PyLondinium 2019: Gentle introduction to TLS, PKI, and Python's ssl module

Abstract

TLS/SSL is the most important and widely-used protocol for secure and encrypted communication. I'm going to introduce you to TLS 1.2 and 1.3, cryptographic building blocks, best-practice configuration, certificates, and public key infrastructure using Python's ssl module
Description

TLS is an ubiquitous protocol for secure communication. It's used in HTTPS, email (IMAP, POP3, SMTP), LDAP, FTP, and more. Some recent protocols like HTTP/2 are not defined for unencrypted channels. TLS offers more than just encryption with symmetric cryptography. It also ensures data integrity and strong authentication with the help of X.509 certificates and public key infrastructure (PKI).

Did you ever wonder what's the difference between SSL, TLS, and StartTLS? Or what is the meaning of cryptic terms and names like Server Name Indication, Subject Alternative Name, or TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384? What is perfect forward secrecy and why is it so important for privacy? Does HTTPS make my website slow? What is the difference between a root CA, intermediate CA and end-entity certificate? My talk explains how a client and a server establish a secure connection, why a certificate is required, and how TLS 1.3 has improved the handshake.

Some prior knowledge of cryptography and networking basics are helpful but not required to follow this talk.

Christian Heimes

June 15, 2019
Tweet

More Decks by Christian Heimes

Other Decks in Programming

Transcript

  1. Gentle introduction to TLS, PKI, and Python's ssl module PyLondinium

    2019 / London Christian Heimes Principal Software Engineer [email protected] / [email protected] @ChristianHeimes
  2. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Who am I?

    • from Hamburg/Germany • Linux user since 1997 • Python and C developer • Fellow of the PSF • Python core developer since 2008 • maintainer of ssl and hashlib module • Python security team • Occasional contributor to OpenSSL
  3. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Professional life •

    Principal Software Engineer at Red Hat • Security Engineering • FreeIPA Identity Management • Dogtag PKI
  4. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Agenda • high

    level view • ssl module • cryptography 101 • TLS handshake • certs & PKI • TLS 1.3 • books & resources
  5. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Talk • Slides

    https://speakerdeck.com/tiran/ • Attribution-ShareAlike 4.0 International • Assumptions • Python 3.6 - 3.8 • OpenSSL 1.1.0 or 1.1.1 • TLS 1.2 and TLS 1.3 • modern cryptography, perfect forward secrecy (PFS)
  6. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 TLS has exactly

    one performance problem: it is not used widely enough. Everything else can be optimized. https://istlsfastyet.com/
  7. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Troy Hunt, I

    wanna go fast: HTTPS' massive speed advantage https://www.troyhunt.com/i-wanna-go-fast-https-massive-speed-advantage/
  8. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Troy Hunt, I

    wanna go fast: HTTPS' massive speed advantage https://www.troyhunt.com/i-wanna-go-fast-https-massive-speed-advantage/
  9. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Reasons to deploy

    TLS • Privacy • Security (Ad / Malware injection • Performance (HTTP/2, HTTP/3) • SEO • User Experience (password warning) • Browers are deprecating HTTP support
  10. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Wikipedia definition Transport

    Layer Security (TLS) – and its predecessor, Secure Sockets Layer (SSL) – are cryptographic protocols that provide communications security over a computer network. The TLS protocol aims primarily to provide privacy and data integrity between two communicating computer applications.
  11. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 TLS core features

    • encrypted transport stream • application protocol agnostic • integrity check • replay attack protection • strong authentication of server • strong authentication of client (optional) • extensible protocol
  12. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 TLS standard •

    IETF standard (Internet engineering task force) • IANA (Internet assigned number authority) • TLS (TCP), DTLS (UDP), QUIC • ASN.1 • PKI with X.509 certificates
  13. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 ssl module, an

