1. Anirudh Ramananathan (foxish@google.com) Software Engineer (Kubernetes) Timothy Chen (tim@hyperpilot.io) Co-founder & CTO (HyperPilot) Apache Spark on Kubernetes
2. Agenda • Kubernetes & Containers • Motivation • Design • Demo • Deep Dive • Roadmap
3. What is Kubernetes?
4. Kubernetes Kubernetes is an open-source system
5. Kubernetes Kubernetes is an open-source system for automating deployment, scaling, and management
6. Kubernetes Kubernetes is an open-source system for automating deployment, scaling, and management of containerized applications.
7. ‘Containerized’
8. Containers libs app kernel libs app libs app libs app • Repeatable Builds and Workflows • Application Portability • High Degree of Control over Software • Faster Development Cycle • Reduced dev-ops load • Improved Infrastructure Utilization
9. • Large OSS Community - 1200+ contributors and 45k+ commits • Ecosystem and Partners - 100+ organizations involved • One of the top 100 projects overall on GitHub - 23k+ stars Kubernetes
10. Overview
11. At a Glance kubelet UI kubelet CLI API users master nodes etcd kubelet scheduler controllers apiserver
12. Nodes and Pods Pod Volume Containers Pod Containers 80 80 8080 8080 Volume Node • A pod is a set of co-located containers • Created by a declarative specification supplied to the master • Each pod has its own IP address • Volumes can be local or network-attached
13. Motivation
14. Why Spark on Kubernetes? • Resource sharing between batch, serving and stateful workloads – Streamlined developer experience – Reduced operational costs – Improved infrastructure utilization • Kubernetes and the Container Ecosystem – Lots of addon services: third-party logging, monitoring, and security tools – For example, the Istio project, announced May 24, by IBM, Google and Lyft, provides a service mesh for authenticating, authorizing, tracing, and timing, and rate-limiting container-to-container communication, and more.
15. Design
16. Spark, meet Kubernetes! Spark Core Kubernetes Standalone YARN Mesos GraphX SparkSQL MLlib Streaming
17. Spark, meet Kubernetes! Spark Core Kubernetes Scheduler Backend Kubernetes Cluster new executors remove executors configuration • Resource Requests • Authnz • Communication with K8s
18. Kubernetes, meet Spark! Kubernetes Cluster File Staging Server • Staging server: component to stage local files • Spark Shuffle service: component to store shuffle data for dynamic allocation • ThirdParty/CustomResources: extend Kubernetes API with Spark Knowledge Shuffle Service SparkJob API Endpoint
19. Kubernetes Integration Dependencies Container images with dependencies baked in Files from GCS/S3/HDFS/HTTP File Staging Server Staged files and JARs Several ways of running Spark Jobs along with their dependencies on Kubernetes
20. Administration Namespaces Resource Accounting Logging Monitoring Resource Quota Pluggable Authorization Admission Control RBAC • Launch Spark Jobs as a particular user into a specific namespace • RBAC and Namespace-level resource quotas • Audit logging for clusters • Several monitoring solutions to see node, cluster and pod-level statistics
21. Focus Areas Wordcloud of the command-line options we added to spark-submit on Kubernetes
22. Demo
23. Deep Dive
24. Deep Dive spark-subm it kubernetes cluster apiserver scheduler • Spark Submit submits job to K8s
25. • Spark Submit submits job to K8s • K8s schedules the driver for job Deep Dive kubernetes cluster apiserver scheduler schedule driver pod spark driver
26. • Spark Submit submits job to K8s • K8s schedules the driver for job Deep Dive • Spark Submit submits job to K8s • K8s schedules the driver for job • Driver requests executors as needed kubernetes cluster apiserver scheduler spark driver create executor pods
27. • Spark Submit submits job to K8s • K8s schedules the driver for job Deep Dive • Spark Submit submits job to K8s • K8s schedules the driver for job • Driver requests executors as needed • Executors scheduled and created kubernetes cluster apiserver scheduler spark driver schedule executor pods executors
28. • Spark Submit submits job to K8s • K8s schedules the driver for job Deep Dive • Spark Submit submits job to K8s • K8s schedules the driver for job • Driver requests executors as needed • Executors scheduled and created • Executors run tasks kubernetes cluster apiserver scheduler spark driver executors
29. • Spark Submit submits job to K8s • K8s schedules the driver for job Deep Dive • Spark Submit submits job to K8s • K8s schedules the driver for job • Driver requests executors as needed • Executors scheduled and created • Executors run tasks • Driver “completes” job and persists logs kubernetes cluster apiserver scheduler spark driver
30. Roadmap
31. Spark Streaming Spark Roadmap Spark Shell Client Mode Python/R support Cluster Mode Java/Scala Support Dynamic Allocation Local File Staging High Availability Spark SQL GraphX MLlib Dec 2016 Development Began Mar 2017 Alpha Release June 2017 Beta Release Nov 2016 Design = supported but untested = not yet supported
32. We’re just getting started... • Kubernetes CustomResources • Priorities and Preemption for Pods • Batch Scheduling and Resource Sharing • Cluster Federation and Multi-cloud deployments • Ecosystem: Kafka, Cassandra, HDFS, etc
33. Contributors Organizations Alphabetically: • Google • Haiwen • Hyperpilot • Intel • Palantir • Pepperdata • Red Hat Links: • Spark 2.2.0 Documentation • https://issues.apache.org/jira/browse /SPARK-18278 • https://github.com/kubernetes/kubern etes/issues/34377
34. Try it out today! https://github.com/apache-spark-on-k8s/spark
35. Thank You. HDFS on Kubernetes - Lessons Learned June 7 at 11:00 AM in Room 2003 Join us Wednesdays at 10am PT at the SIG BigData meeting https://github.com/kubernetes/community/
