1. Building Clients for OpenID Connect/OAuth 2-based Systems Dominick Baier @leastprivilege https://github.com/leastprivilege/AspNetCoreSecuritySamples
2. 2 @leastprivilege / @brocklallen Me • Independent Consultant – Specializing on Application Security Architectures – Working with Software Development Teams (ISVs and in-house) • Co-Creator of IdentityServer & IdentityModel OSS Project – Certified OpenID Connect & OAuth 2.0 Implementation for .NET – https://identityserver.io • Co-Creator of PolicyServer – Modern Authorization Solution – https://policyserver.io email dominick.baier@leastprivilege.com blog https://leastprivilege.com twitter @leastprivilege slides https://speakerdeck.com/leastprivilege
3. 3 @leastprivilege / @brocklallen Objectives • Discuss common challenges for building clients • Look at recommended approaches for several client types – server to server – web applications – native/mobile applications – SPAs • Give you references to further reading material
4. 4 @leastprivilege / @brocklallen It's complicated! https://openid.net/wg/ https://tools.ietf.org/wg/oauth/
5. 5 @leastprivilege / @brocklallen Timeline 2005 SAML 2.0 2007 2009 2012 2014 2015 2017 2019 Future OpenID Connect Session Management OpenID Connect Front-Channel Notifications OpenID Connect Back-Channel Notifications Authentication Method Reference Values OAuth 2.0 for Native Apps OAuth 2.0 Browser-based Apps OAuth 2.0 Security Topics BCP OAuth 2.0 Incremental AuthZ OAuth 2.0 Token Exchange OAuth 2.0 Mutual TLS OAuth 2.0 Device Flow OAuth 2.0 Resource Indicators OAuth 1.0 WS-Federation 1.2 OAuth 1.0a OAuth 2.0 Bearer Tokens OpenID Connect Core OpenID Connect Discovery OpenID Connect Dynamic Registration OAuth 2.0 Assertion Framework OAuth 2.0 Dynamic Client Registration OAuth 2.0 Token Introspection JSON Web Token (JWT) OAuth 2.0 JSON Web Token (JWT) Profile OAuth 2.0 SAML 2.0 Profile OAuth 2.0 PKCE
6. 6 @leastprivilege / @brocklallen The Big Picture Browser Native App Server App "Thing" Web App Web API Web API Web API Security Token Service 1 2 1 public client 2 confidential client 1 2 2
7. 7 @leastprivilege / @brocklallen Challenges for Clients • Request token • Use token • Manage token
8. 8 @leastprivilege / @brocklallen Server to Server Communication APIs Authorization Server Scopes: api1, api2 api3… client_id=client1, client_secret=***, scope=api1 api2 access token access token
9. 9 @leastprivilege / @brocklallen Access Tokens { "typ": "at+jwt", "alg": "RS256" "kid": "1" } { "iss": "https://my_issuer", "exp": "1340819380", "aud": "invoice.api", "client_id": "client1", } Header Payload
10. 10 @leastprivilege / @brocklallen Use Token • Token (typically) transmitted via Authorization header – form body or query string as alternative Authorization: Bearer <token> GET /service/resource https://tools.ietf.org/html/rfc6750
11. 11 @leastprivilege / @brocklallen Token Management • Store tokens server-side – in-memory, distributed cache, cookie, session storage, database… • Pro-active – keep track of expiration and renew token ahead of time • Re-active – wait for 401, renew, re-send
12. 12 @leastprivilege / @brocklallen User-Centric Clients • Typical Pattern – authenticate user – start/join session – make API calls on behalf of the user • Typical client challenges – how to securely retrieve access token – access token storage & lifetime management – session management
13. 13 @leastprivilege / @brocklallen Authorization Code Flow • Front-Channel – UI redirect to authorize endpoint – starts/joins a session – consent (if enabled) – returns authorization code • Back-Channel – exchange of authorization with access token – typically involves client authentication
14. 14 @leastprivilege / @brocklallen Authorization Code Flow Request GET /authorize ?client_id=app1 &redirect_uri=https://app.com/cb &response_type=code &scope=openid email api1 api2
15. 15 @leastprivilege / @brocklallen Authorization Code Flow Response GET /cb?code=xyz
16. 16 @leastprivilege / @brocklallen Retrieving the Access Token • Exchange code for access token – using client id and secret code (client_id:client_secret) { id_token: "xxae…988", access_token: "xyz…123", expires_in: 3600, token_type: "Bearer" }
17. 17 @leastprivilege / @brocklallen Issues with Code Flow • Code substitution attack – client can be tricked into using its client secret with a leaked/stolen code • Different mitigation approaches – OpenID Connect: Hybrid Flow – OAuth2: Proof Key for Code Exchange (PKCE)
18. 18 @leastprivilege / @brocklallen Approach 1: Hybrid Flow Request GET /authorize ?client_id=app1 &redirect_uri=https://app.com/cb &response_type=code id_token &response_mode=form_post &nonce=j1y…a23 &scope=openid email api1 api2