    OpenSSL wrapper • ssl.SSLContext (SSL_CTX*) • configuration • certificates • trust anchors (root CA) • PROTOCOL_*, CERT_*, VERIFY_*, OP_*, TLSVersion.* • ... • ssl.SSLSocket (SSL*) • ssl.SSLObject • ssl.MemoryBIO (BIO*) • ssl.wrap_socket()
  14. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Example import socket

    import ssl HOSTNAME = 'pylondinium.org' ctx = ssl.create_default_context() sock = socket.create_connection((HOSTNAME, 443)) ssock = ctx.wrap_socket(sock, server_hostname=HOSTNAME) import socket import ssl HOSTNAME = 'pylondinium.org' ctx = ssl.create_default_context() sock = socket.create_connection((HOSTNAME, 443)) ssock = ctx.wrap_socket(sock, server_hostname=HOSTNAME)
  15. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Example (2) ctx

    = ssl.SSLContext(ssl.PROTOCOL_TLS_CLIENT) ctx.minimum_version = ssl.TLSVersion.TLSv1_2 ctx.maximum_version = ssl.TLSVersion.TLSv1_2 # TLSv1_3 ctx.verify_mode = ssl.CERT_REQUIRED ctx.load_default_certs() ctx.check_hostname = True ctx = ssl.SSLContext(ssl.PROTOCOL_TLS_CLIENT) ctx.minimum_version = ssl.TLSVersion.TLSv1_2 ctx.maximum_version = ssl.TLSVersion.TLSv1_2 # TLSv1_3 ctx.verify_mode = ssl.CERT_REQUIRED ctx.load_default_certs() ctx.check_hostname = True ssock = ctx.wrap_socket(sock, server_hostname=HOSTNAME) ssock = ctx.wrap_socket(sock, server_hostname=HOSTNAME) print(ssock.cipher()) ('ECDHE-ECDSA-CHACHA20-POLY1305', 'TLSv1.2', 256) ('ECDHE-RSA-AES128-GCM-SHA256', 'TLSv1.2', 128) ('TLS_AES_256_GCM_SHA384', 'TLSv1.3', 256) print(ssock.cipher()) ('ECDHE-ECDSA-CHACHA20-POLY1305', 'TLSv1.2', 256) ('ECDHE-RSA-AES128-GCM-SHA256', 'TLSv1.2', 128) ('TLS_AES_256_GCM_SHA384', 'TLSv1.3', 256) sock = socket.create_connection((HOSTNAME, 443)) sock = socket.create_connection((HOSTNAME, 443))
  16. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Secure hash functions

    Hash functions for MAC, signatures, and more. • MD5 • SHA (SHA1) • SHA2 • SHA-256 • SHA-384
  17. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Symmetric-key algorithm (bulk

    encryption) Same key for encryption and decryption. • DES • Triple DES (3DES) • RC4 • AES (AES-128, AES-256) • CHACHA20
  18. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Symmetric-key algorithm (2)

    • Padding • Mode of operation • CBC • GCM • Authenticated encryption • CBC with MtE • AEAD (GCM, Poly1305)
  19. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Asymmetric cryptographic algorithms

    public / private key cryptography • asymmetric encryption • signatures • key agreement
  20. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Asymmetric encryption public

    key encrypts, private key decrypts • ElGamal encryption • RSA encryption (PKCS#1) • RSAES-PKCS1-v1.5 • RSAES-OAEP
  21. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Signatures private key

    signs hash of message message, public key verifies • RSA signature (PKCS#1) • RSASSA-PKCS1-v1.5 • RSAES-PSS • DSS (DSA) • ECDSA (secp256r1, secp384r1, …) • EdDSA (Edward Curve25519, …)
  22. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Key agreement protocol

    own private key + peer's public = key • finite field Diffie-Hellman (DH) • elliptic curve Diffie-Hellman (ECDH) • ephemeral DH / ECDH Common secret = = Secret colours + + (assume that mixture separation is expensive) Public transport = = Secret colours + + Common paint Alice Bob
  23. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Cryptographic building blocks

