Python & PostgreSQL - A Wonderful Wedding (English)

Python and PostgreSQL, two tools we like to use for our projects but do you know everything about them?

The talk will give an overview of psycopg2, Peewee, SQLAlchemy, Alembic and PL/Python, these libraries can be used with PostgreSQL.

* psycopg2, the well known connector, this basic component is really useful, well documented and battle-tested and used by the most famous toolkits of the Python ecosystem.
* Peewee is a basic but awesome Object Relational Mapper.
* SQLAlchemy, a Python SQL toolkit and Object Relational Mapper, you can use this library to create your models and interact with them.
* Alembic, a lightweight database migration tool for usage with SQLAlchemy, allows to create some migration scripts for your project.
* PL/Python, a procedural language for PostgreSQL, allows to write functions in the Python language.
* MultiCorn, a Foreign Data Wrapper in Python

Transcript

1. Python & Postgresql A Wonderful Wedding Stéphane Wirtel @PythonFOSDEM 2015 http://goo.gl/c3U0vA
2. Stéphane Wirtel #fellow Python Software Foundation #member EuroPython Society #member AFPy @PythonFOSDEM @matrixise stephane@wirtel.be http://wirtel.be
3. Schedule Qu’allons-nous apprendre ?
5. Python
6. Python, what is it? Programming language Clear and easy syntax Interpreted Multi-plateforms Dynamic Typing Multi-paradigms Garbage Collector
7. Postgresql
8. PostgreSQL - Story Developed at Berkeley Rewriting of Ingres 1985 -> Postgres (come from Post-Ingres) 1995 -> Postgres95 (0.01) (Add the SQL Interpreter) 1997 -> PostgreSQL 6.0 2013 -> PostgreSQL 9.3 2014 -> PostgreSQL 9.4 (b4)
9. PostgreSQL - TL;DR ORDBMS, ACID SQL:2011 DataTypes Transactional DDL Concurrent Index Extensions Common Table Expression MultiVersion Concurrency Control Cross-Platform
10. PostgreSQL - TL;DR Replication Foreign Data Wrappers Procedural Languages Triggers Full text Search Views (Materialized) Table Inheritance Listen/Notify
11. PostgreSQL, FDW ? Allow to use external resources from PostgreSQL Twitter, RSS, CSV, XML FileSystem Processes
12. PostgreSQL, PL ? PL => Procedural Languages Stored Functions Safe (sandbox, SQL, PL/pgSQL) / Unsafe (C) PL/Python, PL/V8, PL/PERL
13. DB-API 2.0 The Standard… http://python.org/peps/pep-0249
14. DB-API 2.0 aka PEP-249 API for the Database Engines Connectors Easy to use and to understand Use 2 concepts: • Connection • Cursor http://legacy.python.org/dev/peps/pep-0249/
15. Connection Wrap a database connection Handle the transactions and their internal state (commit and rollback) You cant’ execute SQL queries.
16. Connection - API • connect(parameters=None) • close() • commit() • rollback() • cursor([name=None])
17. Connection - Example import driver conn = driver.connect(database='database', host='localhost', port=5432) try: # create the cursor # use the cursor except Exception: conn.rollback() else: conn.commit() conn.close()
18. Cursor Created from an existing connection Used for DML (Database Manipulation Language), INSERT, SELECT, UPDATE, DELETE cursor = conn.cursor() cursor.execute(""" SELECT column1, column2 FROM tableA """) for column1, column2 in cursor.fetchall(): print(column1, column2)
19. Cursor - API • callproc(procname[, parameters]) • execute(query[, parameters]) • fetchone(), fetchmany([size=cursor.arraysize]), fetchall() • close()
20. Cursor - execute execute(query[, parameters]) Performance and Security NEVER use the string interpolation (%) and the concatenation (+) => SQL Injection
21. Cursor - execute (2) Accept string formatting for the request. qmark Question mark WHERE field = ? numeric Numeric positional WHERE field = :1 named Named WHERE field = :code format ANSI C print format WHERE field = %s pyformat Python format WHERE field = %(name)s
22. “Advanced” Example ;-) import driver conn = driver.connect(database='database', host='localhost', port=5432) cursor = conn.cursor() try: cursor.execute("SELECT column1, column2 FROM tableA") for column1, column2 in cursor.fetchall(): print(column1, column2) except Exception: conn.rollback() else: conn.commit() finally: cursor.close() conn.close()
23. psycopg2 Basic… pip install psycopg2
24. Introduction PostgreSQL Adaptor, based on libpq (C lib for PostgreSQL) DB-API 2.0 Compliant Multi-thread / Thread-safe Connection Pool Full Asynchronous, Coroutines Support ALL the data types(Json, Hstore, …) Python 2.5+, 3.1+, PostgreSQL 7.4+
25. Cursor cursor = conn.cursor() cursor = conn.cursor(name=“pycon_cursor”) • Database Cursor • DML. • Named Cursor => Used for the big result set.
