Effective DI with Multi-Modular Architecture

Dividing the module of a Monolithic Android app to realise multi-module application is considered as an important concern in recent Android development.

This session distils all the pitfalls and best practices in building a complex app and take a look at the usefulness of multi-module application and how we implemented Dependency Injection in our consumer app at Gojek(superapp.is)

Some of the highlight points of this session are :

1. Reintroduction to DI
2. Reintroduction to Dagger-Android
3. DI in single module projects
4. DI hotness in multi-module projects
5. Realise DI in multi-module projects using Dagger2

Transcript

1. Effective DI with Multi-Modular Architecture
2. Adit Lal GoPay $6.5B @aditlal We have 20+ products from food tech to fin-tech to hyper local delivery and massage services Ride Sharing 20m KM
3. app core feature 2 feature 1 Monolith Expensive Object
4. What could possibly go wrong?
5. Solve DI with Multi-Modular codebase
6. Modularise?
7. app core Feature B Feature A Feature modules Expensive Object
8. • Organise and decouple independent pieces of functionality • Improve project build times • Define clear ownership boundaries between different teams Thoughts on modularisation
9. Feature module : • Owned by single team ? Set of team members • Encapsulates single feature • Single entry point • Smaller is better • Cannot depend on other feature modules Thoughts on modularisation
10. App module : • No feature-specific code • No infrastructure-specific code. • Creates the dagger component Thoughts on modularisation
11. Ownership? core auth common Feature n-1 Feature n+2 Feature n-2 Feature z Feature n Feature n+1 app … … … … …
12. Ownership? core auth common Feature n-1 Feature n+2 Feature n-2 Feature z Feature n Feature n+1 app … … … … …
13. Inversion of control Dependency Inversion Dependency Injection IoC Principle
14. • Declare Components that can be reused. • High level modules should not depend on low level modules • Build abstractions so any implementation can be easily changed with new one. • Dependencies can be injected into components. IoC Principle
15. Should I do Modularise to use Dagger?
16. Don’t do it for Dagger , do it for yourself
17. :feature1 F1SubComponent F1Module :feature2 F2SubComponent F2Module :core CoreComponent CoreModule Expensive Object :app MainComponent MainModule
18. :app MainComponent MainModule :feature1 F1Component F1Module :feature2 F2Component F2Module :core CoreComponent CoreModule Expensive Object
19. • We should prefer to be explicit with the module dependencies • We don’t want CoreComponent to know about FeatureComponent • It can’t check if the graph is correct. SubComponent goes away! It needs the parent = slower compilation
20. Core @Module class CoreModule { @Provides @Singleton fun provideExpObj(): ExpensiveObject = ExpensiveObject() }
21. @Component(modules = [CoreModule::class]) @Singleton interface CoreComponent { @Component.Builder interface Builder { fun build(): CoreComponent } fun provideExpensiveObject(): ExpensiveObject } Core
22. class OurMainApplication : Application() { private val coreComponent: CoreComponent by lazy { DaggerCoreComponent .builder() .build() } companion object { @JvmStatic fun coreComponent(context: Context) = (context.applicationContext as OurMainApplication).coreComponent } }
23. class OurMainApplication : Application() { private val coreComponent: CoreComponent by lazy { DaggerCoreComponent .builder() .build() } companion object { @JvmStatic fun coreComponent(context: Context) = (context.applicationContext as OurMainApplication).coreComponent } }
24. class OurMainApplication : Application() { private val coreComponent: CoreComponent by lazy { DaggerCoreComponent .builder() .build() } companion object { @JvmStatic fun coreComponent(context: Context) = (context.applicationContext as OurMainApplication).coreComponent } }
25. fun Activity.coreComponent() = OurMainApplication.coreComponent(this) Extension function
26. @Module class Feature1Module { @Provides fun provideString() = "test" } Feature 1
