Kotlin Flows

They finally arrived - Kotlin Flows!
Are they really great or just good enough?
Does RxJava finally have a true competitor?
Will they be the saviour we all have been waiting for?

Transcript

1. Kotlin Flows In-depth analysis of Kotlin Flows
2. Rostyslav Lesovyi
3. Kotlin Flows ➙ About ➙ Using ➙ Internals ➙ Extending ➙ Benchmarks ➙ Conclusion
4. // KLUG - Kotlin Flows About Flows Who is this new kid on the block?
5. // KLUG - Kotlin Flows Flows - Introduction val list = listOf(1, 2, 3) list.forEach { print(it) } val sequence = sequenceOf(1, 2, 3) sequence.forEach { print(it) } val flow = flowOf(1, 2, 3) flow.collect { print(it) } val observable = Observable.fromArray( 1, 2, 3) observable.subscribe { print(it) } -> 1, 2, 3
6. // KLUG - Kotlin Flows Flows - Introduction listOf(1, 2, 3) .filter { it % 2 != 0 } .map { it * 2 } .forEach { print(it) } 1 2 3 1 3 2 6 2 6 listOf filter map forEach List created
7. // KLUG - Kotlin Flows Flows - Introduction sequenceOf(1, 2, 3) .filter { it % 2 != 0 } .map { it * 2 } .forEach { print(it) } 1 2 3 1 6 6 sequenceOf filter map forEach 2 2 3 .. ..
8. // KLUG - Kotlin Flows IO Thread Caller Thread flowOf(1, 2, 3) .filter { it % 2 != 0 } .flowOn(Dispatchers.IO) .collect { print(it) } Flows - Introduction 1 2 3 1 3 flowOf filter forEach 1 3 .. ..
9. // KLUG - Kotlin Flows Flows - Introduction flowOf(1, 2, 3) .filter { it % 2 != 0 } .flowOn(Dispatchers.IO) .collect { print(it) } Observable.fromArray( 1, 2, 3) .filter { it % 2 != 0 } .subscribeOn(Schedulers.io()) .observeOn(mainScheduler) .subscribe { print(it) }
10. // KLUG - Kotlin Flows Using Flows Wow, they are so similar to Rx. I know them already!
11. // KLUG - Kotlin Flows Using Flows - Type of the Operators • Builders • Terminal operators • Flow operators • Context • Delay • Error • Distinct • Transform • Limit • Merge • Emitters • Zip
12. // KLUG - Kotlin Flows Using Flows - Terminology flowOf(1, 2, 3) .filter { it % 2 != 0 } .map { it * 2 } .map { "value = $it" } .catch { print(it.message) } .collect() < Builder < Flow operators < Terminal operator
13. // KLUG - Kotlin Flows Using Flows - Terminology flowOf(1, 2, 3) .filter { it % 2 != 0 } .map { it * 2 } .map { "value = $it" } .catch { print(it.message) } .collect() Upstream Downstream
14. // KLUG - Kotlin Flows Using Flows - Builders
15. // KLUG - Kotlin Flows Using Flows - Builders val flow1 = flowOf(1, 2, 3) // Observable.fromArray val flow2 = listOf(1, 2, 3).asFlow() // toObservable() val empty = emptyFlow<Int>() // Observable.empty<Int>()
16. // KLUG - Kotlin Flows Using Flows - Builders val list = flowOf(1, 2, 3).toList() // Observable.toList() val set = flowOf(1, 2, 3).toSet() val linkedList = flowOf(1, 2, 3).toCollection(LinkedList())
17. // KLUG - Kotlin Flows Using Flows - Builders val flow = flow { // Observable.create emit(1) scope.launch { emit(2) <-- prohibited } } val flow = channelFlow { // Observable.create send(1) launch { send(2) <-- allowed } awaitClose { /* free resources if needed */ } }
18. // KLUG - Kotlin Flows Using Flows - Terminal operators
