Support Library 総復習
DroidKaigi 2016 Day2で発表した資料です。
This is a reference that was presented at DroidKaigi 2016 Day 2.
Takahiro Shimokawa
February 19, 2016
Transcript
82 slides
-
Support Library total review Takahiro Shimokawa ( @androhi ) 1
DroidKaigi 2016 -
I am ... • engineer at Zaim Inc. • DroidKaigi
2015 & 2016 staff • DroidKaigi 2015 & 2016 speaker 2 DroidKaigi 2016 -
Support Library? The Android Support Library package is a set
of code libraries that provide backward-compatible versions of Android framework APIs as well as features that are only available through the library APIs. — Android Developers 5 DroidKaigi 2016 -
Chronicle-1 The release date of android OS and the number
of Support Library1 1 Reference: Android developers - API Levels and Android version history. 6 DroidKaigi 2016 -
Chronicle-2 Interval of updates2 2 Reference: Android Developers - Support
Library Revisions. 8 DroidKaigi 2016 -
Why does it need? In order to implement the function
across different API level. 10 DroidKaigi 2016 -
What can we do? 1. We can better implementation. (Not
the best) • e.g. Use of RxJava 2. We can easily implement a user interface that Google is recommended. • e.g. Implementation of Material design 12 DroidKaigi 2016 -
Sorry, exclude these today. • Android Testing Support Library •
Data Binding Library 13 DroidKaigi 2016 -
V series • v4 Support Library • v7 Support Library
• v8 Support Library • v13 Support Library • v14 Preference Support Library • v17 Preference Support Library • v17 Leanback Library 14 DroidKaigi 2016 -
v4 Support Library • Android 1.6 (API level 4) and
higher • With the biggest API set in Support Library • Without resouces dependencies { compile 'com.android.support:support-v4:23.1.1' } 15 DroidKaigi 2016 -
Frequently used class • Fragment • ViewPager • NotificationCompat •
DrawerLayout • SwipeRefreshLayout • Loader (AsyncTaskLoader / CursorLoader) 16 DroidKaigi 2016 -
Demo: DrawerLayout • Including v7-appcompat and design support library •
ActionBarDrawerToggle • NavigationView 17 DroidKaigi 2016 -
AndroidStudio Templete: Navigation Drawer Activity public class MainActivity extends AppCompatActivity
implements NavigationView.OnNavigationItemSelectedListener { @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); DrawerLayout drawer = (DrawerLayout) findViewById(R.id.drawer_layout); ActionBarDrawerToggle toggle = new ActionBarDrawerToggle( this, drawer, toolbar, R.string.xx, R.string.xx); drawer.setDrawerListener(toggle); toggle.syncState(); ... 18 DroidKaigi 2016 -
The Class that I want you to remember NestedScrollView >>
There is a case to be required in Design Support Library. 20 DroidKaigi 2016 -
Helpful class Many class named ʙCompat Helper for accessing features
in [name of class] introduced after API level 4 in a backwards compatible fashion. 21 DroidKaigi 2016 -
Example: NotificationCompat Helper for accessing features in Notification introduced after
API level 4 in a backwards compatible fashion. — NotificationCompat - Class overview 22 DroidKaigi 2016 -
// v4 Support Library Notification notification = new NotificationCompat.Builder(); .setContentTitle("Title")
.setContentText("message") .setSmallIcon(R.drawable.new_mail) .build(); // android.app Notivication notification = new Notification.Builder(context); .setContentTitle("Title") .setContentText("message") .setSmallIcon(R.drawable.new_mail) .build(); 23 DroidKaigi 2016 -
v7 Support Library • Android 2.1 (API level 7) and
higher • You can be included independently. • With resouces 24 DroidKaigi 2016 -
Each v7 library 1. v7-appcompat 2. v7-cardview 3. v7-gridlayout 4.