    • key agreement / exchange • authentication algorithm • bulk encryption (symmetric) • cipher mode • one-way function for message authentication (MAC)
  24. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 TLS handshake •

    exchange parameters • version, ciphers, server name (virtual host) • verify identity of server • server signs with its private key • certificate, trust chain, hostname • agree on pre-master secret • derive secrets • verify handshake ssock = ctx.wrap_socket(sock, server_hostname=HOSTNAME) ssock = ctx.wrap_socket(sock, server_hostname=HOSTNAME)
  25. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 TLS 1.2 handshake

    with RSA key exchange ClientHello Supported cipher suites max version, client random, ... ServerHello select cipher suite version, server random, ... Certificate Chain ServerHelloDone Finish MAC of handshake message ChangeCipherSpec ClientKeyChange RSA encrypted pre-master secret Finish MAC of handshake message ChangeCipherSpec HTTP GET (verify mac)
  26. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 TLS 1.2 handshake

    with Diffie-Hellman ClientHello supported cipher suites max version, client random, server name indicator (SNI), ... Finish MAC of handshake message ChangeCipherSpec ClientKeyChange Diffie-Hellman server params Finish MAC of handshake message ChangeCipherSpec HTTP GET (verify mac) ServerHello select cipher suite version, server random, ... Certificate Chain ServerHelloDone ServerKeyExchange Diffie-Hellman server params Signature
  27. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Message callback (Python

    3.8) def msg_cb(conn, direction, version, content_type, msg_type, data): if content_type is not ssl._TLSContentType.HEADER: print(f"{direction:<5} {version._name_:<7} " f"{msg_type._name_:<20} {len(data)}") ctx._msg_callback = msg_cb def msg_cb(conn, direction, version, content_type, msg_type, data): if content_type is not ssl._TLSContentType.HEADER: print(f"{direction:<5} {version._name_:<7} " f"{msg_type._name_:<20} {len(data)}") ctx._msg_callback = msg_cb write TLSv1_2 CLIENT_HELLO 213 read TLSv1_2 SERVER_HELLO 63 read TLSv1_2 CERTIFICATE 4616 read TLSv1_2 SERVER_KEY_EXCHANGE 115 read TLSv1_2 SERVER_DONE 4 write TLSv1_2 CLIENT_KEY_EXCHANGE 37 write TLSv1_2 CHANGE_CIPHER_SPEC 1 write TLSv1_2 FINISHED 16 read TLSv1_2 NEWSESSION_TICKET 202 read TLSv1_2 FINISHED 16 write TLSv1_2 CLIENT_HELLO 213 read TLSv1_2 SERVER_HELLO 63 read TLSv1_2 CERTIFICATE 4616 read TLSv1_2 SERVER_KEY_EXCHANGE 115 read TLSv1_2 SERVER_DONE 4 write TLSv1_2 CLIENT_KEY_EXCHANGE 37 write TLSv1_2 CHANGE_CIPHER_SPEC 1 write TLSv1_2 FINISHED 16 read TLSv1_2 NEWSESSION_TICKET 202 read TLSv1_2 FINISHED 16
  28. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Certificate validation ctx

    = ssl.SSLContext(ssl.PROTOCOL_TLS_CLIENT) ctx.minimum_version = ssl.TLSVersion.TLSv1_2 ctx.maximum_version = ssl.TLSVersion.TLSv1_2 ctx.verify_mode = ssl.CERT_REQUIRED ctx.load_default_certs() ctx.check_hostname = True ssock = ctx.wrap_socket(sock, server_hostname=HOSTNAME) ctx = ssl.SSLContext(ssl.PROTOCOL_TLS_CLIENT) ctx.minimum_version = ssl.TLSVersion.TLSv1_2 ctx.maximum_version = ssl.TLSVersion.TLSv1_2 ctx.verify_mode = ssl.CERT_REQUIRED ctx.load_default_certs() ctx.check_hostname = True ssock = ctx.wrap_socket(sock, server_hostname=HOSTNAME)
  29. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 X.509 certificates •