19. // KLUG - Kotlin Flows Using Flows - Terminal operators val flow = flowOf(1, 2, 3) scope.launch { flow.collect { print(it) } // Observable.subscribe { print(it) } } -> 1, 2, 3
20. // KLUG - Kotlin Flows Using Flows - Terminal operators val flow = flowOf(1, 2, 3) flow.launchIn(scope) scope.launch { flow.collect() }
21. // KLUG - Kotlin Flows Using Flows - Terminal operators val flow = flow { emit(1) delay(50) // suspend block, we can delay here emit(2) } flow.collectLatest { delay(100) // emulate work println(it) } -> 2
22. // KLUG - Kotlin Flows Using Flows - Terminal operators val flow = flowOf(1, 2, 3) flow.count() // Observable.count() -> 3
23. // KLUG - Kotlin Flows Using Flows - Terminal operators val flow = flowOf(1) flow.single() // Observable.singleOrError() flow.singleOrNull() // Observable.singleElement() flow.first() // Observable.firstElement() flow.firstOrNull() // Observable.firstOrError() -> 1
24. // KLUG - Kotlin Flows Using Flows - Terminal operators val flow = flowOf(1, 2, 3) flow.reduce { accumulator, value -> // Observable.reduce() accumulator + value } -> 6
25. // KLUG - Kotlin Flows Using Flows - Terminal operators val flow = flowOf(1, 2, 3) flow.fold(20) { accumulator, value -> // Observable.reduce() accumulator + value } -> 26
26. // KLUG - Kotlin Flows Using Flows - Flow operators
27. // KLUG - Kotlin Flows Using Flows - Flow operators val flow = flowOf(1, 2, 3) flow.map { it * 2 } // Observable.map { ... } -> 2, 4, 6
28. // KLUG - Kotlin Flows Using Flows - Flow operators val flow = flowOf(1, 2, 3) flow.filter { it % 2 != 0 } // Observable.filter { ... } -> 1, 3
29. // KLUG - Kotlin Flows Using Flows - Flow operators val flow = flowOf(1, 2, 3) flow.flatMapMerge { // Observable.flatMap { ... } flowOf(it * 2, it * 3) } -> [1, 2, 3] -> [[2, 3], [4, 6], [6, 9]] -> [2, 3, 4, 6, 6, 9]
30. // KLUG - Kotlin Flows Using Flows - Flow operators val flow = flowOf(1, 2, 3) flow.transform { // Observable.flatMap { ... } emit(it * 2) emit(it * 3) } -> [1, 2, 3] -> [[2, 3], [4, 6], [6, 9]] -> [2, 3, 4, 6, 6, 9]
31. // KLUG - Kotlin Flows Using Flows - Flow operators val flow = flowOf(1, 2, 3) // Observable.onErrorResumeNext { } flow.map { throw Exception("oops") } .catch { print(it.message) } .collect() -> oops
32. // KLUG - Kotlin Flows Using Flows - Flow operators val flow = flowOf(1, 2, 3) flow.onStart { coroutineContext[CoroutineName]?. name } .flowOn(CoroutineName( "name2")) .onStart { coroutineContext[CoroutineName]?. name } .flowOn(CoroutineName( "name1")) .collect() -> name1, name2
33. // KLUG - Kotlin Flows Using Flows - Cancellation
34. // KLUG - Kotlin Flows Using Flows - Cancellation #1 val flow = flowOf(1, 2, 3) val job = scope.launch { flow.collect { } } job.cancel() // Disposable.dispose()
35. // KLUG - Kotlin Flows Using Flows - Cancellation #2 val flow = flowOf(1, 2, 3) try { flow.collect { if (it == 2) throw Exception("cancel") print(it) } } catch (e: Exception) { print(e.message) } -> 1, cancel
36. // KLUG - Kotlin Flows Using Flows - Cancellation #3 val flow = flowOf(1, 2, 3) withTimeoutOrNull(400) { flow.collect { delay(150) print(it) } } -> 1, 2
37. // KLUG - Kotlin Flows Flow Internals The truth is more complicated... !
