RequestGen

Request builder generator with Go generate.

Building Request Builder without Pain.

Transcript

1. c9s @ 2022 Mar 27 requestgen Request builder generator with Go generate
2. What’s request builder? • A request builder helps you build up the HTTP request object for the API. • A request builder contains a set of methods that help you set the parameters.
3. What’s request builder generator • A request builder generator helps you generate the request builder • With a simple schema or con fi guration. • DRY (Do not repeat yourself)
4. Why write a request builder generator • Di ff erent Authentication Methods (Some are very complicated) • Response structure could be di ff erent. • Some exchanges return paginated results.
5. The Request Builder API The Request Build Usage From adshao/go-binance
6. The hand-written Implementation
7. We Want Some Automation
8. The Same API
9. But Generate It Automatically
10. How to use it?
11. Basic Usage
12. type PlaceOrderRequest struct { client requestgen.APIClient symbol string `param:"symbol,required"` } Your APIClient implementation for sending requests
13. type PlaceOrderRequest struct { client requestgen.APIClient symbol string `param:"symbol,required"` } symbol=BTCUSDT In the request body
14. //go:generate requestgen —type PlaceOrderRequest type PlaceOrderRequest struct { client requestgen.APIClient symbol string `param:"symbol,required"` } Add the go generate command with your type name
15. //go:generate requestgen —type PlaceOrderRequest type PlaceOrderRequest struct { client requestgen.APIClient symbol string `param:"symbol,required"` } Equivalent to this command curl -X POST -F symbol=BTCUSDT https://…….
16. // APIClient defines the request builder method and request method for the API service type APIClient interface { // NewRequest builds up the http request for public endpoints NewRequest(ctx context.Context, method, refURL string, params url.Values, payload interface{}) (*http.Request, error) // SendRequest sends the request object to the api gateway SendRequest(req *http.Request) (*Response, error) } Simply implement the following interface to support HTTP request:
17. ctx := context.Background() client := NewClient() Allocate your HTTP client
18. ctx := context.Background() client := NewClient() req := PlaceOrderRequest{client: client} Construct your request builder
19. ctx := context.Background() client := NewClient() req := PlaceOrderRequest{client: client} req.Symbol(“BTCUSDT"). ClientOrderID(“0aa1a0123"). Side(SideTypeBuy). OrdType(OrderTypeLimit) Assign values
20. ctx := context.Background() client := NewClient() req := PlaceOrderRequest{client: client} req.Symbol(“BTCUSDT"). ClientOrderID(“0aa1a0123"). Side(SideTypeBuy). OrdType(OrderTypeLimit) response, err := req.Do(ctx) if err != nil { // ... } Send request
21. Adding More Fields
22. type PlaceOrderRequest struct { client requestgen.APIClient clientOrderID *string `param:"clientOid,required" defaultValuer:"uuid()"` } Default value UUID
23. * Pointer fi eld = optional fi eld type PlaceOrderRequest struct { client requestgen.APIClient tag *string `param:"tag"` }
24. type PlaceOrderRequest struct { client requestgen.APIClient // "buy" or "sell" side SideType `param:"side,required" validValues:"buy,sell"` } Simple Value Validator For String type and Integer type
25. type PlaceOrderRequest struct { client requestgen.APIClient // "buy" or "sell" side SideType `param:"side,required" validValues:"buy,sell"` } User-de fi ned types are supported type SideType string const ( SideTypeBuy SideType = "buy" SideTypeSell SideType = "sell" )
26. type PlaceOrderRequest struct { client requestgen.APIClient startTime *time.Time `param:"startTime,milliseconds" defaultValuer:"now()"` } Millisecond timestamp conversion curl -X POST -F startTime=1648467987762 https://…….
27. type PlaceOrderRequest struct { client requestgen.APIClient // page defines the query parameters for something like '?page=123' page *int64 `param:"page,query"` } Query parameter in the POST request
28. Parsing Response
29. { “code”: 0, “data”: { … } “page”: 1 } Response Data Container
30. //go:generate requestgen -type PlaceOrderRequest -responseType .Response -responseDataField Data -responseDataType .Order type Response struct { Code string `json:"code"` Message string `json:"msg"` CurrentPage int `json:"currentPage"` PageSize int `json:"pageSize"` TotalNum int `json:"totalNum"` TotalPage int `json:"totalPage"` Data json.RawMessage `json:"data"` } Response Type
31. //go:generate requestgen -type PlaceOrderRequest -responseType .Response -responseDataField Data -responseDataType .Order type Response struct { Code string `json:"code"` Message string `json:"msg"` CurrentPage int `json:"currentPage"` PageSize int `json:"pageSize"` TotalNum int `json:"totalNum"` TotalPage int `json:"totalPage"` Data json.RawMessage `json:"data"` } Response Data Field Response Data Field
32. //go:generate requestgen -type PlaceOrderRequest -responseType .Response -responseDataField Data -responseDataType .Order type Response struct { Code string `json:"code"` Message string `json:"msg"` CurrentPage int `json:"currentPage"` PageSize int `json:"pageSize"` TotalNum int `json:"totalNum"` TotalPage int `json:"totalPage"` Data json.RawMessage `json:"data"` } Parsed into the Order struct
33. var apiResponse APIResponse if err := response.DecodeJSON(&apiResponse); err != nil { return nil, err } var data OrderResponse if err := json.Unmarshal(apiResponse.Data, &data); err != nil { return nil, err } return &data, nil The generated code Response Wrapper Type
34. var apiResponse APIResponse if err := response.DecodeJSON(&apiResponse); err != nil { return nil, err } var data OrderResponse if err := json.Unmarshal(apiResponse.Data, &data); err != nil { return nil, err } return &data, nil The generated code Data Type
35. var apiResponse APIResponse if err := response.DecodeJSON(&apiResponse); err != nil { return nil, err } var data OrderResponse if err := json.Unmarshal(apiResponse.Data, &data); err != nil { return nil, err } return &data, nil The generated code Data Field
36. Request Methods
37. go:generate requestgen -method POST -type PlaceOrderRequest go:generate requestgen -method GET -type PlaceOrderRequest go:generate requestgen -method PUT -type PlaceOrderRequest go:generate requestgen -method DELETE -type PlaceOrderRequest HTTP Method
38. //go:generate -command GetRequest requestgen -method GET //go:generate -command PostRequest requestgen -method POST //go:generate GetRequest -type ListSymbolsRequest -url "/api/v1/symbols" -responseDataType []Symbol Go Generate Alias
39. Return Type
40. //go:generate GetRequest -type ListSymbolsRequest -url "/api/v1/symbols" -responseDataType []Symbol Return Slice Data Type
41. Return Simple Struct Type //go:generate GetRequest -type GetAllTickersRequest -url "/api/v1/market/allTickers" -responseDataType AllTickers
42. How Does It Work?
43. Go 1.5 transit to Go compiler from C compiler
44. go/types Go’s type checker
45. Parsing go/{parser, ast, scanner, token} Type Checker go/types vet lint eg gorename stringer mockgen mockery
46. a.go c.go b.go fmt Type Checker go/types compilation errors expressions type-checked packages imported packages
47. Step 1 parse package fi les package main func parsePackage(patterns []string, tags []string) { cfg := &packages.Config{ Mode: packages.NeedName | packages.NeedFiles | packages.NeedCompiledGoFiles | packages.NeedImports | packages.NeedTypes | packages.NeedTypesSizes | packages.NeedTypesInfo | packages.NeedFiles | packages.NeedSyntax | packages.NeedTypesInfo, Tests: false, BuildFlags: []string{fmt.Sprintf("-tags=%s", strings.Join(tags, " "))}, } pkgs, err := packages.Load(cfg, patterns...) if err != nil { log.Fatal(err) } }
48. Step 2 traverse the syntax tree for _, pkg := range pkgs { for i, file := range pkg.Syntax { ast.Inspect(file.file, func(node ast.Node) bool { switch decl := node.(type) { case *ast.ImportSpec: case *ast.FuncDecl: // .... } return true } } } USVF

