Probabilistic modeling and Inference in Astronomy
Guest lecture for "Inference and Representation" at NYU
Dan Foreman-Mackey
September 22, 2015
Transcript
80 slides
-
Probabilistic modeling and Inference in Astronomy Dan Foreman-Mackey Sagan Fellow,
University of Washington github.com/dfm // @exoplaneteer // dfm.io -
I study astronomy. Photo credit NASA Ames/SETI Institute/JPL-Caltech this isn't
what my data look like -
Why Astronomy? simple but interesting physical models precise open-access data
observational only no chance of financial gain ever -
ex·o·plan·et ˈeksōˌplanət/ noun. a planet that orbits a star outside
the solar system. Credit Google -
transit radial velocity direct imaging microlensing timing astrometry 1281 616
45 32 20 0 Data from Open Exoplanet Catalogue -
Data from Open Exoplanet Catalogue 2000 2005 2010 2015 year
of discovery 0 200 400 600 800 1000 number of exoplanets transit RV microlensing direct imaging timing -
Data from Open Exoplanet Catalogue 2000 2005 2010 2015 year
of discovery 0 200 400 600 800 1000 number of exoplanets transit RV microlensing direct imaging timing first public data release from Kepler -
1.0 0.5 0.0 0.5 1.0 time since transit [days] 100
50 0 relative brightness [ppm] -
Fig. 3.— Calculation of the transit probability. Left.—Transits are visible
by observers within the penumbra of the planet, a cone with opening angle Θ with sin Θ = (R⋆ +Rp )/r, where r is the instantaneous star-planet distance. Right.—Close-up showing the penumbra (thick lines) as well as the antumbra (thin lines) within which the transits are full, as opposed to grazing. are tangent at four contact times tI –tIV , illustrated in Fig- ure 2. (In a grazing eclipse, second and third contact do not occur.) The total duration is Ttot = tIV − tI , the full duration is Tfull = tIII − tII , the ingress duration is ingress and egress. In practice the difference is slight; to leading order in R⋆/a and e, τe − τi ∼ e cosω R⋆ 3 1 − b2 3/2 , (17) Credit Winn (2010) arXiv:1001.2010 -
need to look at the right place at the right
time and measure extremely precise photometry -
Credit Fabrycky et al. (2012) 12 Fabrycky et al. Figure
16. Kepler-31 phase curves, in the style of figure 3. For the small inner candidate KOI-952.05, the phase is with respect to terest. The Kepler Follow-up spectra of Kepler-32: one sp servatory and one from Keck are weak due to the faintness cross correlation function be and available models is max ∼ 3900 K and ∼ 3600 K, atmospheric parameters are star is cooler than the library able. Both spectra are con sification as a cool dwarf ( [M/H]=0.172). We conserva Teff and log g with uncertain a [M/H] of 0± 0.4 based on t By comparing to the Yonse values for the stellar mass ( (0.53 ± 0.04R⊙ ) that are sli the KIC. We estimate a lum and an age of ≤ 9Gyr. Muirhead et al. (2011) h resolution IR spectrum of K a stellar Teff = 3726+73 −67 , [Fe ing their data via Padova m they inferred a considerably l We encourage further detail properties, as these have con directly affect the sizes and The probability of a star u being the actual host is only ity of a physical companion h This latter number is relative all the transit depths are sma be much larger planets hoste ically diluted. This opens up -
101 102 orbital period [days] 100 101 planet radius [R
] Data from NASA Exoplanet Archive -
101 102 orbital period [days] 100 101 planet radius [R
] Data from NASA Exoplanet Archive -
101 102 orbital period [days] 100 101 planet radius [R
] Data from NASA Exoplanet Archive -
100 101 102 103 104 105 orbital period [days] 100
101 planet radius [R ] Data from NASA Exoplanet Archive -
May 2013 The Kepler Mission goes up in flames *
not exactly -
4000 2000 0 2000 4000 raw: 301 ppm EPIC 201374602;
Kp = 11.5 mag 10 20 30 40 50 60 70 80 time [BJD - 2456808] 400 0 400 residuals: 35 ppm relative brightness [ppm] 4000 2000 0 2000 4000 raw: 301 ppm EPIC 201374602; Kp = 11.5 mag 10 20 30 40 50 60 70 80 time [BJD - 2456808] 400 0 400 residuals: 35 ppm relative brightness [ppm] -
7.2 7.4 7.6 x [pix] 10 20 30 40 50
60 70 80 time [BJD - 2456808] 9.05 9.10 9.15 9.20 y [pix] -
Anatomy of a transit signal + + + = planet
star space craft detector signal -
Designing the probabilistic model n Pn xn K Sn stars:
n = 1, · · · , N n Pn xn K Sn planet star space craft detector -
Designing the probabilistic model planet: star: noise: space craft: physics
and geometry continuous in time → GP CCD, photon noise → Poisson ?? representation: -
The planet orbit model cba Wikipedia user Gonfer Kepler's Laws
of Planetary Motion -
The planet orbit model cba Wikipedia user Gonfer Kepler's Laws
of Planetary Motion -
TRANSIT LIGHT CURVES Vol. 580 mb darkening. The star is
