Rebuild The Heaven's Gate: from 32 bit Hell back to Heaven Wonderland

Microsoft embeds a translation design named WoW64 (Windows 32 on Windows 64) used for running 32 bit PE (Portable Executable format) on 64 bit Windows. The design basically hosts every 32 bit PE file inside as a native standalone 64-bit process and translates every 32-bit system interrupt into a 64-bit syscall. In this talk, we’re going to talk about deep reversing engineering on WoW64 architecture how it does translations, and some uncovered issues about crossing-architecture could be abused in the wild.

https://conference.hitb.org/hitbsecconf2021ams/sessions/wow-hell-rebuilding-heavens-gate/

adr

May 27, 2021
Tweet

More Decks by adr

Other Decks in Technology

Transcript

  1. • Intern at CyCraft • Core member of CHROOT Security

    Group • Spoke at S&P, BlackHat, DEFCON, HITCON • Instructor of Ministry Of National Defense, Ministry of Education, HITCON, and etc. • Publication Windows APT Warfare #Windows #Reversing #Pwn #Exploit Sheng-Hao Ma (aaaddress1) Threat Researcher at TXOne Networks
  2. [email protected] • 32-bit Hell & Userland HIPS Design • Understanding

    WOW64 Design by Reversing Engineering 1. WOW64 Process Initiation 2. Path to The Heaven 3. The Paradise Translator • The 32-bit Hell v.s. 64-bit Heaven • wowGrail: Rebuild the Heaven's Gate • wowInjector: One Gadget to Take Over The Hell /?outline
  3. a.exe wow64 ntdll.dll kernel32.dll ... wow64.dll wow64cpu.dll wow64win.dll 4G ntdll.dll

    x86 Modules x64 Modules Ring0 ntdll64!NtAPI#ZwOpenProcess KiFastCall Heaven's Gate A. switch to 64bit CPU mode by setting cs flag B. get PEB64 by (GS:0x30)->PEB C. enumerate loaded 64bit modules via PEB->Ldr D. locate imageBase of NtDll64 E. get expored API ntdll!LdrGetProcedureAddress F. BOOM! we got the key of Heaven's Gate! #theGate
  4. [email protected] Reference • 2011 - Mixing x86 with x64 code

    by ReWolf • 2012 - Knockin’ on Heaven’s Gate by george_nicolaou • 2012 - KERNEL: Creation of Thread Environment Block (TEB) by waleedassar • 2015 - WoW64 and So Can You Bypassing EMET by Duo Labs • 2018 - WoW64 internals by wbenny • 2020 - WOW64 Subsystem Internals and Hooking Techniques by FireEye #theGate too difficult to use & not stable enough ಥ_ಥ • 2021 - wowGrail: Abusing the Translator to Simulate 32-bit Interrupts
  5. [email protected] #Simulate [FireEye] WOW64!Hooks: WOW64 Subsystem Internals and Hooking Techniques

    wow64cpu!CpupReturnFromSimulatedCode 1. save current 32bit context status, stack, and caller retAddr 2. simulate 32bit behavior to 64bit KiFastCall by wow64SystemServiceEx 3. save NTSTATUS into WoW64 Thread CONTEXT.eax
  6. [email protected] a.exe wow64 ntdll.dll kernel32.dll ... wow64.dll wow64cpu.dll wow64win.dll #WoW64

    wow64cpu!X86SwitchTo64BitMode a. NtAPI b. switch x86 → x64 architecture
  7. [email protected] a.exe wow64 ntdll.dll kernel32.dll ... wow64.dll wow64cpu.dll wow64win.dll #WoW64

    wow64cpu!X86SwitchTo64BitMode a. NtAPI b. switch x86 → x64 architecture wow64cpu!CpupReturnFromSimulatedCode c. save context status
  8. [email protected] a.exe wow64 ntdll.dll kernel32.dll ... wow64.dll wow64cpu.dll wow64win.dll #WoW64

    wow64cpu!X86SwitchTo64BitMode a. NtAPI b. switch x86 → x64 architecture wow64cpu!CpupReturnFromSimulatedCode c. save context status wow64!Wow64SystemServiceEx d. lookup turbo function
  9. [email protected] a.exe wow64 ntdll.dll kernel32.dll ... wow64.dll wow64cpu.dll wow64win.dll #WoW64

    wow64cpu!X86SwitchTo64BitMode a. NtAPI b. switch x86 → x64 architecture wow64cpu!CpupReturnFromSimulatedCode c. save context status wow64!Wow64SystemServiceEx d. lookup turbo function wow64!turbo_func e. translate x86 arguments & invoke ntdll64!NtAPI
  10. [email protected] a.exe wow64 ntdll.dll kernel32.dll ... wow64.dll wow64cpu.dll wow64win.dll #WoW64