v7-mediarouter 5. v7-palette 6. v7-recyclerview 7. v7-preference 25 DroidKaigi 2016 -
v7-appcompat • Depend on v4-support. • Support for material design
user interface implementations. dependencies { compile 'com.android.support:appcompat-v7:23.1.1' } 27 DroidKaigi 2016 -
i.e. depend on v4-support $ gradle -q dependencies app:dependencies ------------------------------------------------------------
Root project ------------------------------------------------------------ No configurations ------------------------------------------------------------ Project :app - Injects the build id used by the Fabric SDK. ------------------------------------------------------------ _debugCompile - ## Internal use, do not manually configure ## +--- com.android.support:appcompat-v7:23.0.1 (*) | +--- com.android.support:support-v4:23.0.1 (*) ... 28 DroidKaigi 2016 -
i.e support for material design implementations e.g. AlertDialog // v7-appcompat
new android.support.v7.app.AlertDialog.Builder(context) .setTitle("Hi!") .setMessage("Welcome to DroidKaigi 2016.") .setNegativeButton("close", null) .show(); // android.app new AlertDialog.Builder(context) .setTitle("Hi!") .setMessage("Welcome to DroidKaigi 2016.") .setNegativeButton("close", null) .show(); 29 DroidKaigi 2016 -
v7-recyclerview • There is also a case to replace the
ListView of ViewHolder pattern. • It increases the degree of freedom in the display of the List format. dependencies { compile 'com.android.support:recyclerview-v7:23.1.1' } 31 DroidKaigi 2016 -
e.g. Calendar view with v7- recyclerview • Customized LayoutManager •
Customized ItemDecoration 32 DroidKaigi 2016 -
Create calendar view RecyclerView recyclerView = (RecyclerView) rootView.findViewById(R.id.calendar_recyclerview); // appearance
of the cell CalendarLayoutManager layoutManager = new CalendarLayoutManager(getActivity(), 7); recyclerView.setLayoutManager(layoutManager); // draw the separator recyclerView.addItemDecoration(new CalendarDividerItemDecoration(getActivity())); mAdapter = new CalendarAdapter(getActivity(), mCurrentYear, mCurrentMonth); mAdapter.setOnActionListener(this); recyclerView.setAdapter(mAdapter); 33 DroidKaigi 2016 -
Other v7: cardview • Support for the CardView widget. dependencies
{ compile 'com.android.support:cardview-v7:23.1.1' } 34 DroidKaigi 2016 -
Other v7: gridlayout • Support for the GridLayout class. dependencies
{ compile 'com.android.support:gridlayout-v7:23.1.1' } 35 DroidKaigi 2016 -
Other v7: palette • Add the Palette class which lets
you extract prominent colors from an image. dependencies { compile 'com.android.support:palette-v7:23.1.1' } 36 DroidKaigi 2016 -
Other v7: preference • Add preference object, such as ChexboxPreference
and ListPreference. • Add v4-support based PreferenceFragmentCompat class. dependencies { compile 'com.android.support:preference-v7:23.1.1' } 37 DroidKaigi 2016 -
Other v7: mediarouter • Provide MediaRouter and MediaRouteProvider class. •
Google recommend using the library only in connection with Google Cast. dependencies { compile 'com.android.support:mediarouter-v7:23.1.1' } 38 DroidKaigi 2016 -
v8 Support Library • Android 2.2 (API level 8) and
higher • Support for the RenderScript computation framework. defaultConfig { renderscriptTargetApi 18 renderscriptSupportModeEnabled true } 39 DroidKaigi 2016 -
What is the RenderScript?3 • High-speed drawing processing using GPU.
• Not tied to a machine-architectures like AndroidNDK. 3 Reference: Android Developers - RenderScript. 40 DroidKaigi 2016 -
v13 Support Library • Android 3.2 (API level 13) and
higher • Support for using the ViewPager with "android.app.Fragment". dependencies { compile 'com.android.support:support-v13:23.1.1' } 41 DroidKaigi 2016 -
v14 Preference Support Library • Support for PreferenceFragment using "android.app.Fragment".
