Android Device Porting Walkthrough

Android Device Porting Walkthrough

The talk introduces you to Android AOSP platform's internals and let you know about the necessary steps for cooking your own Android ROM and porting the OS to your favorite board.

Benjamin Zores

February 13, 2012
Tweet

More Decks by Benjamin Zores

Other Decks in Technology

Transcript

  1. COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. 1 Benjamin Zores

    ABS 2012 – 13th February 2012 – Redwood Shores, SF Bay, CA, USA Android Device Porting Walkthrough
  2. 2 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. Android Device

    Porting Walkthrough About Me ALCATEL LUCENT SOFTWARE ARCHITECT • Expert and Evangelist on Open Source Software. • 9y experience on various multimedia/network embedded devices design. • From low-level BSP integration to global applicative software architecture. OPEN SOURCE PROJECT FOUNDER, LEADER AND/OR CONTRIBUTOR FOR: • OpenBricks Embedded Linux cross-build framework. • GeeXboX Embedded multimedia HTPC distribution. • Enna EFL Media Center. • uShare UPnP A/V and DLNA Media Server. • MPlayer Linux media player application. EMBEDDED LINUX CONFERENCE FORMER ELC EDITIONS SPEAKER • ELC 2010 GeeXboX Enna: Embedded Media Center. • ELC-E 2010 State of Multimedia in 2010 Embedded Linux Devices. • ELC-E 2011 Linux Optimization Techniques: How Not to Be Slow ?
  3. 3 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Expert

    in Linux Embedded Systems and Cross-Build Systems. • Used to work on various embedded arch and Vendors: - x86 (AMD Geode, Intel Tolapai and CE4xxx). - PowerPC (Freescale 6xx, e300 and e500 cores). - MIPS 64 (Cavium Octeon CN52xx). - ARM: - XScale (Intel PXA 250). - ARM 9 (Marvell Orion and Kirkwood). - ARM 11 (Broadcom Bcmring). - Cortex-A8 (TI OMAP 3 and Freescale i.MX5x). - Cortex-A9 (TI OMAP 4, Freescale i.MX6 and nVidia Tegra2). Newbie in Android though learning more about it every day ... Android Device Porting Walkthrough My Experience
  4. 5 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. Android Device

    Porting Walkthrough Work Context • Designing an Enterprise Desktop IP Phone. • Differs heavily from usual Android devices: - Always connected, no battery - No GSM/CDMA Phone/Modem - Always docked - No screen rotation - No accelerometer - No GPS - => Not a Smartphone
  5. 6 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Goals

    - Ensure Google device certification. - Provide Android MarketPlace support. - Provide Android applications compatibility. - Provide access to Google services (GMail, Calendar ...). • Key Requirements - Memory: Minimum of 512 MB. - Storage: Minimum of 2 GB. - Display: Minimum resolution of 460x320. - Graphics: Hardware 2D/3D engine is more than recommended. - DO NOT modify Google APIs and framework. - Android "Telephony" refers to 3G/CDMA, hence IP-Phones are NOT considered as Android phones. Android Device Porting Walkthrough Ice Cream Sandwich Device Compatibility Guidelines
  6. 7 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Google

    - Up-to-date reference but limited devices support (reference design only). - https://android.googlesource.com/platform/manifest • Linaro - Most integrated with wide hardware support. - git://android.git.linaro.org/platform/manifest.git • Cyanogen Mod - Most features but mostly used for tuning already released commercial products. - https://github.com/cyanogenmod • Vendor BSP - Potentially outdated but best support for a given platform/SoC. We’ll base our example on TI OMAP4 Pandaboard-derived board based on Linaro sources. Android Device Porting Walkthrough Which Android Sources to Start With ?
  7. 8 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Extra

