Espresso: A Screenshot is Worth 1,000 Words
Clickable slides: https://docs.google.com/presentation/d/14INMGCJumDrEj4OpuQubUJ5nrql572yjVy4Qm8Abfso/edit
Video: Will link when available.
Description: Do your product owners, designers and the people that pay you understand what in the world your Espresso tests are doing and why they are valuable? You've spent so much time and effort writing these tests and your whole team deserves to get the most benefit out of them. In this talk you'll learn how to setup your Espresso tests to take programatic screenshots, and leverage the Robot pattern of testing for clean, readable, and maintainable tests.
Presented at:
* Droidcon NYC 2016
* DevFestDC 2016
* Richmond Java Users Group
Sam Edwards:
* Twitter: https://twitter.com/handstandsam
* Website: http://handstandsam.com
Sam Edwards
Transcript
104 slides
-
: A Screenshot is Worth 1,000 Words Sam Edwards -
@HandstandSam - Capital One -
Sam Edwards @HandstandSam • Android since 2011 • Architected and
leading Espresso efforts for Capital One Wallet • Opinions in this talk are my own, not Capital One http://handstandsam.com -
Outline • Espresso in 2 minutes • Screenshots - Why?
How? When? The Cost? • Maintainable Test Architecture • Tips and Tricks -
What is Espresso? • A library provided by Google for
Android UI testing • Built on Android Test Instrumentation • Aware of the idle state and therefore FAST • Easy to read and write -
Target Audience for Espresso “Espresso is targeted at developers, who
believe that automated testing is an integral part of the development lifecycle. While it can be used for black-box testing, Espresso’s full power is unlocked by those who are familiar with the codebase under test.” -
Oops, Your Test Failed android.support.test.espresso.NoMatchingViewException: No views in hierarchy found
matching: with text: “DONE!” View Hierarchy: +>DecorView{id=-1, visibility=VISIBLE, width=720, height=1280, has-focus=false, has-focusable=false, has-window-focus=true, is-clickable=false, is-enabled=true, is-focused=false, is-focusable=false, is-layout-requested=false, is-selected=false, root-is-layout-requested=false, has-input-connection=false, x=0.0, y=0.0, child-count=3} | +->ActionBarOverlayLayout{id=16909230, res-name=decor_content_parent, visibility=VISIBLE, width=720, height=1184, has-focus=false, has-focusable=false, has-window-focus=true, is-clickable=false, is-enabled=true, is-focused=false, is-focusable=false, is-layout-requested=false, is-selected=false, root-is-layout-requested=false, has-input-connection=false, x=0.0, y=0.0, child-count=2} | +-->FrameLayout{id=16908290, res-name=content, visibility=VISIBLE, width=720, height=1024, has-focus=false, has-focusable=false, has-window-focus=true, is-clickable=false, is-enabled=true, is-focused=false, is-focusable=false, is-layout-requested=false, is-selected=false, root-is-layout-requested=false, has-input-connection=false, x=0.0, y=160.0, child-count=1} | +--->TextView{id=2131230720, res-name=greeting, visibility=VISIBLE, width=656, height=960, has-focus=false, has-focusable=false, has-window-focus=true, is-clickable=false, is-enabled=true, is-focused=false, is-focusable=false, is-layout-requested=false, is-selected=false, root-is-layout-requested=false, has-input-connection=false, x=32.0, y=32.0, text=Hello world!, input-type=0, ime-target=false, has-links=false} | +-->ActionBarContainer{id=16909231, res-name=action_bar_container, visibility=VISIBLE, width=720, height=112, has-focus=false, has-focusable=false, has-window-focus=true, is-clickable=false, is-enabled=true, is-focused=false, is-focusable=false, is-layout-requested=false, is-selected=false, root-is-layout-requested=false, has-input-connection=false, x=0.0, y=48.0, child-count=2} -
Ahh, I See Why android.support.test.espresso.NoMatchingViewException: No views in hierarchy found
