Whitelisting LD_PRELOAD For Fun and No Profit

Sometimes bolting a security solution on the side of technology just doesn’t work as well as built-in protection. One example of this on Linux systems is libpreloadvaccine, a whitelisting solution I built that aimed, and failed, to provide foolproof protection against abuse of LD_PRELOAD process injection. This talk will cover how adversaries use LD_PRELOAD, how its built-in audit system works, and how the audit system can be leveraged for whitelisting. We’ll also examine design and implementation considerations for whitelisting, closing the talk by showing how checks built into the dynamic linker would be much more effective than a solution thrown on top.

Transcript

1. Whitelisting LD_PRELOAD For Fun and No Profit
2. ▪ Professional tinkerer & educator ▪ Recovering system administrator ▪ Love to make bad guys have bad days Tony Lambert Detection Engineer/Intel Red Canary @ForensicITGuy id -un
3. What is LD_PRELOAD and how is it used? Examining the rtld-audit subsystem Whitelisting LD_PRELOAD What worked and what didn’t Overview
4. ▪ glibc & musl environment variable ▪ Injects arbitrary SO file into process ▪ LD_PRELOAD or /etc/ld.so.preload Intro to LD_PRELOAD
5. rtld.c
6. Get Started With Env Var LS SHELL=/bin/bash PATH=/long/list/of/folders … LD_PRELOAD=injected.so /proc/PID/env
7. Make It Persistent $ LD_PRELOAD=injected.so ls $ export LD_PRELOAD=injected.so # echo injected.so > /etc/ld.so.preload # echo LD_PRELOAD=injected.so >> /etc/profile
8. It Can Be Good! LS libdl.so libc.so test-libc.so
9. Evil Use Cases ▪ Hooking functions and calls ▪ Automatic code execution on load
10. Hooking Functions ▪ Define function with same name ▪ Manipulate output and fool user ▪ libprocesshider
11. It Can be Very Bad! PS libc.so readdir() evil.so readdir() Intact Listing Bash Python evil.py Tainted Listing Bash ...
12. Hooking Example
13. Execution on Load ▪ No knowledge of target binary needed ▪ Code stored in ELF .init section ▪ Zombie Ant Farm Project
14. Execution Example
15. The rtld-audit Subsystem ▪ Audit API for the dynamic linker ▪ Write a SO library to implement ▪ Use with LD_AUDIT variable
16. Lots of functions la_objsearch() la_activity() la_objopen() la_objclose() la_preinit() la_symbind*() la_pltenter() la_pltexit()
17. At First, I Wanted to Log la_objsearch() la_activity() la_objopen() la_objclose() la_preinit() la_symbind*() la_pltenter() la_pltexit()
18. I Realized I Could Prevent la_objsearch() la_activity() la_objopen() la_objclose() la_preinit() la_symbind*() la_pltenter() la_pltexit()
19. Intercept Before Load la_objsearch() The dynamic linker invokes this function to inform the auditing library that it is about to search for a shared object. rtld-audit(7) manpage
20. You Had Me At “return NULL” la_objsearch() ...returns the pathname that the dynamic linker should use... If NULL is returned, then this pathname is ignored for further processing. rtld-audit(7) manpage
22. Let’s Block Some Preloads! ▪ Define unauthorized preloads ▪ Define authorized preloads ▪ Monitor for unauthorized loads ▪ Mitigate the loads
23. Unauthorized Preloads ▪ Unpredictable preloads ▪ Unlimited forms of evil ▪ Block by default
24. Authorized Preloads ▪ Unpredictable system configuration ▪ Wanted ease of administration ▪ Modeled after cron.allow, hosts.allow
25. Monitor & Block Preloads ▪ Intercept module search ▪ Check the allowed list ▪ Return NULL if not allowed to block
26. Enter Libpreloadvaccine! ▪ LD_AUDIT SO library ▪ Intercepts and blocks ▪ Just worksTM github.com/ForensicITGuy/libpreloadvaccine Logo left intentionally blank.
27. Simple Logic
28. Simple Authorized List /etc/libpreloadvaccine.allow ▪ Check the allowed list ▪ Return NULL if not allowed to block
29. Simple Deployment 1. Compile with gcc 2. Move to folder 3. Set LD_AUDIT export LD_AUDIT=/usr/lib/libpreloadvaccine.so
30. Success! Sort of...
31. Catch it in Action!
32. And Bypass it After!
33. Lessons Learned
34. Keep Security Close to Code ▪ Bolted on solutions don’t always work ▪ Code inside rtld.c would be harder to bypass ▪ Attackers with root can have unlimited access
35. FEEDBACK Q & A REDCANARY.COM/BLOG @REDCANARYCO GITHUB.COM/FORENSICITGUY/LIBPRELOADVACCINE @FORENSICITGUY
