Containing Chaos with Kubernetes

Containing Chaos with Kubernetes

An Introduction to the whys and hows of Kubernetes.

Terrence Ryan

October 08, 2015
Tweet

More Decks by Terrence Ryan

Other Decks in Technology

Transcript

  1. ‹#› @tpryan # BACKEND FROM ubuntu:12.04 ADD ./mysql-setup.sh /tmp/mysql-setup.sh RUN

    /bin/sh /tmp/mysql-setup.sh EXPOSE 3306 CMD ["/usr/sbin/mysqld"]
  2. ‹#› @tpryan # FRONTEND AND SERVICES FROM nginx-php-fpm COPY nginx.conf

    /etc/nginx/nginx.conf ADD www /var/www/ # JUST SERVICES FROM nginx-php-fpm COPY nginx.conf /etc/nginx/nginx.conf ADD www /var/www/
  3. ‹#› @tpryan # FRONTEND AND SERVICES FROM nginx-php-fpm COPY nginx.conf

    /etc/nginx/nginx.conf ADD www /var/www/ # FRONTEND FROM nginx COPY nginx.conf /etc/nginx/nginx.conf ADD www /var/www/
  4. ‹#› @tpryan # BACKEND FROM ubuntu:12.04 ADD ./mysql-setup.sh /tmp/mysql-setup.sh RUN

    /bin/sh /tmp/mysql-setup.sh EXPOSE 3306 CMD ["/usr/sbin/mysqld"] # BACKEND FROM ubuntu:12.04 ADD ./mysql-setup.sh /tmp/mysql-setup.sh RUN /bin/sh /tmp/mysql-setup.sh EXPOSE 3306 VOLUME ["/etc/mysql", "/var/lib/mysql"] CMD ["/usr/sbin/mysqld"]
  5. ‹#› @tpryan Kubernetes • Container Orchestration System • Open Source

    • Started by Google • Contributed to by others
  6. ‹#› @tpryan Cattle • Has a number • One is

    much like any other • Run as a group • If it gets ill, you make hamburgers Pet • Has a name • Is unique or rare • Personal Attention • If it gets ill… you make it better
  7. ‹#› @tpryan Child • Go upstairs • Get undressed •

    Put on pajamas • Brush your teeth • Pick out 2 stories Employee • “We had a tough day, go home and get some sleep”
  8. ‹#› @tpryan Nodes • Machines that run Kubernetes • Containers

    will run on these • Can by hardware or virtual
  9. ‹#› @tpryan Pods • Atomic component of Kubernetes • Made

    from one or more containers • Share • IP Address • Local Storage • Namespace • It’s okay to have just one container • Examples • Sidecar (Webserver + File sync) • Ambassador • Adaptor • Converting an all in one box
  10. ‹#› @tpryan Pods apiVersion: v1 kind: Pod metadata: name: php

    labels: name: php spec: containers: - image: nginx-php-fpm:latest name: php ports: - containerPort: 80 name: http apiVersion: v1 kind: Pod metadata: name: php labels: name: php spec: containers: - image: nginx-php-fpm:latest name: php ports: - containerPort: 80 name: http
  11. ‹#› @tpryan Controllers • Handle turning current state into desired

    state • Example • Replication Controllers Observe Diff Act
  12. ‹#› @tpryan Controllers kind: "ReplicationController" apiVersion: "v1" id: fe-rc-1 metadata:

    name: "frontend-controller" labels: state: "serving" spec: replicas: 2 selector: app: "todotodo-fe" version: v1 template: metadata: labels: app: "todotodo-fe" version: v1 spec: volumes: null containers: - name: "php" image: "nginx-php-fpm:latest" ports: - containerPort: 80 protocol: "TCP" imagePullPolicy: "IfNotPresent" restartPolicy: "Always" dnsPolicy: "ClusterFirst" kind: "ReplicationController" apiVersion: "v1" id: fe-rc-1 metadata: name: "frontend-controller" labels: state: "serving" spec: replicas: 2 selector: app: "todotodo-fe" version: v1 template: metadata: labels: app: "todotodo-fe" version: v1 spec: volumes: null containers: - name: "php" image: "nginx-php-fpm:latest" ports: - containerPort: 80 protocol: "TCP" imagePullPolicy: "IfNotPresent" restartPolicy: "Always" dnsPolicy: "ClusterFirst"
  13. ‹#› @tpryan Replica Set • Everything that Replication Controllers do

    • Can do set-based selector • Lot of the docs will refer to Replication Controllers but you can move to Replica sets.
  14. ‹#› @tpryan Deployments • An improvement over previous rolling updates.