    JUFSBUF
    JOUP
    UIF
    OPEF
    CMPDL
    TUBUFNFOU
    GVODUJPO
    ʜ
    FUD UIF
    OPEF
    UZQF
    UIBU
    ZPV
    XBOU
    UP
    JOTQFDU
49. type ( // An ImportSpec node represents a single package import. ImportSpec struct { Doc *CommentGroup // associated documentation; or nil Name *Ident // local package name (including "."); or nil Path *BasicLit // import path Comment *CommentGroup // line comments; or nil EndPos token.Pos // end of spec (overrides Path.Pos if nonzero) } // A ValueSpec node represents a constant or variable declaration // (ConstSpec or VarSpec production). // ValueSpec struct { Doc *CommentGroup // associated documentation; or nil Names []*Ident // value names (len(Names) > 0) Type Expr // value type; or nil Values []Expr // initial values; or nil Comment *CommentGroup // line comments; or nil } ) import ( "golang.org/x/tools/go/packages" ) a := 1 + 2
50. Step 3 Resolve the AST node to Type Info switch decl := node.(type) { case *ast.FuncDecl: // get the first receiver node receiver := decl.Recv.List[0] // pass the receiver type token to the type info map receiverTypeAndValue, ok := pkg.TypesInfo.Types[receiver.Type] if !ok { return true } // inspect the REAL type switch v := recvTV.Type.(type) { case *types.Named: // type A int case *types.Pointer: // *int } } 5ZQF"OE7BMVF
    DPOUBJOT
    UIF
    UZQF
    JOGPSNBUJPO VTF
    UIF
    UZQF
    JOGPSNBUJPO
    UP
    DIFDL
51. Step 4 generate the code func renderCode() { var sliceCallbackTmpl = template.New("slice-callbacks").Funcs(funcMap) sliceCallbackTmpl = template.Must(sliceCallbackTmpl.Parse(` func ( {{- .RecvName }} *{{ .Field.StructName -}} ) On{{- .Field.EventName -}} (cb {{ .Field.CallbackTypeName .Qualifier -}} ) {{ .RecvName }}.{{ .Field.FieldName }} = append({{- .RecvName }}.{{ .Field.FieldName }}, cb) } func ( {{- .RecvName }} *{{ .Field.StructName -}} ) Emit{{- .Field.EventName -}} {{ .Field.CallbackParamsTuple | typeString }} for _, cb := range {{ .RecvName }}.{{ .Field.FieldName }} { cb({{ .Field.CallbackParamsVarNames | join ", " }}) } } `) sliceCallbackTmpl.Execute(&buf, TemplateArgs{ Field: field, RecvName: recvName, Qualifier: qf, GenerateRemoveMethod: *generateRemoveMethod, }) }
52. Step 5 reformat the code import ( "go/format" ) src, err := format.Source(buf.Bytes()) if err != nil { // Should never happen, but can arise when developing this code. // The user can compile the output to see the error. log.Printf("warning: internal error: invalid Go generated: %s", err) log.Printf("warning: compile the package to analyze the error") return buf.Bytes() } return src
53. Step 6 compile and test your code!
54. Q & A