26. SQL Requests cursor.execute("SELECT * FROM table") cursor.execute("INSERT INTO table (field1, field2) VALUES (%s, %s)", (field1, field2)) cursor.execute("DELETE FROM table") cursor.execute("UPDATE table SET field1=%s", ('value',)) cursor.execute("CREATE DATABASE database") cursor.execute("DROP DATABASE database")
27. Example import psycopg2 conn = psycopg2.connect(host='localhost', port=5432, user='username', password='password', database='database') cursor = conn.cursor() try: cursor.execute("SELECT column1, column2 FROM tableA") for column1, column2 in cursor.fetchall(): print(column1, column2) except Exception: conn.rollback() else: conn.commit() finally: cursor.close() conn.close()
28. Example - Context Manager import psycopg2 DSN = dict(host='localhost', port=5432, user='username', password='password', database='database') with psycopg2.connect(**DSN) as conn: with conn.cursor() as cursor: cursor.execute("SELECT column1, column2 FROM tableA") for column1, column2 in cursor.fetchall(): print(column1, column2) conn.commit()
29. Object Relational Mapping
30. Introduction “Object-relational mapping in computer science is a programming technique for converting data between incompatible type systems in object- oriented programming languages.” Wikipedia
31. In brief • Map a Business Class on a SQL Table! • Add methods for add, modify, delete and search
32. Peewee-ORM a small Object Relational Mapping pip install peewee
33. Peewee ORM Simple, Easy to understand and extensible Python 2.6+ et 3.2+ Extensions CLOC = 3200 (MySQL, Sqlite3 et PostgreSQL) Document is very good
34. Connection import peewee database = peewee.PostgresqlDatabase('demo')
35. Models class BaseModel(peewee.Model): id = peewee.PrimaryKeyField() class Meta: database = database class Address(BaseModel): street = peewee.CharField() zipcode = peewee.CharField() country = peewee.CharField() class Contact(BaseModel): firstname = peewee.CharField(null=False) lastname = peewee.CharField(null=False) email = peewee.CharField(unique=True, null=False, index=True) address = peewee.ForeignKeyField(Address, null=False, related_name=‘contacts')
36. Creation of T ables database.create_tables([Address, Contact])
37. Peewee - T ransactions tx = database.transaction() tx.commit() tx.rollback() with database.transaction(): pass
38. Create with database.transaction(): address = Address.create( street='Avenue Franklin D. Roosevelt 50', zipcode='1050', country='Brussels') contact = Contact.create( firstname='Stephane', lastname='Wirtel', email='stephane@wirtel.be', address=address ) print(contact.id)
39. Read contact = Contact.get(Contact.email == 'stephane@wirtel.be') print(contact.firstname) contacts = Contact.select() for contact in contacts: print(contact.firstname) for contact in contacts.where(Contact.email == 'stephane@wirtel.be'): print(contact.firstname)
40. Update with database.transaction(): contact = Contact.get(Contact.email == 'stephane@wirtel.be') contact.firstname = 'Speaker' contact.save()
41. Delete # Remove an entire collection contacts = Contact.delete().where(Contact.email == 'stephane@wirtel.be') contacts.execute() # Remove one record contact = Contact.get(Contact.email == 'stephane@wirtel.be') contact.delete_instance()
42. SQLAlchemy The Master of Object Relational Mapping pip install sqlalchemy
43. SQLAlchemy • Handle the connections • Abstract the SQL connectors • ORM
44. Connection from sqlalchemy import create_engine engine = create_engine('postgresql:///demo', echo=True)
45. Models from sqlalchemy import Column, Integer, String, ForeignKey from sqlalchemy.ext.declarative import declarative_base from sqlalchemy.orm import relationship Base = declarative_base() class Address(Base): __tablename__ = 'address' id = Column(Integer, primary_key=True) street = Column(String) zipcode = Column(String) country = Column(String, nullable=False) class Contact(Base): __tablename__ = 'contact' id = Column(Integer, primary_key=True) firstname = Column(String, nullable=False) lastname = Column(String, nullable=False) email = Column(String, nullable=False) address_id = Column(Integer, ForeignKey(Address.id), nullable=False) address = relationship('Address')
46. Creation of T ables Base.metadata.create_all(engine)
47. Sessions Wraps the transactions session = Session(engine) session.commit()