    ASN.1 • CER/DER: binary ASN.1 • PEM: base64 encoded ASN.1 + header/footer • P12, PFX: PKCS#12 safe bags • cert / private key pair • content • public key • metadata • extensions • issuer signature
  30. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Fields • Serial

    number • Subject • Issuer • Validity • notBefore • notAfter • Subject Public Key Information • algorithm • public key • X509v3 extensions
  31. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 X509v3 extensions •

    Basic Constraints • Key Usage • Extended Key Usage • Subject Alternative Name • Subject Key ID & Authority Key ID • CRL distribution point • Authority Information Access (OCSP, parent CA) • Certificate Policy & Naming Policy • SCT (Certificate Transparency) • ...
  32. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Certificate types •

    trust anchors (root CA certs) • intermediate CA certs • end-entity certs • server • client • code signing • email • CRL/OCSP signing • ... root CA self-signs intermediate CA 1 intermediate CA 2 signs end-entity cert signs signs
  33. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Trust store for

    root CAs • Linux/BSD: PKCS#11 crypto token dumped to file → • /etc/pki/tls/certs/ca-bundle.crt • /etc/ssl/certs/ca-certificates.crt • /etc/ssl/ca-bundle.pem • /etc/ssl/cert.pem • /usr/local/etc/ssl/cert.pem • /usr/local/share/certs/ca-root-nss.crt • /etc/ssl/certs/ • /system/etc/security/cacerts • Windows: CryptoAPI (registry), SChannel API • macOS: keychain, SecureTransport API
  34. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 pylondinium.org X.509 certificate

    Certificate: Data: Version: 3 (0x2) Serial Number: 2f:90:ae:04:83:e7:4d:41:7c:c7:1e:ff:66:71:ee:11 Signature Algorithm: ecdsa-with-SHA256 Issuer: C = GB, ST = Greater Manchester, L = Salford, O = ... Validity Not Before: Feb 11 00:00:00 2019 GMT Not After : Aug 20 23:59:59 2019 GMT Subject: OU = Domain Control Validated, OU = PositiveSSL Multi- Domain, CN = sni216722.cloudflaressl.com ... X509v3 extensions: X509v3 Subject Alternative Name: DNS:sni216722.cloudflaressl.com, DNS:*.cazinovulkan-platinum.com, DNS:*.club-vulcan-casino.net, ..., DNS:*.pylondinium.org, DNS:*.resident- slot.com, ..., DNS:pylondinium.org, ... Certificate: Data: Version: 3 (0x2) Serial Number: 2f:90:ae:04:83:e7:4d:41:7c:c7:1e:ff:66:71:ee:11 Signature Algorithm: ecdsa-with-SHA256 Issuer: C = GB, ST = Greater Manchester, L = Salford, O = ... Validity Not Before: Feb 11 00:00:00 2019 GMT Not After : Aug 20 23:59:59 2019 GMT Subject: OU = Domain Control Validated, OU = PositiveSSL Multi- Domain, CN = sni216722.cloudflaressl.com ... X509v3 extensions: X509v3 Subject Alternative Name: DNS:sni216722.cloudflaressl.com, DNS:*.cazinovulkan-platinum.com, DNS:*.club-vulcan-casino.net, ..., DNS:*.pylondinium.org, DNS:*.resident- slot.com, ..., DNS:pylondinium.org, ...
  35. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Don't roll your

    own verification • CN/SAN • wildcards • internationalized domain names (IDNA) • > 6 7 bugs in Python's hostname verification code • CVE-2013-2099, bpo-12000, bpo-17997, bpo-17305, bpo-30141 • Python 3.7 uses X509_VERIFY_PARAM_set1_host() OpenSSL 1.0.2+ / LibreSSL 2.7.0
  36. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Kill all the

    bad crypto! • RC4, 3DES, AES-CBC • MD5, SHA1 • NULL ciphers • arbitrary DH groups and curves • static RSA authentication • renegotiation • compression • PKCS#1 v1.5 • MAC then Encrypt
  37. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 New modern crypto

