1. Room: the blessed object mapper Hugo Visser @botteaap hugo@littlerobots.nl
2. Android persistence SharedPreferences: small amounts of key-value pairs SQLite: Large(r) amounts of structured data (Objects)
3. Persistence frameworks Backed by SQLite: SQL Delight, GreenDAO, DBFlow, Cupboard :), ... NoSQL: Realm, Objectbox, ...
4. Knowing SQL • SQL Delight: everything is SQL → little or no abstractions, source of truth • Room → Queries and migrations are SQL • Cupboard → SQL as fallback
5. Key points Part of Architecture Components → opinionated app architecture Does not support entity relations by design (e.g. no lazy loading) Database operations use SQL, no abstractions. Current version: 1.0.0 Created by Google
6. Getting started (Java) android { defaultConfig { javaCompileOptions { annotationProcessorOptions { arguments = ["room.schemaLocation": "$projectDir/schemas".toString()] } } } } dependencies { implementation "android.arch.persistence.room:runtime:1.0.0" annotationProcessor "android.arch.persistence.room:compiler:1.0.0" // 26.1.+ implements LifecyleOwner for LiveData and friends implementation 'com.android.support:appcompat-v7:26.1.0' // For LiveData & Lifecycle support implementation "android.arch.lifecycle:extensions:1.0.0" annotationProcessor "android.arch.lifecycle:compiler:1.0.0" }
7. Getting started (Kotlin) apply plugin: 'kotlin-kapt' kapt { arguments { arg("room.schemaLocation", "${projectDir}/schemas") } } dependencies { implementation "android.arch.persistence.room:runtime:1.0.0" kapt "android.arch.persistence.room:compiler:1.0.0" // 26.1.+ implements LifecyleOwner for LiveData and friends implementation 'com.android.support:appcompat-v7:26.1.0' // For LiveData & Lifecycle support implementation "android.arch.lifecycle:extensions:1.0.0" kapt "android.arch.lifecycle:compiler:1.0.0" }
8. Room annotation processor Code generation Compile time (query) validation Least amount of runtime overhead
9. Room main ingredients Entities → your objects DAO’s → how you persist and retrieve entities RoomDatabase → where everything is persisted
10. Entities @Entity public class User { @PrimaryKey(autoGenerate = true) public Long id; public String firstName; public String lastName; }
11. Entities @Entity public class User { @PrimaryKey(autoGenerate = true) public String id; public String firstName; public String lastName; } error: If a primary key is annotated with autoGenerate, its type must be int, Integer, long or Long.
12. Entities @Entity public class User { @PrimaryKey public String id; public String firstName; public String lastName; } error: You must annotate primary keys with @NonNull. SQLite considers this a bug and Room does not allow it.
13. Entities @Entity public class User { @PrimaryKey @NonNull private final String id; public String firstName; public String lastName; public User(@NonNull String id) { this.id = id; } @Ignore public User() { this.id = UUID.randomUUID().toString(); } @NonNull public String getId() { return id; } }
14. Entities @Entity public class User { @PrimaryKey @NonNull private final String id; @NonNull private final String firstName; private final String lastName; public User(@NonNull String id, @NonNull String firstName, String lastName) { this.id = id; this.firstName = firstName; this.lastName = lastName; } @Ignore public User(String firstName, String lastName) { this(UUID.randomUUID().toString(), firstName, lastName); } // getters --> } @NonNull public String getId() { return id; } @NonNull public String getFirstName() { return firstName; } public String getLastName() { return lastName; }
15. Entities @Entity data class User(@PrimaryKey val id: String = UUID.randomUUID().toString(), val firstName: String, val lastName: String?) val user = User(firstName = "Hugo", lastName = "Visser")
16. Entities @Entity(tableName = "k_user", primaryKeys = arrayOf("firstName", "lastName")) data class User(val id: String = UUID.randomUUID().toString(), val firstName: String, val lastName: String)
17. Entities @Entity(indices = arrayOf(Index("firstName", "lastName", unique = true))) data class User(@PrimaryKey val id: String = UUID.randomUUID().toString(), @ColumnInfo(index = true) val firstName: String, @ColumnInfo(name = "last_name", typeAffinity = ColumnInfo.TEXT, collate = ColumnInfo.NOCASE) val lastName: String?)