    wow64cpu!X86SwitchTo64BitMode a. NtAPI b. switch x86 → x64 architecture wow64cpu!CpupReturnFromSimulatedCode c. save context status wow64!Wow64SystemServiceEx d. lookup turbo function wow64!turbo_func e. translate x86 arguments & invoke ntdll64!NtAPI Ring0 f. syscall
  11. [email protected] a.exe wow64 ntdll.dll kernel32.dll ... wow64.dll wow64cpu.dll wow64win.dll #WoW64

    wow64cpu!X86SwitchTo64BitMode a. NtAPI b. switch x86 → x64 architecture wow64cpu!CpupReturnFromSimulatedCode c. save context status wow64!Wow64SystemServiceEx d. lookup turbo function wow64!turbo_func e. translate x86 arguments & invoke ntdll64!NtAPI Ring0 f. syscall wow64cpu!restoreStatus g. back to caller
  12. [email protected] #Recap • Switching the CS segment to 23h or

    33h makes it possible for the Intel chip to change the chosen instruction set with 32 bit or 64 bit. • Register r13 point to the 32-bit thread context used as snapshot status. It will be back up when the thread jumps from 32-bit to 64-bit, and reset from 64 bit back to 32-bit. • wow64!Wow64SystemServiceEx used as translator for us to simulate any 32-bit system interrupt to the 64-bit kernel.
  13. a.exe wow64 ntdll.dll kernel32.dll ... wow64.dll wow64cpu.dll wow64win.dll 4G ntdll.dll

    x86 Modules x64 Modules wow64cpu!X86SwitchTo64BitMode wow64cpu!CpupReturnFromSimulatedCode wow64!Wow64SystemServiceEx wow64!turbo_func Ring0 ntdll32!NtAPI#ZwOpenProcess ntdll64!NtAPI#ZwOpenProcess WoW64 Layer normal KiFastCall
  14. a.exe wow64 ntdll.dll kernel32.dll ... wow64.dll wow64cpu.dll wow64win.dll 4G ntdll.dll

    x86 Modules x64 Modules wow64cpu!X86SwitchTo64BitMode wow64cpu!CpupReturnFromSimulatedCode wow64!Wow64SystemServiceEx wow64!turbo_func Ring0 ntdll32!NtAPI#ZwOpenProcess ntdll64!NtAPI#ZwOpenProcess WoW64 Layer normal KiFastCall Abusing The Heaven's Translator
  15. a.exe wow64 ntdll.dll kernel32.dll ... wow64.dll wow64cpu.dll wow64win.dll 4G ntdll.dll

    x86 Modules x64 Modules Ring0 ntdll64!NtAPI#ZwOpenProcess KiFastCall wowGrail A. switch to 64bit CPU mode by setting cs flag B. get PEB64 by (GS:0x30)->PEB C. enumerate loaded 64bit modules via PEB->Ldr D. locate imageBase of WoW64.dll E. get expored API wow64!Wow64SystemServiceEx F. pass 32-bit va_start & executing it to simulate our 32-bit as 64-bit interrupt ;) #wowGrail wow64!Wow64SystemServiceEx
  16. Ring0 f. syscall wow64!Wow64SystemServiceEx d. lookup turbo function wow64!turbo_func e.

    translate x86 arguments & invoke ntdll64!NtAPI a.exe wow64 ntdll.dll kernel32.dll ... wow64.dll wow64cpu.dll wow64win.dll wow64cpu!X86SwitchTo64BitMode b. switch x86 → x64 architecture wow64cpu!CpupReturnFromSimulatedCode c. save context status wow64cpu!restoreStatus g. back to caller a. NtAPI
  17. [email protected] Recap • Register r13 point to the 32-bit thread

    context used as snapshot status. It will be back up when the thread jumps from 32-bit to 64-bit, and reset from 64 bit back to 32-bit. • when $RIP jump into wow64cpu!X86SwitchTo64BitMode, current thread context status will be saved into the 32-bit thread context dereferenced from r13. • $RIP jump from 64-bit back to 32-bit, and the thread context will be restored from the 32-bit thread context.
 → It can be used as one gadget to exploit the next 32-bit $RIP ;)
  18. • 0x2000 or 0x3000 (it's up to WoW64) • TEB64

    + TEB32 + PEB64 + PEB32 • fixup TEB64: .self, .peb, .stack etc • TEB64.ExceptionList always null • fixup TEB32 based on TEB64 • TEB32.ExceptionList[0] = ffffffff 0x3000 → Leak any one of the 4 blocks, and we can get the other 3 blocks. nt!MiCreatePebOrTeb
  19. [email protected] DEMO: wowInjector One Gadget Injection to Take Over The

    32-bit Hell Process Inject & Bypass HIPS of another AV github.com/aaaddress1/wowInjector