    Packages: - x264, ffmpeg, powertop, ARM DS-5 Gator Profiler, U-Boot, Linux Kernel, BusyBox • Optimized Packages: - Dalvik, IPSec, libvpx, libpng, libjpeg-turbo, OpenSSL, GCC Toolchain • Proprietary-Open Firmwares (BT, WiFi ...) • More hardware devices support than stock Google ICS: - TI Pandaboard - TI BeagleBoard - Freescale i.MX53 - ST Snowball - Samsung Origen Android Device Porting Walkthrough Linaro Android Added-Value
  8. 9 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Create

    your own device/my_company/my_device directory with complete product description. • Mandatory vendorsetup.sh: add_lunch_combo my_device-eng • Mandatory Android.mk: LOCAL_PATH := $(call my-dir) include $(call all-makefiles-under,$(LOCAL_PATH)) • Mandatory AndroidProducts.mk: PRODUCT_MAKEFILES := $(LOCAL_DIR)/my_device_name.mk • Mandatory my_device_name.mk: $(call inherit-product, $(SRC_TARGET_DIR)/product/full_base.mk) $(call inherit-product, device/my_company/common/common.mk) $(call inherit-product, device/my_company/my_device/device.mk) PRODUCT_BRAND := my_device_brand PRODUCT_DEVICE := my_device_name PRODUCT_NAME := my_device_name Android Device Porting Walkthrough AOSP Custom Device HowTo
  9. 10 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Mandatory

    device.mk: PRODUCT_COPY_FILES += device/my_company/my_device/init.rc:root/init.rc PRODUCT_PACKAGES += audio.primary.omap4 PRODUCT_PROPERTY_OVERRIDES += hwui.render_dirty_regions=false PRODUCT_CHARACTERISTICS := tablet,nosdcard PRODUCT_TAGS += dalvik.gc.type-precise $(call inherit-product, frameworks/base/build/tablet-dalvik-heap.mk) $(call inherit-product-if-exists, device/ti/proprietary-open/install-binaries.mk) • Mandatory BoardConfig.mk (product-specific compile-time definitions): - See build/core/product.mk for a list of nice-to-know build options. - # Platform TARGET_BOARD_PLATFORM := omap4 Android Device Porting Walkthrough AOSP Custom Device HowTo
  10. 11 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • #

    Target and compiler options TARGET_CPU_ABI := armeabi-v7a TARGET_CPU_ABI2 := armeabi TARGET_CPU_SMP := true • # Enable NEON feature TARGET_ARCH_VARIANT := armv7-a-neon ARCH_ARM_HAVE_TLS_REGISTER := true TARGET_EXTRA_CFLAGS += $(call cc-option,"-march=armv7-a -mtune=cortex-a9", $(call cc-option,"-march=armv7-a -mtune=cortex-a8")) • # Filesystem and partitioning BOARD_SYSTEMIMAGE_PARTITION_SIZE := 256M BOARD_USERDATAIMAGE_PARTITION_SIZE := 512M BOARD_CACHEIMAGE_PARTITION_SIZE := 256M BOARD_CACHEIMAGE_FILE_SYSTEM_TYPE := ext4 BOARD_FLASH_BLOCK_SIZE := 4096 TARGET_USERIMAGES_USE_EXT4 := true TARGET_USERIMAGES_SPARSE_EXT_DISABLED := true • # System TARGET_NO_RECOVERY := true TARGET_PROVIDES_INIT_RC := true Android Device Porting Walkthrough AOSP Custom Device HowTo
  11. 12 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Configuration

    Overlay - In device.mk: DEVICE_PACKAGE_OVERLAYS := device/my_company/my_device/overlay - Create a device/my_company/my_device/overlay directory with same depth and files you want to overwrite. e.g: - frameworks/base/core/res/res/values/config.xml - frameworks/base/core/res/res/values/dimens.xml - frameworks/base/core/res/res/xml/storage_list.xml Android Device Porting Walkthrough AOSP Custom Device HowTo
  12. 13 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Google

    provides one in bootable/bootloader/legacy. • But usually replaced by U-Boot with Fastboot protocol support. • Can be either out of AOSP sources or integrated. • In BoardConfig.mk: - TARGET_USE_XLOADER := false XLOADER_CONFIG := omap4430panda_config TARGET_NO_BOOTLOADER := true # Uses u-boot instead TARGET_USE_UBOOT := true UBOOT_CONFIG := omap4_panda_config Android Device Porting Walkthrough Bootloader
  13. 14 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Kernel