38. // KLUG - Kotlin Flows Flow Internals • Properties ◦ Context preservation ◦ Exception transparency • Tax Flow collectors • Operator fusing • Backpressure • Cold vs Hot
39. // KLUG - Kotlin Flows Flow Internals - Context preservation
40. // KLUG - Kotlin Flows Flow Internals - Context preservation 1. scope.launch { 2. flow { 3. emit(1) 4. 5. launch { 6. emit(2) 7. } 8. } 9. } < OK < prohibited < coroutine context #1 < coroutine context #2 Rule #1: emit must always be called on the coroutine context of its flow
41. // KLUG - Kotlin Flows Flow Internals - Context preservation 1. scope.launch { 2. channelFlow { 3. send(1) 4. 5. launch { 6. send(2) 7. } 8. } 9. } Rule #2: send/offer doesn’t care about coroutine context
42. // KLUG - Kotlin Flows Flow Internals - Context preservation 1. flow { 2. val channel = Channel<Int>(Channel. BUFFERED) 3. 4. launch { 5. channel.send(1) 6. channel.send( 2) 7. channel.send( 3) 8. } 9. 10. for (value in channel) { 11. emit(value) 12. } 13. }
43. // KLUG - Kotlin Flows Flow Internals - Exception transparency
44. // KLUG - Kotlin Flows Flow Internals - Exception transparency 1. @Throws(Exception::class) 2. fun doSomethingOrCrash(): Int 3. 4. flow { 5. try { 6. emit(doSomethingOrCrash()) 7. } catch (e: Exception) { 8. // handle or ignore 9. } 10. } < prohibited Rule #3: emit (downstream) exception must never be handled
45. // KLUG - Kotlin Flows Flow Internals - Exception transparency 1. val flow = flow { 2. for (value in 0..1000) { 3. try { 4. emit(value) 5. } catch (e: Exception) { 6. print(e.message) 7. } 8. } 9. } 10. flow.collect { 11. if (it == 2) throw Exception("cancel") 12. print(it) 13. } -> 0, 1, cancel, 3, 4, 5, ...
46. // KLUG - Kotlin Flows Flow Internals - Exception transparency 1. withTimeoutOrNull(25) { 2. val flow = flow { 3. for (value in 0..1000) { 4. try { 5. emit(value) 6. delay(50) 7. } catch (e: Exception) { 8. print(e.message) 9. } 10. } 11. } 12. flow.collect { print(it) } 13. } -> 0, Timed out waiting for 25 ms, 1, Timed out waiting for 25 ms, 2, ...
47. // KLUG - Kotlin Flows Flow Internals - Flow collectors
48. // KLUG - Kotlin Flows Flow Internals - Flow collectors 1. public interface Flow<out T> { 2. public suspend fun collect(collector: FlowCollector< T>) 3. } 1. public interface FlowCollector< in T> { 2. public suspend fun emit(value: T) 3. }
49. // KLUG - Kotlin Flows Flow Internals - Flow collectors 1. val flow = flow { 2. emit(1) 3. emit(2) 4. } 1. val flow = object : Flow<Int> { 2. override suspend fun collect(collector: FlowCollector<Int>) { 3. collector.emit( 1) 4. collector.emit( 2) 5. } 6. } Almost the same except flow {...} also enforces properties checks
50. // KLUG - Kotlin Flows Flow Internals - Operator fusing
51. // KLUG - Kotlin Flows Flow Internals - Operator fusing ### Operator fusion Adjacent applications of [channelFlow], [flowOn], [buffer], [produceIn], and [broadcastIn] are always fused so that only one properly configured channel is used for execution. 1. flowOf(1, 2, 3) 2. .flowOn(Dispatchers.IO) 3. .buffer(20) 4. .flowOn(Dispatchers.Main) 5. .count { } < channel-based < channel-based < channel-based all reusing single channel
52. // KLUG - Kotlin Flows Flow Internals - Backpressure
53. // KLUG - Kotlin Flows Flow Internals - Backpressure 1. val flow = flow { 2. for (value in 0..5) { 3. print("out $value") 4. emit(value) 5. } 6. } 7. flow.collect { 8. print("in $it") 9. delay(100) 10. } -> out 0, in 0, out 1, in 1, out 2, in 2, ...
54. // KLUG - Kotlin Flows Flow Internals - Backpressure 1. val flow = flow { 2. for (value in 0..5) { 3. print("out $value") 4. emit(value) 5. } 6. } 7. flow.buffer(1).collect { 8. delay(100) 9. print("in $it") 10. } -> out 0, out 1, out 2, in 0, out 3, in 1, out 4, in 2, out 5, ...