27. @Component(modules = [Feature1Module::class], dependencies = [CoreComponent::class]) interface Feature1Component { @Component.Builder interface Builder { fun coreComponent(coreComponent: CoreComponent): Builder } fun inject(activity: OtherActivity) } Feature 1
28. DaggerFeature1Component .builder() .coreComponent(this.coreComponent) .build() .inject(this) Feature 1
29. @Module class Feature2Module { @Provides fun provideInt() = 1 } Feature 2
30. @Component(modules = [Feature2Module::class], dependencies = [CoreComponent::class]) interface Feature2Component { @Component.Builder interface Builder { fun coreComponent(coreComponent: CoreComponent): Builder } fun inject(activity: MainActivity) } Feature 2
31. When dealing with component dependencies we must follow 2 simple rules: • An un-scoped component cannot depend on scoped components. • A scoped component cannot depend on a component with the same scope.
32. @Scope @Retention annotation class FeatureScope
33. @Component(modules = [Feature1Module::class], dependencies = [CoreComponent::class]) @FeatureScope interface Feature1Component { @Component.Builder interface Builder { fun coreComponent(coreComponent: CoreComponent): Builder } fun inject(activity: OtherActivity) }
34. @Component(modules = [Feature2Module::class], dependencies = [CoreComponent::class]) @FeatureScope interface Feature2Component { @Component.Builder interface Builder { fun coreComponent(coreComponent: CoreComponent): Builder } fun inject(activity: MainActivity) }
35. Component.dependencies • We can choose what we expose from each component • more verbosity • we can get dependencies from multiple components faster compilation
36. Let’s get to it
37. interface CoreComponentProvider { fun provideCoreComponent(): CoreComponent }
38. object CoreInjectHelper { fun provideCoreComponent(applicationContext: Context): CoreComponent{ return if (applicationContext is CoreComponentProvider) { (applicationContext as CoreComponentProvider).provideCoreComponent() } else { throw IllegalStateException( "The context passed does not implement CoreComponentProvider" ) } } }
39. object CoreInjectHelper { fun provideCoreComponent(applicationContext: Context): CoreComponent{ return if (applicationContext is CoreComponentProvider) { (applicationContext as CoreComponentProvider).provideCoreComponent() } else { throw IllegalStateException( "The context passed does not implement CoreComponentProvider" ) } } }
40. object CoreInjectHelper { fun provideCoreComponent(applicationContext: Context): CoreComponent{ return if (applicationContext is CoreComponentProvider) { (applicationContext as CoreComponentProvider).provideCoreComponent() } else { throw IllegalStateException( "The context passed does not implement CoreComponentProvider" ) } } }
41. class OurMainApplication : Application(), CoreComponentProvider { private lateinit var coreComponent: CoreComponent override fun provideCoreComponent(): CoreComponent { if (!this::coreComponent.isInitialized) { coreComponent = DaggerCoreComponent .builder() .build() } return coreComponent } }
42. class OurMainApplication : Application(), CoreComponentProvider { private lateinit var coreComponent: CoreComponent override fun provideCoreComponent(): CoreComponent { if (!this::coreComponent.isInitialized) { coreComponent = DaggerCoreComponent .builder() .build() } return coreComponent } }
43. class OurMainApplication : Application(), CoreComponentProvider { private lateinit var coreComponent: CoreComponent override fun provideCoreComponent(): CoreComponent { if (!this::coreComponent.isInitialized) { coreComponent = DaggerCoreComponent .builder() .build() } return coreComponent } }
44. class MainActivity : AppCompatActivity() { @Inject lateinit var expensiveObject: ExpensiveObject override fun onCreate(savedInstanceState: Bundle?) { ... DaggerFeature2Component .builder() .coreComponent(this.coreComponent()) .build() .inject(this) } }
45. class MainActivity : AppCompatActivity() { @Inject lateinit var expensiveObject: ExpensiveObject override fun onCreate(savedInstanceState: Bundle?) { ... DaggerFeature2Component .builder() .coreComponent(this.coreComponent()) .build() .inject(this) } }
46. Dagger.Android