    • Allow for easy updates to application pieces.
  15. ‹#› @tpryan apiVersion: extensions/v1beta1 kind: Deployment metadata: name: frontend-deployment spec:

    replicas: 2 strategy: type: RollingUpdate template: metadata: labels: app: todotodo-fe spec: containers: - name: php image: nginx-php-fpm:latest ports: - containerPort: 80 Deployments apiVersion: extensions/v1beta1 kind: Deployment metadata: name: frontend-deployment spec: replicas: 2 strategy: type: RollingUpdate template: metadata: labels: app: todotodo-fe spec: containers: - name: php image: nginx-php-fpm:latest ports: - containerPort: 80
  16. ‹#› @tpryan Services • Defines an endpoint from which to

    access applications • Gets a virtual IP address • Can get a public load balancer • Used for exposing an application • Other Kubernetes clients • Non-Kubernetes clients 192.168.99.100
  17. ‹#› @tpryan Services apiVersion: v1 kind: Service metadata: labels: name:

    frontend name: frontend spec: type: LoadBalancer ports: - port: 80 targetPort: 80 protocol: TCP selector: app: "todotodo-fe" apiVersion: v1 kind: Service metadata: labels: name: frontend name: frontend spec: type: LoadBalancer ports: - port: 80 targetPort: 80 protocol: TCP selector: app: "todotodo-fe"
  18. ‹#› @tpryan Labels & Selectors • Metadata for Objects •

    Select sections of your infrastructure App Tier Env todo frontend stage App Tier Env todo frontend prod App Tier Env todo frontend dev App Tier Env todo frontend test App Tier Env todo api prod App Tier Env todo backend prod App Tier Env todo api stage App Tier Env todo api test App Tier Env todo api dev App Tier Env todo backend stage App Tier Env todo backend test App Tier Env todo backend dev
  19. ‹#› @tpryan Labels & Selectors & Services App todo-fe apiVersion:

    extensions/v1beta1 kind: Deployment metadata: name: fe-deployment spec: replicas: 4 strategy: type: RollingUpdate template: metadata: labels: app: todo-fe spec: containers: - name: php image: app ports: - containerPort: 80 App todo-fe App todo-fe App todo-fe apiVersion: v1 kind: Service metadata: labels: name: frontend name: frontend spec: type: LoadBalancer ports: - port: 80 targetPort: 80 protocol: TCP selector: app: "todo-fe" 192.168.99.100 130.91.xxx.xxx Public Private
  20. ‹#› @tpryan Networking • Pod IPs are routable • Docker

    default is private IP • Pods can reach each other without NAT • even across Kubernetes nodes
  21. ‹#› @tpryan apiVersion: apps/v1beta1 kind: StatefulSet metadata: name: mysql labels:

    name: mysql spec: serviceName: "mysql" replicas: 1 template: metadata: labels: name: mysql Stateful Set spec: terminationGracePeriodSeconds: 0 containers: - name: mysql image: "gcr.io/gke-test-tpryan/mysql-php" ports: - containerPort: 3306 name: mysql volumeMounts: - name: mysqlpet mountPath: /var/lib/mysql volumeClaimTemplates: - metadata: name: mysqlpet spec: accessModes: [ "ReadWriteOnce" ] resources: requests: storage: 1Gi apiVersion: apps/v1beta1 kind: StatefulSet metadata: name: mysql labels: name: mysql spec: serviceName: "mysql" replicas: 1 template: metadata: labels: name: mysql spec: terminationGracePeriodSeconds: 0 containers: - name: mysql image: "gcr.io/gke-test-tpryan/mysql-php" ports: - containerPort: 3306 name: mysql volumeMounts: - name: mysqlpet mountPath: /var/lib/mysql volumeClaimTemplates: - metadata: name: mysqlpet spec: accessModes: [ "ReadWriteOnce" ] resources: requests: storage: 1Gi
  22. ‹#› @tpryan Secrets • Secrets interface for sensitive data •

    Can be mounted as files • Can be imported directly to ENV
  23. ‹#› @tpryan apiVersion: v1 kind: Secret metadata: name: mysecret type:

    Opaque data: password: MWYyZDFlMmU2N2Rm username: YWRtaW4= Secrets apiVersion: v1 kind: Secret metadata: name: mysecret type: Opaque data: password: MWYyZDFlMmU2N2Rm username: YWRtaW4=
  24. ‹#› @tpryan containers: - name: php image: gcr.io/gke-test-tpryan/php ports: -

    containerPort: 80 env: - name: USERNAME valueFrom: secretKeyRef: name: mysecret key: username - name: PASSWORD valueFrom: secretKeyRef: name: mysecret key: password Secrets containers: - name: php image: gcr.io/gke-test-tpryan/php ports: - containerPort: 80 env: - name: USERNAME valueFrom: secretKeyRef: name: mysecret key: username - name: PASSWORD valueFrom: secretKeyRef: name: mysecret key: password
  25. ‹#› @tpryan Horizontal Autoscaler • Upscales or downscales as necessary