matching: with text: “DONE!” View Hierarchy: +>DecorView{id=-1, visibility=VISIBLE, width=720, height=1280, has-focus=false, has-focusable=false, has-window-focus=true, is-clickable=false, is-enabled=true, is-focused=false, is-focusable=false, is-layout-requested=false, is-selected=false, root-is-layout-requested=false, has-input-connection=false, x=0.0, y=0.0, child-count=3} | +->ActionBarOverlayLayout{id=16909230, res-name=decor_content_parent, visibility=VISIBLE, width=720, height=1184, has-focus=false, has-focusable=false, has-window-focus=true, is-clickable=false, is-enabled=true, is-focused=false, is-focusable=false, is-layout-requested=false, is-selected=false, root-is-layout-requested=false, has-input-connection=false, x=0.0, y=0.0, child-count=2} | +-->FrameLayout{id=16908290, res-name=content, visibility=VISIBLE, width=720, height=1024, has-focus=false, has-focusable=false, has-window-focus=true, is-clickable=false, is-enabled=true, is-focused=false, is-focusable=false, is-layout-requested=false, is-selected=false, root-is-layout-requested=false, -
Screenshots on FAILURES Espresso.setFailureHandler(new FailureHandler() { @Override public void handle(Throwable
throwable, Matcher<View> matcher) { ScreenshotHelper.takeScreenshotForcefully("test_failed"); try { new DefaultFailureHandler(applicationContext).handle(throwable, matcher); } catch (Exception e) { logger.error(e.getMessage(), e); throw new RuntimeException(e); } } }); -
Screenshots on FAILURES Espresso.setFailureHandler(new FailureHandler() { @Override public void handle(Throwable
throwable, Matcher<View> matcher) { ScreenshotHelper.takeScreenshotForcefully("test_failed"); try { new DefaultFailureHandler(applicationContext).handle(throwable, matcher); } catch (Exception e) { logger.error(e.getMessage(), e); throw new RuntimeException(e); } } }); -
Screenshots on FAILURES Espresso.setFailureHandler(new FailureHandler() { @Override public void handle(Throwable
throwable, Matcher<View> matcher) { ScreenshotHelper.takeScreenshotForcefully("test_failed"); try { new DefaultFailureHandler(applicationContext).handle(throwable, matcher); } catch (Exception e) { logger.error(e.getMessage(), e); throw new RuntimeException(e); } } }); -
1. See What is Being Tested 2. Diagnose Failures 3.
Share Your Tests -
NO ONE Sees The Value of Your Tests… YET •
Your Boss • Product Owners • Designers • Manual Testers -
That’s because they can’t tell what your tests are doing
and don’t find any use for them. To them it’s just console output. -
User Interfaces are VISUAL • A User Interface is something
very hard to represent in a non-visual way. • Exercise: ◦ Imagine you need to tell someone who is blind what the Mona Lisa painting looks like. What would you say? https://en.wikipedia.org/wiki/Mona_Lisa -
Spoon Test Runner java -jar spoon-runner-1.7.0-jar-with-dependencies.jar \ --apk example-app.apk \
--test-apk example-tests.apk • Run instrumentation tests in parallel • Shard tests across multiple devices • Beautiful HTML reports -
GIFs • Generated by default • Processing overhead ◦ 11
Seconds for 21 Screenshots -> • Disable using “--no-animations” -
Falcon & (Falcon Spoon Compat) FalconSpoon.screenshot(activity, tag); FalconSpoon.screenshot(activity, tag, testClassName,
testMethodName); https://github.com/jraska/Falcon/ -
UiAutomator File outputFile = Spoon.screenshot(activity, tag, testClass, testMethod); uiDevice.takeScreenshot(outputFile); •
Works inside and outside of your app • API 18+ (Jelly Bean MR2) https://developer.android.com/topic/libraries/testing-support-library/i ndex.html#UIAutomator -
Other Alternatives • Firebase Test Lab’s “Screenshotter” ◦ https://firebase.google.com/docs/test-lab/test-screenshots •
Fastlane’s “Screengrab” ◦ https://github.com/fastlane/fastlane/tree/master/screengrab -
Get Currently RESUMED Activity private static Activity getCurrentActivityInstance() { final