48. Create session = Session(engine) address = Address(street='SQLAlchemy Street', zipcode='5432', country='Belgique') contact = Contact( firstname='Stephane', lastname='Wirtel', email='stephane@wirtel.be', address=address ) session.add(contact) session.commit()
49. Read contact = session.query(Contact).filter_by(email='stephane@wirtel.be').first() print(contact.firstname) contacts = session.query(Contact).all() for contact in contacts: print(contact.firstname) contacts = session.query(Contact).filter_by(email='stephane@wirtel.be').all() for contact in contacts: print(contact.firstname)
50. Update contact = session.query(Contact) \ .filter_by(email='stephane@wirtel.be').first() contact.email = ‘stephane.wirtel@mgx.io' session.add(contact) session.commit()
51. Delete contact = session.query(Contact) \ .filter_by(email='stephane@wirtel.be').first() session.delete(contact) session.commit()
52. Alembic La Migration Facile pip install alembic
53. Alembic Based on SQLAlchemy Use a Migration environment Configuration File INI Migration Scripts http://alembic.readthedocs.org/
54. Alembic cd votreproject alembic init migrations > tree migrations/ !"" README !"" alembic.ini !"" env.py !"" script.py.mako #"" versions
55. Alembic revision = '22630db6f519' down_revision = None from alembic import op import sqlalchemy as sa def upgrade(): op.create_table('user', sa.Column('id', sa.Integer(), nullable=False), sa.Column('created_at', sa.DateTime(), nullable=False), sa.Column('name', sa.String(length=255), nullable=False), sa.Column('email', sa.String(length=255), nullable=True), sa.Column('password', sa.String(length=255), nullable=True), sa.Column('active', sa.Boolean(), nullable=True), sa.Column('confirmed_at', sa.DateTime(), nullable=True), sa.PrimaryKeyConstraint('id'), sa.UniqueConstraint('email') ) def downgrade(): op.drop_table('user') alembic revision -m “bootstrap" alembic upgrade head
56. Alembic revision = '7e4b6a43e6c' down_revision = '22630db6f519' from alembic import op import sqlalchemy as sa def upgrade(): op.add_column('user', sa.Column('slug', sa.Unicode(length=255), nullable=False, server_default='')) def downgrade(): op.drop_column('user', 'slug') alembic revision -m “add_slug” alembic upgrade head
57. Alembic > tree migrations/ !"" README !"" alembic.ini !"" env.py !"" script.py.mako #"" versions !"" 22630db6f519_bootstrap.py #"" 7e4b6a43e6c_add_slug.py
58. Alembic from alembic import op from sqlalchemy.orm import Session from youproject import models def upgrade(): engine = op.get_bind() session = Session(bind=engine) for contact in session.query(models.Contact).all(): session.add( models.WifiUser( login=contact.name.lower(), password=random_string() ) ) session.commit() alembic upgrade head
59. Alembic alembic revision alembic upgrade head alembic upgrade +2 alembic downgrade -1 alembic downgrade base alembic current alembic history
60. Danger Area !
61. Multicorn How to connect PostgreSQL to the rest of the World! http://multicorn.org
62. Reminder: Foreign Data Wrappers Use an external resource from PostgreSQL Twitter, RSS, CSV, XML FileSystem Processes PostgreSQL, Oracle, MongoDB
63. declarations for dynamic loading */ _MODULE_MAGIC; G_FUNCTION_INFO_V1(mongo_fdw_handler); PG_FUNCTION_INFO_V1(mongo_fdw_validator); /* * mongo_fdw_handler creates and returns a struct with pointers to foreign table * callback functions. */ Datum mongo_fdw_handler(PG_FUNCTION_ARGS) { FdwRoutine *fdwRoutine = makeNode(FdwRoutine); fdwRoutine->GetForeignRelSize = MongoGetForeignRelSize; fdwRoutine->GetForeignPaths = MongoGetForeignPaths; fdwRoutine->GetForeignPlan = MongoGetForeignPlan; fdwRoutine->ExplainForeignScan = MongoExplainForeignScan; fdwRoutine->BeginForeignScan = MongoBeginForeignScan; fdwRoutine->IterateForeignScan = MongoIterateForeignScan; fdwRoutine->ReScanForeignScan = MongoReScanForeignScan; fdwRoutine->EndForeignScan = MongoEndForeignScan; fdwRoutine->AnalyzeForeignTable = MongoAnalyzeForeignTable; PG_RETURN_POINTER(fdwRoutine);
64. Multicorn • PostgreSQL Extension • Allow to write a Foreign Data Wrapper in Python • You can use your favourites SQL tools with FDW • Support FULL SQL ;-)
65. Examples of Basic FDW • RSS, CSV, XML • LDAP • Gmail, IMAP • Google Search • SQLAlchemy (mysql, sqlite, oracle, …)
66. Simple Example CREATE EXTENSION multicorn;
