factor `and_then` ((literal '*') `xthen` factor)) `using` times)
87. division = ((factor `and_then` ((literal '/') `xthen` factor)) `using` divide)
88. parenthesised_expression = ((nibble (literal '(')) `xthen` ((nibble expn) `thenx`(nibble (literal ')'))))
89. value xs = Const (numval xs) plus (x,y) = x `Add` y minus (x,y) = x `Sub` y times (x,y) = x `Mul` y divide (x,y) = x `Div` y
90. expn = addition `alt` subtraction `alt` term
91. term = multiplication `alt` division `alt` factor
92. factor = (number `using` value) `alt` parenthesised_expn
93. expn "12*(5+(7-2))" # !=> [ (Const 12.0 `Mul` (Const 5.0 `Add` (Const 7.0 `Sub` Const 2.0)),""), … ]
94. value xs = Const (numval xs) plus (x,y) = x `Add` y minus (x,y) = x `Sub` y times (x,y) = x `Mul` y divide (x,y) = x `Div` y
95. value = numval plus (x,y) = x + y minus (x,y) = x - y times (x,y) = x * y divide (x,y) = x / y
96. expn "12*(5+(7-2))" # !=> [(120.0,""), (12.0,"*(5+(7-2))"), (1.0,"2*(5+(7-2))")]
97. expn "(12+1)*(5+(7-2))" # !=> [(130.0,""), (13.0,"*(5+(7-2))")]
98. Moving beyond toy parsers
99. Whitespace? (
100. white = (literal " ") `alt` (literal "\t") `alt` (literal "\n")
101. white = many (any literal " \t\n")
102. /\s!*/
103. any p = foldr (alt.p) fail
104. any p [x1,x2,!!...,xn] = (p x1) `alt` (p x2) `alt` !!... `alt` (p xn)
105. white = many (any literal " \t\n")
106. nibble p = white `xthen` (p `thenx` white)
107. The parser (nibble p) has the same behaviour as parser p, except that it eats up any white- space in the input string before or afterwards
108. (nibble (literal 'a')) " a " # !=> [('a',""),('a'," "),('a'," ")]
109. symbol = nibble.string
110. symbol "$fold" " $fold " # !=> [("$fold", ""), ("$fold", " ")]
111. The Offside Rule
112. w = x + y where x = 10 y = 15 - 5 z = w * 2
113. w = x + y where x = 10 y = 15 - 5 z = w * 2
114. When obeying the offside rule, every token must lie either directly below, or to the right of its first token
115. i.e. A weak indentation policy
116. The Offside Combinator
117. type Pos a = (a, (Integer, Integer))
118. prelex "3 + \n 2 * (4 + 5)" # !=> [('3',(0,0)), ('+',(0,2)), ('2',(1,2)), ('*',(1,4)), … ]
119. satisfy !:: (a !-> Bool) !-> Parser a a satisfy p [] = failure [] satisfy p (x:xs) | p x = succeed x xs !-- if p(x) is true | otherwise = failure []
120. satisfy !:: (a !-> Bool) !-> Parser (Pos a) a satisfy p [] = failure [] satisfy p (x:xs) | p a = succeed a xs !-- if p(a) is true | otherwise = failure [] where (a, (r, c)) = x
121. satisfy !:: (a !-> Bool) !-> Parser (Pos a) a satisfy p [] = failure [] satisfy p (x:xs) | p a = succeed a xs !-- if p(a) is true | otherwise = failure [] where (a, (r, c)) = x
122. offside !:: Parser (Pos a) b !-> Parser (Pos a) b offside p inp = [(v, inpOFF) | (v, []) !<- (p inpON)] where inpON = takeWhile (onside (head inp)) inp inpOFF = drop (length inpON) inp onside (a, (r, c)) (b, (r', c')) = r' !>= r !&& c' !>= c
123. offside !:: Parser (Pos a) b !-> Parser (Pos a) b
124. offside !:: Parser (Pos a) b !-> Parser (Pos a) b offside p inp = [(v, inpOFF) | (v, []) !<- (p inpON)]
125. (nibble (literal 'a')) " a " # !=> [('a',""),('a'," "),('a'," ")]
126. offside !:: Parser (Pos a) b !-> Parser (Pos a) b offside p inp = [(v, inpOFF) | (v, []) !<- (p inpON)]
