Modern Java Component Design with Spring Framework 4.3

Spring's programming and configuration model has a strong design philosophy with respect to application components and configuration artifacts. Spring's annotation-based component story is fine-tuned for source code readability as well as consistency across an entire application's codebase. This session presents selected Spring Framework 4 component model highlights, with a focus on the current Spring Framework 4.3 and a selection of Java 8 enabled features, illustrated with many code examples and noteworthy design considerations.

Juergen Hoeller

October 15, 2016
Tweet

More Decks by Juergen Hoeller

Other Decks in Programming

Transcript

  1. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 1 Modern Java Component Design with Spring Framework 4.3 Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Juergen Hoeller Spring Framework Lead Pivotal
  2. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 2 The State of the Art: Component Classes @Service @Lazy public class MyBookAdminService implements BookAdminService { // @Autowired public MyBookAdminService(AccountRepository repo) { ... } @Transactional public BookUpdate updateBook(Addendum addendum) { ... } }
  3. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 3 Composable Annotations @Service @Scope("session") @Primary @Transactional(rollbackFor=Exception.class) @Retention(RetentionPolicy.RUNTIME) public @interface MyService {} @MyService public class MyBookAdminService { ... }
  4. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 4 Composable Annotations with Overridable Attributes @Scope(scopeName="session") @Retention(RetentionPolicy.RUNTIME) public @interface MySessionScoped { @AliasFor(annotation=Scope.class, attribute="proxyMode") ScopedProxyMode mode() default ScopedProxyMode.NO; } @Transactional(rollbackFor=Exception.class) @Retention(RetentionPolicy.RUNTIME) public @interface MyTransactional { @AliasFor(annotation=Transactional.class) boolean readOnly(); }
  5. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 5 The State of the Art: Configuration Classes @Configuration @Profile("standalone") @EnableTransactionManagement public class MyBookAdminConfig { @Bean public BookAdminService myBookAdminService() { MyBookAdminService service = new MyBookAdminService(); service.setDataSource(bookAdminDataSource()); return service; } @Bean public DataSource bookAdminDataSource() { ... } }
  6. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 6 Configuration Classes with Autowired Constructors @Configuration public class MyBookAdminConfig { private final DataSource bookAdminDataSource; // @Autowired public MyBookAdminConfig(DataSource bookAdminDataSource) { this.bookAdminDataSource = bookAdminDataSource; } @Bean public BookAdminService myBookAdminService() { MyBookAdminService service = new MyBookAdminService(); service.setDataSource(this.bookAdminDataSource); return service; } }
  7. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 7 Configuration Classes with Base Classes @Configuration public class MyApplicationConfig extends MyBookAdminConfig { ... } public class MyBookAdminConfig { @Bean public BookAdminService myBookAdminService() { MyBookAdminService service = new MyBookAdminService(); service.setDataSource(bookAdminDataSource()); return service; } }
  8. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 8 Configuration Classes with Java 8 Default Methods @Configuration public class MyApplicationConfig implements MyBookAdminConfig { ... } public interface MyBookAdminConfig { @Bean default BookAdminService myBookAdminService() { MyBookAdminService service = new MyBookAdminService(); service.setDataSource(bookAdminDataSource()); return service; } }
  9. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 9 Generics-based Injection Matching @Bean public MyRepository<Account> myAccountRepository() { ... } @Bean public MyRepository<Product> myProductRepository() { ... } @Service public class MyBookAdminService implements BookAdminService { @Autowired public MyBookAdminService(MyRepository<Account> repo) { // specific match, even with other MyRepository beans around } }
  10. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 10 Ordered Collection Injection @Bean @Order(2) public MyRepository<Account> myAccountRepositoryX() { ... } @Bean @Order(1) public MyRepository<Account> myAccountRepositoryY() { ... } @Service public class MyBookAdminService implements BookAdminService { @Autowired public MyBookAdminService(List<MyRepository<Account>> repos) { // 'repos' List with two entries: repository Y first, then X } }
  11. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 11 Injection of Collection Beans @Bean public List<Account> myAccountList() { ... } @Service public class MyBookAdminService implements BookAdminService { @Autowired public MyBookAdminService(List<Account> repos) { // if no raw Account beans found, looking for a // bean which is a List of Account itself } }
  12. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 12 Lazy Injection Points @Bean @Lazy public MyRepository<Account> myAccountRepository() { return new MyAccountRepositoryImpl(); } @Service public class MyBookAdminService implements BookAdminService { @Autowired public MyBookAdminService(@Lazy MyRepository<Account> repo) { // 'repo' will be a lazy-initializing proxy } }
  13. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 13 Component Declarations with JSR-250 & JSR-330 import javax.annotation.*; import javax.inject.*; @ManagedBean public class MyBookAdminService implements BookAdminService { @Inject public MyBookAdminService(Provider<MyRepository<Account>> repo) { // 'repo' will be a lazy handle, allowing for .get() access } @PreDestroy public void shutdown() { ... } }
  14. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 14 Optional Injection Points on Java 8 import java.util.*; import javax.annotation.*; import javax.inject.*; @ManagedBean public class MyBookAdminService implements BookAdminService { @Inject public MyBookAdminService(Optional<MyRepository<Account>> repo) { if (repo.isPresent()) { ... } } @PreDestroy public void shutdown() { ... } }
  15. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 15 Annotated MVC Controllers @Controller @CrossOrigin public class MyRestController { @RequestMapping(path="/books/{id}", method=GET) public Book findBook(@PathVariable long id) { return this.bookAdminService.findBook(id); } @RequestMapping(path="/books/new", method=POST) public void newBook(@Valid Book book) { this.bookAdminService.storeBook(book); } }
  16. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 16 Precomposed Annotations for MVC Controllers @RestController @CrossOrigin public class MyRestController { @GetMapping("/books/{id}") public Book findBook(@PathVariable long id) { return this.bookAdminService.findBook(id); } @PostMapping("/books/new") public void newBook(@Valid Book book) { this.bookAdminService.storeBook(book); } }
  17. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 17 STOMP on WebSocket @Controller public class MyStompController { @SubscribeMapping("/positions") public List<PortfolioPosition> getPortfolios(Principal user) { ... } @MessageMapping("/trade") public void executeTrade(Trade trade, Principal user) { ... } }
  18. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 18 Annotated JMS Endpoints @JmsListener(destination="order") public OrderStatus processOrder(Order order) { ... } @JmsListener(id="orderListener", containerFactory="myJmsFactory", destination="order", selector="type='sell'", concurrency="2-10") @SendTo("orderStatus") public OrderStatus processOrder(Order order, @Header String type) { ... }
  19. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 19 Annotated Event Listeners @EventListener public void processEvent(MyApplicationEvent event) { ... } @EventListener public void processEvent(String payload) { ... } @EventListener(condition="#payload.startsWith('OK')") public void processEvent(String payload) { ... }
  20. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software,

    Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 20 Learn More. Stay Connected. ▪ Current: Spring Framework 4.3.3 (September 2016) ▪ Coming: Spring Framework 4.3.4 (November 2016) ▪ Check out Spring Boot! http://projects.spring.io/spring-boot/ Twitter: twitter.com/springcentral YouTube: spring.io/video LinkedIn: spring.io/linkedin Google Plus: spring.io/gplus
