Machine Learning on Apple Watch

Presented at MADcon at the University of Texas on April 21st, 2018.

Sample code: https://github.com/cnstoll/Snowman

Transcript

1. Machine Learning on Apple Watch By: Conrad Stoll
4. Agenda 4 Apple Watch History 4 Training a Model for CoreML 4 Building an Apple Watch Game with CoreML
5. The Apple Watch was released on April 24, 2015.
6. Every year, watchOS is getting better !
7. How will watchOS 4 help developers build better Apple Watch apps? 1 Apple Watch Developers
8. CoreML and Accelerate
9. Most apps are designed to assume there is an iPhone...
10. We need Apple Watch apps to work without an iPhone
11. Goal for this year: Ship an app using CoreML
12. Game: Snowman
13. Draw letters to guess a word or phrase
14. Apple Watches don't have keyboards...!
15. Uses Machine Learning for Handwriting Recognition
16. Public MNIST dataset for digits Lots of tutorials online Recently includes letters!!! Tutorials work for digits and letters!!!
17. A model needs to learn how to recognize letters a user might draw.
18. Training the model needs to happen before the game is shipped.
19. Training does not happen on the watch.
20. The watch uses the model by itself, without the iPhone.
21. Training does not change no matter how many letters a user draws. Training is generic for all users.*
22. Download a customized MLModel @interface MLModel (MLModelCompilation) + (nullable NSURL *)compileModelAtURL:(NSURL *)modelURL error:(NSError **)error; @end
23. Tools 4 Python 4 scikit-learn 4 Keras 4 Tensorflow 4 coremltools
24. Resources 4 Machine Learning Guide Podcast http://ocdevel.com/podcasts/machine-learning
25. Dataset Extended MNIST
26. Extended MNIST 387,361 training letter images2 23,941 testing images 28x28 pixels 2 https://arxiv.org/pdf/1702.05373.pdf
27. Model 1 Support Vector Machine
28. SVM models are easy to get started with
29. Simple application of Supervised Learning
30. Model 1 num_samples = 10000 images = all_images[0:num_samples] labels = all_labels[0:num_samples] from sklearn import svm clf = svm.SVC() clf.fit(images,labels)
31. Accuracy: 69% Size: 50 MB Too big for Apple Watch ! Poor user experience
33. Model 2 SVM, Split Alphabet
34. Model 2 half_letters = [1,2,3,6,7,9,10,13,16,19,21,23,24] ind = [val in half_letters for val in labels] labels_2=labels[ind] images_2=images[ind][:] from sklearn import svm clf = svm.SVC() clf.fit(images_2,labels_2)
35. Accuracy: 78% Size: 8 MB, x2 Works on Apple Watch! ! Accuracy could be better
36. Rule of thumb: If you can achieve ~80% accuracy with SVM, then the information you're trying to get at is in your data.
37. Model 3 Dimensionality Reduction with PCA
38. PCA = Principal Component Analysis
39. Reduce the number of variables the model needs to consider
40. Convert 784 variables into 25 variables
41. 784 Variables
42. 25 Variables
43. PCA from sklearn.decomposition import PCA pca = PCA(n_components=components); pca.fit(images) # PCA matrix...Save this for later mat = pca.components_
44. Model 3 # Saved from previous step mat = pca.components_ import numpy as np images_pca = np.matmul(images, mat.transpose()) from sklearn import svm clf = svm.SVC() clf.fit(images_pca,labels)
45. Using PCA in watchOS import Accelerate // Input: 784 // Output: 25 func transform(from input: [NSNumber]) -> [NSNumber] { let image = input.map { $0.floatValue } // 784 let mat = pcaMatrix // Saved from Python var result = [Float](repeating: 0.0, count: 25) // 25 vDSP_mmul(image, 1, mat, 1, &result, 1, 1, 25, 784) return result.map { NSNumber(value: $0) } }
46. Accuracy: 87% Size: 5MB
47. Ok, now we're !
48. Model 4 Convolutional Neural Network
49. Tutorials for Keras and Tensorflow 4 Simple Convolutional Neural Network for MNIST3 4 Deep Learning in Python4 4 https://elitedatascience.com/keras-tutorial-deep-learning-in-python 3 http://machinelearningmastery.com/handwritten-digit-recognition-using-convolutional-neural- networks-python-keras/
50. Keras Model from keras.models import Sequential from keras.layers import Dense, Dropout, Activation, Flatten from keras.layers import Convolution2D, MaxPooling2D def baseline_model(): model = Sequential() model.add(Conv2D(30, (5, 5), padding='valid', input_shape=(28,28,1), activation='relu')) model.add(MaxPooling2D(pool_size=(2, 2))) model.add(Conv2D(15, (3, 3), activation='relu')) model.add(MaxPooling2D(pool_size=(2, 2))) model.add(Dropout(0.2)) model.add(Flatten()) model.add(Dense(128, activation='relu')) model.add(Dense(50, activation='relu')) model.add(Dense(num_classes, activation='softmax')) # softmax # Compile model model.compile(loss='categorical_crossentropy', optimizer='adam', metrics=['accuracy']) return model
51. Model 4 # Build the model model = baseline_model() # Fit the model model.fit(X_train, y_train, validation_split=.1, epochs=10, batch_size=200, verbose=True)