Activity[] activity = new Activity[1]; getInstrumentation().runOnMainSync(new Runnable() { public void run() { Collection resumedActivities = ActivityLifecycleMonitorRegistry.getInstance() .getActivitiesInStage(RESUMED); if (resumedActivities.iterator().hasNext()) { Activity currentActivity = (Activity) resumedActivities.iterator().next(); activity[0] = currentActivity; logger.trace("Activity obtained of type: " + currentActivity.getClass().getName()); } } }); return activity[0]; } -
Get Test Method & Class from Current Stack Trace public
static StackTraceElement getTestMethodStackTraceElement() { StackTraceElement[] stackTrace = Thread.currentThread().getStackTrace(); for (int i = 4; i < stackTrace.length; i++) { StackTraceElement stackTraceElement = stackTrace[i]; try { Method method = Class.forName(stackTraceElement.getClassName()).getMethod( stackTraceElement.getMethodName()); Annotation annotation = method.getAnnotation(Test.class); if (annotation != null) { return stackTraceElement; } } catch (Exception e) { // That's fine, will look at the next stack trace element } } return stackTrace[4]; } -
Get Test Method & Class from Current Stack Trace public
static StackTraceElement getTestMethodStackTraceElement() { StackTraceElement[] stackTrace = Thread.currentThread().getStackTrace(); for (int i = 4; i < stackTrace.length; i++) { StackTraceElement stackTraceElement = stackTrace[i]; try { Method method = Class.forName(stackTraceElement.getClassName()).getMethod( stackTraceElement.getMethodName()); Annotation annotation = method.getAnnotation(Test.class); if (annotation != null) { return stackTraceElement; } } catch (Exception e) { // That's fine, will look at the next stack trace element } } return stackTrace[4]; } -
Well… It Depends • ALWAYS on FAILURE • To generate
reports for product and design teams • On small/low-res emulators during test development/debugging -
Execution Time Overhead in Minutes 384x640 mdpi Nexus 5 Nexus
6P Falcon +16.53% +62.31% +114.39% UiAutomator +28.93% +116.15% +168.87% -
Report Size Overhead in MB 384x640 mdpi Nexus 5 Nexus
6P Falcon +17.35% +66.41% +90.13% UiAutomator +18.41% +64.77% +89.19% -
Robot Testing Pattern • A Test Architecture Pattern for Maintainability
• Learned about it from Jake Wharton’s talk: ◦ VIDEO: https://realm.io/news/kau-jake-wharton-testing-robots/ ◦ SLIDES: https://speakerdeck.com/jakewharton/testing-robots-kotlin-night-may-2016 -
Robot Testing Pattern View Presenter Model Test What Test Test
Test Test Test Test -
Robot Testing Pattern View Presenter Model Test What Test Test
Test Test Test Test X X X X X X X View Changed -
Robot Testing Pattern View Presenter Model Test What Test Test
Test Test Test Test Robot -
Robot Testing Pattern View Presenter Model Test What Test Test
Test Test Test Test Robot X View Changed -
Typical Espresso Test @RunWith(AndroidJUnit4.class) public class LoginTest { @Rule public
ActivityTestRule<LoginActivity> activityRule = new ActivityTestRule(LoginActivity.class); @Test public void testLogin(){ onView(withText("LOGIN")).check(matches(not(isEnabled()))); onView(withId(R.id.username)).perform(typeText("sam")); onView(withText("LOGIN")).perform(click()); onView(withId(R.id.home_view_pager)).check(matches(isDisplayed())); } } -
Typical Espresso Test With Screenshots @RunWith(AndroidJUnit4.class) public class LoginTest {
@Rule public ActivityTestRule<LoginActivity> activityRule = new ActivityTestRule(LoginActivity.class); @Test public void testLogin(){ onView(withText("LOGIN")).check(matches(not(isEnabled()))); takeScreenshot("login_disabled"); onView(withId(R.id.username)).perform(typeText("sam")); takeScreenshot("entered_username"); onView(withText("LOGIN")).perform(click()); takeScreenshot("logged_in_and_at_homescreen"); onView(withId(R.id.home_view_pager)).check(matches(isDisplayed())); } } -
Espresso Test With a Robot @RunWith(AndroidJUnit4.class) public class LoginTest {
@Rule public ActivityTestRule<LoginActivity> activityRule = new ActivityTestRule(LoginActivity.class); @Test public void testLogin(){ new LoginRobot().assertLoginDisabled().username("sam").login().assertHomeScreenShown(); } } -