    Androidisms: - Ashmem, shared memory allocator. - Binder IPC and RMI system. - Pmem, process memory allocator. - Logger, system logging facility. - Wakelocks, power management and suspend. - Low Memory Killer, OOM Tuning. - Alarm Timers. - Paranoid Network Security. - Timed GPIO. - RAM Console. • See http://elinux.org/Android_Kernel_Features for more details. Android Device Porting Walkthrough Linux Kernel Androidisms
  14. 15 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Usually

    no drivers built as modules: - No udev. - Smaller disk footprint. - Faster to load up. - Kernel is built for a static hardware configuration. • Except for proprietary drivers (usually) or those requiring firmware (e.g. WiFi). • Can be added to Android FS separately as for firmwares. • In BoardConfig.mk: BOARD_KERNEL_BASE := 0x80000000 BOARD_KERNEL_CMDLINE := TARGET_NO_KERNEL := false KERNEL_CONFIG := android_omap4_defconfig Hint: Develop and debug raw drivers on Linux OS, not Android. Android Device Porting Walkthrough Linux Kernel Drivers Policy
  15. 16 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Small

    footprint BSD-licensed C library with the following weirdness: - Non POSIX. - No support for locales. - No support for wide chars (i.e. multi-byte characters). - Comes with its own smallish implementation of pthreads based on Linux futexes - C++ exceptions are not supported. - pthread cancellation is NOT supported. - Several functions are just stubs (i.e. runtime weirdness may happen). - Non standard /etc config files: - Dynamic user/groups management (no pam, group, passwd or shadow) - No fstab - No SysV init. Android Device Porting Walkthrough Bionic C Library
  16. 17 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • In-memory

    Bionic System Properties management - Array of volatile property=value fields. - Can be get/set through getprop/setprop shell commands as well as Java API. - No documentation on existing properties. - Anyone can add his own custom properties. • More persistent configuration settings are available in SQLite databases: - e.g: /data/data/com.android.providers.settings/database/settings.db - See secure and system tables. Android Device Porting Walkthrough System Properties and Settings Databases
  17. 18 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Proprietary

    init language based on rules and conditions. • Able to spawn services and restart them on failures through signals and sockets. • Initialization Steps: - Creates basic filesystem (/dev, /proc, /sys) and mounts it. - Parses /init.rc - Parses /init.${hw_name}.rc based on kernel command-line or /proc/cpuinfo - Build exec queues - Start triggers and associated actions and services. - e.g. "early-init", "init", "early-fs", "fs", "post-fs", "early-boot", "boot" … Android Device Porting Walkthrough Android Init
  18. 19 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Actions:

    - Named sequences of commands queued and executed upon events/triggers. - Syntax: on <trigger> <command> <command> ... • Triggers: - Strings which can be used to match certain kinds of events and used to cause an action to occur. • Services: - Programs which init launches and (optionally) restarts when they exit. - Syntax: service <name> <pathname> [ <argument> ]* <option> <option> ... • Options: - Modifiers to services. They affect how and when init runs the service. • Commands: - Android proprietary built-in commands. Android Device Porting Walkthrough Android Init Language
  19. 20 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. Android Device

    Porting Walkthrough Android Init Options Option Syntax Description critical This is a device-critical service. If it exits more than four times in four minutes, the device will reboot into recovery mode. disabled This service will not automatically start with its class. It must be explicitly started by name. setenv <name> <value> Set the environment variable <name> to <value> in the launched process. socket <name> <type> <perm> [ <user> [ <group> ] ] Create a unix domain socket named /dev/socket/<name> and pass its fd to the launched process. group <groupname> [ <groupname> ]* Change to groupname before exec'ing this service. oneshot Do not restart the service when it exits. class <name> Specify a class name for the service. All services in a named class may be started or stopped together onrestart Execute a Command when service restarts. ioprio <rt|be|idle> <ioprio 0-7> Set service priority and scheduling class. console Output logs on console. capability <keycode> Trigger service through keycode in /dev/keychord
  20. 21 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • boot

    - This is the first trigger that will occur when init starts (after /init.rc is loaded) • <name>=<value> - Triggers of this form occur when the property <name> is set to the specific value <value>. • device-added-<path> • device-removed-<path> - Triggers of these forms occur when a device node is added or removed. • service-exited-<name> - Triggers of this form occur when the specified service exits. Android Device Porting Walkthrough Android Init Triggers
  21. 22 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. Android Device