    • Processor utilization • Custom Application metrics • Allows for pods to autoscale but not nodes.
  26. ‹#› @tpryan apiVersion: extensions/v1beta1 kind: HorizontalPodAutoscaler metadata: name: frontend-deployment spec:

    cpuUtilization: targetPercentage: 80 maxReplicas: 5 minReplicas: 1 scaleRef: apiVersion: extensions/v1beta1 kind: Deployment name: frontend-deployment subresource: scale Horizontal Autoscaler apiVersion: extensions/v1beta1 kind: HorizontalPodAutoscaler metadata: name: frontend-deployment spec: cpuUtilization: targetPercentage: 80 maxReplicas: 5 minReplicas: 1 scaleRef: apiVersion: extensions/v1beta1 kind: Deployment name: frontend-deployment subresource: scale
  27. ‹#› @tpryan There’s More • Logging • Monitoring • Events

    • Web Interface • Configmaps • Jobs • Ubernetes
  28. ‹#› @tpryan Kubernetes Docker Swarm Docker Compose Docker Machine Launch

    Container hosts in several clouds Cluster of Container Hosts Replication Orchestration Scheduling Routable Network Scheduled Jobs Stateful Set Autoscaling Secrets Config Maps Multiple containers on same localhost Manage Remote Container Hosts Docker
  29. ‹#› @tpryan Kubernetes • Management software for containers • Has

    strong opinions • Service Discovery • Logging • Can run on top of Mesos Mesos • Multi machine kernel • Turns datacenter (or all installed machines) into a single logical system • Can do containers • Can do other distributed jobs
  30. ‹#› @tpryan Setting up a cluster • Choose an infrastructure:

    • Google Cloud Platform, AWS, Azure, Rackspace, on-premises, …
  31. ‹#› @tpryan Setting up a cluster • Choose an infrastructure:

    • Google Cloud Platform, AWS, Azure, Rackspace, on-premises, … • Choose a node OS: • CoreOS, Atomic, RHEL, Debian, CentOS, Ubuntu, ...
  32. ‹#› @tpryan Setting up a cluster • Choose an infrastructure:

    • Google Cloud Platform, AWS, Azure, Rackspace, on-premises, … • Choose a node OS: • CoreOS, Atomic, RHEL, Debian, CentOS, Ubuntu, ... • Provision machines: • Boot VMs, install and run kube components, ...
  33. ‹#› @tpryan Setting up a cluster • Choose an infrastructure:

    • Google Cloud Platform, AWS, Azure, Rackspace, on-premises, … • Choose a node OS: • CoreOS, Atomic, RHEL, Debian, CentOS, Ubuntu, ... • Provision machines: • Boot VMs, install and run kube components, ... • Configure networking: • IP ranges for Pods, Services, SDN, ...
  34. ‹#› @tpryan Setting up a cluster • Choose an infrastructure:

    • Google Cloud Platform, AWS, Azure, Rackspace, on-premises, … • Choose a node OS: • CoreOS, Atomic, RHEL, Debian, CentOS, Ubuntu, ... • Provision machines: • Boot VMs, install and run kube components, ... • Configure networking: • IP ranges for Pods, Services, SDN, ... • Start cluster services: • DNS, logging, monitoring, ...
  35. ‹#› @tpryan Setting up a cluster • Choose an infrastructure:

    • Google Cloud Platform, AWS, Azure, Rackspace, on-premises, … • Choose a node OS: • CoreOS, Atomic, RHEL, Debian, CentOS, Ubuntu, ... • Provision machines: • Boot VMs, install and run kube components, ... • Configure networking: • IP ranges for Pods, Services, SDN, ... • Start cluster services: • DNS, logging, monitoring, ... • Manage nodes: • kernel upgrades, OS updates, hardware failures...
  36. ‹#› @tpryan Container Engine • Hosted Kubernetes • A few

    smart defaults set • Allow for dipping your feet in • Allows for node autoscaling
  37. ‹#› @tpryan Kubernetes is Open Source We want your help!

    • http://kubernetes.io • https://github.com/kubernetes/kubernetes • irc.freenode.net #google-containers • @kubernetesio
  38. ‹#› @tpryan Roadmap Kubernetes 1.5 Released: December 2016 • Stateful

    State beta • Pod Disruption Budget beta • Federated Kubernetes CLI • Windows Containers alpha http://blog.kubernetes.io/2016/12/kubernetes-1.5-supporting-production-workloads.html
  39. ‹#› @tpryan Everything at Google runs on Containers: • Gmail,

    Web Search, Maps, ... • MapReduce, batch, ... • GFS, Colossus, ... • Even Google’s Cloud Platform: VMs run in containers! We launch 2 Billion Containers a week
