Docker • Docker was started by Solomon Hykes as an
internal project by dotCloud • Docker makes Linux Containers easy to use -
What is Docker? “Docker is an open source engine to
easily create lightweight, portable, self-sufficient containers from any application. The same container that a developer builds and tests on a laptop can run at scale, in production, on VMs, bare metal, OpenStack clusters, public clouds and more” - http://docker.io -
Why Docker? • Deploy everything (webapps, backends, sql, big data,
message queues) • Deploy almost everywhere (Linux servers, VMs or bare metal, any distro, Kernel 3.8) • Deploy reliably & consistently (local and on server same) • Deploy easily • Deploy at scale -
Docker popularity • 330+ Contributors, • 50,000+ docker index pull,
• 1000’s of Dockerized applications • Integration in Jenkins, Travis, Chef, Puppet, Vagrant & OpenStack -
The challenge • Static website, User DB, Queue, Background workers,
Analytics DB, API endpoint, Web Frontend • Development VM, QA Server, Public cloud, Production Servers, Customer data center, Production cluster • Running apps in multiple environments results in N x N nightmare -
What is LXC? • Lightweight Linux Container (LXC) • Operating
system level virtualisation method for running multiple isolated Linux systems • Provides way to run mini Linux systems within another Linux systems • http://en.wikipedia.org/wiki/LXC -
LXC • I can SSH into it • I have
root access • I can apt-get/yum install packages • Speed: boots in seconds • Footprint: 100-1000 containers on one machine. Small disk requirements. -
Control groups & namespaces • LXCs makes use of control
groups & namespaces • Linux kernel feature to limit, account and isolate resource usage, such as — CPU — Memory — Disk I/O -
Docker • Docker is API on top of LXC •
Docker runs as daemon • Docker makes Linux Containers easy to use (LXC) • Docker service exposes REST api that is used by Docker client -
Docker operating system? • Doesn’t include operating system • Relies
on operating system functionality provided by underlying infrastructure -
Requirements • Linux kernel 3.8 & above • AUFS •
LXC • 64-bit -
Installation • Can be directly installed on supported Linux distros.
• Supported Ubuntu versions Ubuntu Precise 12.04 (LTS) (64-bit) Ubuntu Raring 13.04 and Saucy 13.10 (64 bit) -
Installation: boot2docker • On Mac $ brew install boot2docker
$ boot2docker init $ boot2docker up $ export DOCKER_HOST=tcp:// $ docker run -i -t busybox sh #/ -
Installation: Vagrant • Clone the docker repository $ git
clone https://github.com/dotcloud/docker.git • Startup the vagrant image $ vagrant up • SSH into the image $ vagrant ssh • Use docker in VM $ docker • Vagrant client works on Mac -
• Downloaded the image from docker repo • Generated a
new LXC container • Created a new file system • Mounted a read/write layer • Allocated network interface • Setup IP Setup NATing • Executed the bash shell in the container • ** All under a very few minutes What Docker has done? -
Advantages • Elegant application delivery • Throwable sandboxes • Create
uniform development & production environments • Automated testing and continuous integration/deployments • Deploying and scaling web apps, databases and backend services -
Why developers care? • Build once, write everywhere • Clean,
safe, hygienic and portable runtime environment for app • No worries about missing dependencies during subsequent deployments • Reduce / eliminate compatibility concerns on different platforms -
Recommended workflow • Each service will be in its own
container(s) • Build an image for each service • Pin dependencies (packages etc.) accurately. • Link services together