    Porting Walkthrough Android Init Commands Command Syntax Description exec <path> [ <argument> ]* Fork and execute a program (<path>). This will block until the program completes. export <name> <value> Set the environment variable <name> equal to <value> in the global environment. ifup <interface> Bring the network interface <interface> online. hostname <name> Set the host name. chdir <directory> Change working directory. chmod <octal-mode> <path> Change file access permissions. chown <owner> <group> <path> Change file owner and group. chroot <directory> Change process root directory. class_start <serviceclass> Start all services of the specified class if they are not already running. class_stop <serviceclass> Stop all services of the specified class if they are currently running. class_reset <serviceclass> Reset a class. domainname <name> Set the domain name. insmod <path> Install the module at <path> mkdir <path> [mode] [owner] [group] Create a directory at <path>, optionally with the given mode, owner, and group. mount <type> <device> <dir> [ <mountoption> ]* Attempt to mount the named device at the directory <dir>
  22. 23 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. Android Device

    Porting Walkthrough Android Init Commands Command Syntax Description setprop <name> <value> Set system property <name> to <value>. setrlimit <resource> <cur> <max> Set the rlimit for a resource. start <service> Start a service running if it is not already running. stop <service> Stop a service from running if it is currently running. restart <service> Restart a service from running if it is currently running. symlink <target> <path> Create a symbolic link at <path> with the value <target> sysclktz <mins_west_of_gmt> Set the system clock base (0 if system clock ticks in GMT) trigger <event> Trigger an event. Used to queue an action from another action. write <path> <string> [ <string> ]* Open the file at <path> and write one or more strings to it. rm <path> Removes a file. rmdir <path> Removes a directory. wait <file> Wait for file to exist or timeout to be reached. copy <src> <dest> Copy from source to dest. loglevel <level> Set kernel log level. load_persist_props Load properties from files in /data/property
  23. 24 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Somehow

    replaces udevd from desktop Linux. • Used to set user/group/permissions on /dev nodes. • Steps: - Parses /ueventd.rc - Parses /ueventd.${hw_name}.rc based on kernel command-line or /proc/cpuinfo. - Set nodes permissions. Android Device Porting Walkthrough uEventd
  24. 25 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • HAL

    Library for some HW Components (see hardware/libhardware): - Audio (Configuration, Mixing, Routing, Streaming, Echo Cancellation, FX ...). - Framebuffer (Configuration, Composition, Display). - GFX Allocator (GPU Memory Buffer Management). - GFX HW Composer (Surface Composition and Transformation). - Camera (Facing, Orientation, Buffer Management, Pictures, Recording ...). - WiFi (AP/STA/P2P Configuration and Firmware Support). - GPS (Configuration, Location Data Acquisition). - Lights (Backlight and LEDS control). - Sensors (Accelerometer/Pressure/Proximity/Gravity/... Controls). - NFC Android Device Porting Walkthrough Hardware Abstraction Library
  25. 26 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Series

    of dynamically loaded plugin (.so files): - MUST match board-specific plugin name - See APIs in hardware/libhardware/include/hardware - Default/dummy implementation provided in AOSP (hardware/libhardware/modules) - MUST be fully implemented by device vendor. - Can be closed-source. • For each HAL class module plugins are checked: - based on system properties values in the following order: - ro.hardware - ro.product.board - ro.board.platform - ro.arch - in the following directories order: - /vendor/lib/hw - /system/lib/hw Android Device Porting Walkthrough Hardware Abstraction Library
  26. 27 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Kernel

