LoRaWan, Sigfox, NB-IoT, LTE-M: quel LPWAN choisir pour son objet connecté ?

Les nouvelles technologies Low-Power Wide Area Networks (LPWAN) comme LoRa, Sigfox, ou NB-IoT permettent une communication de très longue portée (plusieurs kilomètres) avec une faible consommation d’énergie. Grace à ça, de nombreux acteurs voient dans LPWAN la possibilité d’éviter à la fois le coût prohibitif des réseaux cellulaires de type 4G pour la collecte des données pour l’Internet de Objets, mais aussi les réseaux multi-sauts de type IEEE802.15.4, coûteux à construire et à maintenir.

Alexis DUQUE

July 11, 2019
Tweet

More Decks by Alexis DUQUE

Other Decks in Technology

Transcript

  1. CRITERIA OF CHOICE ▸ Power Source? Battery capacity? ▸ Mobility?

    ▸ Localization? ▸ Local? Country? Worldwide? ▸ Range? ▸ Throughput? Latency? Message frequency? ▸ Cost (capex/opex)? Hardware? 6
  2. SIGFOX ▸ UNB combined with DBPSK (UL) and GFSK (DL)

    ▸ Unlicensed ISM bands 868MHz in Europe ▸ Random Access ▸ Bandwidth is 100Hz ▸ 100 bps ▸ Bidirectional but limited ▹ 140 (UL) - 4 (DL) mess/day ▸ 12 bytes (UL) & 8 bytes (DL) PDU ▸ Range : 10km (urban) - 40km (rural) ▸ Encryption let to the application layer 7
  3. LORAWAN ▸ CSS ▸ Unlicensed ISM bands: 868 MHz in

    Europe ▸ Bandwidth : 50 kHz and 125 kHz ▸ Adaptive data rate: SF7->SF12 ▸ 3 class of devices: A, B, C ▸ 300bps - 50 kbps - Bidirectional ▹ 243 bytes PDU ▸ 5 km (urban), 20 km (rural) ▸ Allow private network ▸ Encryption w/ AES 8
  4. NB-IOT ▸ QPSK + FDMA (UL) /OFDMA (DL) ▸ LTE

    Bands - 200 kHz bandwidth ▸ Inband - Guardband - Standalone ▸ 60 kbps DL - 30 kbps UL w/ CAT-N1 module (R13) ▹ X2 w/ Cat-N2 module (R14) ▸ Half-duplex and unlimited ▸ 1600 bytes PDU ▸ 2s latency ▸ 1 km (urban), 15km (rural) ▸ LTE authentication and encryption ▸ 100K devices per cell 9
  5. LTE-M ▸ 1Mbps(UL & DL) w/ Cat-M1 module (R13) ▸

    7Mbps(UL) & 4Mbps(DL) w/ Cat-M2 module (R14) ▸ 1,4MHz (Cat-M1) or 5MHz (Cat-M2) bandwidth ▸ Only Inband mode ▸ Handover support ▸ Voice ▸ LTE authentication and encryption ▸ 200ms latency - 300 km/h ▸ 10km (rural) 10
  6. 11

  7. BATTERY LIFE ▸ Cellular-IoT end device consumes additional power ▹

    synchronous communication and QoS ▹ OFDM/FDMA require more peak current. ▹ NB-IoT Battery Life > LTE-M removing LTE features ▹ Both support eDRX & PSM ▸ Depend on the LoRaWAN device class IoT devices are in sleep mode most of the time outside operation ⇒ battery life is use case dependant 12
  8. 13

  9. 15

  10. 16

  11. QUALITY OF SERVICE ▸ Sigfox and LoRa can bounce interference,

    multipath, and fading. However, they cannot offer the same QoS provided by Cellular-IoT ▸ QoS vs ¥ $€ NB-IoT is preferred for applications that require guaranteed QoS Applications that do not have this constraint should choose LoRa or Sigfox. 17
  12. SCALABILITY - DATA RATE ▸ Cellular-IoT allows up to 100K

    concurrent dev./cell ▸ NB-IoT 1600B vs LoRa 243B vs Sigfox 12B. ▸ LoRa more robust against motion vs Sigfox. Cellular-IoT is designed for that. Cellular IoT offers the advantage of very higher scalability than Sigfox and LoRa. 18
  13. LATENCY ▸ NB-IoT offers the advantage of low latency. ▸

    LoRa with class C ▹ low-bidirectional latency. ▹ expense of increased energy consumption. For applications that doesn’t requires low latency and low data to send, Sigfox and class-A LoRa are the best options. For applications that require real-time, LTE-M is required. For low latency (~s), NB-IoT and class-C LoRa are the better choices. 19
  14. LOCALIZATION CAPABILITY ▸ Sigfox: YES with RSSI. ▸ LoRaWAN: YES

    with TDOA ▸ LTE-M / NB-IoT: YES with Enhanced Cell Identity (ECID) & OTDOA but under standardization, not always deployed 20
  15. COSTS Hardware Module ▸ Sigfox & LoRaWAN < 2$ ▸

    Cellular-IoT ~15$ Network Operator ▸ Lora-Sigfox ~0.40$/month. ▸ Cellular IoT ~0.60$/MB/month 21
  16. REFERENCES ▸ B. E. Benhiba et al. “Comparative Study of

    The Various new Cellular IoT Technologies” in 2018 International Conference on Electronics, Control, Optimization and Computer Science (ICECOCS), 2018. ▸ A. Ikpehai et al., “Low-Power Wide Area Network Technologies for Internet-of-Things: A Comparative Review” IEEE Internet Things J., vol. 6, no. 2, Apr. 2019. ▸ W. Ayoubet al., “Internet of Mobile Things: Overview of LoRaWAN, DASH7, and NB-IoT in LPWANs standards and Supported Mobility” IEEE Commun. Surv. Tutorials, no. April 2016, 2018. ▸ S. C. Gaddam and M. K. Rai, “A Comparative Study on Various LPWAN and Cellular Communication Technologies for IoT Based Smart Applications” in 2018 International Conference on Emerging Trends and Innovations In Engineering And Technological Research (ICETIETR), 2018. ▸ X. Lin et al., “Positioning for the Internet of Things: A 3GPP Perspective” IEEE Commun. Mag., vol. 55, no. 12, 2017. 29
  17. REFERENCES ▸ O. Iova et al., “LoRa from the City

    to the Mountains : Exploration of Hardware and Environmental Factors” Int. Conf. Embed. Wirel. Syst. Networks, 2017. ▸ M. Bor et al. “Do LoRa Low-Power Wide-Area Networks Scale ?” 2016. ▸ F. Adelantado et al., “Understanding the limits of LoRaWAN”, 2016. ▸ https://lora-alliance.org/ ▸ https://www.orange-business.com/fr/reseau-LTE-M ▸ https://www.sfrbusiness.fr/room/internet-des-objets/ ▸ https://www.gsma.com/iot/mobile-iot/ 30