127. offside !:: Parser (Pos a) b !-> Parser (Pos a) b offside p inp = [(v, inpOFF) | (v, []) !<- (p inpON)] where inpON = takeWhile (onside (head inp)) inp
128. offside !:: Parser (Pos a) b !-> Parser (Pos a) b offside p inp = [(v, inpOFF) | (v, []) !<- (p inpON)] where inpON = takeWhile (onside (head inp)) inp inpOFF = drop (length inpON) inp
129. offside !:: Parser (Pos a) b !-> Parser (Pos a) b offside p inp = [(v, inpOFF) | (v, []) !<- (p inpON)] where inpON = takeWhile (onside (head inp)) inp inpOFF = drop (length inpON) inp onside (a, (r, c)) (b, (r', c')) = r' !>= r !&& c' !>= c
130. (3 + 2 * (4 + 5)) + (8 * 10) (3 + 2 * (4 + 5)) + (8 * 10)
131. (offside expn) (prelex inp_1) # !=> [(21.0,[('+',(2,0)),('(',(2,2)),('8',(2,3)),('*', (2,5)),('1',(2,7)),('0',(2,8)),(')',(2,9))])] (offside expn) (prelex inp_2) # !=> [(101.0,[])]
132. Quick recap before we
133. ∅ !|> succeed, fail !|> satisfy, literal !|> alt, and_then, using !|> many, some !|> string, thenx, xthen, return !|> expression parser & evaluator !|> any, nibble, symbol !|> prelex, offside
134. Practical parsers
135. Syntactical analysis Lexical analysis Parse trees
136. type Parser a b = [a] !-> [(b, [a])] type Pos a = (a, (Integer, Integer))
137. data Tag = Ident | Number | Symbol | Junk deriving (Show, Eq) type Token = (Tag, [Char])
138. (Symbol, "if") (Number, "123")
139. Parse the string with parser p, & apply token t to the result
140. (p `tok` t) inp = [ (((t, xs), (r, c)), out) | (xs, out) !<- p inp] where (x, (r,c)) = head inp
141. (p `tok` t) inp = [ ((<token>,<pos>),<unused input>) | (xs, out) !<- p inp] where (x, (r,c)) = head inp
142. (p `tok` t) inp = [ (((t, xs), (r, c)), out) | (xs, out) !<- p inp] where (x, (r,c)) = head inp
143. ((string "where") `tok` Symbol) inp # !=> ((Symbol,"where"), (r, c))
144. many ((p1 `tok` t1) `alt` (p2 `tok` t2) `alt` !!... `alt` (pn `tok` tn))
145. [(p1, t1), (p2, t2), …, (pn, tn)]
146. lex = many.(foldr op failure) where (p, t) `op` xs = (p `tok` t) `alt` xs
148. lex = many.(foldr op failure) where (p, t) `op` xs = (p `tok` t) `alt` xs
149. # Rightmost computation cn = (pn `tok` tn) `alt` failure
150. # Followed by (pn-1 `tok` tn-1) `alt` cn
151. many ((p1 `tok` t1) `alt` (p2 `tok` t2) `alt` !!... `alt` (pn `tok` tn))
152. lexer = lex [ ((some (any_of literal " \n\t")), Junk), ((string "where"), Symbol), (word, Ident), (number, Number), ((any_of string ["(", ")", "="]), Symbol)]
153. lexer = lex [ ((some (any_of literal " \n\t")), Junk), ((string "where"), Symbol), (word, Ident), (number, Number), ((any_of string ["(", ")", "="]), Symbol)]
154. lexer = lex [ ((some (any_of literal " \n\t")), Junk), ((string "where"), Symbol), (word, Ident), (number, Number), ((any_of string ["(", ")", "="]), Symbol)]
155. head (lexer (prelex "where x = 10")) # !=> ([((Symbol,"where"),(0,0)), ((Ident,"x"),(0,6)), ((Symbol,"="),(0,8)), ((Number,"10"),(0,10)) ],[])
156. (head.lexer.prelex) "where x = 10" # !=> ([((Symbol,"where"),(0,0)), ((Ident,"x"),(0,6)), ((Symbol,"="),(0,8)), ((Number,"10"),(0,10)) ],[])
157. (head.lexer.prelex) "where x = 10" # !=> ([((Symbol,"where"),(0,0)), ((Ident,"x"),(0,6)), ((Symbol,"="),(0,8)), ((Number,"10"),(0,10)) ],[]) Function composition