Example Robot static final Matcher<View> VIEW_MATCHER_USERNAME_EDIT_TEXT = withId(R.id.username); static final
Matcher<View> VIEW_MATCHER_LOGIN_BUTTON = withText("LOGIN"); static final Matcher<View> VIEW_MATCHER_HOME_SCREEN = withId(R.id.home_view_pager); public LoginRobot assertLoginDisabled() { onView(VIEW_MATCHER_LOGIN_BUTTON).check(matches(not(isEnabled()))); takeScreenshot("login_disabled"); return this; } public LoginRobot username(String username) { onView(VIEW_MATCHER_USERNAME_EDIT_TEXT).perform(clearText(), typeText(username), closeSoftKeyboard()); takeScreenshot("username_entered"); return this; } public LoginRobot login() { onView(VIEW_MATCHER_LOGIN_BUTTON).check(matches(isDisplayed())); takeScreenshot("logging_in"); onView(VIEW_MATCHER_LOGIN_BUTTON).perform(click()); return this; } public LoginRobot assertHomeScreenShown() { onView(VIEW_MATCHER_HOME_SCREEN).check(matches(isDisplayed())); takeScreenshot("home_screen_shown"); return this; } -
Example Robot static final Matcher<View> VIEW_MATCHER_USERNAME_EDIT_TEXT = withId(R.id.username); static final
Matcher<View> VIEW_MATCHER_LOGIN_BUTTON = withText("LOGIN"); static final Matcher<View> VIEW_MATCHER_HOME_SCREEN = withId(R.id.home_view_pager); public LoginRobot assertLoginDisabled() { onView(VIEW_MATCHER_LOGIN_BUTTON).check(matches(not(isEnabled()))); takeScreenshot("login_disabled"); return this; } public LoginRobot username(String username) { onView(VIEW_MATCHER_USERNAME_EDIT_TEXT).perform(clearText(), typeText(username), closeSoftKeyboard()); takeScreenshot("username_entered"); return this; } public LoginRobot login() { onView(VIEW_MATCHER_LOGIN_BUTTON).check(matches(isDisplayed())); takeScreenshot("logging_in"); onView(VIEW_MATCHER_LOGIN_BUTTON).perform(click()); return this; } public LoginRobot assertHomeScreenShown() { onView(VIEW_MATCHER_HOME_SCREEN).check(matches(isDisplayed())); takeScreenshot("home_screen_shown"); return this; } -
Example Robot static final Matcher<View> VIEW_MATCHER_USERNAME_EDIT_TEXT = withId(R.id.username); static final
Matcher<View> VIEW_MATCHER_LOGIN_BUTTON = withText("LOGIN"); static final Matcher<View> VIEW_MATCHER_HOME_SCREEN = withId(R.id.home_view_pager); public LoginRobot assertLoginDisabled() { onView(VIEW_MATCHER_LOGIN_BUTTON).check(matches(not(isEnabled()))); takeScreenshot("login_disabled"); return this; } public LoginRobot username(String username) { onView(VIEW_MATCHER_USERNAME_EDIT_TEXT).perform(clearText(), typeText(username), closeSoftKeyboard()); takeScreenshot("username_entered"); return this; } public LoginRobot login() { onView(VIEW_MATCHER_LOGIN_BUTTON).check(matches(isDisplayed())); takeScreenshot("logging_in"); onView(VIEW_MATCHER_LOGIN_BUTTON).perform(click()); return this; } public LoginRobot assertHomeScreenShown() { onView(VIEW_MATCHER_HOME_SCREEN).check(matches(isDisplayed())); takeScreenshot("home_screen_shown"); return this; } -
Example Robot static final Matcher<View> VIEW_MATCHER_USERNAME_EDIT_TEXT = withId(R.id.username); static final
Matcher<View> VIEW_MATCHER_LOGIN_BUTTON = withText("LOGIN"); static final Matcher<View> VIEW_MATCHER_HOME_SCREEN = withId(R.id.home_view_pager); public LoginRobot assertLoginDisabled() { onView(VIEW_MATCHER_LOGIN_BUTTON).check(matches(not(isEnabled()))); takeScreenshot("login_disabled"); return this; } public LoginRobot username(String username) { onView(VIEW_MATCHER_USERNAME_EDIT_TEXT).perform(clearText(), typeText(username), closeSoftKeyboard()); takeScreenshot("username_entered"); return this; } public LoginRobot login() { onView(VIEW_MATCHER_LOGIN_BUTTON).check(matches(isDisplayed())); takeScreenshot("logging_in"); onView(VIEW_MATCHER_LOGIN_BUTTON).perform(click()); return this; } public LoginRobot assertHomeScreenShown() { onView(VIEW_MATCHER_HOME_SCREEN).check(matches(isDisplayed())); takeScreenshot("home_screen_shown"); return this; } -