18. Entities Annotated Java or Kotlin classes Must specify a non-null primary key Database representation is controlled by annotations
19. Entities vs POJOs Distinction is made in the Room documentation @Entity → Object that has a table in the database POJO → any object that a result can be mapped to
20. Data access objects (DAOs) Define methods of working with entities interface or abstract class marked as @Dao One or many DAOs per database
21. DAO @Query @Dao interface UserDao { @Query("select * from User limit 1") fun firstUser(): User @Query("select * from User") fun allUsers(): List<User> @Query("select firstName from User") fun firstNames(): List<String> @Query("select * from User where firstName = :fn") fun findUsersByFirstName(fn: String): List<User> @Query("delete from User where lastName = :ln") fun deleteUsersWithLastName(ln: String): Int @Query("select firstName as first, lastName as last from User where lastName = :ln") fun findPersonByLastName(ln: String): List<Person> }
22. Map result on any POJO data class Person(val first: String, val last:String) Room matches column names Must be able to convert column to type
23. @Insert @Insert(onConflict = OnConflictStrategy.REPLACE) fun addUser(user: User) @Insert fun addUsers(users: List<User>): List<Long> @Insert fun addUserWithBooks(user: User, books: List<Book>)
24. @Delete @Delete fun deleteUser(user: User) @Delete fun deleteUsers(users: List<User>)
25. @Update @Update fun updateUser(user: User) @Update fun updateUsers(users: List<User>)
26. User with books @Entity data class User @Ignore constructor(@PrimaryKey val id: String, val firstName: String, val lastName: String?, @field:Ignore val books: List<Book>) { constructor(id: String = UUID.randomUUID().toString(), firstName: String, lastName: String?) : this(id, firstName, lastName, listOf()) } Needs @field:Ignore on books Primary constructor is @Ignored for Room
27. Abstract DAO class @Dao abstract class UserBookDao { @Insert protected abstract fun insertSingleUser(user: User) @Insert protected abstract fun insertBooks(books: List<Book>) @Query("select * from User where id = :id") protected abstract fun findUserById(id: String) : User? @Query("select * from Book where userId = :userId") protected abstract fun findUserBooks(userId: String) : List<Book> @Transaction open fun insertUser(user: User) { insertBooks(user.books) insertSingleUser(user) } fun findUser(id: String) : User { val user = findUserById(id) return user?.copy(books = findUserBooks(id)) ?: throw IllegalArgumentException("No user with id $id") } }
28. The database @Database(entities = arrayOf(User::class, Book::class), version = 1) abstract class MyDatabase : RoomDatabase() { abstract fun getUserDao(): UserDao companion object { private var instance: MyDatabase? = null fun getInstance(context: Context): MyDatabase { return instance ?: Room.databaseBuilder(context, MyDatabase::class.java, "my.db"). build().also { instance = it } } } } Annotated with @Database abstract class that extends RoomDatabase Room.databaseBuilder() → create singleton (use DI, or other means)
29. Let’s do this! val dao = MyDatabase.getInstance(context).getUserDao() val users = dao.allUsers() java.lang.IllegalStateException: Cannot access database on the main thread since it may potentially lock the UI for a long period of time.