158. length ((lexer.prelex) "where x = 10") # !=> 198
159. Conflicts? Ambiguity?
160. In this case, "where" is a source of conflict. It can be a symbol, or identifier.
161. lexer = lex [ {- 1 -} ((some (any_of literal " \n\t")), Junk), {- 2 -} ((string "where"), Symbol), {- 3 -} (word, Ident), {- 4 -} (number, Number), {- 5 -} ((any_of string ["(",")","="]), Symbol)]
162. Higher priority, higher precedence
163. Removing Junk
164. strip !:: [(Pos Token)] !-> [(Pos Token)] strip = filter ((!!= Junk).fst.fst)
165. ((!!= Junk).fst.fst) ((Symbol,"where"),(0,0)) # !=> True ((!!= Junk).fst.fst) ((Junk,"where"),(0,0)) # !=> False
166. (fst.head.lexer.prelex) "where x = 10" # !=> [((Symbol,"where"),(0,0)), ((Junk," "),(0,5)), ((Ident,"x"),(0,6)), ((Junk," "),(0,7)), ((Symbol,"="),(0,8)), ((Junk," "),(0,9)), ((Number,"10"),(0,10))]
167. (strip.fst.head.lexer.prelex) "where x = 10" # !=> [((Symbol,"where"),(0,0)), ((Ident,"x"),(0,6)), ((Symbol,"="),(0,8)), ((Number,"10"),(0,10))]
168. Syntax Analysis
169. characters !|> lexical analysis !|> tokens
170. tokens !|> syntax analysis !|> parse trees
171. f x y = add a b where a = 25 b = sub x y answer = mult (f 3 7) 5
172. f x y = add a b where a = 25 b = sub x y answer = mult (f 3 7) 5 Script
173. f x y = add a b where a = 25 b = sub x y answer = mult (f 3 7) 5 Definition
174. f x y = add a b where a = 25 b = sub x y answer = mult (f 3 7) 5 Body
175. f x y = add a b where a = 25 b = sub x y answer = mult (f 3 7) 5 Expression
176. f x y = add a b where a = 25 b = sub x y answer = mult (f 3 7) 5 Definition
177. f x y = add a b where a = 25 b = sub x y answer = mult (f 3 7) 5 Primitives
178. data Script = Script [Def] data Def = Def Var [Var] Expn data Expn = Var Var | Num Double | Expn `Apply` Expn | Expn `Where` [Def] type Var = [Char]
179. prog = (many defn) `using` Script
180. defn = ( (some (kind Ident)) `and_then` ((lit "=") `xthen` (offside body))) `using` defnFN
181. body = ( expr `and_then` (((lit "where") `xthen` (some defn)) `opt` [])) `using` bodyFN
182. expr = (some prim) `using` (foldl1 Apply)
183. prim = ((kind Ident) `using` Var) `alt` ((kind Number) `using` numFN) `alt` ((lit "(") `xthen` (expr `thenx` (lit ")")))
184. !-- only allow a kind of tag kind !:: Tag !-> Parser (Pos Token) [Char] kind t = (satisfy ((!== t).fst)) `using` snd — only allow a given symbol lit !:: [Char] !-> Parser (Pos Token) [Char] lit xs = (literal (Symbol, xs)) `using` snd
185. prog = (many defn) `using` Script
186. defn = ( (some (kind Ident)) `and_then` ((lit "=") `xthen` (offside body))) `using` defnFN
187. body = ( expr `and_then` (((lit "where") `xthen` (some defn)) `opt` [])) `using` bodyFN
188. expr = (some prim) `using` (foldl1 Apply)
189. prim = ((kind Ident) `using` Var) `alt` ((kind Number) `using` numFN) `alt` ((lit "(") `xthen` (expr `thenx` (lit ")")))
190. data Script = Script [Def] data Def = Def Var [Var] Expn data Expn = Var Var | Num Double | Expn `Apply` Expn | Expn `Where` [Def] type Var = [Char]
191. Orange functions are for transforming values.
192. Use data constructors to generate parse trees
193. Use evaluation functions to evaluate and generate a value
194. f x y = add a b where a = 25 b = sub x y answer = mult (f 3 7) 5
195. Script [ Def "f" ["x","y"] ( ((Var "add" `Apply` Var "a") `Apply` Var "b") `Where` [ Def "a" [] (Num 25.0), Def "b" [] ((Var "sub" `Apply` Var "x") `Apply` Var "y")]), Def "answer" [] ( (Var "mult" `Apply` ( (Var "f" `Apply` Num 3.0) `Apply` Num 7.0)) `Apply` Num 5.0)]
196. Strategy for writing parsers
197. 1. Identify components i.e. Lexical elements
198. lexer = lex [ ((some (any_of literal " \n\t")), Junk), ((string "where"), Symbol), (word, Ident), (number, Number), ((any_of string ["(", ")", "="]), Symbol)]
199. 2. Structure these elements a.k.a. syntax
200. defn = ((some (kind Ident)) `and_then` ((lit "=") `xthen` (offside body))) `using` defnFN body = (expr `and_then` (((lit "where") `xthen` (some defn)) `opt` [])) `using` bodyFN expr = (some prim) `using` (foldl1 Apply) prim = ((kind Ident) `using` Var) `alt` ((kind Number) `using` numFN) `alt` ((lit "(") `xthen` (expr `thenx` (lit ")")))
201. 3. BNF notation is very helpful
202. 4. TDD in the absence of types
203. Where to, next?
204. Monadic Parsers Graham Hutton, Eric Meijer
205. Introduction to FP Philip Wadler
206. The Dragon Book If your interest is in compilers
207. Libraries?
208. Haskell: Parsec, MegaParsec. ✨ OCaml: Angstrom. ✨ Ruby: rparsec, or roll you own Elixir: Combine, ExParsec Python: Parsec. ✨
209. Thank you!
210. Twitter: @_swanand GitHub: @swanandp