67. Simple Example (2) CREATE SERVER wirtel_be_srv FOREIGN DATA WRAPPER multicorn OPTIONS ( wrapper 'multicorn.rssfdw.RssFdw' ); CREATE FOREIGN TABLE wirtel_be_rss ( "pubDate" TIMESTAMP, description CHARACTER VARYING, title CHARACTER VARYING, link CHARACTER VARYING ) SERVER wirtel_be_srv OPTIONS( url 'http://wirtel.be/feeds/python.rss.xml' );
68. Simple Example (3) SELECT "pubDate", title, link FROM wirtel_be_rss LIMIT 1; -[ RECORD 1 ]------------------------------------------------------------------------ pubDate | 2014-10-19 00:00:00 title | Python @ FOSDEM 2015 - Call For Proposals link | http://wirtel.be/posts/en/2014/10/19/python-fosdem-2015-call-for-proposals/
69. with Odoo (OpenERP) from multicorn import ForeignDataWrapper import erppeek class OdooForeignDataWrapper(ForeignDataWrapper): def __init__(self, options, columns): super(OdooForeignDataWrapper, self).__init__(options, columns) url = 'http://{hostname}:{password}'.format(**options) self.client = erppeek.Client(url, options['database'], options['username'], options['password']) self.object_name = options['object'] def execute(self, quals, columns): proxy = self.client.model(self.object_name) item = {} for record in proxy.browse([]): for column in columns: item[column] = record[column] yield item
70. with Odoo (OpenERP) (2) CREATE EXTENSION multicorn; CREATE SERVER multicorn_odoo FOREIGN DATA WRAPPER multicorn OPTIONS (wrapper 'multicorn.odoofdw.OdooForeignDataWrapper'); CREATE FOREIGN TABLE odoo_users ( login character varying, name character varying) SERVER multicorn_odoo OPTIONS ( hostname 'localhost', port '8069', database 'odoo', username 'admin', password 'admin', object 'res.users' ); SELECT id, login, name, active FROM odoo_users WHERE login = 'admin';
71. PL/Python Extend PostgreSQL with Python 2.x/3.x
72. PL/Python Python 2 or Python 3 Use all your favourite Python libraries (PyPI) Learning Curve very small PL/pgSQL Untrusted
73. PL/Python apt-get install postgresql-plpython-9.4 CREATE EXTENSION IF NOT EXISTS plpythonu;
74. PL/Python CREATE OR REPLACE FUNCTION str_title(s VARCHAR) RETURNS VARCHAR AS $$ return s.title() $$ LANGUAGE plpythonu; demo=# select str_title('hello world'); -[ RECORD 1 ]---------- str_title | Hello World
75. PL/Python - DataT ypes PostgreSQL Python integer, bigint int, long boolean bool text types str SQL Array list Custom Types dict
76. PL/Python - Debug Built-in Functions • plpy.notice(“<msg>”) • plpy.debug(“<msg>”) • plpy.error(“<msg>”) • plpy.fatal(“<msg>”) Don’t use ”print”
77. PL/Python CREATE OR REPLACE FUNCTION get_pid_cpu_mem(pid INT) RETURNS TABLE(pid INT, cpu_perc FLOAT, mem_perc FLOAT) AS $$ import psutil process = psutil.Process(pid) return [ { 'pid': pid, 'cpu_perc': process.get_cpu_percent(interval=0), 'mem_perc': process.get_memory_percent() } ] $$ LANGUAGE plpythonu;
78. PL/Python -[ RECORD 1 ]----+--------------------------------- datid | 16416 datname | demo pid | 14680 usesysid | 16384 usename | stephane application_name | psql client_addr | client_hostname | client_port | -1 backend_start | 2014-10-25 04:22:08.235532+02 xact_start | 2014-10-25 04:25:28.712812+02 query_start | 2014-10-25 04:25:28.712812+02 state_change | 2014-10-25 04:25:28.712815+02 waiting | f state | active query | select * from pg_stat_activity ; SELECT * FROM pg_stat_activity;
79. PL/Python pid | cpu_perc | mem_perc -------+----------+-------------- 14680 | 0 | 1.4454081372 (1 row) SELECT * FROM get_pid_cpu_mem(14680);
80. PL/Python pid | cpu_perc | mem_perc | application_name -------+----------+---------------+------------------ 14680 | 0 | 1.50435626678 | psql (1 row) WITH stats AS ( SELECT psa.*, get_pid_cpu_mem(psa.pid) as attrs from pg_stat_activity psa ) SELECT (stats.attrs).pid, (stats.attrs).cpu_perc, (stats.attrs).mem_perc, stats.application_name FROM stats;
81. PL/Python - Attention Unsafe -> pas de sandbox Difficult to maintain and to debug Your DBA will become Crazy ;-) No virtualenv and ask the superuser privileges.
82. PL/Python - Pistes ;-) Treatment of big results Add hard constraints and business logic in the system. Add new features to PostgreSQL (see “str_title”) Triggers ? Use external libs from PyPI (requests, redis, zeromq, smtp…) Full Access to the database !!!
84. Questions ? @matrixise https://speakerdeck.com/matrixise
