Digitransit – how to deploy 100% open journey planners

Presentation at State of the Map 2016 conference in Brussels on OpenStreetMap, in workshop
The state of public transport routing

Tuukka Hastrup

September 25, 2016
Tweet

More Decks by Tuukka Hastrup

Other Decks in Technology

Transcript

  1. Introducing HSL: Helsinki Regional Transport Authority HSL organises all bus,

    tram, subway and commuter train lines, ticketing and passenger information in the region. • 1.3 million citizens • 1 million boardings per day • 344 lines + citybike rental system
  2. HSL Journey Planner • People love our journey planner since

    2001. • Open data and APIs since 2009. • Tens of mobile apps, mostly ”serverless”.
  3. Problems with closed map data • Costs: Use as little

    as possible. • Fragmented: Need to manually combine datasets. • Incomplete: Own additional dataset of walking paths. • Slow: Need to self-maintain, still out of date. • Inaccurate: Bad paths to stops (~8000) and addresses. • Inconsistent: Routing doesn’t match basemap. • Non-sharable: Consumers of data and APIs left without.
  4. 100% open passenger information • Open data − Schedules in

    GTFS format − Vehicle positions, timetable estimates and service alerts − Addresses from OSM, OpenAddresses and Who’s On First − Street routing and basemap from OpenStreetMap • Open APIs − Raster tiles for basemap − Vector tiled data − GraphQL for flexible and efficient queries − MQTT for realtime data push
  5. 100% open passenger information • Open source − Digitransit-ui using

    HTML5, React, Leaflet, Piwik, Sentry etc. − OpenTripPlanner 1.0 (contributed GraphQL API, airlines etc.) − Pelias (improvements for i18n, Finland l10n, QA tools) − OSM2VectorTiles (public transport improvements, fixes) − HSL map style based on OSM Bright − Docker deployment scripts • (HSL font and logo are not open.)
  6. Current coverage • Helsinki region instance provided by HSL •

    Finland provided by Finnish Transport Agency • Finnish cities in the works by Waltti travel card • Norway provided by Nasjonal Reiseplanlegger • South Tyrol, Italy provided by SASA • Tallinn, Estonia in the works as a EU project
  7. OpenTripPlanner • Multimodal combinations of walking/wheelchair, elevators, escalators, bicycle, citybike,

    car, public transport • Routing based on realtime data and elevation profile. • Routing configurable by many parameters. • Next generation, lighter codebase in the works as R5 (Rapid Realistic Routing on Real-world and Reimagined networks).
  8. Contributions to OSM via a use case • People want

    to go places taking advantage of public transport. − Public transport routing on OpenStreetMap.org front page to help how to get there, what route is best, realtime situation? • Raise awareness among government, cities, citizens, developers, consultants, IT students, researchers. • Bring new users and contributors for crowdsourced validation, especially routability, access, addresses. • Mapping and validation work by government
  9. Wishlist • Wider, more inclusive community − HOT-OSM! • Our

    own namespace − hsl_thinks:access=no • Clear separation of ODBL and government open data • Completion of goverment open data import in Finland • 3D editing of station indoor areas.
  10. Thank you! Old demo for Belgium: http://dev.hsl.fi/belgium Project site: http://digitransit.fi/en

    Open data at HSL: http://dev.hsl.fi/ GitHub: http://github.com/HSLdevcom Contact: @tuukkah [email protected]