52. Go get some ☕
53. Accuracy: 95% Size: 245 KB
55. Exporting Model to CoreML
56. coremltools import coremltools coreml_model = coremltools.converters.keras.convert(model, input_names = ['imageAlpha'], output_names = ['letterConfidence']) coreml_model.author = 'Kate Bonnen and Conrad Stoll' coreml_model.license = 'MIT' coreml_model.short_description = "Recognize the hand-drawn letter from an input image." coreml_model.input_description['imageAlpha'] = 'The input image alpha values, from top down, left to right.' coreml_model.output_description['letterConfidence'] = 'Confidence for each letter ranging from index 1 to 26. Ignore index 0.' coreml_model.save('letters_keras.mlmodel')
57. Importing a CoreML Model
58. Code Generation for your Model // Generated by CoreML class letters_keras { var model: MLModel convenience init() { let bundle = Bundle(for: letters_keras.self) let assetPath = bundle.url(forResource: "letters_keras", withExtension:"mlmodelc") try! self.init(contentsOf: assetPath!) } func prediction(imageAlpha: MLMultiArray) throws -> letters_kerasOutput { let input_ = letters_kerasInput(imageAlpha: imageAlpha) return try self.prediction(input: input_) } }
59. Building the Game
60. Snowman
61. Drawing a Letter Anywhere
62. Overlapping Interface Layers 4 Game Interface 4 SpriteKit Drawing Path 4 Pan Gesture 4 Confirmation Interface
63. Pan Gesture Captures Path @IBAction func didPan(sender : WKPanGestureRecognizer) { let location = sender.locationInObject() updateRecognitionLine(for: location, currentRecognizer: currentRecognizer) if sender.state == .ended { addSegmentAndWaitForConfirmation(with: currentRecognizer) } }
64. Setting up a Path Shape Node let line = SKShapeNode() line.fillColor = SKColor.clear line.isAntialiased = false line.lineWidth = strokeWidth line.lineCap = .round line.strokeColor = UIColor.white lineNode = line let scene = SKScene(size: size) scene.addChild(line) scene.backgroundColor = UIColor.clear drawScene.presentScene(scene)
65. Updating the Shape Node's Path func updateRecognitionLine(for location: CGPoint, currentRecognizer: Recognizer) { // Add the point to our path let path = currentRecognizer.addPoint(location) // Update the node's path lineNode?.path = path }
66. Making a Prediction
67. Prediction Steps 4 Stroke Path to Image 4 Center and Crop Image 4 Get Pixel Alpha Values Between 0 and 1 4 Convert to Vector 4 Send to CoreML
68. Stroke Path to Image UIGraphicsBeginImageContextWithOptions(CGSize(width: drawingWidth, height: drawingHeight), false, 0.0) let context = UIGraphicsGetCurrentContext()! context.setStrokeColor(UIColor.black.cgColor) path.lineJoinStyle = .round path.lineCapStyle = .round path.lineWidth = strokeWidth path.stroke(with: .normal, alpha: 1)
69. Compute Center and Crop Image 4 Letter centered 4 2px padding on every side 4 Square aspect ratio 4 Must be 28x28 pixels
70. Get Image Alpha Values extension UIImage { func getPixelAlphaValue(at point: CGPoint) -> CGFloat { guard let cgImage = cgImage, let pixelData = cgImage.dataProvider?.data else { return 0.0 } let data: UnsafePointer<UInt8> = CFDataGetBytePtr(pixelData) let bytesPerPixel = cgImage.bitsPerPixel / 8 let pixelInfo: Int = ((cgImage.bytesPerRow * Int(point.y)) + (Int(point.x) * bytesPerPixel)) // We don't need to know about color for this // let b = CGFloat(data[pixelInfo]) / CGFloat(255.0) // let g = CGFloat(data[pixelInfo+1]) / CGFloat(255.0) // let r = CGFloat(data[pixelInfo+2]) / CGFloat(255.0) // All we need is the alpha values let a = CGFloat(data[pixelInfo+3]) / CGFloat(255.0) return a } }
71. Matching Training and Input Data Structure let a = CGFloat(data[pixelInfo+3]) / CGFloat(255.0) a is between 0 and 1 not between 0 and 255
72. The order of the points in your image also matter!
73. Get Every Pixel's Alpha Value extension UIImage { func pixelAlpha() -> [NSNumber] { var pixels = [NSNumber]() for w in 0...Int(self.size.width) - 1 { for h in 0...Int(self.size.height) - 1 { let point = CGPoint(x: w, y: h) let alpha = getPixelAlphaValue(at: point) let number = NSNumber(value: Float(alpha)) pixels.append(number) } } return pixels } }
74. Convert to MLMultiArray import CoreML let alphaValues = drawing.generateImageVectorForAlphaChannel() let multiArray = try! MLMultiArray(shape: [1,28,28], dataType: MLMultiArrayDataType.double) for (index, number) in alphaValues.enumerated() { multiArray[index] = number }
75. Here's what an MLMultiArray looks like
77. Make a Prediction with CoreML import CoreML let model = letters_keras() let prediction = try! model.prediction(imageAlpha: multiArray)
78. Demo
79. Thank You
80. Conrad Stoll @conradstoll https://github.com/cnstoll/Snowman https://speakerdeck.com/cnstoll/machine-learning-on- apple-watch