seen edge-on, with the observer off the top of the page. The star has radius , and v is defined as the r∗ d the normal to the stellar surface, while . (b) Transit geometry from the perspective of the observer. m p cos v 3. NONLINEAR LIMB DARKENING s a star to be more centrally peaked in brightness compared to a uniform source. This leads to more ng eclipse and creates curvature in the trough. Thus, including limb darkening is important for computing Reference Mandel & Agol (2002); arXiv:astro-ph/0210099 The planet transit model -
TRANSIT LIGHT CURVES Vol. 580 mb darkening. The star is
seen edge-on, with the observer off the top of the page. The star has radius , and v is defined as the r∗ d the normal to the stellar surface, while . (b) Transit geometry from the perspective of the observer. m p cos v 3. NONLINEAR LIMB DARKENING s a star to be more centrally peaked in brightness compared to a uniform source. This leads to more ng eclipse and creates curvature in the trough. Thus, including limb darkening is important for computing Reference Mandel & Agol (2002); arXiv:astro-ph/0210099 The planet transit model -
TRANSIT LIGHT CURVES Vol. 580 mb darkening. The star is
seen edge-on, with the observer off the top of the page. The star has radius , and v is defined as the r∗ d the normal to the stellar surface, while . (b) Transit geometry from the perspective of the observer. m p cos v 3. NONLINEAR LIMB DARKENING s a star to be more centrally peaked in brightness compared to a uniform source. This leads to more ng eclipse and creates curvature in the trough. Thus, including limb darkening is important for computing Reference Mandel & Agol (2002); arXiv:astro-ph/0210099 The planet transit model "…elliptic integral of the third kind…" -
TRANSIT LIGHT CURVES Vol. 580 mb darkening. The star is
seen edge-on, with the observer off the top of the page. The star has radius , and v is defined as the r∗ d the normal to the stellar surface, while . (b) Transit geometry from the perspective of the observer. m p cos v 3. NONLINEAR LIMB DARKENING s a star to be more centrally peaked in brightness compared to a uniform source. This leads to more ng eclipse and creates curvature in the trough. Thus, including limb darkening is important for computing Reference Mandel & Agol (2002); arXiv:astro-ph/0210099 The planet transit model "…elliptic integral of the third kind…" 1.0 0.5 0.0 0.5 1.0 time since transit [days] 100 50 0 relative brightness [ppm] -
Designing the probabilistic model planet: star: noise: space craft: physics
and geometry continuous in time → GP CCD, photon noise → Poisson ?? representation: -
The stellar variability model y ⇠ N(f✓ (t), K↵(t)) Gaussian
Mean Covariance -
0 1 2 3 4 5 x 6 4 2
0 2 4 6 y y ⇠ N (f✓ (t), K↵(t)) -
0 1 2 3 4 5 x 6 4 2
0 2 4 6 y y ⇠ N (f✓ (t), K↵(t)) -
0 1 2 3 4 5 x 6 4 2
0 2 4 6 y y ⇠ N (f✓ (t), K↵(t)) -
0 1 2 3 4 5 x 6 4 2
0 2 4 6 y y ⇠ N (f✓ (t), K↵(t)) -
Designing the probabilistic model planet: star: noise: space craft: physics
and geometry continuous in time → GP CCD, photon noise → Poisson ?? representation: -
Designing the probabilistic model planet: star: noise: space craft: physics
and geometry continuous in time → GP CCD, photon noise → Poisson ?? representation: -
Designing the probabilistic model n Pn xn K Sn stars:
n = 1, · · · , N n Pn xn K Sn -
stars: n = 1, · · · , N n
xn K Designing the probabilistic model simple space craft assumption: -
4000 2000 0 2000 4000 raw: 301 ppm EPIC 201374602;
Kp = 11.5 mag 10 20 30 40 50 60 70 80 time [BJD - 2456808] 400 0 400 residuals: 35 ppm relative brightness [ppm] 4000 2000 0 2000 4000 raw: 301 ppm EPIC 201374602; Kp = 11.5 mag 10 20 30 40 50 60 70 80 time [BJD - 2456808] 400 0 400 residuals: 35 ppm relative brightness [ppm] -
4000 2000 0 2000 4000 raw: 301 ppm EPIC 201374602;
Kp = 11.5 mag 10 20 30 40 50 60 70 80 time [BJD - 2456808] 400 0 400 residuals: 35 ppm relative brightness [ppm] -
Designing the probabilistic model planet: star: noise: space craft: physics
and geometry continuous in time → GP CCD, photon noise → Poisson data-driven linear model representation: -
Designing the probabilistic model n Pn xn K Sn stars:
n = 1, · · · , N n Pn xn K Sn -
2 0 2 4 (a) raw 4 2 0 (b)
10 ELCs depth: 3.2 ppt 4 2 0 (c) 150 ELCs depth: 2.7 ppt 63 64 65 66 67 time [BJD - 2456808] 4 2 0 (d) conditional depth: 3.7 ppt relative brightness [ppt] -
stars days of data planet candidates confirmed planets 21,703 80
36 18 K2 Campaign 1 exoplanet discoveries Published: Foreman-Mackey, Montet, Hogg, et al. (arXiv:1502.04715) Montet, Morton, Foreman-Mackey, et al. (arXiv:1503.07866) Schölkopf, Hogg, Wang, Foreman-Mackey, et al. (arXiv:1505.03036) -
Foreman-Mackey, Montet, Hogg, et al. (arXiv:1502.04715) Montet, Morton, Foreman-Mackey, et
al. (arXiv:1503.07866) Schölkopf, Hogg, Wang, Foreman-Mackey, et al. (arXiv:1505.03036) Probabilistic modeling—combining physical and data-driven models—enables the discovery of new planets using open data and open source software