55. // KLUG - Kotlin Flows Flow Internals - Backpressure 1. val flow = flow { 2. for (value in 0..5) { 3. print("out $value") 4. emit(value) 5. } 6. } 7. flow.buffer(Channel.CONFLATED).collect { 8. delay(100) 9. print("in $it") 10. } -> out 0, out 1, out 2, out 3, out 4, out 5, in 0, in 5
56. // KLUG - Kotlin Flows Flow Internals - Cold vs Hot
57. // KLUG - Kotlin Flows Flow Internals - Cold vs Hot 1. val flow = flow { 2. print("emitting") 3. emit(1) 4. emit(2) 5. } 6. 7. delay(100) 8. 9. print("collecting") 10. flow.collect { 11. print(it) 12. } -> collecting, emitting, 1, 2 Cold
58. // KLUG - Kotlin Flows Flow Internals - Cold vs Hot 1. val channel = flow { 2. print("emitting") 3. emit(1) 4. emit(2) 5. }.produceIn(scope) 6. 7. delay(100) 8. 9. print("collecting") 10. for (value in channel) { 11. print(value) 12. } -> emitting, collecting, 1, 2 HOT Convert to channel
59. // KLUG - Kotlin Flows Extending Flows When it is just not enough.
60. // KLUG - Kotlin Flows Extending Flows - take() example 1. public fun <T> Flow<T>.take(count: Int) = flow { 2. var consumed = 0 3. try { 4. collect { value -> 5. emit(value) 6. if (++consumed == count) { 7. throw AbortFlowException() 8. } 9. } 10. } catch (e: AbortFlowException) { 11. // Nothing, bail out 12. } 13. }
61. // KLUG - Kotlin Flows Extending Flows - AndroidX Room @Dao interface UsersDao { @Query("SELECT * FROM users WHERE id == :id") suspend fun getById(id: String): UserRecord @Query("SELECT * FROM users WHERE id == :id") fun rxTrackById(id: String): Flowable<UserRecord> @Query("SELECT * FROM users WHERE id == :id") fun flowTrackById(id: String): Flow<UserRecord> }
62. // KLUG - Kotlin Flows Extending Flows - AndroidX Room 1. flow { 2. val observerChannel = Channel<Unit>(Channel.CONFLATED) 3. val observer = object : InvalidationTracker.Observer(tableNames) { 4. override fun onInvalidated(tables: MutableSet<String>) { 5. observerChannel.offer(Unit) 6. } 7. } 8. observerChannel.offer(Unit) 9. 10. val flowContext = coroutineContext 11. withContext(coroutineContext) { 12. db.invalidationTracker.addObserver(observer) 13. try { 14. for (signal in observerChannel) { 15. val result = performQuery() 16. withContext(flowContext) { emit(result) } 17. } 18. } finally { 19. db.invalidationTracker.removeObserver(observer) 20. } 21. } 22. } < create channel < notify on change < signal initial query < add listener < query table < ensure context & emit < release listener
63. // KLUG - Kotlin Flows Extending Flows - Interval flow 1. val flow = flow { 2. while (true) { 3. emit(Unit) 4. delay(delay) 5. } 6. } 1. flow.collect { 2. print("trigger") 3. } > trigger, [delay], trigger, [delay], trigger, [delay], ...
64. // KLUG - Kotlin Flows Extending Flows - Observable to Flow 1. fun <T> Observable<T>.toFlow() = channelFlow { 2. val disposable = subscribeWith(object : DisposableObserver<T>() { 3. override fun onNext(t: T) { offer(t) } 4. override fun onComplete() { close() } 5. override fun onError(e: Throwable) { close(e) } 6. }) 7. awaitClose { disposable.dispose() } 8. } 1. Observable.fromArray(1, 2, 3).toFlow() 2. .collect { 3. print(it) 4. } -> 1, 2, 3 < send next value < close channel < crash channel < release Observable
65. // KLUG - Kotlin Flows Extending Flows - Log Flow Lifecycle 1. fun <T> Flow<T>.logLifecycle() = flow { 2. try { 3. print("flow start") 4. collect { 5. print("flow emit") 6. emit(it) 7. } 8. print("flow finish") 9. } catch (e: Exception) { 10. print("flow error") 11. throw e 12. } 13. } 1. flowOf(1, 2, 3) 2. .logLifecycle() 3. .collect { 4. print(it) 5. } -> flow start, flow emit, 1, flow emit, 2, flow emit, 3, flow finish
66. // KLUG - Kotlin Flows Benchmarks All is great but can it run Cr… I mean Flows?