19. 19 @leastprivilege / @brocklallen Approach 1: Hybrid Flow Response <form> <input type="hidden" name="id_token" value="xjsj…aas" /> <input type="hidden" name="code" value="i8j1…jj19" /> </form> POST /cb cryptographically linked via c_hash
20. 20 @leastprivilege / @brocklallen Issues with Hybrid Flow • Heavier client libraries – id_token validation – cryptographic linking of artifacts • Identity token via front channel – might leak identity information – at least sub
21. 21 @leastprivilege / @brocklallen Approach 2: PKCE Front-Channel GET /authorize ?client_id=app1 &redirect_uri=https://app.com/cb &response_type=code &scope=openid email api1 api2 &code_challenge=xyz code_verifier = random number code_challenge = hash(code_verifier) https://tools.ietf.org/html/rfc7636
22. 22 @leastprivilege / @brocklallen Approach 2: PKCE Back-Channel • Pass code verifier in addition to client ID and secret code, code verifier (client_id:client_secret) { id_token: "xxae…988", access_token: "xyz…123", expires_in: 3600, token_type: "Bearer" }
23. 23 @leastprivilege / @brocklallen Access Token Lifetime Management • Access tokens have finite lifetimes – requesting a new token requires browser round trip to authorization server – should be as short lived as possible • Refresh tokens allow renewal semantics – no user interaction required – typically combined with a revocation feature
24. 24 @leastprivilege / @brocklallen Requesting a Refresh Token GET /authorize ?client_id=app1 &redirect_uri=https://app.com/cb &response_type=code &scope=openid email api1 offline_access
25. 25 @leastprivilege / @brocklallen Retrieving the Access Token (w/ Refresh Token) code (client_id:client_secret) { id_token: "xxae…988", access_token: "xyz…123", refresh_token: "jdj9…192j", expires_in: 3600, token_type: "Bearer" }
26. 26 @leastprivilege / @brocklallen Refreshing an Access Token refresh_token (client_id:client_secret) { id_token: "xxae…988", access_token: "xyz…123", refresh_token: "jdj9…192j", expires_in: 3600, token_type: "Bearer" }
27. 27 @leastprivilege / @brocklallen Revocation
28. 28 @leastprivilege / @brocklallen Token Revocation • Endpoint to programmatically revoke tokens (RFC 7009) – reference tokens – refresh tokens /revoke?token=a19..18a
29. 29 @leastprivilege / @brocklallen ASP.NET Core OpenID Connect Client • Supports both Hybrid Flow and PKCE – PKCE recommended • Token storage using session mechanism – can revoke refresh tokens at logout time (if not needed anymore) • Automatic token management by plugging in IdentityModel.AspNetCore – https://github.com/IdentityModel/IdentityModel.AspNetCore
30. 30 @leastprivilege / @brocklallen Public Clients • So far we only looked at server-based clients – typically unique client IDs – can store a secret securely • Public clients cannot store a client secret securely – e.g. SPAs, mobile apps – 1:many mapping of client id to instance • Dynamic client registration can turn public into confidential client – additional bootstrapping infrastructure necessary
31. 31 @leastprivilege / @brocklallen Native/Mobile Applications • Applications that have access to native platform APIs – desktop or mobile • "OAuth 2.0 for native Applications" – https://tools.ietf.org/html/rfc8252
32. 32 @leastprivilege / @brocklallen Anti Pattern: Resource Owner Password Flow Username Password Login username/password token token trust Token service API 1 2 3
33. 33 @leastprivilege / @brocklallen Using a browser for driving the authentication workflow (aka AppAuth) authentication request render UI & workflow
34. 34 @leastprivilege / @brocklallen Request GET /authorize ?client_id=nativeapp &scope=openid profile api1 api2 offline_access &redirect_uri=com.mycompany.nativeapp://cb &response_type=code &code_challenge=x929..1921
35. 35 @leastprivilege / @brocklallen Receiving the response GET com.mycompany.nativeapp://cb?code=818…1299 callback
36. 36 @leastprivilege / @brocklallen Token Management • Tokens should be stored using secure data storage provided by OS – e.g. KeyChain on iOS, DPAPI on Windows… – some support additional security mechanisms (e.g. biometrics) • Refresh can be automated by client libraries – e.g. using HTTP message handler & HttpClient • Tokens can be revoked when not needed anymore – logout – uninstall
37. 37 @leastprivilege / @brocklallen Client Libraries • Native libraries – https://github.com/openid/AppAuth-iOS – https://github.com/openid/AppAuth-Android • C# .NET standard library (desktop .NET, UWP, mobile, iOS, Android) – https://github.com/IdentityModel/IdentityModel.OidcClient2 – https://github.com/IdentityModel/IdentityModel.OidcClient.Samples