    Board Config: - Disable HDMI device: - static struct omap_dss_device *omap4_panda_dss_devices[] = { - &omap4_panda_hdmi_device, + &omap4_panda_lcd_device, }; - Use DPI-LCD as primary video device: - static struct omap_dss_board_info omap4_panda_dss_data = { .num_devices = ARRAY_SIZE(omap4_panda_dss_devices), .devices = omap4_panda_dss_devices, .default_device = &omap4_panda_lcd_device, }; - Match custom DPI-LCD panel driver name: - static struct panel_generic_dpi_data omap4_lcd_panel = { .name = "my_dpi_lcd_panel", .platform_enable = omap4_panda_enable_lcd, .platform_disable = omap4_panda_disable_lcd, }; - struct omap_dss_device omap4_panda_lcd_device = { .type = OMAP_DISPLAY_TYPE_DPI, .name = "lcd", .driver_name = "generic_dpi_panel", .data = &omap4_lcd_panel, .channel = OMAP_DSS_CHANNEL_LCD2, }; Android Device Porting Walkthrough LCD Display
  27. 28 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • DPI-LCD

    panel driver config: - Hack drivers/video/omap2/displays/panel-generic-dpi.c: - static struct panel_config generic_dpi_panels[] = { [...] /* My custom DPI-LCD Panel */ { .x_res = 800, .y_res = 480, .pixel_clock = REFRESH_RATE * 1056 * 525 / 1000, […], .config = OMAP_DSS_LCD_IVS | OMAP_DSS_LCD_IHS, .power_on_delay = 102, .power_off_delay = 100, .name = "my_dpi_lcd_panel", }, […] }; Android Device Porting Walkthrough LCD Display
  28. 29 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Force

    Tablet Mode (120dpi) - LCD 800x480 WVGA 7” (1.667 aspect ratio) => 133 dpi => Phone Mode. - In BoardConfig.mk: PRODUCT_PROPERTY_OVERRIDES += ro.sf.lcd_density=120 PRODUCT_CHARACTERISTICS := tablet • Forced Landscape Orientation - In frameworks/base/core/res/res/values/config.xml: <bool name="config_allowAllRotations">false</bool> <integer name="config_deskDockKeepsScreenOn">1</integer> <bool name="config_deskDockEnablesAccelerometer">false</bool> Android Device Porting Walkthrough Orientation and Docked Tablet
  29. 30 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Force

    HW GPU Usage - In BoardConfig.mk: - BOARD_EGL_CFG := device/my_company/my_device/egl.cfg - BOARD_USES_HGL := true - BOARD_USES_OVERLAY := true - USE_OPENGL_RENDERER := true • Deploy (in /vendor) vendor-provided binary blobs of: - Gralloc HAL Moduler - OpenGL|ES 1.x and 2.x libraries. • Optionally force OpenGL|ES libs version detection. - In BoardConfig.mk: - PRODUCT_PROPERTY_OVERRIDES += ro.opengles.version=131072 - => Makes AngryBirds happy ... and so are we ! Android Device Porting Walkthrough 2D/3D GPU
  30. 31 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • See

    http://source.android.com/tech/input/overview.html • Many changes occurred with Android 4.0 Android Device Porting Walkthrough Input Subsystem
  31. 32 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Maps

    Linux key and axis codes to Android key and axis codes. • Required for all internal (built-in) input devices that have keys, including special keys such as volume, power and headset media keys. • Location: - Located by USB vendor, product (and optionally version) id or by input device name. - The following paths are consulted in order: /system/usr/keylayout/Vendor_XXXX_Product_XXXX_Version_XXXX.kl /system/usr/keylayout/Vendor_XXXX_Product_XXXX.kl /system/usr/keylayout/DEVICE_NAME.kl /system/usr/keylayout/Generic.kl /data/system/devices/keylayout/Vendor_XXXX_Product_XXXX_Version_XXXX.kl /data/system/devices/keylayout/Vendor_XXXX_Product_XXXX.kl /data/system/devices/keylayout/DEVICE_NAME.kl /data/system/devices/keylayout/Generic.kl Android Device Porting Walkthrough Input Key Layout Files
  32. 33 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Syntax:

    - key - Linux scan code number - Android key code name - [policy flags] - key 1 ESCAPE key 114 VOLUME_DOWN WAKE key 16 Q VIRTUAL WAKE • Policy flags: - WAKE|WAKE_DROPPED: The key should wake the device when it is asleep. - SHIFT: The key should be interpreted as if the SHIFT key were also pressed. - CAPS_LOCK: The key should be interpreted as if the CAPS LOCK key were also pressed. - ALT: The key should be interpreted as if the ALT key were also pressed. - ALT_GR: The key should be interpreted as if the RIGHT ALT key were also pressed. - FUNCTION: The key should be interpreted as if the FUNCTION key were also pressed. - VIRTUAL: The key is a virtual soft key that is adjacent to the main touch screen. Android Device Porting Walkthrough Input Key Layout Files
  33. 34 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Contains

    device-specific configuration properties that affect the behavior of input devices. • Optional for standard peripherals such as HID keyboard and mouse. • Mandatory for built-in embedded devices such as touch screens. • Location: - Located by USB vendor, product (and optionally version) id or by input device name. - The following paths are consulted in order: /system/usr/idc/Vendor_XXXX_Product_XXXX_Version_XXXX.idc /system/usr/idc/Vendor_XXXX_Product_XXXX.idc /system/usr/idc/DEVICE_NAME.idc /data/system/devices/idc/Vendor_XXXX_Product_XXXX_Version_XXXX.idc /data/system/devices/idc/Vendor_XXXX_Product_XXXX.idc /data/system/devices/idc/DEVICE_NAME.idc Android Device Porting Walkthrough Input Device Configuration Files
  34. 35 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Driver

    needs to calculate correct position relative to screen. - Android does not do interpolation like X.Org xf86-input-evdev driver would do. • Kernel I2C Board Config: - Pin Multiplexing: - /* TS IRQ - GPIO 48 */ OMAP4_MUX(GPMC_A24, OMAP_MUX_MODE3 | OMAP_PIN_INPUT); - I2C Device Registration: - struct cy8ctmg110_pdata omap_panda_ts_data __initdata = { .irq_pin = GPIO_TS_IRQ, }; static struct i2c_board_info __initdata panda_i2c_cy8ctmg110[] = { I2C_BOARD_INFO("cy8ctmg110", 0x20), .platform_data = &omap_panda_ts_data, }; omap_register_i2c_bus(2, 100, panda_i2c_cy8ctmg110, ARRAY_SIZE(panda_i2c_cy8ctmg110)); Android Device Porting Walkthrough I2C Touchscreen
  35. 36 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Initialization

    (driver name MUST match .idc filename): - input_dev->name = "cy8ctmg110"; input_dev->evbit[0] = BIT(EV_SYN) | BIT(EV_KEY) | BIT(EV_ABS); input_dev->keybit[BIT_WORD(BTN_TOUCH)] = BIT_MASK(BTN_TOUCH); input_dev->absbit[ABS_X] = BIT(ABS_X); input_dev->absbit[ABS_Y] = BIT(ABS_Y); input_dev->absbit[ABS_PRESSURE] = BIT(ABS_PRESSURE); input_set_abs_params(input_dev, ABS_X, min_x, max_x, 0, 0); input_set_abs_params(input_dev, ABS_Y, min_y, max_y, 0, 0); input_set_abs_params(input_dev, ABS_PRESSURE, 0, 1, 0, 0); • Touch Press Events: - static void ts_press_on(struct input_dev *input, int x, int y) { input_report_abs(input, ABS_X, x); input_report_abs(input, ABS_Y, y); input_report_abs(input, ABS_PRESSURE, 1); input_report_key(input, BTN_TOUCH, 1); input_sync(input); } • Touch Release Events: - static void ts_press_off(struct input_dev *input, int x, int y) { input_report_abs(input, ABS_PRESSURE, 0); input_report_key(input, BTN_TOUCH, 0); input_sync(input); } Android Device Porting Walkthrough I2C Touchscreen Driver
  36. 37 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Add

    cy8ctmg110.idc to system: - In device.mk, add: - PRODUCT_COPY_FILES += device/my_company/my_device/cy8ctmg110.idc:system/usr/idc/cy8ctmg110.idc • Example of cy8ctmg110.idc: - # Basic Parameters touch.deviceType = touchScreen touch.orientationAware = 0 # Size touch.size.calibration = none # Orientation touch.pressure.calibration = none Android Device Porting Walkthrough Touchscreen Device Configuration File
  37. 38 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Overlay

    storage configuration file: - See frameworks/base/core/res/res/xml/storage_list.xml: - <storage android:mountPoint="/mnt/sdcard" android:storageDescription="@string/storage_internal" android:primary="true" android:removable="false" android:emulated="true" android:mtpReserve="100" /> • Edit list of mount points: - See device/my_company/my_device/vold.fstab: - dev_mount sdcard /mnt/sdcard 6 /devices/platform/omap/omap_hsmmc.0/mmc_host/mmc0 Android Device Porting Walkthrough Storage Subsystem
  38. 39 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • In