dependencies { compile 'com.android.support:preference-v14:23.1.1' } 42 DroidKaigi 2016 -
v17 Preference Support Library • Provide preference interfaces on TV
devices dependencies { compile 'com.android.support:preference-leanback-v17:23.1.1' } 43 DroidKaigi 2016 -
v17 Leanback Library • Support for use the UI widgets
for TV apps. • Provide the theme of Theme.Leanback. • Depend on v4-support and v7-recyclerview. dependencies { compile 'com.android.support:leanback-v17:23.1.1' } 45 DroidKaigi 2016 -
Demo: androidtv-leanbackGitHub For me all access to local network and
internet do not work with android tv emulator sdk 22 and 23. — Playback/Streaming does not work. #50 GitHub https:/ /github.com/googlesamples/androidtv-Leanback 47 DroidKaigi 2016 -
Speciality series • Multidex Support Library • Annotations Support Library
• Design Support Library • Custom Tabs Support Library • Percent Support Library • Recommendation Support Library for TV 50 DroidKaigi 2016 -
Multidex Support Library • Building apps with multiple Dalvik Executable(DEX)
files. • Without resouces 51 DroidKaigi 2016 -
What case does multidex need? If you get in such
a build error... Conversion to Dalvik format failed: Unable to excute dex: method ID not in [0, 0xffff]: 65536 52 DroidKaigi 2016 -
What case does multidex need? Or that's recently... trouble writing
output: Too many field references: 131000; max is 65536. You may try using --multi-dex option. 53 DroidKaigi 2016 -
How to create the multidex app? android { compileSdkVersion 21
buildToolsVersion "21.1.0" defaultConfig { ... minSdkVersion 14 targetSdkVersion 21 ... // Enabling multidex support. multiDexEnabled true } ... } dependencies { compile 'com.android.support:multidex:1.0.0' } 54 DroidKaigi 2016 -
Optimizing multidex development builds For the development flavor, set a
minimum SDK version of 21. This setting generates multidex output much faster using the ART-supported format. For the release flavor, set a minimum SDK version which matches your actual minimum support level. — from Android Developers 55 DroidKaigi 2016 -
Build configuration sample android { productFlavors { // Define separate
dev and prod product flavors. dev { // dev utilizes minSDKVersion = 21 to allow the Android gradle plugin // to pre-dex each module and produce an APK that can be tested on // Android Lollipop without time consuming dex merging processes. minSdkVersion 21 } prod { // The actual minSdkVersion for the application. minSdkVersion 14 } } ... buildTypes { release { runProguard true proguardFiles getDefaultProguardFile('proguard-android.txt'), 'proguard-rules.pro' } } } dependencies { compile 'com.android.support:multidex:1.0.0' } 56 DroidKaigi 2016 -
What happens when you create the multidex app?4 $ unzip
app-debug.apk extracting: ... inflating: ... $ ls AndroidManifest.xml app-normal-debug.apk classes.dex lib res META-INF assets classes2.dex org resources.arsc $ ls *.dex classes.dex classes2.dex 4 Reference to Building Apps with Over 65K Methods 57 DroidKaigi 2016 -
Annotations Support Library • Support for annotation metadata. • With
resouces dependencies { compile 'com.android.support:support-annotations:23.1.1' } 58 DroidKaigi 2016 -
e.g. @NotNull private void something() { setMessage(null); // Out warning
setMessage("message"); // Not out warning } private void setMessage(@NotNull String message) { ... } 59 DroidKaigi 2016 -
Various annotation Check whether resouce id -> @StringRes / @LayoutRes
/ @DrawableRes Using like enum -> @IntDef / @StringDef Check the executing thread -> @MainThread / @WorkerThread and more... 60 DroidKaigi 2016 -
Design Support Library • Support for material design components and
patterns. • With resouces dependencies { compile 'com.android.support:design:23.1.1' } 61 DroidKaigi 2016 -
For design pattern • AppBarLayout • CollapsingToolbarLayout • CoordinatorLayout •
TabLayout • TextInputLayout 63 DroidKaigi 2016 -
Demo: CoordinatorLayout / AppBarLayout / FloatingActionButton • Each component move