67. // KLUG - Kotlin Flows Benchmarks - Flow vs Rx - Emit 1. flow { 2. for (value in 0..count) { 3. emit("") 4. } 5. }.collect() 1. Observable.create<String> { 2. for (value in 0..count) { 3. it.onNext("") 4. } 5. it.onComplete() 6. }.blockingSubscribe()
68. // KLUG - Kotlin Flows Benchmarks - Flow vs Rx - Emit ~4x slower ~5x slower ~1.3x slower ~1.7x slower
69. // KLUG - Kotlin Flows Benchmarks - Flow vs Rx - Cancel flowOf("", "").collect { throw Exception() } flowOf("", "").collect { throw exception } flowOf("", "").collect { coroutineContext[Job]?.cancel() } 1. Observable.fromArray( "", "") 2. .subscribe( object : DisposableObserver<String>() { 3. override fun onComplete() {} 4. override fun onNext(t: String) = dispose() 5. override fun onError(e: Throwable) {} 6. }) “Correct” - throw exception (still need to catch exception) Bad - throw cached exception (exception has wrong stack trace) Bad - cancel job (but it also cancels parent job)
70. // KLUG - Kotlin Flows Benchmarks - Flow vs Rx - Cancel ~49x slower ~9x slower ~14x slower
71. // KLUG - Kotlin Flows Benchmarks - Why Job.cancel is faster? internal class JobCancellationException constructor(...) : CancellationException(...), CopyableThrowable<JobCancellationException> { // ... override fun fillInStackTrace(): Throwable { if (DEBUG) { return super.fillInStackTrace() } /* * In non-debug mode we don't want to have a stacktrace * on every cancellation, parent job reference is enough. * Stacktrace of JCE is not needed most of the time and hurts performance. */ return this } // ... }
72. // KLUG - Kotlin Flows Benchmarks - Flow vs Rx Benchmark Mode Cnt Score Error Units Benchmarks.flow_emit_1 thrpt 5 3652247.139 ± 16668.981 ops/s Benchmarks.flow_emit_10 thrpt 5 3281303.599 ± 42834.687 ops/s Benchmarks.flow_emit_1000 thrpt 5 366228.664 ± 8101.192 ops/s Benchmarks.flow_emit_1_000_000 thrpt 5 368.609 ± 2.751 ops/s Benchmarks.rx_emit_1 thrpt 5 19697204.475 ± 415523.489 ops/s Benchmarks.rx_emit_10 thrpt 5 19168316.124 ± 446412.865 ops/s Benchmarks.rx_emit_1000 thrpt 5 460720.252 ± 3492.123 ops/s Benchmarks.rx_emit_1_000_000 thrpt 5 627.488 ± 2.768 ops/s Benchmarks.flow_cancel thrpt 5 656798.927 ± 173212.926 ops/s Benchmarks.flow_cancel_cacheException thrpt 5 3658436.373 ± 696998.489 ops/s Benchmarks.flow_cancel_cancelJob thrpt 5 2363809.629 ± 408097.912 ops/s Benchmarks.rx_cancel thrpt 5 32290853.094 ± 8736309.342 ops/s
73. // KLUG - Kotlin Flows Conclusion Just some thoughts about all of this greatness
74. // KLUG - Kotlin Flows Conclusion Pros: • Built-in suspend functions support • No need to handle cancellation • Easy to write simple extensions Cons: • Much bigger overhead -> much slower (especially for cancellation) • Requires scope to call terminal function • More edge-cases (for ex. context preservation, exception transparency) • Most interesting functions are marked as FlowPreview/ExperimentalCoroutinesApi
75. More info: 1. Always read sources, a lot of interesting stuff there :) 2. https://kotlinlang.org/docs/reference/coroutines/flow.html
76. // Q&A