30. It was never okay to do database ops on the main thread! (but we all did it)
31. @Insert, @Delete and @Update Nothing provided by Room to run off the main thread Run in an executor, AsyncTask, RxJava, Kotlin co-routines For testing only: allowMainThreadQueries() on the database builder
32. Abstract Dao strikes again abstract class BaseDao<in T> { @Insert protected abstract fun insertSync(vararg obj:T): LongArray suspend fun insert(vararg obj: T): LongArray { return insertSync(*obj) } } fun updateMyData() { val dao = MyDatabase.getInstance(this).getMyDao() async { dao.insert(User(firstName = "John", lastName = "Doe")) } }
33. Observable queries Using LiveData → android.arch.lifecycle:extensions RxJava 2 → android.arch.persistence.room:rxjava2 Delivers result async with updates @Query("select * from User") fun allUsers(): LiveData<List<User>> @Query("select * from User") fun allUsersRx(): Flowable<List<User>>
34. Observable queries override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) val dao = MyDatabase.getInstance(this).getUserDao() dao.allUsers().observe(this, Observer { it?.let { showUsers(it) } }) } private fun showUsers(users: List<User>) { }
35. TypeConverter Convert a field (object) to column and vice versa Can be scoped from field, entity, ..., Database No default converters for things like Date or enums :(
36. TypeConverter object MyTypeConverters { @TypeConverter @JvmStatic fun dateToLong(date: Date?) : Long? { return date?.time } @TypeConverter @JvmStatic fun longToDate(value: Long?) : Date? { return if (value == null) { null } else { Date(value) } } }
37. TypeConverter @Entity data class User(@PrimaryKey val id: String, val firstName: String, val lastName: String, @field:TypeConverters(MyTypeConverters::class) val birthDate: Date) @Entity @TypeConverters(MyTypeConverters::class) data class User(@PrimaryKey val id: String, val firstName: String, val lastName: String, val birthDate: Date) @TypeConverters(MyTypeConverters::class) @Database(...) abstract class MyDatabase : RoomDatabase() { }
38. TypeConverter @Query("select * from User where birthDate > :date") fun bornAfterDate(date: Date): List<User>
39. Complex objects Flatten objects onto a table using @Embedded data class Address(val street: String, val houseNumber: String, val city: String) @Entity class User(@PrimaryKey(autoGenerate = true) val id: Long, val name: String, val address: Address)
40. @Embedded User table will now have a street, houseNumber and city column too data class Address(val street: String, val houseNumber: String, val city: String) @Entity class User(@PrimaryKey(autoGenerate = true) val id: Long, val name: String, @Embedded val address: Address)
41. Migrations When adding, changing, removing entities: schema updates Database version number Migrate from version x to version y Missing migration will crash your app, but save user data
42. Creating & using migrations class UserBirthDayMigration : Migration(1, 2) { override fun migrate(database: SupportSQLiteDatabase) { // execute the statements required database.execSQL("ALTER TABLE User ADD COLUMN `birthDate` INTEGER") } } Room.databaseBuilder(context, MyDatabase::class.java, "mydatabase.db"). addMigrations(UserBirthDayMigration(), MyOtherMigration()). build()
43. Migrations Tip: use exported schema definitions 1.json, 2.json etc Testing migrations https://goo.gl/3F1kvQ fallbackToDestructiveMigration() discards data
44. Large result sets w/ Paging Cursors (+ CursorAdapter) have their problems https://goo.gl/CfVs7C Room integrates with Paging architecture component https://developer.android.com/topic/libraries/architecture/paging.html
45. Data sources for PagedLists // this might be a huge list @Query("select * from User") fun allUsers():List<User> // Generates a TiledDataSource (not observable) @Query("select * from User") fun allUsers(): TiledDataSource<User> // Generates a LivePagedListProvider (observable) that uses LIMIT and OFFSET @Query("select * from User") fun allUsers(): LivePagedListProvider<Integer, User>
47. More stuff Foreign key support (cascading deletes, integrity checks) SupportSQLiteDatabase allows for alternative SQLite implementations @Relation annotation to eager fetch relations in POJOs only Testing support
48. Wrapping up Full featured persistence library Kotlin support Integration with other architecture components + RxJava 2
49. Learn more https://d.android.com/topic/libraries/architecture/room.html https://d.android.com/reference/android/arch/persistence/room/package-summary. html https://medium.com/@florina.muntenescu https://goo.gl/NTKSb6
50. Thanks @botteaap hugo@littlerobots.nl speakerdeck.com/hugovisser