with together. 64 DroidKaigi 2016 -
Structure of the layout file <android.support.design.widget.CoordinatorLayout ...> <!-- ActionBar -->
<android.support.design.widget.AppBarLayout ...> <android.support.v7.widget.Toolbar ... app:layout_scrollFlags="scroll|enterAlways"/> </android.support.design.widget.AppBarLayout> </android.support.design.widget.CoordinatorLayout> 66 DroidKaigi 2016 -
Structure of the layout file <android.support.design.widget.CoordinatorLayout ...> <!-- ActionBar -->
<android.support.design.widget.AppBarLayout ...> <android.support.v7.widget.Toolbar ... app:layout_scrollFlags="scroll|enterAlways"/> </android.support.design.widget.AppBarLayout> <!-- FAB --> <android.support.design.widget.FloatingActionButton ... android:layout_gravity="bottom|end"/> </android.support.design.widget.CoordinatorLayout> 67 DroidKaigi 2016 -
Structure of the layout file <android.support.design.widget.CoordinatorLayout ...> <!-- ActionBar -->
<android.support.design.widget.AppBarLayout ...> <android.support.v7.widget.Toolbar ... app:layout_scrollFlags="scroll|enterAlways"/> </android.support.design.widget.AppBarLayout> <!-- Body --> <android.support.v4.widget.NestedScrollView .../> <!-- FAB --> <android.support.design.widget.FloatingActionButton ... android:layout_gravity="bottom|end"/> </android.support.design.widget.CoordinatorLayout> 68 DroidKaigi 2016 -
Animation of FAB FloatingActionButton fab = (FloatingActionButton) findViewById(R.id.fab); CoordinatorLayout.LayoutParams params
= (CoordinatorLayout.LayoutParams) fab.getLayoutParams(); // Set custom behavior class params.setBehavior(new ScrollingFabBehavior()); 69 DroidKaigi 2016 -
Custom Tabs Support Library • Support for managing CustomTabs. •
With resouces dependencies { compile 'com.android.support:customtabs:23.1.1' } 70 DroidKaigi 2016 -
Custom Tabs?5 Chrome Custom Tabs allow an app to customize
how Chrome looks and feels. — from official site 5 CustomTabs's oficial site: Chrome Custom Tabs 71 DroidKaigi 2016 -
Demo: Custom Tabs • UI customization • Performance optimization •
Need pre-fetch 72 DroidKaigi 2016 -
How to open the page with CustomTabs CustomTabsIntent customTabsIntent =
new CustomTabsIntent.Builder() // customize toolbar's color .setToolbarColor(getResources().getColor(R.color.colorPrimary)) .build(); // use shared project String packageName = CustomTabsHelper.getPackageNameToUse(MainActivity.this); customTabsIntent.intent.setPackage(packageName); customTabsIntent.launchUrl(MainActivity.this, Uri.parse("http://zaim.net/")); 74 DroidKaigi 2016 -
Percent Support Library • Support for managing percentage based dimmentions.
• With resouces dependencies { compile 'com.android.support:percent:23.1.1' } 75 DroidKaigi 2016 -
Sample layout file <android.support.percent.PercentFrameLayout xmlns:android="http://schemas.android.com/apk/res/android" xmlns:app="http://schemas.android.com/apk/res-auto" android:layout_width="match_parent" android:layout_height="match_parent"> <ImageView app:layout_widthPercent="50%"
app:layout_heightPercent="50%" app:layout_marginTopPercent="25%" app:layout_marginLeftPercent="25%"/> </android.support.percent.PercentFrameLayout/> 77 DroidKaigi 2016 -
Recommendation Support Library for TV • Content catalog in the
TV home screen. • With resouces dependencies { compile 'com.android.support:recommendation:23.1.1' } 78 DroidKaigi 2016 -
Build recommendations6 public class RecommendationBuilder { ... public RecommendationBuilder setTitle(String
title) { mTitle = title; return this; } public RecommendationBuilder setDescription(String description) { mDescription = description; return this; } public RecommendationBuilder setImage(String uri) { mImageUri = uri; return this; } public RecommendationBuilder setBackground(String uri) { mBackgroundUri = uri; return this; } ... 6 Reference: Android Developers - Recommending TV Content. 80 DroidKaigi 2016 -
Summary - First, let's use v4-support and v7-appcompat library. -
The speciality series will use if neccessary. 81 DroidKaigi 2016
