Amazon DynamoDB Essentials

Agenda
- Hash Table vs. DynamoDB
- Partition Key + Sort Key
- Local Secondary Index
- Global Secondary Index
- Scaling DynamoDB
- DynamoDB Key Design Guide: Composite Keys

Transcript

1. Amazon DynamoDB Essentials Sungmin Kim AWS Solutions Architect (2023-05-10)
2. Agenda • Hash Table vs. DynamoDB • Partition Key + Sort Key • Local Secondary Index (LSI) • Global Secondary Index (GSI) • Scaling DynamoDB • DynamoDB Key Design Guide - Composite Key
3. Amazon DynamoDB Document or Key-Value Scales to Any Workload Fully Managed NoSQL Access Control Event Driven Programming Fast and Consistent
4. Why NoSQL? Optimized for storage Optimized for compute Normalized/relational Denormalized/hierarchical Ad hoc queries Instantiated views Scale vertically Scale horizontally Good for OLAP Built for OLTP at scale SQL NoSQL
5. Table Table Items Attributes Partition Key Sort Key Mandatory Key-value access pattern Determines data distribution Optional Model 1:N relationships Enables rich query capabilities All items for key ==, <, >, >=, <= “begins with” “between” “contains” “in” sorted results counts top/bottom N values
6. Hash vs. DynamoDB Key Hash Function ex) h(k) = k % TableSize • In Memory • Collision • Range Query • (Full) Scan • Resizing (Rehash) V1 V2 Vn Hash Table 11~20 • Disk • Partition + Sort Key • Secondary Index- Local (LSI), Global (GSI) • Parallel Scan • Split partitions & Add more storage Split & Add more storage Key Partition Key + Sort Key (Required) (Optional) Key Space PK1 PK11 PK7 PKn 1~5 6~10 . . . HF(k) HF(pk) . . .
7. 00 55 A9 54 FF AA 00 FF Partition Keys • Partition Key uniquely identifies an item • Partition Key is used for building an unordered hash index • Allows table to be partitioned for scale Id = 1 Name = Jim Hash (1) = 7B Id = 2 Name = Andy Dept = Eng Hash (2) = 48 Id = 3 Name = Kim Dept = Ops Hash (3) = CD Key Space
8. Partition 3 Partition:Sort Key • Partition:Sort Key uses two attributes together to uniquely identify an Item • Within unordered hash index, data is arranged by the sort key • No limit on the number of items (∞) per partition key § Except if you have local secondary indexes 00:0 FF:∞ Hash (2) = 48 Customer# = 2 Order# = 10 Item = Pen Customer# = 2 Order# = 11 Item = Shoes Customer# = 1 Order# = 10 Item = Toy Customer# = 1 Order# = 11 Item = Boots Hash (1) = 7B Customer# = 3 Order# = 10 Item = Book Customer# = 3 Order# = 11 Item = Paper Hash (3) = CD 55 A9:∞ 54:∞ AA Partition 1 Partition 2
9. Partitions are three-way replicated Id = 2 Name = Andy Dept = Engg Id = 3 Name = Kim Dept = Ops Id = 1 Name = Jim Id = 2 Name = Andy Dept = Engg Id = 3 Name = Kim Dept = Ops Id = 1 Name = Jim Id = 2 Name = Andy Dept = Engg Id = 3 Name = Kim Dept = Ops Id = 1 Name = Jim Replica 1 Replica 2 Replica 3
10. Local Secondary Index (LSI) • Alternate sort key attribute • Index is local to a partition key A1 (partition) A3 (sort) A2 (item key) A1 (partition) A2 (sort) A3 A4 A5 LSIs A1 (partition) A4 (sort) A2 (item key) A3 (projected) Table KEYS_ONLY INCLUDE A3 A1 (partition) A5 (sort) A2 (item key) A3 (projected) A4 (projected) ALL 10 GB max per partition key, i.e. LSIs limit the # of range keys!