    BoardConfig.mk: - BOARD_USES_GENERIC_AUDIO := false #BOARD_USES_ALSA_AUDIO := false BUILD_WITH_ALSA_UTILS := false • MUST implement Audio HAL - See hardware/libhardware/modules/audio for example. - MUST declare as AUDIO_HARDWARE_MODULE_ID. - MUST implement audio HAL API; see hardware/libhardware/include/hardware/audio.h. - Implements audio in/out, volume get/set, mute get/set, gain get/set, list and configure all supported in/out devices, open/close input/output streams, configure mixer and router, add/remove audio effects (e.g. Automatic Gain Control and Acoustic Echo Cancellation). - MUST link against TinyALSA (new in ICS). - To be implemented in: device/my_company/my_device/audio/audio_hw.c - MUST be declared in LOCAL_MODULE as "audio.primary.${ro.product.board}" - e.g. : audio.primary.omap4 • See http://goo.gl/zPFQ8 for example. Android Device Porting Walkthrough Audio Subsystem
  39. 40 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Low-level

    kernel drivers work just like a charm up to Linux user-space. • For Java apps connectivity, each connection type must register a specific ConnectivityManager and associated ConnectivityService that handles device configuration, packet routing and HTTP(S) proxy settings. Android Device Porting Walkthrough Network & Connectivity
  40. 41 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Overlay

    some resources in frameworks/base/core/res/res/values/config.xml: - <!-- Used by the connectivity manager to decide which networks can coexist --> <string-array translatable="false" name="networkAttributes"> <item>"wifi,1,1,1,-1,true"</item> <item>"bluetooth,7,7,0,-1,true"</item> <item>"ethernet,9,9,2,-1,true"</item> </string-array> <string-array translatable="false" name="radioAttributes"> <item>"1,1"</item> <item>"7,1"</item> <item>"9,1"</item> </string-array> Android Device Porting Walkthrough Network & Connectivity
  41. 42 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Ethernet

    connection type exists in ICS API. • But with no ConnectivityManager or ConnectivityService implementation. - => Can't be configured nor used easily through regular Java apps (with exception to the Web Browser). - Experimental ECM patch has been integrated in Linaro ICS. - Allow low-level device configuration and settings. - Uses Persistent Secure Settings SQLite database. - Doesn't register with ConnectivityManager (i.e "No Internet Connection" symptom). - Doesn't provide HTTP(S) proxy support. - => To be implemented !! :-( Android Device Porting Walkthrough Ethernet Connectivity
  42. 43 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Obviously

    requires kernel drivers + potentially associated firmware blobs. • Station Mode: - In BoardConfig.mk: - WIFI_DRIVER_MODULE_PATH := "/system/modules/wl12xx_sdio.ko" WIFI_DRIVER_MODULE_NAME := "wl12xx_sdio" WIFI_DRIVER_FW_PATH_STA := "/system/etc/firmware/wl1271-fw.bin" WIFI_FIRMWARE_LOADER := - Add WiFi hardware permission, in device.mk: - PRODUCT_COPY_FILES += frameworks/base/data/etc/android.hardware.wifi.xml:system/etc/permissions/android.hardware.wifi.xml - HAL driver in hardware/libhardware_legacy/wifi. - Default implementation should be sufficient in most cases. - Loads/unloads kernel drivers, loads up firmware and register UNIX socket connection to WPA supplicant for further control. - Used by JNI Java framework. Android Device Porting Walkthrough WiFi Connectivity
  43. 44 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Access