38. 38 @leastprivilege / @brocklallen Browser-based Clients (aka SPAs) • The most problematic client type from a security point of view – but also most popular client type • Unique attacks due to "shared execution environment" nature of browser – Cross-Site Request Forgery (CSRF) – Cross-Site Scripting (XSS) • Ongoing work in IETF to produce useful guidance – https://tools.ietf.org/html/draft-parecki-oauth-browser-based-apps
39. 39 @leastprivilege / @brocklallen Two approaches to authenticate APIs for SPAs • Implicit credential that browser sends automatically – Cookies – Integrated Windows authentication (Kerberos) – X509 client certificates • Explicit credential that must be sent from application code – Tokens
40. 40 @leastprivilege / @brocklallen Server-side Application Threat: cross-site request forgery (CSRF) Browser Tab/Process Tab/Process login & set authentication cookie http://app.com http://app.com/delete/5 send authentication cookie
41. 41 @leastprivilege / @brocklallen CSRF mitigation with anti-forgery tokens • Add explicit “credential” on every request – Authenticates calling app Server-side Application render page & anti-forgery cookie <form> <input type="hidden" value="anti-forgery token" /> </form> <script>…</script> post-back: cookie + hidden field Page web api call: cookie + header
42. 42 @leastprivilege / @brocklallen CSRF mitigation with same-site cookies • Browser only sends cookie from page in same origin • Decent browser support (as of mid-2019) https://caniuse.com/#search=samesite HTTP/1.1 200 OK Set-Cookie: key=value; HttpOnly; SameSite=strict
43. 43 @leastprivilege / @brocklallen Restrictions using cookies for APIs • Same-site cookies is still new – Some people still on older browsers • API must have server-side code to issue cookie to browser – Easy for legacy/mixed, more work for modern/SPA • Application must be same origin as API – Will your app always be the same domain as the API(s)? • Browser-based app is only app that can call the API – Will you ever want other apps to use the API?
44. 44 @leastprivilege / @brocklallen Token based authentication • Tokens are a different form of credential – Commonly use JSON web token (JWT) – Sent via authorization header to authenticate HTTP request – Provides solution to CSRF that combines anti-forgery and authentication • Tokens help solve the architectural issues – More than just browser-based apps can use tokens – No cookie management needed in API – Can call APIs cross-domain
45. 45 @leastprivilege / @brocklallen "SPA" Architecture HTML, JS, CSS APIs access token
46. 46 @leastprivilege / @brocklallen History (2) • OAuth 2 designed for JavaScript-based applications – original Implicit Flow – now deprecated and replaced with Code Flow with PKCE
47. 47 @leastprivilege / @brocklallen Token Management for JS Apps • Regardless of the flow, tokens will be stored in the browser – e.g. session storage – prone to XSS-based attacks • potential exfiltration of tokens • even worse with refresh tokens – Content Security Policy (CSP) highly recommend – but not always easy • Not recommended to use refresh tokens in SPAs – rather use "token renew" technique – renewal bound to session
48. 48 @leastprivilege / @brocklallen Java Script Client Library • https://github.com/IdentityModel/oidc-client-js var settings = { authority: 'http://localhost:5152/', client_id: 'spa', redirect_uri: 'http://localhost:5152/callback.html', response_type: 'code', scope: 'openid profile api', }; var mgr = new Oidc.UserManager(settings); mgr.getUser().then(function (user) { if (user) { log("logged in", user); } else { mgr.signinRedirect(); } });
49. 49 @leastprivilege / @brocklallen "BFF" Architecture Front-End private Back-End httponly cookies + anti forgery protection APIs access token client https://leastprivilege.com/2019/01/18/an-alternative-way-to-secure-spas-with-asp-net-core-openid-connect-oauth-2-0-and-proxykit/
50. 50 @leastprivilege / @brocklallen Devices with constrained Input
51. 51 @leastprivilege / @brocklallen OAuth 2.0 Device Flow for Browserless and Input Constrained Devices
52. 52 @leastprivilege / @brocklallen Further Reading • OAuth 2.0 – https://tools.ietf.org/html/rfc6749 • OAuth 2.0 Threat Model – https://tools.ietf.org/html/rfc6819 • OpenID Connect – https://openid.net/specs/openid-connect-core-1_0.html • PKCE – https://tools.ietf.org/html/rfc7636 • OAuth 2.0 Security Best Practices – https://tools.ietf.org/html/draft-ietf-oauth-security-topics-11 • SameSite Cookies – https://tools.ietf.org/html/draft-west-first-party-cookies-07 • IdentityServer samples – https://github.com/IdentityServer/IdentityServer4/tree/master/samples/Clients • ASP.NET Core Security & SPA Samples – https://github.com/leastprivilege/AspNetCoreSecuritySamples • Native Client Samples – https://github.com/IdentityModel/IdentityModel.OidcClient.Samples
53. 53 @leastprivilege / @brocklallen Thanks! …and (because I always forget) - we have stickers!