11. Global Secondary Index (GSI) • Alternate partition and/or sort key • Index is across all partition keys • Use composite sort keys for compound indexes A1 (partition) A2 A3 A4 A5 A5 (partition) A4 (sort) A1 (item key) A3 (projected) INCLUDE A3 A4 (partition) A5 (sort) A1 (item key) A2 (projected) A3 (projected) ALL A2 (partition) A1 (itemkey) KEYS_ONLY GSIs Table RCUs/WCUs provisioned separately for GSIs Online indexing
12. How Do GSI Updates Work? Table Primary table Primary table Primary table Primary table Global Secondary Index Client 1. Update request 2. Asynchronous update (in progress) 2. Update response If GSIs don’t have enough write capacity, table writes will be throttled!
13. Scaling NoSQL “We are stuck with technology when what we really want is just stuff that works.”
14. What bad NoSQL looks like … Partition Time Heat
15. Getting the most out of Amazon DynamoDB throughput • “To get the most out of DynamoDB throughput, create tables where the partition key element has a large number of distinct values, and values are requested fairly uniformly, as randomly as possible.” • —DynamoDB Developer Guide • Space: access is evenly spread over the key-space • Time: requests arrive evenly spaced in time
16. Much better picture …
17. Auto Scaling • Throughput automatically adapts to your actual traffic With Auto Scaling Without Auto Scaling
18. Composite Keys “Hierarchies are celestial. In hell all are equal.”
19. Secondary index Opponent Date GameId Status Host Alice 2014-10-02 d9bl3 DONE David Carol 2014-10-08 o2pnb IN_PROGRESS Bob Bob 2014-09-30 72f49 PENDING Alice Bob 2014-10-03 b932s PENDING Carol Bob 2014-10-03 ef9ca IN_PROGRESS David Bob Partition key Sort key Multi-value Sorts and Filters
20. Secondary Index Approach 1: Query Filter Bob Opponent Date GameId Status Host Alice 2014-10-02 d9bl3 DONE David Carol 2014-10-08 o2pnb IN_PROGRESS Bob Bob 2014-09-30 72f49 PENDING Alice Bob 2014-10-03 b932s PENDING Carol Bob 2014-10-03 ef9ca IN_PROGRESS David SELECT * FROM Game WHERE Opponent='Bob' ORDER BY Date DESC FILTER ON Status='PENDING' (filtered out)
21. Approach 2: Composite Key StatusDate DONE_2014-10-02 IN_PROGRESS_2014-10-08 IN_PROGRESS_2014-10-03 PENDING_2014-09-30 PENDING_2014-10-03 Status DONE IN_PROGRESS IN_PROGRESS PENDING PENDING Date 2014-10-02 2014-10-08 2014-10-03 2014-10-03 2014-09-30 + =
22. Secondary Index Approach 2: Composite Key Opponent StatusDate GameId Host Alice DONE_2014-10-02 d9bl3 David Carol IN_PROGRESS_2014-10-08 o2pnb Bob Bob IN_PROGRESS_2014-10-03 ef9ca David Bob PENDING_2014-09-30 72f49 Alice Bob PENDING_2014-10-03 b932s Carol Partition key Sort key
23. Opponent StatusDate GameId Host Alice DONE_2014-10-02 d9bl3 David Carol IN_PROGRESS_2014-10-08 o2pnb Bob Bob IN_PROGRESS_2014-10-03 ef9ca David Bob PENDING_2014-09-30 72f49 Alice Bob PENDING_2014-10-03 b932s Carol Secondary index Approach 2: Composite Key Bob SELECT * FROM Game WHERE Opponent='Bob' AND StatusDate BEGINS_WITH 'PENDING'
24. References • DynamoDB Deep Dive: Advanced Design Patterns • https://aws.amazon.com/ko/dynamodb/resources/reinvent-2019-advanced- design-patterns/ • Implementing advanced design patterns for Amazon DynamoDB • https://www.slideshare.net/AmazonWebServices/implementing-advanced- design-patterns-for-amazon-dynamodb-adb401-chicago-aws-summit • Amazon DynamoDB Labs (workshop) • https://catalog.us-east-1.prod.workshops.aws/workshops/3319b690-3a41- 4921-9af8-f31c7bef4cdb/en-US
