Amazon API Gateway Study Workshop

Transcript

1. API Gateway Study Workshop 06/18/2020 by 37108
2. API Application Programming Interface
3. API Gateway is a fully managed service that makes it easy for developers to create, publish, maintain, monitor, and secure APIs at any scale. https://go.aws/30gXhc7
4. API Gateway
5. Talking Basic knowledge of API Gateway Core Feature of API Gateway REST API and HTTP API
6. Basic Components method res method req integration req integration res
7. Basic Components Method Request method res method req integration req integration res
8. Basic Components Integration Request method res method req integration req integration res
9. Basic Components Integration Response method res method req integration req integration res
10. Basic Components Method Response method res method req integration req integration res
11. Resource / Method / ANY /members GET /members/{id} GET POST /parts/ GET method req… method req… method req… method req…
12. Request API Flow /members GET method req integ req integ res method res /members/{id} POST method req integ req integ res method res
13. Integration Types AWS Services Directly calls AWS services and fire the specify action. HTTP Connects via internet to a HTTP endpoint. Lambda Connects via proxy or direct integration to a Lambda. Mock Directly calls AWS services and fire the specify action. VPC Endpoint Connects to a VPC Endpoint. Access through a NLB.
14. Lambda Backend via Proxy Synchronous res res req Wrapped req Wrapped req res
15. Lambda Backend via direct integration Synchronous req req res res req req res res
16. Lambda Resource Policy { “version”: “2012-10-17”, “statement”: { “Effect” : “Allow”, “Principle”: “apigateway.amazonaws.com”, “Action” : “lambda:InvokeFunction”, “Resource” : “arn:aws:lambda:…:function_name”, “Condition”: { “ArnLike”: { “AWS:SourceArn”: “arn:aws:execute-api:…:id/stage/method/resource” } } } }
17. Lambda Resource Policy Allow every stages, resources { “version”: “2012-10-17”, “statement”: { “Effect” : “Allow”, “Principle”: “apigateway.amazonaws.com”, “Action” : “lambda:InvokeFunction”, “Resource” : “arn:aws:lambda:…:function_name”, “Condition”: { “ArnLike”: { “AWS:SourceArn”: “arn:aws:execute-api:…:id ” } } } }
18. Lambda Resource Policy Allow every lambda authorizer { “version”: “2012-10-17”, “statement”: { “Effect” : “Allow”, “Principle”: “apigateway.amazonaws.com”, “Action” : “lambda:InvokeFunction”, “Resource” : “arn:aws:lambda:…:function_name”, “Condition”: { “ArnLike”: { “AWS:SourceArn”: “arn:aws:execute-api:…:id/authorizers ” } } } }
19. Mapping Template before after { “FirstName”: “Alexander”, “LastName” : “Pierce”, “phone” : “000-0000-0000”, “address” : “xxx”, “favorite” : “eggplant” } { “Name” : “Alexander Pierce”, “phone” : “000-0000-0000”, “address” : “xxx”, “favorite”: “beef” }
20. method res method req integration req </> {;} integration res </> {;} Mapping Template
21. Request API Flow /members GET method req integ req integ res method res /members/{id} POST method req integ req integ res method res
22. Stages v1 v2 v3 https://xxx.execute-api…/v1/… https://xxx.execute-api…/v2/… https://xxx.execute-api…/v3/…
23. Deploy Deploy 2020/06/18 Deploy 2020/06/05 v1 v2 v3 https://xxx.execute-api…/v1/… https://xxx.execute-api…/v2/… https://xxx.execute-api…/v3/…
24. Request API Flow /members GET method req integ req integ res method res /members/{id} POST method req integ req integ res method res v1 v2
25. Endpoint Type Edge Regional VPC Routing from CloudFront Distribution. Routing directly to region. Can combine with CloudFront. Routing from VPC Private Link. No public endpoint.
26. Release it ! 1. Design API 2. Choose Protocol and Endpoint 3. Define Resources and Methods 4. Integrate Backend 5. Create Stage and deploy
27. Protect API Open IAM Lambda Authorizer Cognito Authorizer No AuthN and AuthZ. API is Public and everybody can access. Use IAM credentials for grant access. Connect Cognito User Pool for grant access. Validate bearer token via Lambda for grant access.
28. Lambda Authorizer
29. Lambda Authorizer input output eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXV CJ9.eyJzdWIiOiIxMjM0NTY3ODkwIiwib mFtZSI6IkpvaG4gRG9lIiwiaWF0IjoxNT E2MjM5MDIyfQ.SflKxwRJSMeKKF2QT4fw pMeJf36POk6yJV_adQssw5c { “principalId”: “AlexanderPierce”, “policyDocument”: { “Version”: “2012-10-17”, “Statement”: [ { “Action”: “execute-api:Invoke”, “Effect”: “Allow”, “Resource”: “………” } ] } }
30. SPA Architecture
31. Regular Architecture
32. Manage REST API CDK Terraform CLI CFn SAM
33. Open API OAS OAS export define refer import
34. Token Bucket 5,000 Tokens on Bucket 10,000 tokens/sec Rate: Rate: Burst: Burst: Requests Consumes
35. Throttling 10,000 reqs/sec Account: Account: API 1 API 1 method method method method /members GET /pets GET /parta GET
36. Monitoring/Tracing Metrics by APIs, Stages. API Calls Latency 4xxx / 5xx Error Cache HitCount Execution logs error/info level full req/res logs Access logs specify log destination customize log format Integrate X-Ray and trace request. Just enable tracing, analyze requests end to end.
37. Caching 0.5 GB to 237 GB Capacity 0 sec to 3600 sec TTL
38. Security
39. Canary release n% of traffic x duration prod canary
40. HTTP API Faster reduces up to 60% in latency. Lower Cost Frugality is one of the Leadership Principles. Overall, at least 71% lower cost. More Simple JWT Authorizer Features are specified, but this makes more simple. No need to write code for validating JWT.
41. Routes / /members GET /members/ba GET /members/ba POST /parts GET
42. Integrations / /members GET /members/ba GET /members/ba POST /parts GET Invoke function private integration private integration get https://xxx.example.com
43. stages / deploy Deploy 2020/06/18 Deploy 2020/06/05 $default v1 v2 https://xxx.execute-api…/… https://xxx.execute-api…/v1/… https://xxx.execute-api…/v2/…
44. JWT Authorizer 1. verify token 2. grant access
45. To Closely You know core features. We need practices. We can’t cover whole of features…