47. @Scope annotation class ActivityScope
48. @Module(includes = [ AndroidSupportInjectionModule::class ]) abstract class AppModule { @ActivityScope @ContributesAndroidInjector() abstract fun contributesMainActivityInjector(): MainActivity @ActivityScope @ContributesAndroidInjector() abstract fun contributesOtherActivityInjector(): OtherActivity }
49. @Module(includes = [ AndroidSupportInjectionModule::class ]) abstract class AppModule { @ActivityScope @ContributesAndroidInjector() abstract fun contributesMainActivityInjector(): MainActivity @ActivityScope @ContributesAndroidInjector() abstract fun contributesOtherActivityInjector(): OtherActivity }
50. class OurMainApplication : Application(), CoreComponentProvider, HasActivityInjector { @Inject lateinit var dispatchingActivityInjector: DispatchingAndroidInjector<Activity> private lateinit var coreComponent: CoreComponent override fun onCreate() { super.onCreate() DaggerAppComponent.create().inject(this) } override fun activityInjector(): AndroidInjector<Activity> = dispatchingActivityInjector }
51. class OurMainApplication : Application(), CoreComponentProvider, HasActivityInjector { @Inject lateinit var dispatchingActivityInjector: DispatchingAndroidInjector<Activity> private lateinit var coreComponent: CoreComponent override fun onCreate() { super.onCreate() DaggerAppComponent.create().inject(this) } override fun activityInjector(): AndroidInjector<Activity> = dispatchingActivityInjector }
52. class OurMainApplication : Application(), CoreComponentProvider, HasActivityInjector { @Inject lateinit var dispatchingActivityInjector: DispatchingAndroidInjector<Activity> private lateinit var coreComponent: CoreComponent override fun onCreate() { super.onCreate() DaggerAppComponent.create().inject(this) } override fun activityInjector(): AndroidInjector<Activity> = dispatchingActivityInjector }
53. class OurMainApplication : Application(), CoreComponentProvider, HasActivityInjector { @Inject lateinit var dispatchingActivityInjector: DispatchingAndroidInjector<Activity> private lateinit var coreComponent: CoreComponent override fun onCreate() { super.onCreate() DaggerAppComponent.create().inject(this) } override fun activityInjector(): AndroidInjector<Activity> = dispatchingActivityInjector }
54. class MainActivity : AppCompatActivity() { @Inject lateinit var expensiveObject: ExpensiveObject override fun onCreate(savedInstanceState: Bundle?) { AndroidInjection.inject(this) ... } }
55. class MainActivity : AppCompatActivity() { @Inject lateinit var expensiveObject: ExpensiveObject override fun onCreate(savedInstanceState: Bundle?) { AndroidInjection.inject(this) ... } }
56. AndroidInjection.inject(this) Activity Fragment Service Content Provider Broadcast Receiver this
57. Tip @Inject lateinit var expensiveObject: Lazy<ExpensiveObject> expensiveObject.get()
58. • Always go for static provide methods. • Nobody cares about name of your Scope • Expose the application context through a component builder instead of a module with constructor argument. Or even better: use the new factory! Tip
59. @Module class Feature1Module { @Provides fun provideString() = "test" } Tip
60. @Module abstract class Feature1Module { @Binds abstract fun provideString() } Tip
61. Tip Module Module Factory Component @Provides Create a inject object Component @Binds Create a inject object
62. Tip @Binds @IntoMap @ViewModelKey(X1::class) abstract bindUserViewModel(x1 : ObjX) : ObjX
63. • Provide dependencies through class constructors • Avoid unnecessary scoping - Use scope annotations sparingly and judiciously Tl;Dr
64. • Use reusable components for expensive and immutable dependencies • Use @Binds instead of a @Provides method when simply delegating one type to another. • Write tests , switch dependencies on tests with a test component instead of overriding modules. Tl;Dr
65. • Using Dagger in multi-module by Marcos Holgado • Dependency injection in a multi module project - Plaid - Ben Weiss • Modularising Android Application by Marvin Ramin Resources
66. https://superapp.is https://www.gojek.io
67. Adit Lal @aditlal aditlal.dev Thats all folks! http://bit.ly/3a6Bid4