Example Robot static final Matcher<View> VIEW_MATCHER_USERNAME_EDIT_TEXT = withId(R.id.username); static final
Matcher<View> VIEW_MATCHER_LOGIN_BUTTON = withText("LOGIN"); static final Matcher<View> VIEW_MATCHER_HOME_SCREEN = withId(R.id.home_view_pager); public LoginRobot assertLoginDisabled() { onView(VIEW_MATCHER_LOGIN_BUTTON).check(matches(not(isEnabled()))); takeScreenshot("login_disabled"); return this; } public LoginRobot username(String username) { onView(VIEW_MATCHER_USERNAME_EDIT_TEXT).perform(clearText(), typeText(username), closeSoftKeyboard()); takeScreenshot("username_entered"); return this; } public LoginRobot login() { onView(VIEW_MATCHER_LOGIN_BUTTON).check(matches(isDisplayed())); takeScreenshot("logging_in"); onView(VIEW_MATCHER_LOGIN_BUTTON).perform(click()); return this; } public LoginRobot assertHomeScreenShown() { onView(VIEW_MATCHER_HOME_SCREEN).check(matches(isDisplayed())); takeScreenshot("home_screen_shown"); return this; } -
When to Take Screenshots • Assertions ◦ Assertion(s) ◦ SCREENSHOT
• Actions (Alters screen state) ◦ Displayed Assertion ◦ SCREENSHOT ◦ Action public LoginRobot login() { onView(VIEW_MATCHER_LOGIN_BUTTON).check(matches(isDisplayed())); takeScreenshot("logging_in"); onView(VIEW_MATCHER_LOGIN_BUTTON).perform(click()); return this; } public LoginRobot assertHomeScreenShown() { onView(VIEW_MATCHER_HOME_SCREEN).check(matches(isDisplayed())); takeScreenshot("home_screen_shown"); return this; } -
When to Take Screenshots • Assertions ◦ Assertion(s) ◦ SCREENSHOT
• Actions (Alters screen state) ◦ Displayed Assertion ◦ SCREENSHOT ◦ Action public LoginRobot login() { onView(VIEW_MATCHER_LOGIN_BUTTON).check(matches(isDisplayed())); takeScreenshot("logging_in"); onView(VIEW_MATCHER_LOGIN_BUTTON).perform(click()); return this; } public LoginRobot assertHomeScreenShown() { onView(VIEW_MATCHER_HOME_SCREEN).check(matches(isDisplayed())); takeScreenshot("home_screen_shown"); return this; } -
NEVER Thread.sleep() • AsyncTask Threadpool ◦ Leverage for Networking and
RxJava • Idling Resources - Use CountingIdlingResource ◦ increment(); and decrement(); https://developer.android.com/reference/android/support/test/espresso/contrib/CountingIdlingResource.html -
Define Your “LOW BAR” Device • Android Emulator Virtual Device
• 384x640 • mdpi - 160 dots per inch • Able to run in continuous integration -
Create a Custom Test Runner • Control test runner behavior
without recompiling • Turn on/off all screenshots with a command-line parameter ◦ --e screenshots=true ◦ --e screenshots=false -
Create a Custom Test Runner public class MyAndroidJUnitRunner extends AndroidJUnitRunner
{ @Override public void onCreate(Bundle arguments) { // process you parameters here. super.onCreate(arguments); } } defaultConfig { testInstrumentationRunner "com.handstandsam.MyAndroidJUnitRunner" } -
Create a Custom Test Runner public class MyAndroidJUnitRunner extends AndroidJUnitRunner
{ @Override public void onCreate(Bundle arguments) { // process you parameters here. super.onCreate(arguments); } } defaultConfig { testInstrumentationRunner "com.handstandsam.MyAndroidJUnitRunner" } -
Test Butler by LinkedIn “Reliable Android testing, at your service.”
• Stabilizes the Android emulator ◦ Disables animations ◦ Disables crash & ANR dialogs ◦ Locks the keyguard, WiFi radio, and CPU to ensure they don't go to sleep unexpectedly while tests are running. • Handles changing global emulator settings and holds relevant permissions so your app doesn't have to. ◦ Enable/disable WiFi ◦ Change device orientation ◦ Set location services mode ◦ Set application locale https://github.com/linkedin/test-butler -
Screenshot-tests-for-android by Facebook public class MyTests { @Test public void
doScreenshot() { View view = mLayoutInflater.inflate(R.layout.my_layout, null, false); ViewHelpers.setupView(view) .setExactWidthDp(300) .layout(); Screenshot.snap(view) .record(); } }