    • Elliptic Curve Crypto • Edwards Curve (Ed25519) • Curve25519, X25519 • authenticated encryption (AEAD) • AES-GCM • CHACHA20-Poly1305 • mandatory Diffie-Hellman PFS → • no “out-of-band TLS decryption” • RSAES-PSS signatures
  38. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Protocol improvements •

    Cipher negotiation protected by Finish MAC (LogJam) • Separation of key agreement, ciphers, authentication • Cipher suites • TLS_AES_128_GCM_SHA256, TLS_CHACHA20_POLY1305_SHA256 • TLS extensions • signature_algorithms, cert_signature_algorithms, elliptic_curves • Session resumption with PSK-ECDHE • after Finish, TLS encrypted, next master key • Encrypted Post-Handshake auth (client cert)
  39. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 TLS 1.3 with

    1-RTT handshake ClientHello Supported ciphers, groups, signatures supported versions SNI Key Share ServerHello select cipher, group, signature Key Share Certificate Chain Finish MAC & Signature ChangeCipherSpec Finish MAC HTTP GET ChangeCipherSpec
  40. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 TLS 1.3 with

    OpenSSL 1.1.1 ctx.minimum_version = ssl.TLSVersion.TLSv1_3 ctx.maximum_version = ssl.TLSVersion.TLSv1_3 ctx.minimum_version = ssl.TLSVersion.TLSv1_3 ctx.maximum_version = ssl.TLSVersion.TLSv1_3 write TLSv1_3 CLIENT_HELLO 512 read TLSv1_3 SERVER_HELLO 122 read TLSv1_3 CERTIFICATE_STATUS 1 read TLSv1_3 ENCRYPTED_EXTENSIONS 6 read TLSv1_3 CERTIFICATE 4623 read TLSv1_3 CERTIFICATE_VERIFY 78 read TLSv1_3 FINISHED 52 write TLSv1_3 CHANGE_CIPHER_SPEC 1 write TLSv1_3 CERTIFICATE_STATUS 1 write TLSv1_3 FINISHED 52 write TLSv1_3 CLIENT_HELLO 512 read TLSv1_3 SERVER_HELLO 122 read TLSv1_3 CERTIFICATE_STATUS 1 read TLSv1_3 ENCRYPTED_EXTENSIONS 6 read TLSv1_3 CERTIFICATE 4623 read TLSv1_3 CERTIFICATE_VERIFY 78 read TLSv1_3 FINISHED 52 write TLSv1_3 CHANGE_CIPHER_SPEC 1 write TLSv1_3 CERTIFICATE_STATUS 1 write TLSv1_3 FINISHED 52
  41. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 TLS 1.3 with

    2-RTT retry handshake ClientHello Supported ciphers, groups, signatures supported versions Key Share ServerHello select cipher, group, signature Key Share Certificate Chain Finish MAC HTTP GET Finish MAC & Signature ChangeCipherSpec ChangeCipherSpec HelloRetryRequest select cipher, group, signature Cookie ClientHello Cookie New Key Share
  42. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 TLS 1.3 with

    0-RTT early data ClientHello PSK + PSK mode Key Share ServerHello PSK Key Share Finish MAC & Signature NewSessionTicket PSK Early data HTTP GET Early data HTTP Response Finish MAC TLS Alert close_notify
  43. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 from __future__ import

    ??? • Update to OpenSSL 1.1.1 • 1.02 and 1.1.0 EOL • PEP 543 – A Unified TLS API for Python • Replacement for certifi package “Ceterum censeo certifinem esse delendam” • HTTP/3 (UDP/QUIC)
  44. TLS/SSL, PyLondinium 2019, @ChristianHeimes, CC BY-SA 4.0 Resources • https://www.ssllabs.com/ssltest/

    • https://istlsfastyet.com/ • The Illustrated TLS Connection https://tls.ulfheim.net/ • Deploying TLS 1.3: the great, the good and the bad (33c3) https://www.youtube.com/watch?v=0opakLwtPWk