    Point Mode: - In BoardConfig.mk: - WIFI_DRIVER_FW_PATH_AP := "/system/etc/firmware/wl1271-fw-ap.bin“ BOARD_WPA_SUPPLICANT_DRIVER := WEXT WPA_SUPPLICANT_VERSION := VER_0_8_X BOARD_WPA_SUPPLICANT_PRIVATE_LIB := private_lib_driver_cmd - See external/wpa_supplicant_8/private_lib. - In init.rc: - service wpa_supplicant /system/bin/wpa_supplicant -Dwext -iwlan0 –dd socket wpa_wlan0 dgram 660 wifi wifi disabled oneshot - In wpa_supplicant.conf (both for AP and STA): - ctrl_interface=DIR=/data/system/wpa_supplicant GROUP=wifi update_config=1 ap_scan=1 Android Device Porting Walkthrough WiFi Connectivity
  44. 45 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Obviously

    requires kernel drivers + potentially associated firmware blobs. • In BoardConfig.mk: - BOARD_HAVE_BLUETOOTH := true • Add Bluetooth hardware permission, in /system/etc/permissions/ - <feature name="android.hardware.bluetooth" /> • May requires support in audio HAL for BT A2DP support. • libbluedroid implements enables/disables BT interface and creates HCI socket through rfkill (see system/bluetooth/bluedroid). Android Device Porting Walkthrough Bluetooth
  45. 46 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • In

    media_profiles.xml: - XML file that lists audio/video/image encoder/decoder capabilities. - <!-- If a codec is not enabled, it is invisible to the applications. In other words, the applications won't be able to use the codec or query the capabilities of the codec at all if it is disabled --> <VideoEncoderCap name="h264" enabled="true" minBitRate="64000" maxBitRate="3000000" minFrameWidth="176" maxFrameWidth="800" minFrameHeight="144" maxFrameHeight="480" minFrameRate="1" maxFrameRate="30" /> - No checks on decoder capabilities so far. • OpenMAX components enablement in BoardConfig.mk: - HARDWARE_OMX := true ifdef HARDWARE_OMX OMX_VENDOR := ti OMX_VENDOR_WRAPPER := TI_OMX_Wrapper BOARD_OPENCORE_LIBRARIES := libOMX_Core BOARD_OPENCORE_FLAGS := -DHARDWARE_OMX=1 endif - OMX implementation and StageFright integration really comes as a dedicated talk. Android Device Porting Walkthrough Multimedia Subsystem
  46. 47 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Partial

    trick for Android to believe it’s running on power supply (at least on main UI). - Add new system setting in device.mk: - PRODUCT_PROPERTY_OVERRIDES += hw.nobattery=true - Hack on frameworks/base/services/java/com/android/server/BatteryService.java - String hwNoBatteryStr = SystemProperties.get("hw.nobattery"); boolean hwNoBattery = Boolean.parseBoolean(hwNoBatteryStr); if (!hwNoBattery) mPowerSupplyObserver.startObserving("SUBSYSTEM=power_supply"); private void stubUpdate() { // Hardcode values. We could read them from properties mAcOnline = true; mUsbOnline = false; mBatteryPresent = true; mBatteryLevel = 100; mBatteryVoltage = 4700; mBatteryTemperature = 80; mBatteryStatus = BatteryManager.BATTERY_STATUS_FULL; mPlugType = BatteryManager.BATTERY_PLUGGED_AC; } private synchronized final void update() { if (hwNoBattery) stubUpdate(); else { native_update(); processValues(); } } Android Device Porting Walkthrough No-Battery Trick
  47. 48 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • Overload

    some resources in frameworks/base/core/res/res/values/config.xml: - <!-- This device is not "voice capable"; it's data-only. --> <bool name="config_voice_capable">false</bool> <!-- This device does not allow sms service. --> <bool name="config_sms_capable">false</bool> <!-- Enables SIP on any network interface --> <bool name="config_sip_wifi_only">false</bool> <!-- Enables built-in SIP phone capability --> <bool name="config_built_in_sip_phone">true</bool> Android Device Porting Walkthrough Phone
  48. 49 COPYRIGHT © 2012 ALCATEL-LUCENT. ALL RIGHTS RESERVED. • More

    devices to be supported and described … - Modem / RIL - Camera - GPS - Sensors (Accelerometer …) - HW OpenMAX Multimedia Encoders/Decoders • But that's really another story ... for another day ;-) Android Device Porting Walkthrough What's More ?
