A deep dive into the preemption models of the Linux Kernel and a proposal for reducing the zoo
Thomas Gleixner
Kernel Recipes PRO
September 29, 2023
Transcript
36 slides
-
Coming soon? On preempt_model_none() or preempt_model_voluntary() configurations rescheduling of kernel
threads happens only when they allow it, and only at explicit preemption points, via calls to cond_resched() or similar. That leaves out contexts where it is not convenient to periodically call cond_resched() -- for instance when executing a potentially long running primitive (such as REP; STOSB.) This means that we either suffer high scheduling latency or avoid certain constructs. Define TIF_ALLOW_RESCHED to demarcate such sections. -
Preemption model NONE • Preemptive multitasking in userspace • Timeslicing,
priority • Cooperative multitasking in the kernel • Kernel code runs to completion • Preemption point on return to user space • Task invokes schedule() -
Preemption model NONE • What could go wrong? • Long
running tasks can cause latencies • Long running tasks can starve the system • Detectable but no mitigation possible • Scheduler has no knowledge whether preemption is safe -
Preemption model NONE • How to prevent latencies and starvation?
• Manual placement of voluntary scheduling opportunities, i.e. cond_resched() static inline void cond_resched(void) { if (need_resched()) schedule(); } -
Preemption model NONE • cond_resched() for (i = 0; i
< limit; i++) { process(data[i]); cond_resched(); } for (i = 0; i < limit; i++) { mutex_lock(m); process(data[i]); cond_resched(); mutex_unlock(m); } for (i = 0; i < limit; i++) { mutex_lock(m); process(data[i]); mutex_unlock(m); cond_resched(); } -
Preemption model VOLUNTARY • Same properties as NONE • Additional
opportunistic preemption points • might_sleep() -
Preemption model VOLUNTARY • might_sleep() • might_sleep() is a debug
mechanism • cond_resched() is glued into it • Easy to misplace • Automatically injected by lock and wait primitives -
Preemption model VOLUNTARY might_sleep() ... wait_for_completion(&c); return_to_userspace(); ← Preemption point
... wait_for_completion(c) might_sleep() cond_resched(); ← Preemption point while (!complete(c) schedule(); return_to_userspace(); ← Preemption point The embedded cond_resched() can result in redundant task switching -
Preemption model VOLUNTARY might_sleep() mutex_lock(A); mutex_lock(B); do_work(); mutex_unlock(B); mutex_unlock(A); mutex_lock(A);
mutex_lock(B) might_sleep() cond_resched(); ← Preemption point The embedded cond_resched() can result in redundant task switching and lock contention on mutex A. -
Preemption model VOLUNTARY • Provides better latencies than NONE •
Otherwise the same issues as NONE • More contention possible -
Preemption model FULL • Full preemptive multitasking • Timeslicing, priority
• Restricted in non-preemptible kernel code sections -
Preemption model FULL • Implicit non-preemptible kernel code sections •
[spin|rw]locks are held • [soft]interrupts and exceptions • local_irq_disable(), local_bh_disable() • Per CPU accessors • Explicit non-preemptible kernel code sections • preempt_disable() -
Preemption model FULL • Non-preemptible sections • Prevent preemption •
Prevent migration • No blocking operations allowed • Migration prevention can be made preemptible • migrate_disable() -
Preemption model FULL • Scheduler knows when preemption is safe
• Reduced latencies • Agressive preemption can cause contention • Tradeoff versus throughput -
Preemption model RT • Full preemptive multitasking • Preemption model
is the same as FULL • RT further reduces non-preemtible sections • [spin|rw|local]locks become sleeping locks • Most interrupt handlers are force threaded • Soft interrupt handling is force threaded -
Preemption model RT • Further restrictions for non-preemptible sections •
No memory allocations or other functions which might acquire rw/spinlocks as they are sleepable in RT • Same benefits and tradeoffs as FULL, but: • Smaller worst case latencies • More tradeoff versus throughput -
Preemption model RT • The throughput tradeoff • Affects usually
non-realtime workloads • Caused by overeager preemption and the resulting lock and resource contentions -
Preemption model RT • Mitigating the throughput tradeoff • LAZY
preemption mode for non-RT tasks • lock held sections disable lazy preemption • Still can be force preempted by the scheduler -
Preemption model NONE/VOLUNTARY woes • X86 REP MOV/STO for memcpy()/set()
• Very efficient • Can be interrupted, but NONE and VOLUNTARY cannot preempt • Large copies/clears cause latencies • Chunk based loop processing required with cond_resched() which fails to utilize hardware -
Preemption model NONE/VOLUNTARY woes • Proposed solution: TIF_ALLOW_RESCHED • Wrapped
in allow_resched() and disallow_resched() • Annotate sections which are safe to preempt on NONE and VOLUNTARY https://lore.kernel.org/lkml/[email protected] -
Preemption model NONE/VOLUNTARY woes • Seriously? • cond_resched(), might_sleep(), preempt_disable(),
preempt_enable(), allow_resched(), disallow_resched() • The reverse semantics of preempt_disable() and allow_resched() are just bad -
Let’s take a step back • The goal is to
avoid preemption on NONE and VOLUNTARY • Preemption on time slice exhaustion should be enforcable even on NONE and VOLUNTARY • NONE and VOLUNTARY do not know about preemption safety -
Let’s take a step back • Preempt counter is not
longer expensive • Usually enabled anyway due to dynamic preemption model switching • All preemption models can know when preemption is safe -
Preemption model reduction • Enforce preempt counter enablement • Provide
lazy preemption similar to RT • TIF_NEED_RESCHED_LAZY • Lazy preemption only on return to userspace • Enforced preemption: TIF_NEED_RESCHED -
Preemption model reduction • NONE/VOLUNTARY: TIF_RESCHED_LAZY used for SCHED_OTHER •
Timeslice exhaustion enforces preemption with TIF_NEED_RESCHED • FULL: Switch SCHED_OTHER to TIF_NEED_RESCHED -
Preemption model reduction • Gives full control to the scheduler
• VOLUNTARY semantics can be handled in the scheduler itself • Allows to remove cond_resched() • Avoids new ill defined annotations • Eventually proper hinting required • Can be utilized for RT with minimal effort -
Preemption model reduction Scheduler hints for lazy preemption • If
required must be scope based • Proper nesting • Embeddable into locking primitives preempt_lazy_disable(); // Please avoid preemption do_prep(); do_stuff() mutex_lock(m) preempt_lazy_disable(); … mutex_unlock(m) preempt_lazy_enable(); preempt_lazy_enable(); // Now its fine to preempt -
Preemption model reduction • One preemption model with runtime switching
solely at the scheduler level • RT still separate and compile time selected • PoC works and looks promising. • A few museum architectures in the way. https://lore.kernel.org/lkml/87jzshhexi.ffs@tglx/ -
Coming soon? https://xkcd.com/927/ X X X ___________ PREEMPTION MODELS. MODEL
___________ PREEMPTION MODELS.
