ML Kit 使⽤用簡介 Elvis Lin @Android Taipei 2018-07-18
關於我 • Elvis Lin • Android 與 iOS 永遠的初學者 •
Twitter: @elvismetaphor • Blog: https://blog.elvismetaphor.me
不是業配 https://youtu.be/Z-dqGRSsaBs
⼤大綱 • 什什麼是(我理理解的)機器學習 • 移動裝置上實作機器學習應⽤用的限制 • TensorFlow Lite 與 ML
Kit • 範例例
機器學習的應⽤用
機器學習 • 從資料中歸納出有⽤用的規則 • 訓練模型 • 使⽤用模型 • Mobile Application
Engineer 參參與開發主要是在「使⽤用模型」 這個範圍
Data Result (Trained) Model
移動裝置上 實作機器學習應⽤用的限制 • 記憶體有限與儲存空間有限 • 計算能⼒力力不如⼤大型伺服器 • 電池容量量有限
移動裝置上 實作機器學習應⽤用的改良⽅方向 • 記憶體有限與儲存空間有限 —> 減少模型(Model)的體積 • 計算能⼒力力不如⼤大型伺服器 —> 降低演算法的複雜度
• 電池容量量有限 —> 降低演算法的複雜度
Google 推出的解決⽅方案 • TensorFlow Lite • ML Kit
https://www.tensorflow.org/mobile/tflite/
Neural Networks API Metal
ML Kit • Cloud Vision API / Mobile Vision API
• Tensorflow Lite • 整合 Firebase,託管「客製化的模型」
ML Kit Base APIs • Image labeling • Text recognition
(OCR) • Face detection • Barcode scanning • Landmark detection • others……
使⽤用 ML Kit
建立⼀一個 Firebase 專案
建立⼀一個 Android app 下載設定檔 設定好 Package Name 下載 google-service.json
<root>/build.gradle dependencies { classpath 'com.android.tools.build:gradle:3.1.3' classpath 'com.google.gms:google-services:4.0.2' }
<root>/app/build.gradle dependencies { // ... implementation 'com.google.firebase:firebase-ml-vision:16.0.0' }
掃描 barcode (local) FirebaseVisionImage image = FirebaseVisionImage.fromBitmap(image); FirebaseVisionBarcodeDetectorOptions options =
new FirebaseVisionBarcodeDetectorOptions.Builder() .setBarcodeFormats( FirebaseVisionBarcode.FORMAT_QR_CODE, FirebaseVisionBarcode.FORMAT_AZTEC ) .build(); FirebaseVisionBarcodeDetector detector = FirebaseVision.getInstance() .getVisionBarcodeDetector(options); detector.detectInImage(image) .addOnSuccessListener( new OnSuccessListener<List<FirebaseVisionBarcode>>() { @Override public void onSuccess(List<FirebaseVisionBarcode> barcodes) {} }) .addOnFailureListener(new OnFailureListener() { @Override public void onFailure(@NonNull Exception e) {} });
初始化 Detector FirebaseVisionImage image = FirebaseVisionImage.fromBitmap(image); FirebaseVisionBarcodeDetectorOptions options = new
FirebaseVisionBarcodeDetectorOptions.Builder() .setBarcodeFormats( FirebaseVisionBarcode.FORMAT_QR_CODE, FirebaseVisionBarcode.FORMAT_AZTEC ) .build(); FirebaseVisionBarcodeDetector detector = FirebaseVision .getInstance() .getVisionBarcodeDetector(options);
取得結果 detector.detectInImage(image) .addOnSuccessListener( new OnSuccessListener<List<FirebaseVisionBarcode>>() { @Override public void onSuccess(List<FirebaseVisionBarcode>
barcodes) {} }) .addOnFailureListener(new OnFailureListener() { @Override public void onFailure(@NonNull Exception e) {} });
⽀支援的 barcode 格式 • Code 128 (FORMAT_CODE_128) • Code 39
(FORMAT_CODE_39) • Code 93 (FORMAT_CODE_93) • Codabar (FORMAT_CODABAR) • EAN-13 (FORMAT_EAN_13) • EAN-8 (FORMAT_EAN_8) • ITF (FORMAT_ITF) • UPC-A (FORMAT_UPC_A) • UPC-E (FORMAT_UPC_E) •QR Code (FORMAT_QR_CODE) • PDF417 (FORMAT_PDF417) • Aztec (FORMAT_AZTEC) • Data Matrix (FORMAT_DATA_MATRIX)
辨識⽂文字 (local) FirebaseVisionImage image = FirebaseVisionImage.fromBitmap(selectedImage); FirebaseVisionTextDetector detector = FirebaseVision.getInstance().getVisionTextDetector();
detector.detectInImage(image) .addOnSuccessListener(new OnSuccessListener<FirebaseVisionText>() { @Override public void onSuccess(FirebaseVisionText text) {} }) .addOnFailureListener(new OnFailureListener() { @Override public void onFailure(@NonNull Exception e) {} });
辨識⽂文字 (cloud) FirebaseVisionCloudDetectorOptions options = new FirebaseVisionCloudDetectorOptions.Builder() .setModelType(FirebaseVisionCloudDetectorOptions.LATEST_MODEL) .setMaxResults(15) .build();
FirebaseVisionImage image = FirebaseVisionImage.fromBitmap(selectedImage); FirebaseVisionCloudDocumentTextDetector detector = FirebaseVision.getInstance() .getVisionCloudDocumentTextDetector(options); detector.detectInImage(image) .addOnSuccessListener(new OnSuccessListener<FirebaseVisionCloudText>() { @Override public void onSuccess(FirebaseVisionCloudText text) {} }) .addOnFailureListener(new OnFailureListener() { @Override public void onFailure(@NonNull Exception e) {} });
補充資料 • ML Kit 簡介 (for Android) https://blog.elvismetaphor.me/ml-kit-fundamentals-for- android-6444e2db0fdb •
ML Kit 簡介 (for iOS) https://blog.elvismetaphor.me/ml-kit-fundamentals-for- ios-cb705044e69b
參參考資料 • https://youtu.be/Z-dqGRSsaBs • https://codelabs.developers.google.com/codelabs/mlkit- android/ • https://github.com/firebase/quickstart-android/tree/ master/mlkit
